Racers tip
When using an electronic speed controller, please set the throttle trim to neutral and
make adjustments to the speed control. On a gas powered model, set the trim to
neutral and adjust the linkage to the point where carburetor is fully closed in
accordance with the engine instruction manual.
Trim operation and travel
Trim adjustments will affect the overall servo travel, so please check the (back-ward)
movement after the adjustment
When trim movement goes to extremes
That means if you make a lot of the trim movement to get the servo to the neutral
position, please re-center the servo horn closer to the neutral position and Inspect
your throttle linkage.

3.2 Handling procedure for batteries

Battery Replacement
1. Remove the battery cover from the transmitter by sliding it in the direction of the
arrow.
2. Remove the used batteries.
3. Load the new AA size batteries. Pay very close attention to the polarity marking
and reinsert accordingly.
4 .Slide the battery cover back onto the case.
Caution
Always be sure your reinsert the batteries in the correct polarity order. If the batteries
are loaded incorrectly, the transmitter may be damaged.
When the transmitter is not used, always remember to remove the batteries. If the
batteries do happen to leak, clean the batteries case and contacts thoroughly. Make
sure the contacts are free of corrosion.
Battery low voltage alarm indicator
Shows the remote control to a low battery, renew or
recharge batteries earliest possible. Rechargeable
batteries can be charged via the charging jack on the
device. It is important to observe correct polarity.
The assignment is:
Pin +
Ring -
Battery Disposal
Some countries require special handling of used of batteries, please contact the
agencies responsible for recycling hazardous wastes in your local area.
25
