Chapter 7 Building the Second Row Table Assembly
Parts List
Step 38 Attach one microphone to each table segment and attach the microphone extension cords to the
microphone cables. There are six microphones for the second row table.
Steps for routing the microphone cables are in Chapter 9, "Routing Power and Signal Cables."
Note
Tip Label each microphone cable where it exits from the table. You attach the microphones to the
Audio/Video Expansion Unit in Chapter 9, "Routing Power and Signal Cables."
Figure 7-38 Microphone Assembly
51
53 52
