Table of Contents

Advertisement

Quick Links

See also: Feature Manual , Programming Manual
Digital Super Hybrid System
Programming Guide
KX-TD816
KX-TD1232
Model
Please read this manual before using the Digital Super Hybrid System.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TD816

Summary of Contents for Panasonic KX-TD816

  • Page 1 Digital Super Hybrid System Programming Guide KX-TD816 KX-TD1232 Model Please read this manual before using the Digital Super Hybrid System.
  • Page 2 About the other manuals Along with this Programming Guide, the following manuals are available to help you install, know the available features and use the KX-TD816 / KX-TD1232 system: Installation Manual Provides instructions for installing the hardware and optional equipment.

  • Page 3: Table Of Contents

    Table of Contents 1 Programming Instructions ...............9 1.1 Programming Instructions ..................10 1.2 Using Proprietary Telephones ..................11 1.3 Programming Methods ....................15 1.4 Entering Characters.....................17 1.5 User Programming Mode ....................22 1.6 Programming Example ....................23 2 General Programming ..............27 2.1 Manager Programming ....................28 [000] Date and Time Set.......................28 [001] System Speed Dialling Number Set ................30 [002] System Speed Dialling Name Set ................32...
  • Page 4 [124] Phantom Extension Number Set ................91 [125] Area Code Assignment ....................93 [126] Caller ID Modification for Local Call ............... 95 [127] Caller ID Modification for Long Distance Call ............97 [128] PBX Code ........................98 [129] E&M Signal Assignment ................... 99 [130] Message Waiting Control..................
  • Page 5 [311] Special Carrier Access Codes...................152 [312] ARS Mode ........................153 [313] ARS Time .........................154 [314-321] ARS Leading Digit Entry for Plans 1 through 8 ..........156 [322-329] ARS Routing Plans 1 through 8 ................158 [330] ARS Modify Removed Digit ..................160 [331] ARS Modify Added Number..................161 [332] Extra Entry Table Selection ..................162 [333] TRS Entry Code Assignment for Extra Table ............163 [334] Emergency Dial Number Set ..................164...
  • Page 6 [450] DID Forward Group-II Signal Code (for MFC-R2) ..........221 [451] DID Backward Group-A Signal Code (for MFC-R2) ..........222 [452] DID Backward Group-B Signal Code (for MFC-R2)..........223 [457-458] DIL 1:1 – Lunch / Break Group ............... 224 2.6 COS Programming ....................226 [500-501] Toll Restriction Level –...
  • Page 7 [018] Budget Management for ISDN Extension..............288 3.2 System Programming....................290 [109] Expansion Unit Type ....................290 [112] ISDN Network Type Assignment ................293 [140] DDI Number / Phantom Extension Number Conversion .........294 [149] ISDN Data Assignment ....................295 [154] DID Transfer Table for DDI Call................298 3.3 ISDN Line Programming...................299 [418] Outside Line Number Assignment for ISDN / E1............299 [419] ISDN Outgoing CLIR Service Assignment..............301...
  • Page 8 [744] E1 DID Receive Digit ....................361 [745] E1 DR2 Receiver ..................... 362 [747] E1 Line Coding ......................363 [748] E1 Frame Sequence ....................364 [749] E1 Frame Option...................... 365 [750] E1 First Dial Timer (DR2 / TIE)................366 [751] E1 %Break ....................... 367 [752] E1 Dial Click Tone....................

  • Page 9: Programming Instructions

    Section 1 Programming Instructions Programming Instructions...

  • Page 10: Programming Instructions

    1.1 Programming Instructions 1.1 Programming Instructions Default Setting This system has a default factory setting. If any of the programming needs to be changed, you will find the necessary information in the Features Guide. This makes the system very simple to install and customise as required by the customer.

  • Page 11: Using Proprietary Telephones

    1.2 Using Proprietary Telephones 1.2 Using Proprietary Telephones Soft Buttons and SHIFT Button on the Display DPT Three soft buttons are provided just below the display of Digital Proprietary Telephones (DPT), KX-T7433, KX-T7436, KX-T7230 and KX-T7235. The functions of these soft buttons vary as the programming procedures advance step by step.
  • Page 12 1.2 Using Proprietary Telephones You can use either the soft buttons or the overlay buttons. (For overlay buttons, refer to "Using the Overlay" below.) Throughout programming you will see instructions such as "Press PREV". If you use soft buttons, this means press SHIFT, release SHIFT and then press Soft 3. The (PREV) function is performed.

  • Page 13: Viewing The Display

    1.2 Using Proprietary Telephones Location of Controls with the Overlay The pictures below show the functions of the buttons of the proprietary telephone while in programming mode. There are Overlays for the KX-T7400 and KX-T7200 series telephones. KX-T7436 and KX-T7230 are used for the examples. KX-T 7436 SHIFT CLEAR...
  • Page 14 1.2 Using Proprietary Telephones Before entering the programming mode Before entering programming mode, confirm that: • Your telephone is on-hook. • No calls are on hold at your telephone. Entering the programming mode Press PROGRAM (or PAUSE) + + # and enter your System Password (default=1234).

  • Page 15: Programming Methods

    1.3 Programming Methods 1.3 Programming Methods Advancing to the next stage When "SYS-PGM NO? " is displayed, you can select one of the following: • To go to programme [000], press the NEXT button. • To go to another programme, enter the 3-digit programme address. Rotation of jack number Each jack of the Digital Super Hybrid System supports the connection of a digital proprietary telephone and a single line device with different extension numbers (eXtra Device Port: XDP...
  • Page 16 1.3 Programming Methods Going to another programme address After pressing STORE, you can go to another programme with either of the following two methods: To go to the next larger programme address: Press Soft 1 (SKP+) or VOLUME (DOWN) or rotate the Jog Dial in the counter- clockwise direction.

  • Page 17: Entering Characters

    1.4 Entering Characters 1.4 Entering Characters Entering Characters You can enter characters to store names or messages by using the dialling key pad, buttons or the Jog Dial. See the Combination Tables below. Combination Table a SHIFT+ SHIFT+ Soft button SHIFT+S1 SHIFT+S2 SHIFT+S3...
  • Page 18 1.4 Entering Characters Combination Table b Jog Dial Display sequence by rotating the Jog Dial keys 1 Q q R r S s T t ··· 2 A a B b C c D d ··· 3 D d E e F f G g ··· 4 G g H h I i J j ···...
  • Page 19 1.4 Entering Characters Using the Jog Dial (for KX-T7433 / KX-T7436 only) * See Combination Table b. Press 6. ("M" belongs to "6".) Rotate the Jog Dial one pulse. • Rotating the Jog Dial an appropriate number of pulses gives you the desired letter. Rotating the Jog Dial two pulses gives the letter "m", rotating three pulses gives "N", and so on.
  • Page 20 1.4 Entering Characters Enter 5. Press Soft 2 (k). Enter 3. Mik3 Press Soft 2 (e). Mike Using method (2) * See Combination Table a. Procedures The display shows: 1. Enter 6. 2. Press SELECT. 3. Enter 4. 4. Press SELECT six times. 5.
  • Page 21 1.4 Entering Characters Procedures The display shows: 1. Enter 2. 2. Rotate Jog Dial until "M" appears. M 3. Enter 2. 4. Rotate Jog Dial until "i" appears. 5. Enter 2. 6. Rotate Jog Dial until "k" appears. Mik 7. Enter 2. Mik2 8.

  • Page 22: User Programming Mode

    1.5 User Programming 1.5 User Programming Mode User Programming Mode Manager programming items (programme address: [0XX]) are accessible by any display proprietary telephone user in the system. Entering the user programming mode You can access these programmes by entering the User Programming Mode as follows: Before entering the mode, confirm that: •...

  • Page 23: Programming Example

    1.6 Programming Example 1.6 Programming Example Programming Example The following programming instructions assume that you have already entered the programming mode and that you will employ method (b) of "Going to another programme address" in Section 1.3 Programming Methods. Example: programme [001] System Speed Dialling Number Set Sample of Description Explanation (1) Programme address.
  • Page 24 1.6 Programming Example Sample of Description Explanation 6. To programme another speed dial number, (15) Select the best way for you to store another speed press NEXT or PREV, or SELECT and dial number. Pressing the NEXT / PREV allows (15) the desired speed dial number .
  • Page 25 1.6 Programming Example Programming Structure Programme Programming Group Description Address [8XX] Resource Programming Assignment of customer-supplied peripherals connected to the system. [9XX] Optional Programming Used to answer the user's requirements or troubles, if needed. Programming Instructions...
  • Page 26 1.6 Programming Example Programming Instructions...

  • Page 27: General Programming

    Section 2 General Programming General Programming...

  • Page 28: Manager Programming

    2.1 Manager Programming 2.1 Manager Programming [000] Date and Time Set Description Sets the current date and time. A 12 hour clock or 24 hour clock can be selected. Selection • Year: 00 through 99 • Month: Jan. through Dec. •...
  • Page 29 2.1 Manager Programming Enter the hour. To change the current entry, press CLEAR and enter the new hour. Press Enter the minute. To change the current entry, press CLEAR and enter the new minute. Press Press SELECT for AM or PM. Press Press SELECT for 12 or 24 (clock hour).

  • Page 30: System Speed Dialling Number Set

    2.1 Manager Programming [001] System Speed Dialling Number Set Description Used to programme the System Speed Dial numbers. These numbers are available to all extension users. There are 500 numbers available from 000 to 499. Selection • Speed dial number: 000 through 499 •...
  • Page 31 2.1 Manager Programming Conditions • Each speed dial number has a maximum of 24 digits. The valid characters are 0 through 9, and # keys, and the FLASH, PAUSE, SECRET and – (hyphen) buttons. – To store a flash signal, press FLASH. Note: The stored flash will only be effective during a call.

  • Page 32: System Speed Dialling Name Set

    2.1 Manager Programming [002] System Speed Dialling Name Set Description Assigns names to the system speed dial numbers assigned in programme [001] System Speed Dialling Number Set. KX-T7433, KX-T7436 and KX-T7235 telephones can show the stored name during System Speed Dialling. Selection •...
  • Page 33 2.1 Manager Programming Features Guide References Call Directory System Speed Dialling General Programming...

  • Page 34: Extension Number Set

    Assigns an extension number to each extension. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2) KX-TD1232 – 01 through 64 (-1 / -2) (-1 = first part, -2 = second part) • Extension Number: 2 through 4 digits...
  • Page 35 2.1 Manager Programming Conditions • There is a maximum of 32 extension numbers for KX-TD816, and 128 extension numbers for KX-TD1232. Each extension number can be two, three, or four digits, consisting of 0 through 9. The and # keys cannot be used.

  • Page 36: Extension Name Set

    To programme another jack, press NEXT or PREV, or SELECT and the desired jack number. Repeat steps 4 through 6. Press END. Conditions • There is a maximum of 32 names for KX-TD816, and 128 names for KX-TD1232. Each name has a maximum of 10 characters. General Programming...
  • Page 37 2.1 Manager Programming • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.

  • Page 38: Flexible Co Button Assignment

    KX-TD1232 – 01 through 64 • Button Code (plus parameter, if required): Button Code Parameter 0 (Single-CO) KX-TD816: 01 through 08 (Outside line number) KX-TD1232: 01 through 54 (Outside line number) 1 (DSS) 2 through 4 digits (Extension number) 2 (One-Touch Dialling) 16 digits max.
  • Page 39 * Available when this system is connected to a Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP100). Default KX-TD816: All jacks – CO buttons 1 through 8 = Single-CO 01 through 08; Ring tone type 2 Other CO buttons = Not stored KX-TD1232: All jacks –...
  • Page 40 2.1 Manager Programming Conditions • A centralised telephone is a telephone connected to jack 01 or a jack programmed as a manager extension in programme [006] Operator / Manager Extension Assignment. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available.

  • Page 41: Operator / Manager Extension Assignment

    System Programming and manager services. The operators have the ability to perform operator services. Selection • OPE-1 (operator 1) / OPE-2 (operator 2) / MNGER (manager) • Jack number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 Default Operator 1 – Jack 01; Operator 2 and Manager – Not stored Programming Enter 006.
  • Page 42 2.1 Manager Programming • If the assigned jack is in eXtra Device Port (XDP) mode, the proprietary telephone jack is treated as the manager / operator extension. Features Guide References Manager Extension Operator General Programming...

  • Page 43: Console Port And Paired Telephone Assignment

    Assigns the jack numbers for the console and the paired extension. Selection • Console number: KX-TD816 – 1 through 4 KX-TD1232 – 1 through 4 (for Master), 5 through 8 (for Slave) • Jack number for Console: KX-TD816 – 02 through 16 KX-TD1232 –...
  • Page 44 2.1 Manager Programming Conditions • The jack number for the console and that for the paired extension must be entered together. • Multiple consoles cannot be assigned to the same console jack. • Multiple consoles can be paired with the same proprietary telephone jack. •...

  • Page 45: Absent Messages

    2.1 Manager Programming [008] Absent Messages Description Used to programme the absent messages. An absent message, if set by the extension user, is displayed on the calling extension's telephone to show the reason for the user's absence. Selection • Message number: 1 through 9 •...
  • Page 46 2.1 Manager Programming Conditions • Messages 1 through 6 are programmed at the factory but can be changed. • You can enter a maximum of seven "%" characters per message which can be programmed at each user's extension. The extension user can enter 0 through 9, and # for the % characters.

  • Page 47: Quick Dial Number Set

    2.1 Manager Programming [009] Quick Dial Number Set Description Stores up to eight quick dial numbers. Selection • Location number: 1 through 8 • Desired number: 16 digits (max.) Default All location numbers – Not stored Programming Enter 009. Display: 009 QUICK DIAL Press NEXT.

  • Page 48: Vm Name Set

    Description Assigns a name for each voice mail port. Selection • Voice Mail (VM) number: KX-TD816 – 01 through 12 KX-TD1232 – 01 through 24 • Name: 10 characters (max.) Default All Voice Mails – V.Mail xx (xx=01 through 24) Programming Enter 014.

  • Page 49: Budget Management

    Assigns the charge limitation of a call on the extension basis. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), ( =all jacks, -1=first part, -2=second part) • Charge limitation (Charge): 0 through 99999999 Default All jacks –...
  • Page 50 2.1 Manager Programming Features Guide References Budget Management Charge Fee Reference General Programming...

  • Page 51: Disa / Tie User Codes

    2.1 Manager Programming [017] DISA / TIE User Codes Description Assigns the Direct Inward System Access (DISA) and TIE User Codes and a Class of Service (COS) to each code. The code COS determines the toll restriction level of the DISA and TIE caller.
  • Page 52 2.1 Manager Programming To programme another user code, press NEXT or PREV, or SELECT and the desired DISA / TIE user code number. Repeat steps 4 through 8. Press END. Conditions • This setting is required if Trunk (Outside line) Security mode is selected in programmes [439] TIE Security Type and [809] DISA Security Type.

