Page 1 Digital Super Hybrid System Programming Guide KX-TD816 KX-TD1232 Model Please read this manual before using the Digital Super Hybrid System. This manual is for software version P341I, P342I or later for KX-TD816 and P241I, P242I or later for KX-TD1232.
Page 2 About the other manuals Along with this Programming Guide, the following manuals are available to help you install, know the available features and use the KX-TD816 / KX-TD1232 system: Installation Manual Provides instructions for installing the hardware and optional equipment.
Page 3 User Manual Provides operating instructions for the end users using proprietary telephones, single line telephones, consoles or DECT portable stations. Introduction...
Page 4: Table Of Contents
Table of Contents 1 Programming Instructions............... 9 1.1 Programming Instructions..................10 1.2 Using Proprietary Telephones ..................11 1.3 Programming Methods ....................15 1.4 Entering Characters ....................17 1.5 User Programming Mode.................... 22 1.6 Programming Example ....................23 2 General Programming ..............27 2.1 Manager Programming....................
Page 5 [12 5]User Password......................88 [12 6]UCD Overflow......................89 [12 7]UCD Time Table......................91 [13 0]Phantom Extension Number Set ................. 93 [14 8]Off-Hook Monitor....................... 95 [15 4]Message Waiting Control.................... 96 [15 5]Message Waiting Lamp Assignment ................98 [15 6]Message Waiting Port Set ..................100 2.3 Timer Programming....................
Page 6 [413] Flash Time........................ 153 [414] Disconnect Time ...................... 155 [417] Outside Line Name Assignment ................156 [423] Pay Tone Assignment....................158 [441] Line Hunting Sequence.................... 160 2.6 COS Programming ....................161 [500-501] Toll Restriction Level – Day / Night..............161 [502] Extension-to-Outside Line Call Duration Limit ............
Page 7 [01 2]ISDN Extension Number Set..................231 [01 3]ISDN Extension Name Set ..................233 [01 4]Budget Management on ISDN Port ................235 3.2 System Programming ....................237 [10 0]Flexible Numbering ....................53 [10 9]Expansion Unit Type....................69 [11 2]ISDN Network Type Assignment ................243 [15 0]DDI Translation Table ....................
Page 8 [434] TIE Subscriber Number Removed Digit..............316 [435] TIE Added Number....................317 [436] TIE Wink Time Out Assignment ................318 [437] Outside-to-TIE Transfer................... 320 [438] TIE-to-Outside Transfer................... 321 [439] TIE-to-TIE Transfer ....................322 [440] TIE Security Type ....................323 [442] Voice Path Type......................324 [443] Voice Level (Transmit).....................
Page 9: Programming Instructions
Section Programming Instructions Programming Instructions...
Page 10: Programming Instructions
1.1 Programming Instructions 1.1 Programming Instructions Default Setting This system has a default factory setting. If any of the programming needs to be changed, you will find the necessary information in the Features Guide. This makes the system very simple to install and customise as required by the customer.
Page 11: Using Proprietary Telephones
1.2 Using Proprietary Telephones 1.2 Using Proprietary Telephones Soft Buttons and SHIFT Button on the Display DPT Three soft buttons are provided just below the display of Digital Proprietary Telephones (DPT), KX-T7533, KX-T7536, KX-T7433, KX-T7436, KX-T7230 and KX-T7235. The functions of these soft buttons vary as the programming procedures advance step by step.
Page 12 1.2 Using Proprietary Telephones You can use either the soft buttons or the overlay buttons. (For overlay buttons, refer to "Using the Overlay" below.) Throughout programming you will see instructions such as "Press PREV". If you use soft buttons, this means press SHIFT, release SHIFT and then press Soft 3. The (PREV) function is performed.
Page 13 1.2 Using Proprietary Telephones Location of Controls with the Overlay The pictures below show the functions of the buttons of the proprietary telephone while in programming mode. There are Overlays for the KX-T7500, KX-T7400 and KX-T7200 series telephones. KX-T7536 and KX-T7230 are used for the examples. KX-T 7536 KX-T 7436 SHIFT...
Page 14 1.2 Using Proprietary Telephones Viewing the Display The display gives you helpful information, such as what you should do now, what you have done, etc.. The KX-T7533, KX-T7536, KX-T7433, KX-T7436, KX-T7230 and the KX-T7235 utilise two information lines for programming. The upper line is called the Message Line and the lower one is called the Function Line.
Page 15: Programming Methods
1.3 Programming Methods 1.3 Programming Methods Advancing to the next stage When "SYS-PGM NO? " is displayed, you can select one of the following: • To go to programme [000], press the NEXT button. • To go to another programme, enter the 3-digit programme address. Rotation of jack number Each jack of the Digital Super Hybrid System supports the connection of a digital proprietary telephone and a single line device with different extension numbers (eXtra Device Port: XDP...
Page 16 1.3 Programming Methods Going to another programme address After pressing STORE, you can go to another programme with either of the following two methods: To go to the next larger programme address: Press Soft 1 (SKP+) or VOLUME (DOWN) or rorate the Jog Dial in the counter- clockwise direction.
