5 SETPOINTS
This section contains the settings to configure the current demand monitoring elements. Included are a current
demand level for each winding and each phase.
S CURRENT DEMAND
S [ENTER] for more
S W1 CURRENT DEMAND
S [ENTER] for more
W1 CURRENT DEMAND
FUNCTION: Disabled
W1 CURRENT DEMAND
TARGET: Self-reset
W1 CURRENT DEMAND
PICKUP:
100 A
W1 CURRENT DEMAND
BLOCK: Disabled
GE Power Management
This message indicates the start of the CURRENT DEMAND section. To
continue these setpoints press
This message indicates the start of the W1 (2/3) CURRENT DEMAND section. To
continue these setpoints press
Range: Disabled / Enabled
Range: Self-reset / Latched / None
Select None to inhibit the display of the target message when the element
operates. An element whose "target type" is None never disables the LED
self-test feature because it cannot generate a displayable target message.
Range: 0 to 65000 (steps of 1 autoranging)
Enter the current demand above which the W1 (2/3) current demand
element will pickup and operate.
Range: Disabled / Logc Inpt 1 (2-16) /Virt Inpt 1 (2-16) / Output Rly 1 (2-8) /
SelfTest Rly / Virt Outpt 1 (2-5)
745 Transformer Management Relay
5.6 S4 ELEMENTS

5.6.18 CURRENT DEMAND

or press
for the next section.
E N TE R
M E SSA G E
or press
for the next section.
E N TE R
M E SSA G E
5
5-77
