- Page 1 INSTRUCTION MANUAL Circular Saw 5800NB 004086 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model 5800NB Blade diameter 185 mm at 90° 66 mm Max. cutting depth at 45° 44 mm No load speed (min 4,500 Overall length 272 mm Net weight 3.5 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. -
Page 3: Circular Saw Safety Warnings
Do not abuse the cord. Never use the cord for 19. Do not use the power tool if the switch does carrying, pulling or unplugging the power tool. not turn it on and off. Any power tool that Keep cord away from heat, oil, sharp edges or cannot be controlled with the switch is dangerous moving parts. - Page 4 Adjust the cutting depth to the thickness of Maintain a firm grip with both hands on the the workpiece. Less than a full tooth of the blade saw and position your arms to resist kickback teeth should be visible below the workpiece. forces.
- Page 5 13. Do dull damaged blades. For all other sawing, the lower guard should Unsharpened or improperly set blades produce operate automatically. narrow kerf causing excessive friction, blade 21. Always observe that the lower guard is binding and kickback. covering the blade before placing saw down 14.
- Page 6 WARNING: Fig.2 DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to safety rules for the subject product. MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury.
-
Page 7: Functional Description
Sighting 1. Base plate 010011 CAUTION: Be sure the blade is installed with teeth pointing • up at the front of the tool. Use only the Makita socket wrench to install or • remove the blade. 004089... -
Page 8: Operation
To remove the blade, press the shaft lock so that the blade cannot revolve and use the socket wrench to loosen the bolt counterclockwise. Then remove the bolt, outer flange and blade. To install the blade, follow the removal procedure in reverse. -
Page 9: Optional Accessories
Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Saw blades • Rip fence (Guide rule) • Socket wrench •... - Page 12 Makita Corporation Anjo, Aichi, Japan www.makita.com 883212A945...