Page 17: Entering Characters
1.4 Entering Characters 1.4 Entering Characters Entering Characters You can enter characters to store names or messages by using the dialling key pad, buttons or the Jog Dial. See the Combination Tables below. Combination Table a SHIFT+ SHIFT+ Soft button SHIFT+S1 SHIFT+S2 SHIFT+S3...
Page 18 1.4 Entering Characters Combination Table b Jog Dial Display sequence by rotating the Jog Dial keys 1 Q q R r S s T t ··· 2 A a B b C c D d ··· 3 D d E e F f G g ··· 4 G g H h I i J j ···...
Page 19 1.4 Entering Characters • Pressing the SELECT button an appropriate number of times gives you the desired letter. Pressing SELECT twice gives the letter "m", pressing three times gives "N", and so on. Using the Jog Dial (for KX-T7531 / KX-T7533 / KX-T7536 / KX-T7433 / KX-T7436 only) * See Combination Table b.
Page 20 1.4 Entering Characters Enter 5. Press Soft 2 (k). Enter 3. Mik3 Press Soft 2 (e). Mike Using method (2) * See Combination Table a. Procedures The display shows: 1. Enter 6. 2. Press SELEC . 3. Enter 4. 4. Press SELECT six times. 5.
Page 21 1.4 Entering Characters Procedures The display shows: 1. Enter 2. 2. Rotate Jog Dial until "M" appears. M 3. Enter 2. 4. Rotate Jog Dial until "i" appears. 5. Enter 2. 6. Rotate Jog Dial until "k" appears. Mik 7. Enter 2. Mik2 8.
Page 22: User Programming Mode
1.5 User Programming 1.5 User Programming Mode User Programming Mode Manager programming items (programme address: [0XX]) are accessible by any display proprietary telephone user in the system. Entering the user programming mode You can access these programmes by entering the User Programming Mode as follows: Before entering the mode, confirm that: •...
Page 23: Programming Example
1.6 Programming Example 1.6 Programming Example Programming Example The following programming instructions assume that you have already entered the programming mode and that you will employ method (b) of "Going to another programme address" in Section 1.3 P rogramming Methods. Example: programme [001] S ystem Speed Dialling Number Set Sample of Description Explanation...
Page 24 1.6 Programming Example Sample of Description Explanation 6. To programme another speed dial number, (15) Select the best way for you to store another speed press NEXT or PREV, or SELECT and dial number. Pressing the NEXT / PREV allows (15) the desired speed dial number .
Page 25 1.6 Programming Example Programming Structur Programme Programming Group Description Address [8XX] Resource Programming Assignment of customer-supplied peripherals connected to the system. [9XX] Optional Programming Used to answer the user's requirements or troubles, if needed. Programming Instructions...
Page 26 1.6 Programming Example Programming Instructions...
Page 27: General Programming
Section General Programming General Programming...
Page 28: Manager Programming
2.1 Manager Programming 2.1 Manager Programming [000] D ate and Time Set Description Sets the current date and time. Selection • Year: 00 through 99 • Month: Jan. through Dec. • Day: 1 through 31 • Day of the week: SUN / MON / TUE / WED / THU / FRI / SAT •...
Page 29 2.1 Manager Programming To change the current entry, press CLEAR and enter the new hour. Press Enter the minute. To change the current entry, press CLEAR and enter the new minute. Press Press SELECT for AM or PM. Press STORE. Press END.
Page 30: System Speed Dialling Number Set
2.1 Manager Programming [001] S ystem Speed Dialling Number Set Description Used to programme the System Speed Dial numbers. These numbers are available to all extension users. There are 500 numbers available from 000 to 499. Selection • Speed dial number: 000 through 499 •...
Page 31 2.1 Manager Programming Conditions • Each speed dial number has a maximum of 24 digits. The valid characters are 0 through 9, the and # keys, and the FLASH, PAUSE, SECRET and – (hyphen) buttons. – To store a flash signal, press FLASH. Note: The stored flash will only be effective during a call.
Page 32: System Speed Dialling Name Set
2.1 Manager Programming [002] S ystem Speed Dialling Name Set Description Assigns names to the system speed dial numbers assigned in program me [001]System Speed Dialling Number Set. KX-T7531, KX-T7533, KX-T7536, KX-T7433, KX-T7436 and KX- T7235 telephones can show the stored name during System Speed Dialling. Selection •...
Page 33 2.1 Manager Programming Features Guide References Call Directory System Speed Dialling General Programming...
Page 34: Extension Number Set
Assigns an extension number to each extension. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2) KX-TD1232 – 01 through 64 (-1 / -2) (-1 = first part, -2 = second part) • Extension Number: 2 through 4 digits...
Page 35 2.1 Manager Programming Conditions • There is a maximum of 32 extension numbers for KX-TD816, and 128 extension numbers for KX-TD1232. Each extension number can be two, three, or four digits, consisting of 0 through 9. The and # keys cannot be used.