  • Page 53: System Programming

    2.2 System Programming 2.2 System Programming [100] Flexible Numbering Description Assigns the leading digits of extension numbers and feature numbers for system features. Feature Number List Number Feature Default 1st hundred extension block 2nd hundred extension block 03 - 16 3rd through 16th hundred extension block None Operator call...
  • Page 54 2.2 System Programming Feature Number List Number Feature Default External feature access Station feature clear Message waiting Outgoing message Call forwarding / do not disturb Call pickup deny Data line security Call waiting / OHCA / whisper OHCA Executive busy override deny Pickup dialling Absent message Timed reminder...
  • Page 55 2.2 System Programming For KX-TD1232X = 9, Others = 0 For KX-TD1232X = 0, Others = 9 Selection • Selection number: 01 through 91 (See "Feature Number List" for the corresponding features.) • Feature number: 1 or 2 digits (for selection numbers 01 through 16, 74 through 89); 1 through 3 digits (for selection numbers 17 through 73 and 90 through 91) Default See "Feature Number List".
  • Page 56 2.2 System Programming Conditions • Required digits and valid entries for the feature numbers are as follows. Feature number type Required digits Valid entry Extension blocks / other 1 or 2 digits 0 through 9 PBX extensions TIE line access number 1 through 3 digits 0 through 9 Other feature numbers...

  • Page 57: Day / Night Service Switching Mode

    2.2 System Programming [101] Day / Night Service Switching Mode Description This programme is used to determine if night mode is set automatically or manually. Selection Manual / Auto (automatic) Default Manual Programming Enter 101. Display: 101 DAY/NT AUTO Press NEXT. Display example: D/N Mode:Manual Keep pressing SELECT until the desired selection is displayed.

  • Page 58: Day / Night Service Starting Time

    2.2 System Programming [102] Day / Night Service Starting Time Description Sets the starting time on a day of the week basis, when automatic day / night switching is programmed in programme [101] Day / Night Service Switching Mode. Selection •...
  • Page 59 2.2 System Programming To programme another day / night mode or day of the week, press NEXT or PREV, or SELECT and the day of the week selection number. Repeat steps 4 through 10. Press END. Conditions • To select the desired day, you may keep pressing NEXT in step 3. To assign every day of the week to one selection, press the key in step 3.

  • Page 60: Automatic Access Outside Line Group Assignment

    2.2 System Programming [103] Automatic Access Outside Line Group Assignment Description Assigns the sequence in which outside line groups will be accessed when in Automatic Line Access mode. When a user dials the feature number for automatic line access (default=9/0) or presses the Loop-CO button, an idle line is searched for in the programmed outside line group order.

  • Page 61: Account Codes

    2.2 System Programming [105] Account Codes Description Assigns the account codes for Account Code Entry, Verified – All Calls and Verified – Toll Restriction Override modes. If Verified – All Calls is assigned in programme [508] "Account Code Entry Mode", an account code is required to make an outside call. If Verified – Toll Restriction Override is assigned, an account code is only required for a toll call and overrides toll restriction.
  • Page 62 2.2 System Programming Features Guide References Account Code Entry Toll Restriction General Programming...

  • Page 63: Station Hunting Type

    2.2 System Programming [106] Station Hunting Type Description Used to enable or disable hunting and set the Station Hunting type for each extension group. There are six Station Hunting types available: Circular: all of the extensions in the group are searched until an idle one is found. Termination: searching stops at the extension which has the largest jack number in the group.
  • Page 64 2.2 System Programming Conditions • Programme [602] Extension Group Assignment is used to assign the extension group members. • The system supports a maximum of eight jacks (16 jacks during System Connection for KX-TD1232) for connection to a Voice Processing System as VM or AA ports. •...

  • Page 65: System Password

    2.2 System Programming [107] System Password Description Assigns the password required for entering System Programming mode and for maintenance from a personal computer. Selection Password: 4 through 7 digits Default 1234 Programming Enter 107. Display: 107 SYS PASSWORD Press NEXT. Display: Password:1234 Enter a password.

  • Page 66: Automatic Hold By Co / Dss Button

    2.2 System Programming [108] Automatic Hold by CO / DSS Button Description Enables or disables automatically holding an outside call when a DSS (Direct Station Selection) button on the console or proprietary telephone, or a CO button on a proprietary telephone is pressed.

  • Page 67: Expansion Unit Type

    / MD (4 DID-MFC) / EM (4 E&M) / EL (1 E1) / E1 (8 EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) (Master system only: PR, EL) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
  • Page 68 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / DID / E&M) unit can be installed.
  • Page 69 2.2 System Programming Features Guide References None General Programming...

  • Page 70: Caller Id Code Set

    2.2 System Programming [110] Caller ID Code Set Description Sets the identification code of the calling party (Caller ID Code) to utilise a Caller ID Service provided by a specific central office (CO). If an ID Code transmitted from the CO is found in the Caller ID Code Table, the caller's ID Code or name given to the code in programme [111] Caller ID Name Set is displayed on the telephone.
  • Page 71 2.2 System Programming • Programme [406] Caller ID Assignment is used to enable the Caller ID Service on an outside line basis. Features Guide References Caller ID General Programming...

  • Page 72: Caller Id Name Set

    2.2 System Programming [111] Caller ID Name Set Description With Caller ID Service, the calling party is displayed either by its ID Code or by its name. If the name display is required, use this programme to give a name to a caller ID Code stored in programme [110] Caller ID Code Set.

  • Page 73: Vm Status Dtmf Set

    2.2 System Programming [113] VM Status DTMF Set Description Sets the DTMF (Dual Tone Multi-Frequency) signals transmitted to your Voice Processing System (VPS) to inform the VPS of the VPS ports states quickly: The following signals are sent to the VPS with the assigned DTMF signals: RBT (ringback tone): This signal is sent when calling an extension.
  • Page 74 2.2 System Programming Display example: RBT :1 Enter a DTMF signal number. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new number. Press STORE. To programme another selection, keep pressing NEXT or PREV until the desired selection is displayed.

  • Page 75: Vm Command Dtmf Set

    2.2 System Programming [114] VM Command DTMF Set Description Sets the DTMF (Dual Tone Multi-Frequency) command signals transmitted to your Voice Processing System (VPS). There are four commands available: Leave Message; Get Message; Automated Attendant Service; Voice Mail Service. These commands are used in the following ways: (A) If your VPS is used for Voice Mail (VM) Service (1) Call Forwarding / Intercept Routing to Voice Mail...
  • Page 76 2.2 System Programming Default LV-MSG – H; GETMSG – *H; AA-SVC – #8; VM-SVC – #6 Programming Enter 114. Display: 114 VM DTMF CMD Press NEXT to programme the LV-MSG command. To programme another command, keep pressing NEXT until the desired command is displayed.

  • Page 77: Adjust Time

    2.2 System Programming [115] Adjust Time Description Used to adjust the time for checking the normality of system data. Every day at the programmed time, the data adjustment is performed. Selection • Hour: 1 through 12 • Minute: 00 through 59 •...

  • Page 78: Rom Version Display

    The display shows the ROM version of the specified system. Press END. Conditions • The out-of-service system number is unacceptable. • For KX-TD816, you can enter the system number "0" only. Skip step 4. Features Guide References None General Programming...

  • Page 79: Voice Mail Number Assignment

    Processing System. The voice mail port is expandable to six ports (12 ports during System Connection for KX-TD1232). This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP100).
  • Page 80 2.2 System Programming Press END. KX-TD1232 Enter 117. Display: 117 VMS PORT ASN Press NEXT to programme the Master System. Display example: Mast1:# # # Enter a jack number. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new jack number. Press to enter another jack number.

  • Page 81: Voice Mail Extension Number Set

    Assigns the extension number for the voice mail number. These numbers can be used the same way extension numbers are used for station access. This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP100).
  • Page 82 [124] Phantom Extension Number Set Not stored. [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 198, 291 through 294, 296 through 299 Features Guide References...

  • Page 83: Voice Mail Extension Group Assignment

    [119] Voice Mail Extension Group Assignment Description Assigns each voice mail number to a voice mail extension group number. This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP100). Selection •...
  • Page 84 2.2 System Programming programmed in [117] Voice Mail Number Assignment. "-1" of YY-1 means the first part of the jack number in digital line. "YY-2" means the second part of the jack number in digital line. • To assign all voice mail numbers to one selection, press the key in step 3.

  • Page 85: User Password

    2.2 System Programming [120] User Password Description Assigns the password required for entering the User Programming mode. In the User Programming mode, any display digital proprietary telephone user in the system can set the Manager Programmings (Programme address: [0XX]). Selection Password: 4 through 7 digits Default 1234...

  • Page 86: Walking Cos Password

    2.2 System Programming [121] Walking COS Password Description Assigns the password required for Walking COS. Selection Password: 4 through 7 digits Default 1234 Programming Enter 121. Display: 121 COS PASSWORD Press NEXT. Display example: Password:1234 Enter a password. To change the current entry, press CLEAR and enter the new password. Press STORE.

  • Page 87: Ucd Overflow

    2.2 System Programming [122] UCD Overflow Description Assigns the destination where the call is transferred to when all extensions in the Uniform Call Distribution (UCD) group are busy. The Time Table number of the overflow extension must also be assigned. Selection •...
  • Page 88 2.2 System Programming Features Guide References Uniform Call Distribution (UCD) General Programming...

  • Page 89: Ucd Time Table

    2.2 System Programming [123] UCD Time Table Description Assigns the queuing sequence in the Uniform Call Distribution (UCD) Time Table. The queuing sequences are as follows: S1: Sends DISA (Direct Inward System Access) outgoing message 1. S2: Sends DISA outgoing message 2. S3: Sends DISA outgoing message 3.
  • Page 90 2.2 System Programming Conditions • "Sx" can be assigned in a space other than in the first only when another "Sx" is assigned in the first space. • An assignment after "TR", "RT" or "Blank" is not available. Features Guide References Uniform Call Distribution (UCD) General Programming...

  • Page 91: Phantom Extension Number Set

    2.2 System Programming [124] Phantom Extension Number Set Description Assigns the phantom extension numbers. Each number will be assigned to a flexible CO or DSS (Direct Station Selection) button and used as a Phantom Extension button. Selection • Location number: 001 through 128 •...
  • Page 92 KX-TD816 – 165 through 178, 181 through 184 KX-TD1232 – 165 through 188 [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 198, 291 through 294, 296 through 299 Features Guide References...

  • Page 93: Area Code Assignment

    2.2 System Programming [125] Area Code Assignment Description Assigns up to ten area codes which are necessary when using the Caller ID feature. By assigning your area code, the system records the caller's phone number modified by programmes [126] Caller ID Modification for Local Call and [127] Caller ID Modification for Long Distance Call.
  • Page 94 2.2 System Programming Call Log, Incoming General Programming...

  • Page 95: Caller Id Modification For Local Call

    2.2 System Programming [126] Caller ID Modification for Local Call Description Assigns removed digits from the received caller's number of a local call, and adds number to make the final number which serves as the Caller ID number. The system records the modified caller's number to the incoming call log list so that the extension user can call back the caller.
  • Page 96 2.2 System Programming • There are ten location numbers for modified numbers, which corresponds to those in programme [125] Area Code Assignment. Features Guide References Caller ID Call Log, Incoming General Programming...

  • Page 97: Caller Id Modification For Long Distance Call

    2.2 System Programming [127] Caller ID Modification for Long Distance Call Description Assigns removed digits from the received caller's number of a long distance call, and adds number to make the final number which serves as the Caller ID number. The system records the modified caller's number to the incoming call log list so that the extension user can call back the caller.

  • Page 98: Pbx Code

    2.2 System Programming [128] PBX Code Description Assigns the PBX Code as your location number if the "PBX Code method" is employed for TIE Line Network calling. Selection PBX Code: 1 through 3 digits Default Not stored Programming Enter 128. Display: 128 PBX CODE Press NEXT.

  • Page 99: E&M Signal Assignment

    2.2 System Programming [129] E&M Signal Assignment Description Assigns the E&M signal. There are three signals available: Continuous: Continuous E&M (Wink/Immediate) Pulsed Ans: Pulsed E&M with Answer Signal (Wink only) Pulsed No Ans: Pulsed E&M without Answer Signal (Wink only) Selection Continuous / Pulsed Ans / Pulsed No Ans Default...

  • Page 100: Message Waiting Control

    (KX-TD194). Selection • Unit (TD194) number: KX-TD816 – 1 KX-TD1232 – 1 through 6 • Jack number: KX-TD816 – 02 through 16 KX-TD1232 – 02 through 64 Default All units – Not stored Programming Enter 130. Display: 130 MW CONTROL Press NEXT.
  • Page 101 2.2 System Programming Jacks assigned to consoles and paired telephones Jacks already assigned to the message waiting adaptor unit If the unit is connected to a port which is not assigned as the data port, a clicking sound may be heard from the unit. Please make sure that the unit is connected to the assigned port.

  • Page 102: Message Waiting Lamp Assignment

    2.2 System Programming [131] Message Waiting Lamp Assignment Description Assigns the message waiting light pattern. Selection Message waiting light pattern number: 01 through 12 Default Programming Enter 131. Display: 131 MW LAMP Press NEXT. Display: MW LAMP NO:1 Enter a message waiting light number. Display example: MW LAMP NO:12 Press STORE.
  • Page 103 2.2 System Programming Pattern 01 1.25s Pattern 02 500 ms Pattern 03 250 ms Pattern 04 250 ms 250 ms Pattern 05 500 ms 500 ms 10± s Pattern 06 250 ms 20± s Pattern 07 250 ms Pattern 08 1.25 s 1.25 s Pattern 09...

  • Page 104: Message Waiting Port Set

    • Message waiting port number: 01 through 16 • Single line telephone jack number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • Sub port number: 1 or 2 (1 = main port, 2 =XDP single line telephone port) Default All units –...
  • Page 105 2.2 System Programming Press END. Conditions • To programme another unit, start from step 1. • For the KX-TD1232, the unit numbers 1 through 3 are for the Master System and 4 through 6 are for the Slave System, and jack numbers 01 through 32 are for Master System and 33 through 64 are for Slave System.

