ABB i-bus EIB / KNX
2.2.2

Circuit diagram

2.2.3 Description of the inputs
and outputs
2.2.4

Assembly and installation

© 2004 ABB STOTZ-KONTAKT GmbH
Device technology
ABB
LR/M 1.6.1
I
n
U
ABB i-bus
N
N
A
N
4
PE
L
–
+
Output A has a switch output (3-pole plug-in terminal) and a control output
(2-pole plug-in terminal) which are both connected to the electronic ballast.
The light sensor LF/U 1.1 is connected to a further 2-pole plug-in terminal.
The PE conductor is brought out from the device to connect the protective
conductor.
The device is solely intended for operation in the Room Controller Basis
Device. It can be snapped into any module slot. The mounting position can
be selected as required.
= 6 A
= 250 V~
n
®
L + +
1 2 3 4 5 6 7
1...10V
L + +
'
LF/U 1.1
8