Page 36: Extension Name Set
To programme another jack, press NEXT or PREV, or SELECT and the desired jack number. Repeat steps 4 through 6. Press END. Conditions • There is a maximum of 32 names for KX-TD816, and 128 names for KX-TD1232. Each name has a maximum of 10 characters. General Programming...
Page 37 2.1 Manager Programming • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.
Page 38: Flexible Co Button Assignment
KX-TD1232 – 01 through 64 • Button Code (plus parameter, if required): Button Code Parameter 0 (Single-CO) KX-TD816: 01 through 08 (Outside line number) KX-TD1232: 01 through 54 (Outside line number) 1 (DSS) 2 through 4 digits (Extension number) 2 (One-Touch Dialling) 16 digits max.
Page 39 * Available when this system is connected to a Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP200). Default KX-TD816: All jacks – CO buttons 1 through 8 = Single-CO 01 through 08; Ring tone type 2 Other CO buttons = Not stored KX-TD1232: All jacks –...
Page 40 2.1 Manager Programming • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable. • The number of the CO buttons available depends on the telephone type. (Refer to Buttons on Proprietary Telephones and Consoles in the Features Guide.) For the KX-T7500 series telephones, 24 CO buttons can be programmed by adding 12 CO buttons by connecting the KX-T7545 Add-on key Module.
Page 41: Operator / Manager Extension Assignment
System Programming. The operators have the ability to perform operator services. Selection • OPE-1 (operator 1) / OPE-2 (operator 2) / MNGER (manager) • Jack number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 Default Operator 1 – Jack 01;...
Page 42 2.1 Manager Programming Features Guide References Manager Extension Operator General Programming...
Page 43: Console Port And Paired Telephone Assignment
Assigns the jack numbers for the console and the paired extension. Selection • Console number: KX-TD816 – 1 through 4 KX-TD1232 – 1 through 4 (for Master), 5 through 8 (for Slave) • Jack number for Console: KX-TD816 – 02 through 16 KX-TD1232 –...
Page 44 2.1 Manager Programming Conditions • The jack number for the console and that for the paired extension must be entered together. • Multiple consoles cannot be assigned to the same console jack. • Multiple consoles can be paired with the same proprietary telephone jack. •...
Page 45: Absent Messages
2.1 Manager Programming [008] Absent Messages Description Used to programme the absent messages. An absent message, if set by the extension user, is displayed on the calling extension's telephone to show the reason for the user's absence. Selection • Message number: 1 through 9 •...
Page 46 2.1 Manager Programming Conditions • Messages 1 through 6 are programmed at the factory but can be changed. • You can enter a maximum of seven "%" characters per message which can be programmed at each user's extension. The extension user can enter 0 through 9, and # for the % characters.
Page 47: Emergency Dial Number Set
2.1 Manager Programming [009] Emergency Dial Number Set Description Assigns emergency call numbers. Selection • Emergency dial location number: 1 through 8 • Telephone number: 16 digits (max.) Default All locations – Not stored Programming Enter 009. Display: Emergency Call Press NEXT.
Page 48 2.1 Manager Programming Features Guide References Emergency Call General Programming...
Page 49: Budget Management
[010] Budget Management Description Assigns the charge limitation of a call on the extension basis. Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) ( =all jacks, -1=first part, -2=second part) •...
Page 50 2.1 Manager Programming • The displayed currency denomination can be programmed by [121]Assignment of Denomination. Features Guide References Budget Management Charge Fee Reference General Programming...
Page 51: Charge Margin Rate
2.1 Manager Programming [011] Charge Margin Rate Description Assigns the margin rate of a telephone charge. Selection Margin (%): 0 through 999 Default Programming Enter 011. Display: Charge Margin Press NEXT. Display: Margin: 0% Enter a charge margin rate. To delete the charge limitation, press CLEAR. Press STORE.
Page 52: Quick Dialling Number Set
2.1 Manager Programming [015] Q uick Dialling Number Set Description Stores the desired extension or telephone numbers for Quick Dialling. Quick dialling numbers must be assigned in programme [104]Flexible Quick Dialling Number Set. Selection • Location number: 01 through 80 •...
Page 53: System Programming
2.2 System Programming 2.2 System Programming [100] Flexible Numbering Description Assigns the leading digits of extension numbers and feature numbers for system features. Feature Number List Number Feature Default 1st hundred extension block 2nd hundred extension block 03 - 16 3rd through 16th hundred extension block None Operator call...
Page 54 2.2 System Programming Feature Number List Number Feature Default External feature access Station feature clear Message waiting Outgoing message Call forwarding / Do not disturb Call pickup deny Data line security Call waiting / OHCA / Whisper OHCA Executive busy override deny Pickup dialling Absent message Timed reminder...
Page 55 2.2 System Programming Selection • Selection number: 01 through 89 (See "Feature Number List" for the corresponding features.) • Feature number: 1 or 2 digits (for selection numbers 01 through 16, 68 through 83); 1 through 3 digits (for selection numbers 17 through 67, 84 through 89) Default See "Feature Number List".