  • Page 106: Hotel Application

    2.2 System Programming [134] Hotel Application Description Assigns whether the hotel application is enabled or disabled. Selection ON / OFF Default Programming Enter 134. Display: 134 HOTEL ON/OFF Press NEXT. Display example: Hotel:OFF Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 107: Did Number Conversion Selection

    2.2 System Programming [135] DID Number Conversion Selection Description Selects whether the Direct Inward Dialling (DID) number is allocated as an extension number or is converted using the Transfer Table. Selection EXT Number / Transfer Table Default EXT Number Programming Enter 135.

  • Page 108: Did / Ddi Number Assignment

    2.2 System Programming [136] DID / DDI Number Assignment Description Assigns the Direct Inward Dialling (DID) number which is converted from the DID subscriber number using the programmes [433] DID / TIE Subscriber Number Removed Digit and [434] DID / TIE Added Number. And also assigns the Direct Dialling In (DDI) number. If the converted number matches the number assigned in this programme, it reaches the destination assigned in programme [137-138] DID / DDI Extension –...
  • Page 109 2.2 System Programming • To use this programme for DID numbers, "Transfer Table" must be selected beforehand in programme [135] DID Number Conversion Selection. • To use this programme for DDI numbers, "Use" must be selected beforehand in programme [154] DID Transfer Table for DDI Call. Features Guide References Direct Dialling In (DDI) Direct Inward Dialling (DID)

  • Page 110: Did / Ddi Extension - Day / Night

    2.2 System Programming [137-138] DID / DDI Extension – Day / Night Description Determines the extension which receive a Direct Inward Dialling (DID) or Direct Dialling In (DDI) call in both the day and night modes. Selection • Location number: 001 through 200 •...
  • Page 111 2.2 System Programming • To use this programme for DID, "Transfer Table" must be selected first in programme [135] DID Number Conversion Selection, and then the DID number must be assigned in programme [136] DID / DDI Number Assignment. • To use this programme for DDI, "Use" must be selected first in programme [154] DID Transfer Table for DDI Call, and then the DDI number must be assigned in programme [136] DID / DDI Number Assignment.

  • Page 112: Did / Ddi Extension Name Set

    2.2 System Programming [139] DID / DDI Extension Name Set Description Assigns names to the Direct Inward Dialling (DID) or Direct Dialling In (DDI) extension assigned in programme [136] DID / DDI Number Assignment. Selection • Location number: 001 through 200 •...
  • Page 113 2.2 System Programming Direct Inward Dialling (DID) General Programming...

  • Page 114: Charge Rate Decimal Point Assignment

    2.2 System Programming [141] Charge Rate Decimal Point Assignment Description Assigns how many decimal places to set for the charge rate. Selection Number of decimal places: 0 through 8 Default Programming Enter 141. Display: 141 DECI. POINT Press NEXT. Display example: Fraction place 2 Enter the desired number.

  • Page 115: Charge Rate Assignment

    [142] Charge Rate Assignment Description Assigns the rate to each outside line. Selection • Outside line number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Desired number: 10 digits max. (including the decimal point) Default All outside lines –...
  • Page 116 2.2 System Programming • A maximum of ten digits, consisting of 0 through 9 and (decimal point), can be assigned as the rate. The number of spaces depends on the assignment in programme [141] Charge Rate Decimal Point Assignment. <Example> To assign the rate "0.25" when the decimal place is 3 (assigned in [141]), enter "0.250".

  • Page 117: Charge Display Selection

    2.2 System Programming [143] Charge Display Selection Description Assigns the initial display format of charge fee. Selection in Meter / in Charge Default in Meter Programming Enter 143. Display: 143 CHARGE METER Press NEXT. Display example: in Meter Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 118: Currency Assignment

    2.2 System Programming [144] Currency Assignment Description Assigns the currency required for your country. Selection 2 characters (Max.) Default Programming Enter 144. Display: 144 CURRENCY Press NEXT. Display example: Currency: $ Enter a currency. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new currency.

  • Page 119: Off-Hook Monitor

    2.2 System Programming [148] Off-Hook Monitor Description Enables or disables to perform the Off-Hook Monitor. Selection Enable / Disable Default Enable Programming Enter 148. Display: 148 HOOK MONITOR Press NEXT. Display example: Monitor:Enable Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 120: Lunch Service Starting / Ending Time

    2.2 System Programming [150] Lunch Service Starting / Ending Time Description Sets the Lunch starting and ending time for each day of the week. Selection • Day of the week selection number: 1 (Sunday) / 2 (Monday) / 3 (Tuesday) / 4 (Wednesday) / 5 (Thursday) / 6 (Friday) / 7 (Saturday) / (every day of the week) •...
  • Page 121 2.2 System Programming Conditions • This programming can only be used if "Auto (automatic)" is selected in programme [101] Day / Night Service Switching Mode. • Lunch / Break service ends at the assigned time. For example: If Lunch is 3:00 – 4:00 PM, Day mode starts at 4:01 PM. If Lunch is 3:00 –...

  • Page 122: Break Service Starting / Ending Time

    2.2 System Programming [151] Break Service Starting / Ending Time Description Sets the Break starting and ending time for each day of the week. Selection • Day of the week selection number: 1 (Sunday) / 2 (Monday) / 3 (Tuesday) / 4 (Wednesday) / 5 (Thursday) / 6 (Friday) / 7 (Saturday) / (every day of the week) •...
  • Page 123 2.2 System Programming Conditions • This feature can only be used if "Auto (automatic)" is selected in programme [101] Day / Night Service Switching Mode. • Lunch / Break service ends at the assigned time. For example: If Lunch is 3:00 – 4:00 PM, Day mode starts at 4:01 PM. If Lunch is 3:00 –...

  • Page 124: Charge Verification Assignment

    Assigns the extension which is allowed to refer or clear for the call information on the extension, outside line, account code, and the total. Selection • Jack number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all jacks) • Enable / Disable Default All jacks –...

  • Page 125: Charge Verification Id Code Set

    2.2 System Programming [153] Charge Verification ID Code Set Description Assigns an ID code required to refer the charge information. Selection 4 digits (0000 through 9999) Default 1234 Programming Enter 153. Display: 153 CHARGE ID Press NEXT. Display example: Code:1234 Enter an ID code.

  • Page 126: Timer Programming

    2.3 Timer Programming 2.3 Timer Programming [200] Hold Recall Time Description Assigns the length of the hold recall timer. This timer is used to alert an extension that a call has been held for an extended period of time. Selection Time (seconds): 0 through 240 (0=Hold Recall disabled) Default 60 s...

  • Page 127: Transfer Recall Time

    2.3 Timer Programming [201] Transfer Recall Time Description Sets the number of rings before transfer recall occurs. If a transferred call is not answered after the programmed number of rings, the call returns to the original caller. Selection Number of rings: 0 through 48 (0=Transfer Recall disabled) Default 12 rings Programming...

  • Page 128: Call Forwarding - No Answer Time

    2.3 Timer Programming [202] Call Forwarding – No Answer Time Description Sets the number of rings for the Call Forwarding – No Answer feature. If a call is not answered after the programmed number of rings, the call is forwarded to the destination. Selection Number of rings: 1 through 12 Default...

  • Page 129: Intercept Time

    2.3 Timer Programming [203] Intercept Time Description Sets the number of rings for the Intercept Routing – No Answer (IRNA) feature. If a call is not answered after the programmed number of rings, the call is redirected to the programmed extension.

  • Page 130: Pickup Dial Waiting Time

    2.3 Timer Programming [204] Pickup Dial Waiting Time Description Sets the number of seconds for Pickup Dialling. If the telephone user lifts the handset, the programmed party is called when the time expires. Selection Time (seconds): 1 through 5 Default Programming Enter 204.

  • Page 131: Extension-To-Outside Line Call Duration Time

    2.3 Timer Programming [205] Extension-to-Outside Line Call Duration Time Description Sets the maximum time allowed for a conversation with an outside party. If an outside call is originated or answered by a programmed extension user and the timer expires, the call is disconnected.

  • Page 132: Outside-To-Outside Line Call Duration Time

    2.3 Timer Programming [206] Outside-to-Outside Line Call Duration Time Description Sets the maximum time allowed for a conversation between two outside parties. When the timer expires, the outside-to-outside line call is disconnected. Selection Time (minutes): 1 through 64 Default 10 min Programming Enter 206.

  • Page 133: First Digit Time

    2.3 Timer Programming [207] First Digit Time Description Sets the maximum time allowed between the start of an outside dial tone and the first digit dialled on an outgoing outside call. If an extension user fails to dial any digits during this time, the DTMF (Dual Tone Multi-Frequency) receiver is released.

  • Page 134: Inter Digit Time

    2.3 Timer Programming [208] Inter Digit Time Description Assigns the maximum time allowed between digits on an outgoing toll call. If an extension user fails to dial any digits during this time, the DTMF (Dual Tone Multi-Frequency) receiver is released. This timer applies until the Toll Restriction check is completed. Selection Time (seconds): 5 through 30 Default...

  • Page 135: Automatic Redial Repeat Times

    2.3 Timer Programming [209] Automatic Redial Repeat Times Description Sets the number of times Automatic Redial is tried. Automatic redialling of the last dialled or saved number is done up to the specified number of times. Selection Number of times: 1 through 30 Default KX-TD816BX, KX-TD1232(D)BX/ML, KX-TDN1232 –...

  • Page 136: Automatic Redial Interval Time

    2.3 Timer Programming [210] Automatic Redial Interval Time Description Sets the interval time between Automatic Redial attempts. Selection Time (seconds): 3 through 120 ( 10 is the actual time) Default KX-TD816BX, KX-TD1232(D)BX/ML, KX-TDN1232 – 60 s KX-TD816HK, KX-TD1232HK – 900 s (15 min) KX-TD1232X –...

  • Page 137: Dial Start Time

    2.3 Timer Programming [211] Dial Start Time Description Sets the number of milliseconds the system waits before dialling after an outside line is seized. Selection Time (milliseconds): 0 through 40 ( 100 is the actual time) Default KX-TD816BX, KX-TD1232(D)BX/ML/X, KX-TDN1232 – 500 ms KX-TD816HK, KX-TD1232HK –...

  • Page 138: Call Duration Count Start Time

    2.3 Timer Programming [212] Call Duration Count Start Time Description Sets the number of seconds the system waits between the end of dialling and the start of the Station Message Detail Recording (SMDR) timer for outgoing toll calls. When the system has sent out all the digits to the central office and this timer expires, the system starts counting the call.

  • Page 139: Disa Delayed Answer Time

    2.3 Timer Programming [213] DISA Delayed Answer Time Description Assigns the number of rings between a call received and the answer by the Direct Inward System Access (DISA) feature. Selection Number of rings: 0 through 6 Default 1 ring Programming Enter 213.

  • Page 140: Disa Prolong Time

    2.3 Timer Programming [214] DISA Prolong Time Description Sets the maximum allowable prolonged time for an outside-to-outside line call via the Direct Inward System Access (DISA) feature. An outside-to-outside line call is initially limited by the "Outside-to-Outside Line Call Duration Time" (Programme [206]). However, the DISA caller can prolong the call after hearing the warning tones by pressing any key (except the key).

  • Page 141: Outgoing Message Time

    2.3 Timer Programming [215] Outgoing Message Time Description Sets the maximum allowable recording time for Outgoing Messages (OGM). Selection Time (seconds): 0 / 16 / 32 / 64 (0=no recording) Default 32, 0, 32, 0 (for OGM 1 through 4 from left to right) Programming Enter 215.

  • Page 142: Message Waiting Ring Interval Time

    2.3 Timer Programming [216] Message Waiting Ring Interval Time Description Sets the Message Waiting ring interval time for a single line telephone. Selection Time (minutes): 0 through 64 (0=no ring) Default 0 min Programming Enter 216. Display: 216 MW RING TIME Press NEXT.

  • Page 143: Timed Reminder Alarm Ring Time

    2.3 Timer Programming [217] Timed Reminder Alarm Ring Time Description Sets the number of seconds the Timed Reminder alarm rings. Selection Time (seconds): 30 through 240 Default 30 s Programming Enter 217. Display: 217 TIMED REMIND Press NEXT. Display example: Reminder: 30sec Enter the time.

  • Page 144: Disa Aa Wait Time

    2.3 Timer Programming [218] DISA AA Wait Time Description Sets the number of seconds the system waits for a second digit entry. If the timer expires, the system assumes that the first digit is a DISA (Direct Inward System Access) built-in auto attendant number if assigned in programme [815] DISA Built-in Automated Attendant Number.

  • Page 145: Call Park Recall Time

    2.3 Timer Programming [219] Call Park Recall Time Description Sets the number of rings before call park recall occurs. Call park recall is used to alert an extension that a call has been parked for an extended period of time. Selection Number of rings: 0 through 48 (0=Call Park Recall disabled) Default...

  • Page 146: Tie First / Inter Digit Time

    2.3 Timer Programming [220] TIE First / Inter Digit Time Description Assigns the maximum time allowed between the start of the dial tone and the first digit dialled (First Digit Time), and between digits (Inter Digit Time) on an TIE call. If an extension user fails to dial any digits during this time, the DTMF receiver is released.

  • Page 147: Trs / Ars Programming

    2.4 TRS / ARS Programming 2.4 TRS / ARS Programming [300] TRS Override for System Speed Dialling Description Allows you to enable toll restriction override for System Speed Dial Numbers. If this is enabled, all extension users can make System Speed Dialling calls with no restriction. Selection Enable / Disable Default...

  • Page 148: Trs Denied Code Entry For Levels 2 Through 6

    2.4 TRS / ARS Programming [301-305] TRS Denied Code Entry for Levels 2 through 6 Description These allow you to specify the numbers which are toll-restricted for each toll restriction level as follows: Programme [301]: restricts levels 2 through 6 Programme [302]: restricts levels 3 through 6 Programme [303]: restricts levels 4 through 6 Programme [304]: restricts levels 5 through 6...
  • Page 149 2.4 TRS / ARS Programming Conditions • There is a maximum of 20 toll call numbers which can be restricted for each programme. Each number has a maximum of ten digits, consisting of 0 through 9, and . The character "...

  • Page 150: Trs Excepted Code Entry For Levels 2 Through 6

    2.4 TRS / ARS Programming [306-310] TRS Excepted Code Entry for Levels 2 through 6 Description These allow you to assign numbers which are exceptions to the toll restriction specified in programmes [301] through [305] as follows: Programme [306]: applies to level 2 Programme [307]: applies to levels 2 through 3 Programme [308]: applies to levels 2 through 4 Programme [309]: applies to levels 2 through 5...
  • Page 151 2.4 TRS / ARS Programming Conditions There is a maximum of five numbers for each programme. Each number has a maximum of ten digits, consisting of 0 through 9, and . The character " " can be used as a wild card character.

