Item
Power Consumption
Memory Capacity
Hard Disk Capacity
Dimensions (H x W x D)
Weight (Including the toner bottle)
Installation Space (W x D)

1.1.7.1.34 Specifications for Copy Card Reader-F1

[ Manual-related ]
Description
Please explain specifications of the Copy Card Reader-F1.
Field Remedy
Copy Card Reader-F1
Available Cards
Card Readout Method
Magnetic Card Reading Direction
Store/Replay
Power Source
Dimensions (H x W x D)
Weight
[Caution]
- If the Copy Card Reader-F1 is attached to the machine, a control card must be inserted in advance to operate it. The control card is used for the Device ID Man-
agement. If the control card is removed, the machine cannot be operated until the control card is inserted again.
- If a login service other than Department ID Management is used, the Limit Functions mode will not be available.
- If the Server Authentication user authentication system of SSO-H is set as the login service (including when performing Server Authentication with the "Server
Authentication + Local Device Authentication" user authentication system), you cannot use the Copy Card Reader-F1.
[Reference]
- If the Status Monitor/Cancel screen does not appear on the touch panel display when the control card is inserted, check following points.
Is the control card inserted in the correct direction?
Is the control card inserted as far as it can go?
Is an unusable control card inserted?
(For example, a damaged card or card prohibited from use.)
- If the Copy Card Reader-F1 is attached, the cards shown here can be used. They can manage up to 1,000 departments.
Maximum Power Consumption:
3,520W or less
Power Consumption:
When in the Sleep mode:
1Wh
When the main power switch is turned OFF:
"Quick Startup Settings for Main Power" is set to "OFF" : 0.5 Wh
"Quick Startup Settings for Main Power" is set to "ON" : 1.0 Wh
* The power consumption may vary, depending on the environment and conditions under which the machine is
being used.
Standard: 3.5 GB (1.5+2 GB)
Standard: 1TB (Used space: 1TB)
* The hard disk capacity is subject to change in future release.
1,424mm *1 x 1,530mm *2 x 934mm (56 1/8" *1 x 60 1/4" *2 x 36 3/4")
(when the Duplex Color Image Reader Unit-H1 and the Upright Control Panel-D1 are attached.)
*1 To the top of the Upright Control Panel-D1 in the standard position.
*2 To the right edge of the Upright Control Panel-D1 in the standard position.
Approximately 316kg (697 lb)
1,952mm x 934mm (76 7/8" x 36 3/4")
(When the Output Tray-A1, the Duplex Color Image Reader Unit-H1 and the Upright Control
Panel-D1 are attached)
Item
Magnetic
Magnetic readout
Inserting Direction
Replay
From the main unit
40mm x 88mm x 96mm (1 5/8" x 3 1/2" x 3 3/4")
(excluding the attachment kit and cable)
Approximately 200g (7.1 oz )
(including the attachment kit and cable)
Specifications
Maximum Power Consumption:
1,560W + 2,500W or less
Power Consumption:
When in the Sleep mode:
1.5Wh
Specifications