Page 56 2.2 System Programming Feature number type Required digits Valid entry Extension blocks / other 1 or 2 digits 0 through 9 PBX extensions TIE line access number 1 through 3 digits 0 through 9 Other feature numbers 1 through 3 digits 0 through 9, , # •...
Page 57: Day / Night Service Switching Mode
2.2 System Programming [101] Day / Night Service Switching Mode Description This programme is used to determine if night mode is set automatically or manually. Selection Manual / Auto (automatic) Default Manual Programming Enter 101. Display: Day/Night Mode Press NEXT. Display example: D/N Mode:Manual Keep pressing SELECT until the desired selection is displayed.
Page 58: Day / Night Service Starting Time
2.2 System Programming [102] D ay / Night Service Starting Time Description Sets the starting time on a day of the week basis, when automatic day / night switching is programmed in programme [101] D ay / Night Service Switching Mode. Selection •...
Page 59 2.2 System Programming To programme another day / night mode or day of the week, press NEXT or PREV, or SELECT and the day of the week selection number. Repeat steps 4 through 10. Press END. Conditions • To select the desired day, you may keep pressing NEXT in step 3. To assign every day of the week to one selection, press the key in step 3.
Page 60: Automatic Access Outside Line Group Assignment
2.2 System Programming [103]Automatic Access Outside Line Group Assignment Description Assigns the sequence in which outside line groups will be accessed when in Automatic Line Access mode. When a user dials the feature number for automatic line access (default=9) or presses the Loop-CO button, an idle line is searched for in the programmed outside line group order.
Page 61: Flexible Quick Dialling Number Set
2.2 System Programming [104] Flexible Quick Dialling Number Set Description Assigns the flexible quick dialling numbers. The desired extension or telephone numbers must be stored in programme [015]Quick Dialling Number Set. Selection • Location number: 01 through 80 • Flexible quick dialling number: 4 digits (max.) Default All locations –...
Page 62 2.2 System Programming Features Guide References Quick Dialling General Programming...
Page 63: Account Codes
2.2 System Programming [105] Account Codes Description Assigns the account codes for Account Code Entry, Verified – All Calls and Verified – Toll Restriction Override modes. If Verified – All Calls is assigned in programme [508] "Account Code Entry Mode", an account code is required to make an outside call. If Verified – Toll Restriction Override is assigned, an account code is only required for a toll call and overrides toll restriction.
Page 64 2.2 System Programming Features Guide References Account Code Entry Toll Restriction General Programming...
Page 65: Station Hunting Type
2.2 System Programming [106] Station Hunting Type Description Used to enable or disable hunting and set the Station Hunting type for each extension group. There are six Station Hunting types available: Circular, Terminating, Voice Mail (VM), Automated Attendant (AA), Ring Group and Uniform Call Distribution (UCD). If circular hunting is assigned for a group, all of the extensions in the group are searched until an idle one is found.
Page 66 2.2 System Programming Conditions • Programme [ 602]Extension Group Assignment is used to assign the extension group members. • The system supports a maximum of eight jacks (16 jacks during System Connection for KX-TD1232) for connection to a Voice Processing System as VM or AA ports. •...
Page 67: System Password
2.2 System Programming [107] System Password Description Assigns the password required for entering System Programming mode and for maintenance from a personal computer. Selection Password: 4 through 7 digits Default 1234 Programming Enter 107. Display: System Password Press NEXT. Display: Password:1234 Enter a password.
Page 68: One-Touch Transfer By Dss Button
2.2 System Programming [108] O ne-Touch Transfer by DSS Button Description Enables or disables the function of automatically holding the outside call when a DSS button on the console or proprietary telephone is pressed. Selection Enable / Disable Default Enable Programming Enter 108.
Page 69: Expansion Unit Type
EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) / D (No Use) (Master system only: S3, E1 and E2 for the KX-TD144 or KX-TD146) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
Page 70 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / E&M) unit can be installed.
Page 71: Vm Status Dtmf Set
2.2 System Programming [113] VM Status DTMF Set Description Sets the DTMF (Dual Tone Multi-Frequency) signals transmitted to your Voice Processing System (VPS) to inform the VPS of the VPS ports states quickly: The following signals are sent to the VPS with the assigned DTMF signals: RBT (ringback tone): This signal is sent when calling an extension.
Page 72 2.2 System Programming Display example: RBT :1 Enter a DTMF signal number. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new number. Press STORE. To programme another selection, keep pressing NEXT or PREV until the desired selection is displayed.
Page 73: Vm Command Dtmf Set
2.2 System Programming [114] VM Command DTMF Set Description Sets the DTMF (Dual Tone Multi-Frequency) command signals transmitted to your Voice Processing System (VPS). There are four commands available: Leave Message; Get Message; Automated Attendant Service; Voice Mail Service. These commands are used in the following ways: (A) If your VPS is used for Voice Mail (VM) Service (1) Call Forwarding / Intercept Routing to Voice Mail...