  • Page 152: Special Carrier Access Codes

    2.4 TRS / ARS Programming [311] Special Carrier Access Codes Description Assigns special carrier numbers. This allows the system to recognise the user-dialled special carrier number in order to insert the required pause and apply toll restriction. Selection • Location number: 01 through 20 •...

  • Page 153: Ars Mode

    2.4 TRS / ARS Programming [312] ARS Mode Description Allows you to turn on or off the Automatic Route Selection (ARS) mode. ARS, if enabled, selects the least expensive route to be used for an outside call. Selection On / Off Default Programming Enter 312.

  • Page 154: Ars Time

    2.4 TRS / ARS Programming [313] ARS Time Description Assigns times for the four Automatic Route Selection (ARS) time schedules. It is possible to split a day into four time zones (maximum) so that the least expensive line is selected for that time.
  • Page 155 2.4 TRS / ARS Programming Conditions • Enter a starting time for each time schedule. Select "Disable" for idle schedules. • You cannot leave an entry empty. • To assign all days of the week, press the key in step 3. In this case, the display shows the contents programmed for Monday.

  • Page 156: Ars Leading Digit Entry For Plans 1 Through 8

    2.4 TRS / ARS Programming [314-321] ARS Leading Digit Entry for Plans 1 through 8 Description By entering numbers into each leading digit plan (programmes below) you are starting the process to determine which outside line group will be used to route the call. Programme [314] [315]...
  • Page 157 2.4 TRS / ARS Programming Conditions Each number has a maximum of ten digits, consisting of 0 through 9, and . The character " " can be used as a wild card character (i.e., "do not care" digit). The system scans all the ARS Leading Digit Plans simultaneously from left to right.

  • Page 158: Ars Routing Plans 1 Through 8

    2.4 TRS / ARS Programming [322-329] ARS Routing Plans 1 through 8 Description Assigns the outside line group and modification plan to be used for each route plan and time schedule. Programme [322] [323] [324] [325] [326] [327] [328] [329] Plan Selection •...
  • Page 159 2.4 TRS / ARS Programming Press END. Conditions • Up to three outside line groups and modification plans can be assigned for each time schedule. The outside line group number and modification table number must be entered together. The highest priority outside line group number and modification table number is entered first (left to right).

  • Page 160: Ars Modify Removed Digit

    2.4 TRS / ARS Programming [330] ARS Modify Removed Digit Description Determines how the dialled number should be modified before transmitting to the central office. You can delete the digits from the beginning of the dialled number. Selection • Modification table number: 1 through 8 •...

  • Page 161: Ars Modify Added Number

    2.4 TRS / ARS Programming [331] ARS Modify Added Number Description Determines how the dialled number should be modified before transmitting to the central office. Assigned numbers are added to the beginning of the dialled number. Selection • Modification table number: 1 through 8 •...

  • Page 162: Extra Entry Table Selection

    2.4 TRS / ARS Programming [332] Extra Entry Table Selection Description Selects the code table which enables an extra 400 entries within Denied or Except Code Table. Selection • Deny / Except • Level number: 2 through 6 Default Except - 2 Programming Enter 332.

  • Page 163: Trs Entry Code Assignment For Extra Table

    2.4 TRS / ARS Programming [333] TRS Entry Code Assignment for Extra Table Description Used to specify the numbers for extra Denied or Excepted Code Table for expansion. Selection • Location number: 001 through 400 • Toll call number: 10 digits (max.) Default All locations –...

  • Page 164: Emergency Dial Number Set

    2.4 TRS / ARS Programming [334] Emergency Dial Number Set Description Stores up to ten emergency call numbers. Emergency numbers are not subject to toll restriction, Account Code – Verified mode and Electronic Station Lockout. Selection • Location number: 01 through 10 •...

  • Page 165: Tie Line Routing Table

    2.4 TRS / ARS Programming [340] TIE Line Routing Table Description The TIE line routing table can be programmed. This table is referenced by the system to identify the outside line route, when an extension user makes a TIE call. A routing pattern appropriate for each call is decided by the first three digits (except the TIE line access number) of the dialled number.
  • Page 166 2.4 TRS / ARS Programming Conditions • Each TIE line access number has a maximum of three digits, consisting of 0 through 9 and . The character " " can be used as a wild card character. • Programme [341] TIE Modify Removed Digit / Added Number is used to modify the TIE line access number.

  • Page 167: Tie Modify Removed Digit / Added Number

    2.4 TRS / ARS Programming [341] TIE Modify Removed Digit / Added Number Description Assigns the removed digits and added numbers of a received TIE call. Digits are removed and added from the beginning of the dialled digits. Selection • Location number: 01 through 32 •...
  • Page 168 2.4 TRS / ARS Programming Features Guide References TIE Line Service General Programming...

  • Page 169: Outside Line Programming

    Used to identify the outside lines which are connected to the system(s). This prevents users from originating a call to a line which is not connected. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 54, ( =all outside lines) • Connect / No Connect Default All outside lines –...
  • Page 170 2.5 Outside Line Programming • Outside lines 25 through 54 become available when the KX-TD290 or KX-TD188 expansion unit is installed in the KX-TD1232. • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01.

  • Page 171: Outside Line Group Assignment

    CO03 – TRG 3; CO04 – TRG 4; CO05 – TRG 5; CO06 – TRG 6; CO07 – TRG 7; CO08 – TRG 8 (for KX-TD816) CO08 through CO54 – TRG 8 (for KX-TD1232) Programming Enter 401. Display: 401 CO GROUP 1-8 Press NEXT.
  • Page 172 2.5 Outside Line Programming Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • Outside lines 25 through 54 become available when the KX-TD290 or KX-TD188 expansion unit is installed in the KX-TD1232.

  • Page 173: Dial Mode Selection

    When dialling on the line with a touch tone telephone, only the pulse signals are sent to the outside line. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • DTMF / Pulse / C. Block (call blocking) Default KX-TD816BX, KX-TD1232(D)BX/ML, KX-TDN1232: All outside lines –...
  • Page 174 2.5 Outside Line Programming Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all lines to one selection, press the key in step 3.

  • Page 175: Pulse Speed Selection

    10 pps (low) and 20 pps (high). This programme sets the pulse speed for each outside line set to pulse or call blocking mode. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • 10 pps / 20 pps Default All outside lines –...
  • Page 176 2.5 Outside Line Programming • Programme [990] System Additional Information, Area 02 - bit 7, and bits 12 and 11 are used to select a pulse break ratio and inter-digit pause, if needed. Features Guide References Dial Type Selection General Programming...

  • Page 177: Dtmf Time

    Mode Selection can have two settings. This programme sets the duration of the DTMF signals sent to an outside line to DTMF mode. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Time (milliseconds): 80 / 160 Default All outside lines –...
  • Page 178 2.5 Outside Line Programming Features Guide References Dial Type Selection General Programming...

  • Page 179: Cpc Signal Detection Incoming Set

    Signal is detected. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Time (milliseconds): Disable (no detection) / 100 / 200 / 300 / 400 / 500 / 600 Default All outside lines –...
  • Page 180 2.5 Outside Line Programming • Programme [415] CPC Signal Detection Outgoing Set is used to programme CPC Signal Detection for outgoing outside calls. Features Guide References Calling Party Control (CPC) Signal Detection Direct Inward System Access (DISA) General Programming...

  • Page 181: Caller Id Assignment

    Enables the Caller ID feature for the outside lines to which a Caller ID Service is offered by a Central Office by contract. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Enable / Disable Default All outside lines –...
  • Page 182 2.5 Outside Line Programming Features Guide References Caller ID General Programming...

  • Page 183: Dil 1:1 Extension - Day / Night

    These programmes specify the extension number for day or night mode. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Extension number: 2 through 4 digits / Disable (no DIL 1:1) Default All outside lines –...
  • Page 184 2.5 Outside Line Programming • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01. • If an outside line is also programmed for DIL 1:N in programmes [603-604] DIL 1:N Extension and Delayed Ringing –...

  • Page 185: Intercept Extension - Day / Night

    2.5 Outside Line Programming [409-410] Intercept Extension – Day / Night Description Intercept Routing provides an automatic re-direction of calls which cannot or have not been answered (IRNA: Intercept Routing – No Answer). These programmes set the destination in both day and night modes for each outside line group. Selection •...
  • Page 186 2.5 Outside Line Programming Voice Mail extension numbers – [118] Voice Mail Extension Number Set Phantom extension numbers – [124] Phantom Extension Number Set Floating numbers – [813] Floating Number Assignment Features Guide References Intercept Routing General Programming...

  • Page 187: Host Pbx Access Codes

    2.5 Outside Line Programming [411] Host PBX Access Codes Description Assigns Host PBX access codes. If the system is installed behind a host PBX, an access code is required to make an outside call. Up to four codes can be stored for an outside line group assigned to the line.
  • Page 188 2.5 Outside Line Programming • There is a maximum of four access codes per outside line group. Each code has one or two digits, consisting of 0 through 9, and . • If conflicting access codes (such as 8 and 81) are stored for the same outside line group, the 1-digit code (8) only will be in effect.

  • Page 189: Pause Time

    2.5 Outside Line Programming [412] Pause Time Description Assigns the length of the pause time. The programmed pause time is automatically inserted after a line access number or a host PBX access code programmed in [411] Host PBX Access Codes or manually inserted if the PAUSE button is pressed by the user. Selection •...

  • Page 190: Flash Time

    2.5 Outside Line Programming [413] Flash Time Description Assigns the length of the flash time. If your system is installed behind a host PBX, External Feature Access (EFA) is necessary to obtain their services. To enable it, select a required hooking signal sending time for the outside line group.
  • Page 191 2.5 Outside Line Programming • Programme [401] Outside Line Group Assignment is used to assign each outside line to an outside line group. Features Guide References External Feature Access Flash General Programming...

  • Page 192: Disconnect Time

    2.5 Outside Line Programming [414] Disconnect Time Description Determines the amount of time between successive accesses to the same outside line. Selection • Outside line group (TRG) number: 1 through 8, ( =all outside line groups) • Time (seconds): 1.5 / 4.0 Default All outside line groups –...

  • Page 193: Cpc Signal Detection Outgoing Set

    [405] CPC Signal Detection Incoming Set when the CPC Signal is detected. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Enable (detection) / Disable (no detection)
  • Page 194 2.5 Outside Line Programming • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to one selection, press the key in step 3.

  • Page 195: Reverse Circuit Assignment

    This programme is only available for the following models: KX-TD816BX/HK, KX- TD1232DBX/ML, TDN1232. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Regular (no detection) / Reverse (detection)

  • Page 196: Outside Line Name Assignment

    If Caller ID is assigned, each extension can select either the initial display, Caller ID or outside line name, by Station Programming. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 54, ( =all outside lines) • Name: 10 characters (max.) Default All outside lines –...
  • Page 197 2.5 Outside Line Programming • Outside lines 25 through 54 become available when the KX-TD290 or KX-TD188 expansion unit is installed in the KX-TD1232. • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01.

  • Page 198: Did / Tie Format Number Assignment

    2.5 Outside Line Programming [430] DID / TIE Format Number Assignment Description Assigns a Direct Inward Dialling (DID) and TIE format number to each outside line group. Selection • Outside line group (TRG) number: 1 through 8, ( =all outside line groups) •...

  • Page 199: Did / Tie Incoming Assignment

    2.5 Outside Line Programming [431] DID / TIE Incoming Assignment Description Assigns a DID / TIE incoming method, immediate or wink, to each DID / TIE format according to your central office service. Immediate: Incoming DID and TIE calls can be received right after the receiving signal arrives.
  • Page 200 2.5 Outside Line Programming E1 Line Service TIE Line Service General Programming...

  • Page 201: Did / Tie Outgoing Assignment

    2.5 Outside Line Programming [432] DID / TIE Outgoing Assignment Description Assigns a DID and TIE outgoing method, immediate or wink, to each DID / TIE format according to your central office service. Immediate: Outgoing DID and TIE numbers can be transmitted right after seizing the outside line.
  • Page 202 2.5 Outside Line Programming Features Guide References Direct Inward Dialling (DID) E1 Line Service TIE Line Service General Programming...

  • Page 203: Did / Tie Subscriber Number Removed Digit

    2.5 Outside Line Programming [433] DID / TIE Subscriber Number Removed Digit Description Assigns the removed digits of received a DID and TIE subscriber number for each DID / TIE format. In this case, digits are removed from the beginning of the received digits. Selection •...

  • Page 204: Did / Tie Added Number

    2.5 Outside Line Programming [434] DID / TIE Added Number Description Assigns the added number to the DID and TIE subscriber number which is determined in programme [433] DID / TIE Subscriber Number Removed Digit. This makes the final number which serves as the extension number. Note that digits are inserted at the beginning of the number.

  • Page 205: Did / Tie Wink Time Out Assignment

    2.5 Outside Line Programming [435] DID / TIE Wink Time Out Assignment Description The DID / TIE outgoing method can be set to the wink mode in programme [432] DID / TIE Outgoing Assignment. This programme sets the time the system waits for the confirmation wink signal after an outside line is seized according to your central office service.
  • Page 206 2.5 Outside Line Programming E1 Line Service TIE Line Service General Programming...

  • Page 207: Outside-To-Tie Transfer

    2.5 Outside Line Programming [436] Outside-to-TIE Transfer Description Enables or disables transferring an incoming outside call to the TIE line on an outside line group basis. This restriction applies to the following: 1) A TIE call using DISA 2) Call Forwarding to a TIE line 3) Call Transfer to a TIE line.

  • Page 208: Tie-To-Outside Transfer

    2.5 Outside Line Programming [437] TIE-to-Outside Transfer Description Enables or disables transferring TIE calls to an outside line on an outside line group basis. This restriction applies to the following: 1) An outside call through another PBX 2) Call Forwarding to an outside line 3) Call Transfer to an outside line.

  • Page 209: Tie-To-Tie Transfer

    2.5 Outside Line Programming [438] TIE-to-TIE Transfer Description Enables or disables transferring TIE calls to a TIE line on an outside line group basis. This restriction applies to the following: 1) A TIE call through another PBX 2) Call Forwarding to a TIE line 3) Call Transfer to a TIE line.

  • Page 210: Tie Security Type

    2.5 Outside Line Programming [439] TIE Security Type Description Assigns the security mode for TIE calls. There are two modes, Non Security and Trunk Security (Outside line security). Non Security mode allows the caller to access an outside line without dialling a TIE user code. Trunk Security mode requires the caller to enter a TIE User Code assigned in programme [017] DISA / TIE User Codes before making a TIE call.

  • Page 211: Line Hunting Sequence

    2.5 Outside Line Programming [440] Line Hunting Sequence Description Assigns the hunting sequence of idle lines, seizing from the smallest to the largest line number or vice versa in an outside line group, on an outside line group basis. Selection •...

