Getting Started with the Virtex-7 FPGA
VC707 Evaluation Kit

Introduction

This document describes how to use the materials provided in the VC707 Evaluation Kit to
set up the VC707 board and a host computer to run two reference designs, which test and
demonstrate some of the key features of the XC7VX485T FPGA and the VC707 board:
•
•
Note:
Xilinx tools, technology, and reference designs. Additional instructions and background information
are available from the

VC707 Evaluation Kit Contents

The VC707 Evaluation Kit includes:
•
•
•
•
•
•
•
•
•
•
•
Getting Started with the VC707 Evaluation Kit
UG848 (v1.4.1) October 14, 2015
Built-in self test (BIST)
Analog mixed signal (AMS) card demonstration
These design summaries are for use as a quick start method for users who are familiar with
VC707 Evaluation Kit
VC707 board with the Virtex®-7 XC7VX485T FPGA
ISE® Design Suite: Logic Edition (full seat, node-locked, device-locked to the
XC7VX485T FPGA)
Vivado® Design Suite Installation DVD
Printed entitlement voucher: provides entitlement of the Vivado Design Suite Logic
Edition, node-locked, and device-locked to the XC7VX485T FPGA. Follow the
printed instructions on the voucher to redeem your software entitlement.
AMS101 evaluation card
USB cable, standard-A plug to mini-B plug
USB cable, standard-A plug to micro-B plug
HDMI™ cable, type-A plug to type-A plug
Power Supply: 100 VAC–240 VAC input, 12 VDC 5.0A output
Power cords to support three main plug types
Getting Started Guide
www.xilinx.com
website.
Send Feedback
Chapter 1
5