Page 74 2.2 System Programming Default LV-MSG – H; GETMSG – *H; AA-SVC – #8; VM-SVC – #6 Programming Enter 114. Display: VM Command Set Press NEXT to programme the LV-MSG command. To programme another command, keep pressing NEXT until the desired command is displayed.
Page 75: Adjust Time
2.2 System Programming [115] Adjust Time Description Used to adjust the time for checking the normality of system data. Every day at the programmed time, the data adjustment is performed. Selection • Hour: 1 through 12 • Minute: 00 through 59 •...
Page 76: Rom Version Display
The display shows the ROM version of the specified system. Press END. Conditions • The out-of-service system number is unacceptable. • For KX-TD816, you can enter the system number "0" only. Skip step 4. Features Guide References None General Programming...
Page 77: Voice Mail Number Assignment
Processing System. The voice mail port is expandable to four ports (8 ports during System Connection for KX-TD1232). This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP200).
Page 78 2.2 System Programming KX-TD123 Enter 117. Display: VMS Port Asn Press NEXT to programme the Master System. To programme the Slave System, press NEXT again. Display example: Mast1:# # # # Enter a jack numbe . To delete the current entry, press CLEA . To change the current entry, press CLEAR and enter the new jack number.
Page 79: Voice Mail Extension Number Set
Assigns the extension number for the voice mail number. These numbers can be used the same way extension numbers are used for station access. This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP200).
Page 80 [130] Phantom Extension Number Set Not stored. [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 199, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 199, 291 through 294, 296 through 299 [671] PS Extension Number Set Not stored.
Page 81: Voice Mail Extension Group Assignment
[119] Voice Mail Extension Group Assignment Description Assigns each voice mail number to a voice mail extension group number. This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP200). Selection •...
Page 82 2.2 System Programming programmed in [1 17]Voice Mail Number Assignment. "-1" of YY-1 means the first part of the jack number in digital line. "YY-2" means the second part of the jack number in digital line. • To assign all voice mail numbers to one selection, press the key in step 3.
Page 83: Charge Display Selection
2.2 System Programming [120] Charge Display Selection Description Assigns the initial display format of charge fee. Selection in Meter / in Charge Default in Meter Programming Enter 120. Display: Charge Meter Press NEXT. Display example: in Meter Keep pressing SELECT until the desired selection is displayed. Press STORE.
Page 84: Assignment Of Denomination
2.2 System Programming [121] A ssignment of Denomination Description Assigns the Denomination required for your country. Selection 2 characters (Max.) Default Not stored Programming Enter 121. Display: Denomination Press NEXT. Display example: Denomi.: KC Enter a denomination. To delete the current entry, press CLEA . To change the current entry, press CLEAR and enter the new denomination.
Page 85: Charge Verification Assignment
Assigns the extension which is allowed to refer or clear for the call information on the extension, outside line, account code, and the total. Selection • Jack number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all jacks) • Enable / Disable Default All jacks –...
Page 86: Charge Verification Id Code Set
2.2 System Programming [123] C harge Verification ID Code Set Description Assigns an ID code required to refer the charge information. Selection 4 digits (0000 through 9999) Default 1234 Programming Enter 123. Display: Charge ID Code Press NEXT. Display example: Code: 1234 Enter an ID code.
Page 87: Hotel Application
2.2 System Programming [124] Hotel Application Description Assigns whether the hotel application is enabled or disabled. Selection Enable / Disable Default Disable Programming Enter 124. Display: Hotel Apply Asn Press NEXT. Display example: Hotel:Disable Keep pressing SELECT until the desired selection is displayed. Press STORE.
Page 88: [12 5]User Password
2.2 System Programming [125] U ser Password Description Assigns the password required for entering the User Programming mode. In the User Programming mode, any display digital proprietary telephone user in the system can set the Manager Programmings (Programme address: [0XX]). Selection Password: 4 through 7 digits Default...
Page 89: [12 6]Ucd Overflow
2.2 System Programming [126] UCD Overflow Description Assigns the destination where the call is transferred to when all extensions in the Uniform Call Distribution (UCD) group are busy. The Time Table number of the overflow extension must also be assigned. Selection •...
Page 90 2.2 System Programming Features Guide References Uniform Call Distribution (UCD) General Programming...
Page 91: [12 7]Ucd Time Table
2.2 System Programming [127] UCD Time Table Description Assigns the queuing sequence in the Uniform Call Distribution (UCD) Time Table. The queuing sequences are as follows: S1: Sends DISA (Direct Inward System Access) outgoing message 1. S2: Sends DISA outgoing message 2. S3: Sends DISA outgoing message 3.
Page 92 2.2 System Programming Conditions • "Sx" can be assigned in a space other than in the first only when another "Sx" is assigned in the first space. • An assignment after "TR", "RT" or "Blank" is not available. Features Guide References Uniform Call Distribution (UCD) General Programming...