  • Page 212: Voice Path Type

    Assigns the voice path type on an outside line basis. Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) • 2 wire / 4 wire Default All outside lines –...

  • Page 213: Voice Level (Transmit)

    "4 wire". Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) • -6 db / -3 db / 0 db / +3 db Default All outside lines –...

  • Page 214: Voice Level (Receive)

    "4 wire". Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) • -6 db / -3 db / 0 db / +3 db Default All outside lines –...

  • Page 215: Tie Receive Dial

    DIL 1:1 or DIL 1:N. Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) •...

  • Page 216: Did Forward Timer (For Mfc-R2)

    2.5 Outside Line Programming [445] DID Forward Timer (for MFC-R2) Description Assigns the length of waiting time of the incoming Direct Inward Dialling (DID) call forward signal from your central office. Selection • DID format number: 1 through 8, ( =all DID formats) •...

  • Page 217: Did Backward Timer (For Mfc-R2)

    2.5 Outside Line Programming [446] DID Backward Timer (for MFC-R2) Description Assigns the length of waiting time of the outgoing outside call backward signal from your central office. Selection • DID format number: 1 through 8, ( =all DID formats) •...

  • Page 218: Did Disappearance Timer (For Mfc-R2)

    2.5 Outside Line Programming [447] DID Disappearance Timer (for MFC-R2) Description Assigns the length of waiting time of the stop signal from your central office. Selection • DID format number: 1 through 8, ( =all DID formats) • Time (seconds): 1 through 30 Default All DID formats –...

  • Page 219: Did First Dial Start Time (For Mfc-R2)

    2.5 Outside Line Programming [448] DID First Dial Start Time (for MFC-R2) Description Assigns the number of milliseconds the system waits before dialling a Direct Inward Dialling (DID) number after an outside line is seized. Selection • DID format number: 1 through 8, ( =all DID / TIE formats) •...

  • Page 220: Did Forward Group-I Signal Code (For Mfc-R2)

    2.5 Outside Line Programming [449] DID Forward Group-I Signal Code (for MFC-R2) Description Assigns a Direct Inward Dialling (DID) call forward group-I signal code according to your central office service. Selection • Code number: 01 through 15 • Not Use / Dial 1 / Dial 2 / Dial 3 / Dial 4 / Dial 5 / Dial 6 / Dial 7 / Dial 8 / Dial 9 / Dial 0 Default Code 01=Dial 1;...

  • Page 221: Did Forward Group-Ii Signal Code (For Mfc-R2)

    2.5 Outside Line Programming [450] DID Forward Group-II Signal Code (for MFC-R2) Description Assigns a Direct Inward Dialling (DID) call backward group-II signal code according to your central office service. Selection • Code number: 01 through 15 • Not Use / Subscriber / Operator / Collect (collect call) Default Code 01=Not Use;...

  • Page 222: Did Backward Group-A Signal Code (For Mfc-R2)

    2.5 Outside Line Programming [451] DID Backward Group-A Signal Code (for MFC-R2) Description Assigns a Direct Inward Dialling (DID) call backward group-A signal code according to your central office service. Selection • Code number: 01 through 15 • Not Use / Next Digit / Complete / Congestion Default Code 01=Next Digit;...

  • Page 223: Did Backward Group-B Signal Code (For Mfc-R2)

    2.5 Outside Line Programming [452] DID Backward Group-B Signal Code (for MFC-R2) Description Assigns a Direct Inward Dialling (DID) call backward group-B signal code according to your central office service. Selection • Code number: 01 through 15 • Not Use / Idle / Busy / Congestion / Unallocation Default Code 01=Idle;...

  • Page 224: Dil 1:1 - Lunch / Break Group

    Description Assigns a lunch / break group to each Direct In Lines (DIL) 1:1 destination. Selection • Outside (CO) line number: KX-TD816 – 01 through 08 KX-TD1232 – 01 through 24 • Group number: 1 through 8 Default All outside lines – Blank...
  • Page 225 2.5 Outside Line Programming Press NEXT. Display: CO Line NO? Enter an outside line number. To enter outside line number 01, you can also press NEXT. Display example: CO01: Enter a group number. To change the current entry, press CLEAR and the new number. Display example: CO01:1 Press STORE.

  • Page 226: Cos Programming

    2.6 COS Programming 2.6 COS Programming [500-501] Toll Restriction Level – Day / Night Description Each extension must be assigned a Class of Service (COS). These programmes set the toll restriction value for each COS in day or night mode. Selection •...
  • Page 227 2.6 COS Programming Features Guide References Day / Night Service Toll Restriction General Programming...

  • Page 228: Extension-To-Outside Line Call Duration Limit

    2.6 COS Programming [502] Extension-to-Outside Line Call Duration Limit Description Allows you to restrict the duration of outside calls on a Class of Service (COS) basis. Selection • COS number: 1 through 8, ( =all COS) • Disable (no limit) / Enable (limit) Default All COS –...
  • Page 229 2.6 COS Programming Features Guide References Call Forwarding Call Transfer Conference General Programming...

  • Page 230: Call Transfer To Outside Line

    2.6 COS Programming [503] Call Transfer to Outside Line Description Determines which Classes of Services (COS) are allowed to perform the Call Transfer to Outside Line function. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS –...

  • Page 231: Call Forwarding To Outside Line

    2.6 COS Programming [504] Call Forwarding to Outside Line Description Determines which Classes of Services (COS) are allowed to perform the Call Forwarding to Outside Line function. Selection • COS number: 1 through 8, ( =all COS) • Disable / Enable Default All COS –...

  • Page 232: Executive Busy Override

    2.6 COS Programming [505] Executive Busy Override Description Determines which Classes of Services (COS) are allowed to perform Executive Busy Override. Executive Busy Override allows the user to interrupt an established call. Selection • COS number: 1 through 8, ( =all COS) •...

  • Page 233: Executive Busy Override Deny

    2.6 COS Programming [506] Executive Busy Override Deny Description Determines which Classes of Services (COS) are allowed to deny Executive Busy Override. Executive Busy Override Deny allows the user to prevent Executive Busy Override from being executed by another extension user. Selection •...

  • Page 234: Do Not Disturb Override

    2.6 COS Programming [507] Do Not Disturb Override Description Determines which Classes of Services (COS) are allowed to perform Do Not Disturb (DND) Override. Selection • COS number: 1 through 8, ( =all COS) • Disable / Enable Default All COS – Disable Programming Enter 507.

  • Page 235: Account Code Entry Mode

    2.6 COS Programming [508] Account Code Entry Mode Description Determines the account code mode to be used by each Class of Service (COS). Option mode: The user can enter any account code, if needed. Verified – All Calls mode: The user must always enter a pre-assigned account code to make an outside call. Verified –...
  • Page 236 2.6 COS Programming • Programme [105] Account Codes is used to define the Account Codes for the Verified modes. Features Guide References Account Code Entry Toll Restriction General Programming...

  • Page 237: Off-Hook Call Announcement (Ohca)

    2.6 COS Programming [509] Off-Hook Call Announcement (OHCA) Description Determines which Class of Service (COS) are allowed to perform the Off-Hook Call Announcement (OHCA) and Whisper OHCA function. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS –...

  • Page 238: Night Service Access

    2.6 COS Programming [510] Night Service Access Description Enables or disables switching the Day / Night service on a Class of Service (COS) basis. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS – Disable Programming Enter 510.

  • Page 239: Pt Programming Level

    2.6 COS Programming [511] PT Programming Level Description Determines the Station Programming level on a Class of Service (COS) basis. There are two levels as follows. Level 1: enables all Station Programming. Level 2: disables CO button programming in Station Programming. Selection •...
  • Page 240 2.6 COS Programming Features Guide References Station Programming General Programming...

  • Page 241: Extension Programming

    (DPT). This programme assigns which jacks are XDP. The SLT and DPT of the programmed jack work as independent extensions. Selection • Jack number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all jacks) • Disable / Enable Default All jacks –...
  • Page 242 2.7 Extension Programming • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for Jack 01. • Immediately after changing your assignment, the changed setting may not work for a maximum of eight seconds.

  • Page 243: Class Of Service

    Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) • COS number: 1 through 8 Default All jacks-1/2 –...
  • Page 244 2.7 Extension Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • To assign all jacks to one COS, press the key in step 3. In this case, the display shows the contents programmed for Jack 01.

  • Page 245: Extension Group Assignment

    Pickup, Station Hunting, and Paging – Group. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) • Extension group number: 1 through 8 Default All jacks-1/2 –...
  • Page 246 2.7 Extension Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • To assign all jacks to one extension group, press the key in step 3. In this case, the display shows the contents programmed for Jack 01.

  • Page 247: Dil 1:N Extension And Delayed Ringing - Day / Night

    Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) • Outside line (CO) number: KX-TD816 –...
  • Page 248 2.7 Extension Programming Press END. Conditions • An extension can be assigned as the destination of as many outside lines as required. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable.

  • Page 249: Outgoing Permitted Outside Line Assignment - Day / Night

    The extension users can make outgoing outside calls using the assigned outside lines. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) •...
  • Page 250 2.7 Extension Programming Conditions • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.

  • Page 251: Doorphone Ringing Assignment - Day / Night

    Programmed extensions are also allowed to open the door. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) •...
  • Page 252 • Two doorphones can be installed. For the KX-TD1232, doorphones 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available. • You can enter up to two (for KX-TD816) or four (for KX-TD1232) doorphone numbers for each extension.

  • Page 253: Voice Mail Access Codes

    Information, Area 02 - bit 8 is set to "free". Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2) KX-TD1232 – 01 through 64 (-1 / -2) (-1 = first part, -2 = second part) • Mailbox number: 16 digits (max.) Default All jacks –...
  • Page 254 2.7 Extension Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • The system supports a maximum of eight jacks (16 jacks during System Connection for KX-TD1232) for connection to a Voice Processing System as the Voice Mail or Automated Attendant ports.

  • Page 255: Live Call Screening Recording Mode Assignment

    Assigns whether to close the mailbox or keep recording the conversation after a call is intercepted. This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP100). Selection •...
  • Page 256 2.7 Extension Programming • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for jack 01. Features Guide References Voice Mail Integration for Digital Proprietary Telephones General Programming...

  • Page 257: Extension Call Forwarding - No Answer Time

    The number of rings before the call is forwarded is programmable for each extension. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), (-1 = first part, -2 = second part, =all jacks) •...
  • Page 258 2.7 Extension Programming Features Guide References Call Forwarding General Programming...

  • Page 259: Lunch / Break Group Assignment

    2.7 Extension Programming [620] Lunch / Break Group Assignment Description Assigns extensions for a lunch / break group. A lunch / break group can be assigned to up to 8 extensions (PT / SLT). Selection • Group number: 1 through 8 •...

  • Page 260: Cordless Pt Extension Port

    A voice calling: using a voice calling. (Only Ring-calling can be used.) d) Paging: using the paging features. Selection • Jack number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all jacks) • Yes (prevent) / No (allow) Default All jacks –...
  • Page 261 2.7 Extension Programming Conditions • If "Yes" is selected for a jack for wired proprietary telephone, the speakerphone functions written in the description do not work. Connect a cordless proprietary telephone if "Yes" is selected. Features Guide References None General Programming...

  • Page 262: Resource Programming

    2.8 Resource Programming 2.8 Resource Programming [800] SMDR Incoming / Outgoing Call Log Printout Description Used to determine which calls will produce a Station Message Detail Recording (SMDR) printout. Selection • Outgoing calls: All (all calls) / Toll (toll calls only) / Off (no printing) •...
  • Page 263 2.8 Resource Programming Features Guide References Station Message Detail Recording (SMDR) General Programming...

  • Page 264: Smdr Format

    2.8 Resource Programming [801] SMDR Format Description Used to match the SMDR output to the paper size being used in the printer. Page length determines the number of lines per page. Skip perforation determines the number of lines to be skipped at the end of every page.

  • Page 265: System Data Printout

    2.8 Resource Programming [802] System Data Printout Description Starts or stops printing the system data. All or a specific range of the current system- programmed data is printed out. The ranges are as follows: Manager: Manager Programming [0XX] System: System Programming [1XX] Timers: Timer Programming [2XX] TRS / ARS: TRS / ARS Programming [3XX] Outside line: Outside Line Programming [4XX]...
  • Page 266 2.8 Resource Programming Conditions • It is necessary to connect a printer to the Serial Interface (RS-232C) port provided on the system. • You may stop printing by pressing the END button while records are being printed out. • You cannot restart the printout while records are being output. Features Guide References Station Message Detail Recording (SMDR) General Programming...

  • Page 267: Music Source Use

    Press END. Conditions • The music source is a user-supplied item. For KX-TD816, one music source can be installed, for KX-TD1232, two music sources can be installed per system. Music sources 1 and 2 are connected to the Master System, 3 and 4 are to the Slave, if available. Any music source can be used by either system.
  • Page 268 2.8 Resource Programming • To disable music, press CLEAR in steps 3 and 6. • Programme [804] External Pager BGM is used to enable / disable BGM for each external pager. Features Guide References Background Music (BGM) General Programming...

  • Page 269: External Pager Bgm

    Press END. Conditions • In the case of KX-TD816, please skip steps 6 and 7. • The external pager is a user-supplied item. One external pager can be installed for KX- TD816, and two external pagers can be installed for KX-TD1232.
  • Page 270 2.8 Resource Programming Features Guide References Background Music (BGM) General Programming...

  • Page 271: External Pager Confirmation Tone

    Press END. Conditions The external pager is a user-supplied item. For KX-TD816, one external pager can be installed, for KX-TD1232, two external pagers can be installed per system. External pagers 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available.

  • Page 272: Serial Interface (Rs-232C) Parameters

    2.8 Resource Programming [806-807] Serial Interface (RS-232C) Parameters Description Assigns the communication parameters for the Serial Interface (RS-232C) for Port 1 (for KX- TD816 and Master System of KX-TD1232) or Port 2 (for Slave System of KX-TD1232). New line code: Select the code for your printer or personal computer.
  • Page 273 2.8 Resource Programming Display example: Baud Rate:9600 Keep pressing SELECT until the desired selection is displayed. Press STORE. Press NEXT to programme word length. Display example: Word Lengt:8bits Keep pressing SELECT until the desired selection is displayed. Press STORE. Press NEXT to programme parity bit. Display example: Parity:Mark Keep pressing SELECT until the desired selection is displayed.

  • Page 274: Disa Security Type

    2.8 Resource Programming [809] DISA Security Type Description Assigns the security mode for outside calls attempted by the DISA (Direct Inward System Access) caller. There are three modes as follows. Non Security mode: allows the caller to access an outside line without dialling a DISA user code.

