8.3 MODBUS MEMORY MAP
Table 8–6: 745 MEMORY MAP (Sheet 28 of 57)
GROUP ADDR
(HEX)
LOGIC 13B4
INPUTS
13B5
continued
13B6
13B7
13B8
13B9
13BA
13BB
13BC
13BD
13BE
13BF
VIRTUAL 13C0
INPUTS
13C1
13CA
13CB
13D4
13D5
13DE
13DF
13E8
13E9
13F2
13F3
13FC
13FD
1406
1407
8
1410
1411
141A
141B
1424
1425
142E
142F
1438
1439
8-44
DESCRIPTION
Logic Input 5 Target
Logic Input 6 Target
Logic Input 7 Target
Logic Input 8 Target
Logic Input 9 Target
Logic Input 10 Target
Logic Input 11 Target
Logic Input 12 Target
Logic Input 13 Target
Logic Input 14 Target
Logic Input 15 Target
Logic Input 16 Target
Virtual Input 1 Function
Virtual Input 1 Name (9 registers)
Virtual Input 2 Function
Virtual Input 2 Name (9 registers)
Virtual Input 3 Function
Virtual Input 3 Name (9 registers)
Virtual Input 4 Function
Virtual Input 4 Name (9 registers)
Virtual Input 5 Function
Virtual Input 5 Name (9 registers)
Virtual Input 6 Function
Virtual Input 6 Name (9 registers)
Virtual Input 7 Function
Virtual Input 7 Name (9 registers)
Virtual Input 8 Function
Virtual Input 8 Name (9 registers)
Virtual Input 9 Function
Virtual Input 9 Name (9 registers)
Virtual Input 10 Function
Virtual Input 10 Name (9 registers)
Virtual Input 11 Function
Virtual Input 11 Name (9 registers)
Virtual Input 12 Function
Virtual Input 12 Name (9 registers)
Virtual Input 13 Function
Virtual Input 13 Name (9 registers)
745 Transformer Management Relay
8 COMMUNICATIONS
RANGE STEP UNITS
VALUE
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
FORMAT FACTORY
CODE DEFAULT
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F46 0 = Self-Test
F30 0 = Disabled
F33 "Virtual Input 1"
F30 0 = Disabled
F33 "Virtual Input 2"
F30 0 = Disabled
F33 "Virtual Input 3"
F30 0 = Disabled
F33 "Virtual Input 4"
F30 0 = Disabled
F33 "Virtual Input 5"
F30 0 = Disabled
F33 "Virtual Input 6"
F30 0 = Disabled
F33 "Virtual Input 7"
F30 0 = Disabled
F33 "Virtual Input 8"
F30 0 = Disabled
F33 "Virtual Input 9"
F30 0 = Disabled
F33 "Virtual Input 10"
F30 0 = Disabled
F33 "Virtual Input 11"
F30 0 = Disabled
F33 "Virtual Input 12"
F30 0 = Disabled
F33 "Virtual Input 13"