Page 93: [13 0]Phantom Extension Number Set
2.2 System Programming [130] Phantom Extension Number Set Description Assigns the phantom extension numbers. Each number will be assigned to a flexible CO or DSS (Direct Station Selection) button and used as a Phantom Extension button. Selection • Location number: 001 through 128 •...
Page 94 KX-TD1232 – 165 through 180 [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 199, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 199, 291 through 294, 296 through 299 [671] PS Extension Number Set Not stored.
Page 95: [14 8]Off-Hook Monitor
2.2 System Programming [148] Off-Hook Monitor Description Enables or disables to perform the Off-Hook Monitor. Selection Enable / Disable Default Enable Programming Enter 148. Display: Off Hook Monitor Press NEXT. Display example: Monitor:Enable Keep pressing SELECT until the desired selection is displayed. Press STORE.
Page 96: [15 4]Message Waiting Control
Assigns the data ports which communicate with the Message Waiting Lamp Adaptor Unit (KX-TD194). Selection • Unit (TD194) number: KX-TD816 – 1 KX-TD1232 – 1 through 6 • Jack number: KX-TD816 – 02 through 16 KX-TD1232 – 02 through 64 Default All units – Not stored Programming Enter 154. Display: MW CONTROL Press NEXT.
Page 97 2.2 System Programming Jacks assigned to consoles and paired telephones Jacks already assigned to the message waiting adaptor unit If the unit is connected to a port which is not assigned as the data port, a clicking sound may be heard from the unit. Please make sure that the unit is connected to the assigned port.
Page 98: [15 5]Message Waiting Lamp Assignment
2.2 System Programming [155] M essage Waiting Lamp Assignment Description Assigns the message waiting light pattern. Selection Message waiting light pattern number: 01 through 12 Default Programming Enter 155. Display: MW LAMP Press NEXT. Display: MW LAMP NO:1 Enter a message waiting light number. Display example: MW LAMP NO:12 Press STORE.
Page 99 2.2 System Programming 5 sec Pattern 01 1.25 sec Pattern 02 500 msec Pattern 03 250 msec Pattern 04 250 msec 250 msec Pattern 05 500 msec 500 msec 10±α sec Pattern 06 250 msec 20±α sec Pattern 07 250 msec 5 sec Pattern 08 1.25 sec...
Page 100: [15 6]Message Waiting Port Set
• Message waiting port number: 01 through 16 • Single line telephone jack number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • Sub port number: 1 or 2 (1 = main port, 2 =XDP single line telephone port) Default All units –...
Page 101 2.2 System Programming Press END. Conditions • To programme another unit, start from step 1. • For the KX-TD1232, the unit numbers 1 through 3 are for the Master System and 4 through 6 are for the Slave System, and jack numbers 01 through 32 are for Master System and 33 through 64 are for Slave System.
Page 102: Timer Programming
2.3 Timer Programming 2.3 Timer Programming [200] H old Recall Time Description Assigns the length of the hold recall timer. This timer is used to alert an extension that a call has been held for an extended period of time. Selection Time (seconds): 0 through 240 (0=Hold Recall disabled) Default...
Page 103: [20 1]Transfer Recall Time
2.3 Timer Programming [201] Transfer Recall Time Description Sets the number of rings before transfer recall occurs. If a transferred call is not answered after the programmed number of rings, the call returns to the original caller. Selection Number of rings: 3 through 48 Default 12 rings Programming...
Page 104: [20 2]Call Forwarding - No Answer Time
2.3 Timer Programming [202] C all Forwarding – No Answer Time Description Sets the number of rings for the Call Forwarding – No Answer feature. If a call is not answered after the programmed number of rings, the call is forwarded to the destination. Selection Number of rings: 1 through 12 Default...
Page 105: [20 3]Intercept Time
2.3 Timer Programming [203] Intercept Time Description Sets the number of rings for the Intercept Routing – No Answer (IRNA) feature. If a call is not answered after the programmed number of rings, the call is redirected to the programmed station.
Page 106: [20 4]Pickup Dial Waiting Time
2.3 Timer Programming [204] P ickup Dial Waiting Time Description Sets the number of seconds for Pickup Dialling. If the telephone user lifts the handset, the programmed party is called when the time expires. Selection Time (seconds): 1 through 5 Default Programming Enter 204.
Page 107: [20 5]Extension-To-Outside Line Call Duration Time
2.3 Timer Programming [205] Extension-to-Outside Line Call Duration Time Description Sets the maximum time allowed for a conversation with an outside party. If an outside call is originated or answered by a programmed extension user and the timer expires, the call is disconnected.
Page 108: [20 6]Outside-To-Outside Line Call Duration Time
2.3 Timer Programming [206] O utside-to-Outside Line Call Duration Time Description Sets the maximum time allowed for a conversation between two outside parties. When the timer expires, the outside-to-outside line call is disconnected. Selection Time (minutes): 1 through 64 Default 10 min Programming Enter 206.
