Tripp Lite B021-000-17 Specifications

Rackmount Console - 1U Rackmount Console with
17" LCD
MODEL NUMBER: B021-000-17
Description
Tripp Lite's B021-000-17 1U Rackmount Console features an integrated 17" LCD panel, full 88-key keyboard,
and touch pad, all in a 1U rackmountable housing. The included KVM cable kit allows for connection to a PS/2
computer or KVM, and a PS/2 to USB adapter is included, which can be used to connect to a USB computer or
KVM. The unit features a USB 2.0 pass-through port for connection of a USB peripheral, such as a flash drive,
CAC card reader, etc.. Your peripheral device connects to the USB type A port on the front of the unit, and your
computer connects to the USB type A port on the back of the unit using a Tripp Lite
cable. Constructed of heavy-duty steel housing.
Features
Space savings with 1U 19-inch, rack-mount drawer design
Features 17-inch LCD TFT active-matrix, color panel
Features a USB pass-through port for connection of a USB peripheral, such as a flash drive, CAC card
reader, etc.
Supports resolutions of up to 1366 x 768
Included PS/2 to USB adapter allows for connection to a USB computer or KVM
Sleep mode when the monitor cover is closed
Input 120/240 VAC
Constructed of heavy-duty steel housing

Specifications

OVERVIEW
PC/Server VGA; USB; PS/2
UR020-Series type A M/M
1 / 3
Highlights
Control an entire network in just
1U of rack space; includes
keyboard, 17" LCD screen, and
touch pad
Features a USB 2.0
pass-through port for connection
of a USB peripheral, such as a
flash drive, CAC card reader, etc.
Connects to a PS/2 or USB
server or KVM switch
Supports video resolutions up to
1366 x 768
Rackmountable in 19-inch
system rack (1U), from 27" to 42"
deep
Applications
Use where rack space is at a
premium, and where a
Server/KVM display is needed.
System Requirements
Computer or KVM with a VGA
monitor port and USB or PS/2
keyboard/mouse ports
Package Includes
1- B021-000-17 1U Rackmount
Console
1- KVM Cable Kit ( HD15M to
HD15M + 2 PS/2 Male )
1-PS/2 to USB Adapter
1- C13 to 5-15P Power Cord
1- User Manual
