Summary of Contents for Makita HP332DZ
- Page 1 INSTRUCTION MANUAL Cordless Impact Driver TD110D Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: TD110D Fastening capacities Machine screw 4 mm - 8 mm Standard bolt 5 mm - 12 mm High tensile bolt 5 mm - 10 mm No load speed 0 - 2,600 min Impacts per minute 0 - 3,500 min Overall length 153 mm Rated voltage... - Page 3 Avoid body contact with earthed or grounded Always wear protective goggles to protect surfaces, such as pipes, radiators, ranges and your eyes from injury when using power tools. refrigerators. There is an increased risk of elec- The goggles must comply with ANSI Z87.1 in tric shock if your body is earthed or grounded. the USA, EN 166 in Europe, or AS/NZS 1336 in Australia/New Zealand.
- Page 4 Keep handles and grasping surfaces dry, Cordless impact driver safety clean and free from oil and grease. Slippery warnings handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected Hold the power tool by insulated gripping situations.
-
Page 5: Functional Description
12. Use the batteries only with the products specified by Makita. Installing the batteries to non-compliant products may result in a fire, exces- sive heat, explosion, or leak of electrolyte. SAVE THESE INSTRUCTIONS. CAUTION: Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and ► 1 . Red indicator 2. Button 3. Battery cartridge charger. To remove the battery cartridge, slide it from the tool Tips for maintaining maximum while sliding the button on the front of the cartridge. -
Page 6: Battery Protection System
Battery protection system Switch action The tool is equipped with a battery protection system. This system automatically cuts off power to the motor to extend battery life. The tool will automatically stop during operation if the tool and/or battery are placed under one of the following conditions: Overloaded: The tool is operated in a manner that causes it to draw an abnormally high current. In this situation, turn the tool off and stop the application that caused the tool to become overloaded. Then turn the tool on to restart. If the tool does not start, the battery is overheated. In this situation, let the battery cool before turning the tool on again. ► 1 . Switch trigger Low battery voltage: The remaining battery capacity is too low and the tool CAUTION:... - Page 7 Use only driver bit/socket bit that has inserting portion Reversing switch action shown in the figure. Do not use any other driver bit/ socket bit. For tool with shallow driver bit hole A=12mm Use only these type of driver B=9mm bit. Follow the procedure 1. (Note) Bit-piece is not necessary. For tool with deep driver bit hole A=17mm To install these types of driver B=14mm bits, follow the procedure 1. A=12mm To install these types of driver B=9mm bits, follow the procedure 2.
-
Page 8: Installing Hook
Proper fastening torque for standard bolt NOTE: If the driver bit is not inserted deep enough into the sleeve, the sleeve will not return to its original position and the driver bit will not be secured. In this N•m case, try re-inserting the bit according to the instruc- (kgf•cm) tions above. -
Page 9: Using Holster
To maintain product SAFETY and RELIABILITY, Be sure to close the holster securely with the repairs, any other maintenance or adjustment should holster button so that it holds the tool firmly. be performed by Makita Authorized or Factory Service Thread a waist belt or similar through holster holder. Centers, always using Makita replacement parts. ► 1 . Holster holder 2. Waist belt 9 ENGLISH... -
Page 10: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. • Driver bits • Socket bits •... - Page 12 Makita Corporation 885438A8 20170920 www.makita.com...