Page 109: [20 7]First Digit Time
2.3 Timer Programming [207] First Digit Time Description Sets the maximum time allowed between the start of an outside dial tone and the first digit dialled on an outgoing outside call. If an extension user fails to dial any digits during this time, the DTMF (Dual Tone Multi-Frequency) receiver is released.
Page 110: [20 8]Inter Digit Time
2.3 Timer Programming [208] I nter Digit Time Description Assigns the maximum time allowed between digits on an outgoing toll call. If an extension user fails to dial any digits during this time, the DTMF (Dual Tone Multi-Frequency) receiver is released.
Page 111: [20 9]Automatic Redial Repeat Times
2.3 Timer Programming [209] Automatic Redial Repeat Times Description Sets the number of times Automatic Redial is tried. Automatic redialling of the last dialled or saved number is done up to the specified number of times. Selection Number of times: 1 through 30 Default 10 times Programming...
Page 112: [21 0]Automatic Redial Interval Time
2.3 Timer Programming [210]Automatic Redial Interval Time Description Sets the interval time between Automatic Redial attempts. Selection Time (seconds): 3 through 120 ( 10 is the actual time) Default 60 s Programming Enter 210. Display: Interval Time Press NEXT. Display example: Time: 60 sec Enter the time.
Page 113: [21 1]Dial Start Time
2.3 Timer Programming [211] Dial Start Time Description Sets the number of milliseconds the system waits before dialling after an outside line is seised. Selection Time (milliseconds): 0 through 40 ( 100 is the actual time) Default 500 ms Programming Enter 211.
Page 114: [21 2]Call Duration Count Start Time
2.3 Timer Programming [212] C all Duration Count Start Time Description Sets the number of seconds the system waits between the end of dialling and the start of the Station Message Detail Recording (SMDR) timer for outgoing toll calls. When the system has sent out all the digits to the central office and this timer expires, the system starts counting the call.
Page 115: [21 3]Disa Delayed Answer Time
2.3 Timer Programming [213] DISA Delayed Answer Time Description Assigns the number of rings between a call received and the answer by the Direct Inward System Access (DISA) feature. Selection Number of rings: 0 through 6 Default 1 ring Programming Enter 213.
Page 116: [21 4]Disa Prolong Time
2.3 Timer Programming [214] D ISA Prolong Time Description Sets the maximum allowable prolonged time for an outside-to-outside line call via the Direct Inward System Access (DISA) feature. An outside-to-outside line call is initially limited by the "Outside-to-Outside Line Call Duration Time" (Programme [206]). However, the DISA caller can prolong the call after hearing the warning tones by pressing any key (except the key).
Page 117: [21 5]Outgoing Message Time
2.3 Timer Programming [215] Outgoing Message Time Description Sets the maximum allowable recording time for Outgoing Messages (OGM). Selection Time (seconds): 0 / 16 / 32 / 64 (0=no recording) Default 32, 0, 32, 0 (for OGM 1 through 4 from left to right) Programming Enter 215.
Page 118: [21 6]Message Waiting Ring Interval Time
2.3 Timer Programming [216] M essage Waiting Ring Interval Time Description Sets the Message Waiting ring interval time for a single line telephone. Selection Time (minutes): 0 through 64 (0=no ring) Default 10 min Programming Enter 216. Display: MW Ring Time Press NEXT.
Page 119: [21 7]Timed Reminder Alarm Repeat Times
2.3 Timer Programming [217] Timed Reminder Alarm Repeat Times Description Sets the number of times Timed Reminder alarm is tried. Selection Number of times: 1 through 5 Default 3 times Programming Enter 217. Display: Alarm Times Press NEXT. Display example: Attempt: 3 Enter the time.
Page 120: [21 8]Timed Reminder Alarm Interval Time
2.3 Timer Programming [218]Timed Reminder Alarm Interval Time Description Sets the Timed Reminder alarm interval time. Selection Time (seconds): 30 through 240 Default 60 s Programming Enter 218. Display: Alarm Interval Press NEXT. Display example: Interval: 60 sec Enter the time. To change the current entry, press CLEAR and enter the new time.
Page 121: [22 1]Disa Aa Wait Time
2.3 Timer Programming [221] DISA AA Wait Time Description Sets the number of seconds the system waits for a second digit entry. If the timer expires, the system assumes that the first digit is a DISA (Direct Inward System Access) built-in automated attendant number if assigned in progra mme [818]DISA Built-in Automated Attendant Number.
Page 122: Trs / Ars Programming
2.4 TRS / ARS Programming 2.4 TRS / ARS Programming [300] T RS Override for System Speed Dialling Description Allows you to enable toll restriction override for System Speed Dial Numbers. If this is enabled, all extension users can make System Speed Dialling calls with no restriction. Selection Enable / Disable Default...
Page 123: [301-3 05]Trs Denied Code Entry For Levels 2 Through 6
2.4 TRS / ARS Programming [301-305] T RS Denied Code Entry for Levels 2 through 6 Description These allow you to specify the numbers which are toll-restricted for each toll restriction level as follows: Programme [301]: restricts levels 2 through 6 Programme [302]: restricts levels 3 through 6 Programme [303]: restricts levels 4 through 6 Programme [304]: restricts levels 5 through 6...