  • Page 275: Disa Tone Detection

    2.8 Resource Programming [810] DISA Tone Detection Description Enables or disables Tone Detection for outside-to-outside line calls via the Direct Inward System Access (DISA) feature. Enabling tone detection allows the system to detect the end of the call. Selection Enable / Disable Default Enable Programming...

  • Page 276: Disa Dtmf Repeat

    2.8 Resource Programming [812] DISA DTMF Repeat Description Selects whether the system transmits DTMF (Dual Tone Multi-Frequency) signals directly to the central office (CO) or if the system repeats the DTMF signals to CO in order to adjust gain. This can be done for an outside-to-outside line call via the Direct Inward System Access (DISA) feature during dialling and / or during an established call.

  • Page 277: Floating Number Assignment

    2.8 Resource Programming [813] Floating Number Assignment Description Assigns the floating numbers for External Pagers, DISA (Direct Inward System Access) messages, modem and extension groups. These numbers can be used in the same way extension numbers are used for station access. Selection •...
  • Page 278 To avoid making an invalid entry, check the other extension numbers. The default of each extension number is as follows: [003] Extension Number Set KX-TD816 – 101 through 116, 201 through 216 KX-TD1232 – 101 through 164, 201 through 264 [012] ISDN Extension Number Set Not stored.

  • Page 279: Modem Standard

    2.8 Resource Programming [814] Modem Standard Description Assigns the modem standard. There are two standards available – BELL and CCITT. Selection BELL / CCITT Default CCITT Programming Enter 814. Display: 814 MODEM TYPE Press NEXT. Display example: MODEM:CCITT Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 280: Disa Built-In Automated Attendant Number

    2.8 Resource Programming [815] DISA Built-in Automated Attendant Number Description Assigns the DISA (Direct Inward System Access) built-in automated attendant (AA) number. The extension number and the floating number can be assigned as a one digit number and used as a DISA built-in automated attendant number. Selection •...

  • Page 281: Smdr Output Mode

    2.8 Resource Programming [816] SMDR Output Mode Description Assigns the SMDR output mode. There are two standards available – Regular and Charge. Selection Regular / Charge Default Regular Programming Enter 816. Display: 816 SMDR MODE Press NEXT. Display example: SMDR:Regular Keep pressing SELECT until the desired selection is displayed.

  • Page 282: Kx-Td197 / Kx-Td198 Baud Rate Set

    BELL / V.34-9600 / V.34-14400 / V.34-19200 / V.34-28800 / V.34-33600 Default V.34-33600 Programming Enter 817. Display (for KX-TD1232): 817 TD197 TYPE Display (for KX-TD816): 817 TD198 TYPE Press NEXT. Display example: Mast.:V.34-33600 Keep pressing SELECT until the desired selection is displayed. Press NEXT. Display example: Slave:V.34-33600 Keep pressing SELECT until the desired selection is displayed.

  • Page 283: Isdn Programming

    Section 3 ISDN Programming ISDN Programming...

  • Page 284: Manager Programming

    Description Assigns an extension number to each port which is connected to the ISDN S0 unit. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Extension Number: 2 or 3 digits Default All ports – Not stored Programming Enter 012.
  • Page 285 Not stored. [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 198, 291 through 294, 296 through 299 • Programme [013] ISDN Extension Name Set is used to give names to the extension numbers.

  • Page 286: Isdn Extension Name Set

    Assigns names to the ISDN extension numbers programmed in programme [012] ISDN Extension Number Set. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Name: 10 characters (max.) Default All ports – Not stored Programming Enter 013.
  • Page 287 3.1 Manager Programming Features Guide References Integrated Services Digital Network (ISDN) Extension ISDN Programming...

  • Page 288: Budget Management For Isdn Extension

    [018] Budget Management for ISDN Extension Description Assigns the charge limitation of a call on the ISDN extension port basis. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Charge limitation (Charge): 0 through 99999999 Default All ports –...
  • Page 289 3.1 Manager Programming Features Guide References Budget Management Charge Fee Reference ISDN Programming...

  • Page 290: System Programming

    / MD (4 DID-MFC) / EM (4 E&M) / EL (1 E1) / E1 (8 EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) (Master system only: PR, EL) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
  • Page 291 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / DID / E&M) unit can be installed.
  • Page 292 3.2 System Programming Features Guide References None ISDN Programming...

  • Page 293: Isdn Network Type Assignment

    3.2 System Programming [112] ISDN Network Type Assignment Description Assigns the type of ISDN network. Selection ISDN network mode: 000 through 255 Default KX-TD816HK/KX-TD1232HK: Mode 39 Others: Mode 51 Programming Enter 112. Display: 112 SWITCH TYPE Press NEXT. Display example: Mode 51 Enter an ISDN network mode.

  • Page 294: Ddi Number / Phantom Extension Number Conversion

    3.2 System Programming [140] DDI Number / Phantom Extension Number Conversion Description Used to convert a Direct Dialling In (DDI) number to a phantom extension number in order to send an incoming DDI call to a specific extension. Selection • Location number: 000 through 128 •...

  • Page 295: Isdn Data Assignment

    3.2 System Programming [149] ISDN Data Assignment Description Assigns the following ISDN data. Selection (1) ADPCM Type: A-Law / M-Law (2) Status Message: Send / Stop (3) Status Receiving Mode: Disc (disconnect) / Ignr (ignore) (4) Number Type: 0 (Unknown) / 1 (International Number) / 2 (National Number / 3 (Network Specific Number) / 4 (Subscriber Number) (5) Numbering Plan: 0 (Unknown) / 1 (ISDN/Telephone Numbering Plan) / 8 (National Standard Numbering...
  • Page 296 3.2 System Programming (3) Status Receiving Mode: Disc (4) Numbering Type: 0 (Unknown) (5) Numbering Plan: 1 (ISDN/Telephone Numbering Plan) (6) T200 Extension Timer: 1.0 s (7) T203 Extension Timer: 10.0 s (8) T302 Extension Timer: 15.0 s (9) T303 Extension Timer: 4.0 s (10) T304 Extension Timer: 20.0 s (11) T305 Extension Timer: 30.0 s (12) T306 Extension Timer: 30.0 s...
  • Page 297 3.2 System Programming Conditions • After this assignment, you should reset the system so that this assignment is activated. Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 298: Did Transfer Table For Ddi Call

    3.2 System Programming [154] DID Transfer Table for DDI Call Description Selects whether the DID Transfer Table is used for DDI calls. Selection Use / No Use Default No Use Programming Enter 154. Display: 154 DDI TRANS Press NEXT. Display example: No Use Keep pressing SELECT until the desired selection is displayed.

  • Page 299: Isdn Line Programming

    Identification Presentation) feature offered by the ISDN network service. Your E1 line telephone number is sent to the called party (Outgoing ANI). Selection • Outside line (CO) number: KX-TD816 – 01 through 08 KX-TD1232 – 01 through 54 • Telephone number: 16 digits (max.) Default All outside lines –...
  • Page 300 3.3 ISDN Line Programming Conditions • Each number has a maximum of 16 digits, consisting of 0 through 9. • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. •...

  • Page 301: Isdn Outgoing Clir Service Assignment

    If disabled, the subscriber's number of your system is informed to the called party. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Enable / Disable Default All outside lines –...
  • Page 302 3.3 ISDN Line Programming Features Guide References Calling Line Identification Restriction (CLIR) ISDN Programming...

  • Page 303: Isdn Ring Service Assignment

    [407-408] DIL 1:1 Extension – Day / Night and [603-604] DIL 1:N Extension and Delayed Ringing – Day / Night. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • ISDN / Regular Default All outside lines –...
  • Page 304 3.3 ISDN Line Programming • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01. • Lunch / break mode will only work when "Regular" is assigned in this programme. Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 305: Ddi Removed Digit / Added Number Assignment

    Assigns the removed digits and added number to a subscriber's number, and a DDI number sent from the network. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Removed digits: 0 through 16 (0=no deleting) •...
  • Page 306 3.3 ISDN Line Programming Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • Each added number has a maximum of four digits, consisting of 0 through 9. •...

  • Page 307: Isdn Port Type

    Press END. Conditions • For the KX-TD816, port numbers 05 and 06 are fixed as "Extension". • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available.
  • Page 308 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 309: Isdn Layer 1 Active Mode

    KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Permanent / Call Default KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent Programming Enter 424. Display: 424 LAYER1 MODE Press NEXT.
  • Page 310 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 311: Isdn Configuration

    KX-TD1232 – 01 through 12, ( =all ports) • Point (point to point) / Multipoint (point to multipoint) Default KX-TD816: Ports 05 and 06 – Multipoint; Other ports – Point KX-TD1232: All ports – Point Programming Enter 425. Display: 425 ACCESS MODE Press NEXT.
  • Page 312 3.3 ISDN Line Programming • After this assignment, you should reset the system to make this assignment is effective. Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 313: Isdn Data Link Mode

    KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Permanent / Call Default KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent Programming Enter 426. Display: 426 LAYER2 MODE Press NEXT.
  • Page 314 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 315: Isdn Tei Mode

    KX-TD1232 – 01 through 12, ( =all ports) • Fix 0 through 63 / Automatic Default KX-TD816: Port 05 and 06 – Automatic; Other ports – Fix 0 KX-TD1232: All ports – Fix 0 Programming Enter 427. Display: 427 TEI ASSIGN Press NEXT.
  • Page 316 3.3 ISDN Line Programming • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01. • After this assignment, you should reset the system to make this assignment effective. Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 317: Isdn Extension Multiple Subscriber Number

    Selects whether the Multiple Subscriber Numbers (MSN) are allocated to each terminal equipment (e.g. ISDN telephone) on the ISDN S0 bus or not on an ISDN port basis. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Enable / Disable (no number) Default All ports –...
  • Page 318 3.3 ISDN Line Programming Features Guide References Multiple Subscriber Numbers (MSN) Ringing Service ISDN Programming...

  • Page 319: Isdn Extension Progress Tone

    Description Enables or disables to send the progress tone to ISDN extension on ISDN port basis. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Enable / Disable (no tone) Default All ports –...
  • Page 320 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) Extension ISDN Programming...

  • Page 321: Msn Assignment

    Description Assigns a maximum of ten Multiple Subscriber Numbers (MSN) on an ISDN port basis. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Location number: 01 through 10 • MSN: 20 digits (max.) Default All ports –...
  • Page 322 3.3 ISDN Line Programming • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • This programme becomes available when "Multipoint" is selected in programme [425] ISDN Configuration. Features Guide References Integrated Services Digital Network (ISDN) Multiple Subscriber Numbers (MSN) Ringing Service...

  • Page 323: Extension Ringing Assignment - Day / Night For Isdn

    Determines which extension receives a call on a MSN basis of the ISDN port in both the day and night modes. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Location number: 01 through 10 • Extension number:...
  • Page 324 3.3 ISDN Line Programming Conditions • Each extension number can be 2 through 4 digits, consisting of 0 through 9. • These programmes become available when "Multipoint" is selected in programme [425] ISDN Configuration. • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available.

  • Page 325: Pri Configuration

    3.3 ISDN Line Programming [460] PRI Configuration Description Assigns the number of B channels which are actually used out of the 30 PRI line channels. The CRC4 mode can be also assigned. This programme is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290).

  • Page 326: Pri / E1 Reference Co

    3.3 ISDN Line Programming [721] PRI / E1 Reference CO Description Assigns which outside line number system data each PRI line or E1 line uses. After assigning this programme, the following programme data will become available for PRI outside lines 25 through 54. •...
  • Page 327 3.3 ISDN Line Programming Conditions • To assign all outside lines to the same selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 25. Features Guide References E1 Line Service Integrated Services Digital Network (ISDN) ISDN Programming...

  • Page 328: Extension Programming

    DDI call at a specific extension. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2) KX-TD1232 – 01 through 64 (-1 / -2) (-1 = first part, -2 = second part) • DDI Number: 6 digits (max.) Default All jacks –...
  • Page 329 3.4 Extension Programming • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • For an explanation on jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.

  • Page 330: Ddi Number / Floating Number Conversion

    3.4 Extension Programming [612] DDI Number / Floating Number Conversion Description Used to convert a Direct Dialling In (DDI) number to an floating number in order to place an incoming DDI call at a specific floating station. Selection • Floating Station: Operator / Pager 1 / Pager 2 / Pager 3 / Pager 4 / DISA 1 / DISA 2 / MODEM / EXT Group 1 / EXT Group 2 / EXT Group 3 / EXT Group 4 / EXT Group 5 / EXT Group 6 / EXT Group 7 / EXT Group 8...

  • Page 331: Isdn Class Of Service

    Programmes a Class of Service (COS) number for each ISDN extension port. The COS determines the call handling abilities of each port. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • COS number: 1 through 8 Default All ports –...
  • Page 332 3.4 Extension Programming • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01. Features Guide References Class of Service (COS) ISDN Programming...

  • Page 333: Outgoing Permitted Outside Line Assignment - Day / Night For Isdn Extension

    The extension users can make outgoing outside calls using the assigned outside lines. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 –...
  • Page 334 3.4 Extension Programming Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01.

  • Page 335: Ddi Number / Isdn Extension Number Conversion

    Used to convert a Direct Dialling In (DDI) number to an ISDN extension number in order to place an incoming DDI call at a specific extension. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • DDI Number: 6 digits (max.) Default All ports –...
  • Page 336 3.4 Extension Programming Features Guide References Direct Dialling In (DDI) ISDN Programming...

  • Page 337: Clip / Colp Number Assignment For Extension

    None: Subscriber number + Optional number Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2) KX-TD1232 – 01 through 64 (-1 / -2) (-1 = first part, -2 = second part) • Types: DDI / Any number, 6 digits (max.) Default All jacks –...
  • Page 338 3.4 Extension Programming • To use this programme, "DDI conversion number" must be selected in programme [990] System Additional Information, Area 06 - bit 13. Features Guide References Calling / Connected Line Identification Presentation (CLIP / COLP) ISDN Programming...

  • Page 339: Clip / Colp Number Assignment For Isdn Extension

    DDI: Subscriber number + DDI number None: Subscriber number + Optional number Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Types: DDI / Any number, 6 digits (max.) Default All ports – DDI Programming Enter 618.
  • Page 340 3.4 Extension Programming Features Guide References Calling / Connected Line Identification Presentation (CLIP / COLP) ISDN Programming...

  • Page 341: E1 Programming

    Section 4 E1 Programming E1 Programming...

  • Page 342: System Programming

    / MD (4 DID-MFC) / EM (4 E&M) / EL (1 E1) / E1 (8 EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) (Master system only: PR, EL) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
  • Page 343 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / DID / E&M) unit can be installed.
  • Page 344 4.1 System Programming Features Guide References None E1 Programming...

