Chapter 3 Configuring with the Command-Line Interface
Command
Step 1
Router> enable
Password: password
Router#
Step 2
Router# configure terminal
Enter configuration commands, one per line.
End with CNTL/Z.
Router(config)#
Step 3
Router# ip routing
Router# appletalk routing
Router# ipx routing
Step 4
Router(config)# interface async 45
Router(config-if)#
Step 5
Router(config-if)# ip address 172.16.74.1
255.255.255.0
Step 6
Router(config)# interface group-async 1
Step 7
Router(config-if)# ip unnumbered ethernet 0
Step 8
Router(config-if)# peer default ip address
pool default
Step 9
Router(config-if)# group-range 1 16
Step 10
Router(config-if)# appletalk static
cable-range 3-3
Router(config-if)# appletalk zone ZZEth
Router(config-if)# ipx network B005
Step 11
Router(config-if)# async mode interactive
Router(config-if)# async default routing
Router(config-if)# encapsulation ppp
Router(config-if)# ppp authentication chap
pap
Step 12
Router(config-if)# exit
Step 13
Router(config)# modem country microcom_hdms
country-name
Step 14
Router(config-if)# line 1 16
OL-1957-04
Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
Configuring Analog Modem Interfaces
Purpose
Enter enable mode. Enter the password.
You have entered enable mode when the prompt
changes to .
Router#
Enter global configuration mode. You have
entered global configuration mode when the
prompt changes to
Router(config)#.
Enable routing protocols as required for your
global configuration. This example uses IP
routing, AppleTalk routing, and Internetwork
Packet Exchange (IPX) routing.
You can configure asynchronous interfaces either
individually or as a group. This command selects
an individual interface to configure. The prompt
changes to
Router(config-if)#.
Assign an IP address and subnet mask to the
interface.
Assign asynchronous interfaces to a group so you
can configure them together.
Configure the asynchronous interface group as
unnumbered and assign the IP address of the
Ethernet interface to the group.
Define the pool of addresses at the global level.
Define the group range of the interface. This
command defines the range as all modems in
slot 0.
Configure routing protocols on the interface or
group. You must have previously enabled these
protocols as part of global configuration. In this
example, AppleTalk and IPX are being configured
on the interface.
Configure asynchronous parameters according to
your needs.
Exit back to global configuration mode.
Return to Step 4 if your router has more than one
interface that you need to configure.
Set modem parameters (including encoding) to the
correct country. Table 3-8
The default is usa.
Enter the modem line or range of modem lines to
configure.
shows country codes.
