Replacing a Second Row Table Top Section
Step 20 Place the splines in the slots on the edge of the new table top section.
Press the table top sections together.
Step 21
Insert the draw bolts and tighten them between the new table top section and the adjoining table top
Step 22
sections. See
If you are replacing an end piece, insert and attach the attachment plates.
Step 23
Attach the legs to the table top sections with the screws. See
Step 24
Assembly"
Attach the gutter and privacy panel support brackets to the table assembly.
Step 25
See Chapter 7, "Building the Second Row Table Assembly"
bracket attachment points and screw locations.
Attach the gutter panel for the table top section.
Step 26
See Chapter 7, "Building the Second Row Table Assembly"
screw locations.
Attach the floating bracket on each side of the table top section.
Step 27
See Chapter 7, "Building the Second Row Table Assembly"
and screw locations.
Attach the privacy panel hangers to the table legs that support each side of the table top section.
Step 28
See Chapter 7, "Building the Second Row Table Assembly"
attachment points and screw locations.
Step 29 Attach the privacy panel alignment bracket.
See Chapter 7, "Building the Second Row Table Assembly"
brackets.
If you are replacing the left or right tabletop end, attach the privacy panel end pieces and panel end brace.
Step 30
See Figure 7-47
Insert the microphone cable into the hole in the table top and route the cable through the cable gutters
Step 31
to the audio/video extension unit.
Connect the microphone cable to the audio/video extension unit.
Step 32
Step 33 Reconnect the microphone to the new table top section.
See Figure 7-38
Step 34 Attach the privacy panels to the table sections.
Note
Step 35 If required, replace the cable cover for the right end privacy panel as shown in
ties to bundle the microphone cable with other cables.
Step 36 Reposition the second row table so that the trailing edge of the first row table is exactly 59 inches
(150 cm) behind the leading edge of the second row table. See
table positioning.
Cisco TelePresence System 3200
12-26
Chapter 7, "Building the Second Row Table Assembly"
for the location of the table legs and screw attachment locations.
for the privacy panel end piece locations and
for microphone installation instructions.
If required, adjust the privacy panel sections so that there is an equal amount of space between
each section.
Chapter 12 Field-Replaceable Unit Guide
for the location of the draw bolts.
Chapter 6, "Building the First Row Table
for the gutter and privacy panel support
for the gutter panel attachment points and
for the floating bracket attachment points
for the privacy panel support bracket
for the location of the privacy panel support
Figure 7-30 for the end brace locations.
Figure 7-46
Figure 7-48 for the correct second row
and add cable