  • Page 345: E1 Outside Line Programming

    Identification Presentation) feature offered by the ISDN network service. Your E1 line telephone number is sent to the called party (Outgoing ANI). Selection • Outside line (CO) number: KX-TD816 – 01 through 08 KX-TD1232 – 01 through 54 • Telephone number: 16 digits (max.) Default All outside lines –...
  • Page 346 4.2 E1 Outside Line Programming Conditions • Each number has a maximum of 16 digits, consisting of 0 through 9. • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. •...

  • Page 347: Extension Programming

    4.3 Extension Programming 4.3 Extension Programming [622] Extension ANI Number Description Assigns the identification number of the calling party to utilise the Automatic Number Identification (ANI) feature provided by the E1 line service. This programme is available for the KX-TD1232 only. Selection •...
  • Page 348 4.3 Extension Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for Jack 01.

  • Page 349: E1 Line Programming

    4.4 E1 Line Programming 4.4 E1 Line Programming [707] E1 Clock Mode Description Assigns a clock mode for the E1 line. This programme is available for the KX-TD1232 only. Selection External / Internal Default External Programming Enter 707. Display: 707 CLOCK MODE Press NEXT.

  • Page 350: E1 Tie Ringing Service

    4.4 E1 Line Programming [720] E1 TIE Ringing Service Description Sets a call receiving type for the E1 channels assigned to TIE. If "DIL" is selected, DIL 1:1 or DIL 1:N will perform. This programme is available for the KX-TD1232 only. Selection •...
  • Page 351 4.4 E1 Line Programming [721] PRI / E1 Reference CO Description Assigns which outside line number system data each PRI line or E1 line uses. After assigning this programme, the following programme data will become available for PRI outside lines 25 through 54. •...
  • Page 352 4.4 E1 Line Programming Conditions • To assign all outside lines to the same selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 25. Features Guide References E1 Line Service Integrated Services Digital Network (ISDN) E1 Programming...

  • Page 353: E1 Answer Wait Timer

    4.4 E1 Line Programming [722] E1 Answer Wait Timer Description Assigns an automatic disconnect timer to stop making a call on E1 line, if the called party does not answer. This programme is available for the KX-TD1232 only. Selection • Outside (CO) line number: 25 through 54, ( = all outside lines from 25 to 54) •...

  • Page 354: E1 Sending Tie Caller Id

    Repeat steps 4 through 6. Press END. Conditions • This feature is only available between Panasonic PBXs which support a Caller ID on the DTMF. • If a PBX code is assigned, "PBX code + extension number" will be sent. If not assigned, only the extension number will be sent.
  • Page 355 4.4 E1 Line Programming Features Guide References E1 Line Service TIE Line Service E1 Programming...

  • Page 356: E1 Channel Assignment

    4.4 E1 Line Programming [740] E1 Channel Assignment Description Assigns a channel type to each E1 channel. This programme is available for the KX-TD1232 only. Selection • E1 channel number: 01 through 30, ( =All E1 channels) • Channel type: DR2 / E&M-C / E&M-P / Disable Default All E1 channels –...

  • Page 357: E1 Dial Mode

    4.4 E1 Line Programming [741] E1 Dial Mode Description Assigns a dial type to each E1 channel. For DR2 channel, only the dial sending mode can be assigned in this programme. For dial receiving mode, the assignment in programme [745] E1 DR2 Receiver is activated. For the other channels, the assignment in this programme is used for both the dial sending and receiving mode.
  • Page 358 4.4 E1 Line Programming Features Guide References E1 Line Service E1 Programming...

  • Page 359: E1 Cpc (In)

    4.4 E1 Line Programming [742] E1 CPC (IN) Description Sets a CPC signal detection time to each E1 channel on receiving a call. This programme is available for the KX-TD1232 only. Selection • E1 channel number: 01 through 30, ( =All E1 channels) •...

  • Page 360: E1 Cpc (Out)

    4.4 E1 Line Programming [743] E1 CPC (OUT) Description Sets a CPC signal detection time to each E1 channel on making a call. This programme is available for the KX-TD1232 only. Selection • E1 channel number: 01 through 30, ( =All E1 channels) •...

  • Page 361: E1 Did Receive Digit

    4.4 E1 Line Programming [744] E1 DID Receive Digit Description Sets a maximum number of the received dial digits for each E1 channel assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection • E1 channel number: 01 through 30, ( =All E1 channels) •...

  • Page 362: E1 Dr2 Receiver

    4.4 E1 Line Programming [745] E1 DR2 Receiver Description Sets a dial receiving type to each E1 channel assigned to DR2. This programme is available for the KX-TD1232 only. Selection • E1 channel number: 01 through 30, ( =All E1 channels) •...

  • Page 363: E1 Line Coding

    4.4 E1 Line Programming [747] E1 Line Coding Description Sets a line coding for the E1 line. This programme is available for the KX-TD1232 only. Selection AMI / HDB3 Default HDB3 Programming Enter 747. Display: 747 LINE CODING Press NEXT. Display example: HDB3 Keep pressing SELECT until the desired selection is displayed.

  • Page 364: E1 Frame Sequence

    4.4 E1 Line Programming [748] E1 Frame Sequence Description Sets a frame format for the E1 line. This programme is available for the KX-TD1232 only. Selection PCM30 / PCM30-CRC Default PCM30 Programming Enter 748. Display: 748 FRAME SEQ Press NEXT. Display example: PCM30 Keep pressing SELECT until the desired selection is displayed.

  • Page 365: E1 Frame Option

    4.4 E1 Line Programming [749] E1 Frame Option Description Assigns a frame option for the E1 line. This programme is available for the KX-TD1232 only. Selection C=A, D=B / C=0, D=0 / C=1, D=0 / C=0, D=1 / C=1, D=1 Default C=0, D=1 Programming...

  • Page 366: E1 First Dial Timer (Dr2 / Tie)

    4.4 E1 Line Programming [750] E1 First Dial Timer (DR2 / TIE) Description Sets a timer to prevent the first dial being sent too early on the E1 channels assigned to DR2 and E&M. This programme is available for the KX-TD1232 only. Selection Time: 001 through 255 ( 32 milliseconds is the actual time)

  • Page 367: E1 %Break

    4.4 E1 Line Programming [751] E1 %Break Description Sets a "%Break" for the E1 line assigned Pulse. This programme is available for the KX-TD1232 only. Selection 60% / 67% Default Programming Enter 751. Display: 751 %BREAK Press NEXT. Display example: E1 %Break:60% Keep pressing SELECT until the desired selection is displayed.

  • Page 368: E1 Dial Click Tone

    4.4 E1 Line Programming [752] E1 Dial Click Tone Description Sets to send a dial click tone of the E1 line. This programme is available for the KX-TD1232 only. Selection Yes (to send) / No (not to send) Default Programming Enter 752.

  • Page 369: E1 Inter Digit Pause

    4.4 E1 Line Programming [753] E1 Inter Digit Pause Description Sets a time of the inter digit pause for the E1 line. This programme is available for the KX-TD1232 only. Selection Time (milliseconds): 630 / 830 / 1030 Default 830 ms Programming Enter 753.

  • Page 370: E1 Flash Detection

    4.4 E1 Line Programming [754] E1 Flash Detection Description Sets a flash detection time for the E1 line assigned to E&M-C. This programme is available for the KX-TD1232 only. Selection Time (milliseconds): 208-1016 / 80-1016 / 208-1544 / 80-1544 / Disable Default 208-1016 Programming...

  • Page 371: E1 Answer Decision Timer

    4.4 E1 Line Programming [755] E1 Answer Decision Timer Description Sets an answering detection time for the E1 line. This programme is available for the KX-TD1232 only. Selection Time: 001 through 255 ( 32 milliseconds is the actual time) Default Programming Enter 755.

  • Page 372: E1 Seizure Ack Wait Timer

    4.4 E1 Line Programming [756] E1 Seizure ACK Wait Timer Description Sets the waiting time to acknowledge the seizure of the E1 line assigned to DR2. This programme is available for the KX-TD1232 only. Selection Time: 01 through 20 ( 0.5 seconds is the actual time) Default Programming...

  • Page 373: E1 Pulse Type

    4.4 E1 Line Programming [757] E1 Pulse Type Description Sets a dialling pulse type for the E1 line. This programme is available for the KX-TD1232 only. Selection Type-A / Type-B / Type-C Default Type-A Programming Enter 757. Display: 757 PULSE TYPE Press NEXT.

  • Page 374: E1 Dr2 Signalling Type

    4.4 E1 Line Programming [758] E1 DR2 Signalling Type Description Sets a DR2 signalling type. Normal: CCITT Option-1: ANSI Option-2: CCITT + MFC-R2 (Group-C) Option-3: Dialling mode=ANSI, Receiving mode=CCITT This programme is available for the KX-TD1232 only. Selection Normal / Option-1 / Option-2 / Option-3 Default Normal Programming...

  • Page 375: E1 Inter Digit Timer

    4.4 E1 Line Programming [759] E1 Inter Digit Timer Description Sets a maximum time the system waits before answering a call on the E1 line assigned to DR2 of option 1 signalling. This programme is available for the KX-TD1232 only. Selection Time (seconds): 03 through 15 Default...

  • Page 376: E1 Bit Position For Dial Pulse

    4.4 E1 Line Programming [760] E1 Bit Position for Dial Pulse Description Sets a bit position for dial pulse on the E1 line assigned to DR2. This programme is available for the KX-TD1232 only. Selection A-bit / B-bit Default A-bit Programming Enter 760.

  • Page 377: E1 Bit Position For Clear Back

    4.4 E1 Line Programming [761] E1 Bit Position for Clear Back Description Sets a bit position for clear back on the E1 line assigned to DR2. This programme is available for the KX-TD1232 only. Selection A-bit / B-bit / AB-bit Default A-bit Programming...

  • Page 378: E1 E&M Signalling Type

    4.4 E1 Line Programming [762] E1 E&M Signalling Type Description Sets an E&M signalling type for the E1 line. Type-1: A-bit control, default setting=0 Type-2: A-bit control, default setting=1 Type-3: B-bit control, default setting=0 Type-4: B-bit control, default setting=1 This programme is available for the KX-TD1232 only. Selection Type-1 / Type-2 / Type-3 / Type-4 Default...

  • Page 379: E1 E&M Pulse Length (Seizure)

    4.4 E1 Line Programming [763] E1 E&M Pulse Length (Seizure) Description Sets a pulse length when seizing an E1 line assigned to E&M. This programme is available for the KX-TD1232 only. Selection Time (milliseconds): 150 / 600 Default 150 ms Programming Enter 763.

  • Page 380: E1 E&M Pulse Length (Answer)

    4.4 E1 Line Programming [764] E1 E&M Pulse Length (Answer) Description Sets a pulse length when answering an E1 line assigned to E&M. This programme is available for the KX-TD1232 only. Selection Time (millisecond): 150 / 600 Default 600 ms Programming Enter 764.

  • Page 381: E1 E&M Pulse Length (Clear)

    4.4 E1 Line Programming [765] E1 E&M Pulse Length (Clear) Description Sets a pulse length when clearing an E1 line assigned to E&M. This programme is available for the KX-TD1232 only. Selection Time (milliseconds): 150 / 600 Default 600 ms Programming Enter 765.

  • Page 382: E1 Meter Pulse Detection Mode

    4.4 E1 Line Programming [766] E1 Meter Pulse Detection Mode Description Sets the charge meter pulse detection mode for the E1 line assigned to DR2. This programme is available for the KX-TD1232 only. Selection No Detection / Outgoing Only / Both Calls Default No Detection Programming...

  • Page 383: E1 Meter Pulse Detection Bit Position

    4.4 E1 Line Programming [767] E1 Meter Pulse Detection Bit Position Description Sets a bit position for charge meter pulse detection on the E1 line assigned to DR2. This programme is available for the KX-TD1232 only. Selection A-bit / B-bit / C-bit / D-bit Default B-bit Programming...

  • Page 384: E1 Meter Pulse Detection Length

    4.4 E1 Line Programming [768] E1 Meter Pulse Detection Length Description Sets a length of charge meter pulse detection on the E1 line assigned to DR2. This programme is available for the KX-TD1232 only. Selection Time (milliseconds): 01 through 60 ( 8 is the actual time) Default Programming...

  • Page 385: E1 Dsp Gain (Dtmf Transmit)

    4.4 E1 Line Programming [769] E1 DSP Gain (DTMF Transmit) Description Assigns a DTMF transmitting level from DSP on the E1 line. This programme is available for the KX-TD1232 only. Selection Level: 01 through 16 Default Programming Enter 769. Display: 769 DTMF TX DSP Press NEXT.

  • Page 386: E1 Dsp Gain (Dtmf Receive)

    4.4 E1 Line Programming [770] E1 DSP Gain (DTMF Receive) Description Assigns a DTMF receiving level on DSP on the E1 line. This program is available for the KX-TD1232 only. Selection Level: 01 through 32 Default Programming Enter 770. Display: 770 DTMF RX DSP Press NEXT.

  • Page 387: E1 Dsp Gain (Mfc-R2 Transmit)

    4.4 E1 Line Programming [771] E1 DSP Gain (MFC-R2 Transmit) Description Assigns a MFC-R2 transmitting level from DSP on the E1 line. This programme is available for the KX-TD1232 only. Selection Level: 01 through 32 Default Programming Enter 771. Display: 771 MFC TX DSP Press NEXT.

  • Page 388: E1 Dsp Gain (Mfc-R2 Receive)

    4.4 E1 Line Programming [772] E1 DSP Gain (MFC-R2 Receive) Description Assigns a MFC-R2 receiving level on DSP on the E1 line. This programme is available for the KX-TD1232 only. Selection Level: 01 through 16 Default Programming Enter 772. Display: 772 MFC RX DSP Press NEXT.

  • Page 389: E1 Frame Error Detection

    4.4 E1 Line Programming [773] E1 Frame Error Detection Description Sets the frame error detection for the E1 line. This programme is available for the KX-TD1232 only. Selection No / Yes Default Programming Enter 773. Display: 773 ERR DETECT Press NEXT. Display example: Error Detect:No Keep pressing SELECT until the desired selection is displayed.

  • Page 390: E1 Error Rate

    4.4 E1 Line Programming [774] E1 Error Rate Description Sets the number of times of the frame error detection for the E1 line. This programme is available for the KX-TD1232 only. Selection Number of times: 0 through 7 ( 16 is the actual number of time) (0=no limit) Default Programming Enter 774.

