2G GSM Gateway Lift

2.2. INSERT THE PIN CODE

If the protection PIN code of the SIM card is enabled and the PIN has not been set in the gateway, the Status led is ON and the
PIN code request is transmitted to the phone line (double beep repeated with a short pause).
Insert the PIN code using the phone keypad (set DTMF selection) connected to the TEL1 or TEL2 ports:
1. Hook off the phone, you hear the PIN code request tone.
2. Enter the PIN Code using the phone keypad (using a DTMF phone) and confirm by pressing the "#" (hash) button.
3. To cancel the wrong PIN code, hang up before sending the "#" (hash) button.
4. If the PIN code is correct you will hear the configuration tone (continuous tone repeated twice).
5. Hook on the phone and wait for detection of the GSM network.
6. If the PIN code is wrong you will hear the wrong configuration tone (single long tone).
ATTENTION: PIN and PUK codes are present on PIN-PUK card provided by GSM Operator when you buy the
SIM card. Please note that you have 3 possibilities to enter the right PIN code. If insertion fails, you must
insert the PUK code and a new PIN code.
If you write a wrong PUK code 10 times, the SIM card will be blocked.
The PIN code is automatically stored into 2G GSM Gateway Lift and it will be used when necessary. If the SIM card is removed or
stolen then you must newly insert the PIN code manually.
To delete the PIN code from device memory, enter #*99# code using the phone keypad connected to TEL1 or TEL2 connector.
Check the good level of GSM signal and eventually try to improve it by placing the antenna in a different position.

2.3. INSERT THE PUK CODE

The request for PUK code is signalled with a different special tone with respect to the PIN tone request (double beep repeated
with no pause).
Insert the PUK code using the phone keypad (set DTMF selection) connected to the TEL1 or TEL2 port:
1. Hook off the phone, you hear the PUK code request tone (double beep with no pause).
2. Enter the PUK code using the phone keypad (using a DTMF phone) and confirm by pressing the "#" (hash) button, followed
by a new PIN code with 4 digits, then press "#" again.
3. To cancel the wrong PUK code, hang up before sending the first "#" (hash) button.
4. If the PUK code is correct you will hear the configuration tone (continuous tone repeated twice).
5. Hook on the phone and wait for detection to the GSM network.
6. If the PUK code is wrong you will hear the wrong configuration tone (single long tone).
ENG2.2
PIN code#
PUK code#PIN code#
(i.e. 0123#)
(i.e. 12345678#1234#)
Installation