  • Page 391: E1 Ani Service Mode

    4.4 E1 Line Programming [775] E1 ANI Service Mode Description Sets the Automatic Number Identification (ANI) mode for the E1 line. This programme is available for the KX-TD1232 only. Selection None / Incoming Only / Outgoing Only / Both Calls Default None Programming...

  • Page 392: E1 Ani Maximum Digits

    4.4 E1 Line Programming [776] E1 ANI Maximum Digits Description Assigns the maximum digits for Automatic Number Identification (ANI) number. This programme is available for the KX-TD1232 only. Selection Number of digits: 00 through 16 (00=no ANI number) Default Programming Enter 776.

  • Page 393: E1 Mfc-R2 Forward Timer

    4.4 E1 Line Programming [777] E1 MFC-R2 Forward Timer Description Sets the length of waiting time of the incoming call forward signal on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection Time (seconds): 01 through 30 Default 15 s Programming...

  • Page 394: E1 Mfc-R2 Backward Timer

    4.4 E1 Line Programming [778] E1 MFC-R2 Backward Timer Description Sets the length of waiting time of the outgoing call backward signal on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection Time (seconds): 01 through 30 Default 15 s Programming...

  • Page 395: E1 Mfc-R2 Disappearance Timer

    4.4 E1 Line Programming [779] E1 MFC-R2 Disappearance Timer Description Sets the length of waiting time of the stop signal on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection Time (seconds): 01 through 30 Default 24 s Programming...

  • Page 396: E1 Group-I

    4.4 E1 Line Programming [780] E1 Group-I Description Assigns a signal code for Group-I parameters on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection • Parameter number: 01 (ANI Start) / 02 (ANI Complete) / 03 (ANI Reject) •...

  • Page 397: E1 Group-Ii

    4.4 E1 Line Programming [781] E1 Group-II Description Assigns a signal type for Group-II parameters on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection • Parameter number: 01 through 15 • Signal type: Undefined / Subscriber / Operator / Collect Call Default Parameter 02 –...

  • Page 398: E1 Group-A

    4.4 E1 Line Programming [782] E1 Group-A Description Assigns a signal code for Group-A parameters on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection • Parameter number: 01 (Address Complete) / 02 (ANI Request) / 03 (Set UP Speech) / 04 ((First)Request) / 05 ((N)Request) / 06 ((N-1)Request) / 07 ((N-2)Request) / 08 ((N- 3)Request) •...

  • Page 399: E1 Group-B

    4.4 E1 Line Programming [783] E1 Group-B Description Assigns a signal code for Group-B parameters on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection • Parameter number: 01 (Idle(1)) / 02 (Idle(2)) / 03 (Idle(3)) / 04 (No Billing) / 05 (Busy) / 06 (Unallocated) / 07 (Congestion) / 08 (Out of Service) / 09 (Collect Call Reject) •...

  • Page 400: E1 Group-C

    4.4 E1 Line Programming [784] E1 Group-C Description Assigns a signal code for Group-C parameters on the E1 line assigned to MFC-R2. This programme is available for the KX-TD1232 only. Selection • Parameter number: 01 (Group-C ANI(N+1)) / 02 (Group-II ANI) •...

  • Page 401: E1 Tone Type For Making Calls

    4.4 E1 Line Programming [785] E1 Tone Type for Making Calls Description Sets a tone type for busy or reorder mode when making a call using the E1 line assigned to DR2-MFC. This programme is available for the KX-TD1232 only. Selection Busy+Reorder / Busy / Reorder Default...
  • Page 402 4.4 E1 Line Programming E1 Programming...

  • Page 403: Optional Programming

    Section 5 Optional Programming Optional Programming...

  • Page 404: Optional Programming

    5.1 Optional Programming 5.1 Optional Programming [990] System Additional Information Description Allows the following programming items to be changed, if required. Each bit in each Area represents a programming item. Chart for the Areas and Bits Bit Number 16 15 14 13 12 11 10 Display Example Area 01 Area 02 Area 03...
  • Page 405 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Sound source during transfer. 0 : ringback tone • Call Transfer 1 : Music on Hold • Music on Hold Result of pressing the hookswitch 0 : Consultation Consultation lightly and then placing down the Hold Hold...
  • Page 406 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References If an outside party is transferred and 0 : initiating Call Transfer unanswered, assigns whether Transfer extension Recall occurs at the transfer initiating 1 : Operator 1 extension or at Operator 1. If the restriction of outside call duration 0 : both calls None...
  • Page 407 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Determines whether an extension 0 : extension Voice Mail mailbox number is substituted by the number Integration for extension number or it is programmable 1 : free Inband (free). If a call is forwarded or rerouted to the VPS, this system automatically transmits the mailbox number to the VPS to specify the user's mailbox.
  • Page 408 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References 1-16 These bits are provided to assign PAD 0 : 0 dB None Switch Control (volume control of 1 : -3 dB received calls on an outside line). This can be assigned for each outside line.
  • Page 409 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Reserved Have an option to restrict the DISA 0 : 10 times DISA outside-to-outside line extending time. 1 : no limitation 10 attempts are allowed. 0 : disable DISA Enables or disables retry by dialling "...
  • Page 410 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References [For VM DPT Integration] 0 : enable • Voice Mail Enables or disables sending the Follow 1 : disable Integration for On ID when an outside call is routed to Digital a voice mail port by IRNA.
  • Page 411 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Selects the SMDR format for an 0 : <Incoming> + SMDR incoming call with Caller ID. The caller no. caller's number only or caller's number 1 : <I> + caller no. only or caller's number and name is + name selected.
  • Page 412 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Determines whether the account code is 0 : not printed out Account Code printed out or not (shown in dots) by the 1 : printed out Entry SMDR. Reserved Enables or disables sending outside line 0 : enable E&M (TIE)
  • Page 413 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Assigns how the number is changed via 0 : The number the ISDN line into an extension number converted in which receives incoming DDI calls. [421] 1 : The number equals the number from the ISDN line...
  • Page 414 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Enables or disables the DTMF signals to 0 : enable None the ISDN line. 1 : disable Reserved Enables or disables the Whisper OHCA 0 : any telephone Whisper OHCA feature.
  • Page 415 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References 11,10 Determines how the call is treated when 01 : IRNA a call from DID arrives at a DND 10 / 11 : receive at extension or busy extension which has the CO button disabled Call Waiting.
  • Page 416 5.1 Optional Programming Explanation Area Description Selection Default Features Guide References Determines the ring interval time for 0 : short Caller ID incoming calls with Caller ID. 1 : normal Reserved Selects the LED flashing pattern of the 11 : Red Flashing / •...
  • Page 417 5.1 Optional Programming Default See "Default" shown in the explanation table. Programming Enter 990. Display: 990 SYS ADD DATA Press NEXT. Display: Area NO? Enter an area code (01 through 10). Display example: 0010100011000001 Keep pressing to move the cursor to the desired bit. Enter your selection (0 or 1).

  • Page 418: Cos Additional Information

    5.1 Optional Programming [991] COS Additional Information Description Sets the number of digits allowed to dial out during an analogue outside call on a Class of Service (COS) basis. If an outside party hangs up and the extension user tries to dial out still on the outside line, the system will disconnect the line at the time the assigned number of digits are dialled.
  • Page 419 5.1 Optional Programming Enter your selection (0 or 1). To change the current entry, press STORE and the new selection. To programme another bit, repeat steps 4 and 5. Press STORE. To programme another COS, press SELECT and the desired COS number. Repeat steps 4 through 8.
  • Page 420 5.1 Optional Programming Optional Programming...

  • Page 421: Default Values

    Section 6 Default Values Default Values...
  • Page 422 All speed dial numbers – Not stored [002] System Speed Dialling Name Set All speed dial numbers – Not stored [003] Extension Number Set KX-TD816: Jack 01-1 through 16-1 = 101 through 116; Jack 01-2 through 16-2 = 201 through 216 KX-TD1232: Jack 01-1 through 64-1 = 101 through 164;...
  • Page 423 1234 [108] Automatic Hold by CO / DSS Button DSS button – Enable, CO button – Disable [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 [110] Caller ID Code Set All locations – Not stored [111] Caller ID Name Set All locations –...
  • Page 424 Programme Default [118] Voice Mail Extension Number Set KX-TD816: VM-01=165, VM-02=166, VM-03=167, VM- 04=168, VM-05=169, VM-06=170, VM-07=177, VM-08=178, VM-09=181, VM-10=182, VM- 11=183, VM-12=184 KX-TD1232: VM-01=165, VM-02=166, VM-03=167, VM- 04=168, VM-05=169, VM-06=170, VM-07=177, VM-08=178, VM-09=181, VM-10=182, VM- 11=183, VM-12=184, VM-13=171, VM-14=172,...
  • Page 425 Programme Default [136] DID / DDI Number Assignment All locations – Not stored [137-138] DID / DDI Extension – Day / Night All locations – Not stored [139] DID / DDI Extension Name Set All locations – Not stored [141] Charge Rate Decimal Point Assignment [142] Charge Rate Assignment All outside lines –...
  • Page 426 Programme Default [209] Automatic Redial Repeat Times KX-TD816BX, KX-TD1232(D)BX/ML, KX- TDN1232 – 10 times KX-TD816HK, KX-TD1232HK – 3 times KX-TD1232X – 2 times [210] Automatic Redial Interval Time KX-TD816BX, KX-TD1232(D)BX/ML, KX- TDN1232 – 60 s KX-TD816HK, KX-TD1232HK – 900 s (15 min) KX-TD1232X –...
  • Page 427 CO04 – TRG 4; CO05 – TRG 5; CO06 – TRG 6; CO07 – TRG 7; CO08 – TRG 8 (for KX-TD816) CO08 through CO54 – TRG 8 (for KX-TD1232) [402] Dial Mode Selection KX-TD816BX, KX-TD1232(D)BX/ML, KX- TDN1232: All outside lines – Pulse KX-TD816HK, KX-TD1232HK/X: All outside lines –...
  • Page 428 Programme Default [407-408] DIL 1:1 Extension – Day / Night All outside lines – Disable (Day / Night) [409-410] Intercept Extension – Day / Night All outside line groups – Disable (Day / Night) [411] Host PBX Access Codes All outside line groups – Not stored [412] Pause Time All outside line groups –...
  • Page 429 Programme Default [445] DID Forward Timer (for MFC-R2) All DID formats – 15 s [446] DID Backward Timer (for MFC-R2) All DID formats – 15 s [447] DID Disappearance Timer (for MFC-R2) All DID formats – 24 s [448] DID First Dial Start Time (for MFC-R2) All DID formats –...
  • Page 430 Programme Default [510] Night Service Access All COS – Disable [511] PT Programming Level All COS – LVL1 [600] EXtra Device Port All jacks – Disable [601] Class of Service All jacks-1/2 – COS 1 [602] Extension Group Assignment All jacks-1/2 – Extension group 1 [603-604] DIL 1:N Extension and Delayed All jacks-1/2 –...
  • Page 431 [013] ISDN Extension Name Set All ports – Not stored [018] Budget Management for ISDN Extension All ports – 0 [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 [112] ISDN Network Type Assignment KX-TD816HK/KX-TD1232HK: Mode 39...
  • Page 432 All outside lines – Removed digit=0; Added Assignment number=Not stored [423] ISDN Port Type All ports – CO [424] ISDN Layer 1 Active Mode KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent Default Values...
  • Page 433 KX-TD816: Ports 05 and 06 – Multipoint; Other ports – Point KX-TD1232: All ports – Point [426] ISDN Data Link Mode KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent [427] ISDN TEI Mode KX-TD816: Port 05 and 06 –...
  • Page 434 4 E1 Programming Programme Default [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 [418] Outside Line Number Assignment for All outside lines – Not stored ISDN / E1 [622] Extension ANI Number All jacks-1/2 – Not stored...
  • Page 435 Programme Default [755] E1 Answer Decision Timer [756] E1 Seizure ACK Wait Timer [757] E1 Pulse Type Type-A [758] E1 DR2 Signalling Type Normal [759] E1 Inter Digit Timer [760] E1 Bit Position for Dial Pulse A-bit [761] E1 Bit Position for Clear Back A-bit [762] E1 E&M Signalling Type Type-2...
  • Page 436 Programme Default [779] E1 MFC-R2 Disappearance Timer 24 s [780] E1 Group-I Parameter 01 – 14; Parameter 02 – 15; Parameter 03 – 12 [781] E1 Group-II Parameter 02 – Subscriber; Other parameters – Undefined [782] E1 Group-A Parameter 01 – 03; Parameter 02 – 05; Parameter 03 –...

  • Page 437: Index

    Section 6 Index Index...
  • Page 438 Calling Line Identification Restriction (CLIR) AA hunting Characters AA Service Charge Display Selection Absent Messages Charge limitation Account button Charge Rate Assignment Account code Charge Rate Decimal Point Assignment Account Code Entry Charge Verification Assignment Account Code Entry Mode Charge Verification ID Code Set Adjust Time Circular hunting Alarm tone...
  • Page 439 Dial tone E1 ANI Maximum Digits DID / DDI Extension Name Set E1 ANI Service Mode DID / DDI Extension – Day / Night E1 Answer Decision Timer DID / DDI Number Assignment E1 Answer Wait Timer DID / TIE Added Number E1 Bit Position for Clear Back DID / TIE Format Number Assignment E1 Bit Position for Dial Pulse...
  • Page 440 Extension Call Forwarding – No Answer Time ISDN Data Assignment ISDN Data Link Mode Extension Group Assignment ISDN Extension Multiple Subscriber Number Extension hooking signal Extension Name Set ISDN Extension Name Set Extension Number Set ISDN Extension Number Set Extension Ringing Assignment – Day / Night for ISDN Extension Progress Tone ISDN ISDN Layer 1 Active Mode...
  • Page 441 Message waiting ring type Programming Methods Modem Standard PT Programming Level MSN (Multiple Subscriber Numbers) Pulse break ratio Pulse dialling signals MSN Assignment Pulse feedback Multiple Subscriber Numbers (MSN) Pulse mode Pulse Speed Selection Music on Hold Music Source Use Quick Dial Number Set NEXT button Night button...
  • Page 442 Voice Mail Extension Number Set Voice Mail Number Assignment Termination hunting Voice Mail Transfer button TIE Added Number Voice Path Type TIE First / Inter Digit Time Voice Processing System (VPS) TIE Format Number Assignment TIE Incoming Assignment VOLUME button TIE Line Routing Table VPS (Voice Processing System) TIE Modify Removed Digit / Added Number...
  • Page 443 Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Kyushu Matsushita Electric Co., Ltd. 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Copyright: This manual is copyrighted by Kyushu Matsushita Electric Co., Ltd.

This manual is also suitable for:

Kx-td1232

Table of Contents