Page 124 2.4 TRS / ARS Programming Conditions • There is a maximum of 20 toll call numbers which can be restricted for each programme. Each number has a maximum of seven digits, consisting of 0 through 9, and . The character ""...
Page 125: [306-3 10]Trs Excepted Code Entry For Levels 2 Through 6
2.4 TRS / ARS Programming [306-310] T RS Excepted Code Entry for Levels 2 through 6 Description These allow you to assign numbers which are exceptions to the toll restriction specified in programmes [301] through [305] as follows: Programme [306]: applies to level 2 Programme [307]: applies to levels 2 through 3 Programme [308]: applies to levels 2 through 4 Programme [309]: applies to levels 2 through 5...
Page 126 2.4 TRS / ARS Programming Conditions There is a maximum of five numbers for each programme. Each number has a maximum of seven digits, consisting of 0 through 9, and . The character " " can be used as a wild card character.
Page 127: [31 2]Ars Mode
2.4 TRS / ARS Programming [312] ARS Mode Description Allows you to turn on or off the Automatic Route Selection (ARS) mode. ARS, if enabled, selects the least expensive route to be used for an outside call. Selection On / Off Default Programming Enter 312.
Page 128: [31 3]Ars Time
2.4 TRS / ARS Programming [313] A RS Time Description Assigns times for the four Automatic Route Selection (ARS) time schedules. It is possible to split a day into four time zones (maximum) so that the least expensive line is selected for that time.
Page 129 2.4 TRS / ARS Programming Features Guide References Automatic Route Selection (ARS) General Programming...
Page 130: [314-3 21]Ars Leading Digit Entry For Plans 1 Through 8
2.4 TRS / ARS Programming [314-321] A RS Leading Digit Entry for Plans 1 through 8 Description By entering numbers into each leading digit plan (programmes below) you are starting the process to determine which outside line group will be used to route the call. Programme [314] [315]...
Page 131 2.4 TRS / ARS Programming Conditions Each number has a maximum of seven digits, consisting of 0 through 9, and . The character " " can be used as a wild card character. Features Guide References Automatic Route Selection (ARS) General Programming...
Page 132: [322-3 29]Ars Routing Plans 1 Through 8
2.4 TRS / ARS Programming [322-329] A RS Routing Plans 1 through 8 Description Assigns the outside line group and modification plan to be used for each route plan and time schedule. Programme [322] [323] [324] [325] [326] [327] [328] [329] Plan Selection...
Page 133 2.4 TRS / ARS Programming Press END. Conditions • Up to three outside line groups and modification plans can be assigned for each time schedule. The outside line group number and modification table number must be entered together. The highest priority outside line group number and modification table number is entered first (left to right).
Page 134: [33 0]Ars Modify Removed Digit
2.4 TRS / ARS Programming [330] A RS Modify Removed Digit Description Determines how the dialled number should be modified before transmitting to the central office. You can delete the digits from the beginning of the dialled number. Selection • Modification table number: 1 through 8 •...
Page 135: [33 1]Ars Modify Added Number
2.4 TRS / ARS Programming [331] ARS Modify Added Number Description Determines how the dialled number should be modified before transmitting to the central office. Assigned numbers are added to the beginning of the dialled number. Selection • Modification table number: 1 through 8 •...
Page 136: Outside Line Programming
Used to identify the outside lines which are connected to the system(s). This prevents users from originating a call to a line which is not connected. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 54, ( =all outside lines) • Connect / No Connect Default All outside lines –...
Page 137 2.5 Outside Line Programming • Outside lines 25 through 54 become available when the KX-TD290 expansion unit is installed in the KX-TD1232. • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01.
Page 138: [40 1]Outside Line Group Assignment
CO03 – TRG 3; CO04 – TRG 4; CO05 – TRG 5; CO06 – TRG 6; CO07 – TRG 7; CO08 – TRG 8 (for KX-TD816) CO08 through CO54 – TRG 8 (for KX-TD1232) Programming Enter 401. Display: Trunk Group Asn Press NEXT.
Page 139 2.5 Outside Line Programming Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • Outside lines 25 through 54 become available when the KX-TD290 expansion unit is installed in the KX-TD1232.
Page 140: [40 2]Dial Mode Selection
When dialling on the line with a touch tone telephone, only the pulse signals are sent to the outside line. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • DTMF / Pulse / C. Block (call blocking) Default All outside lines –...
Page 141 2.5 Outside Line Programming Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all lines to one selection, press the key in step 3.
Page 142: [40 3]Pulse Speed Selection
10 pps (low) and 20 pps (high). This programme sets the pulse speed for each outside line set to pulse or call blocking mode. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • 10 pps / 20 pps Default All outside lines –...
Page 143 2.5 Outside Line Programming • Programme [ 990]System Additional Information, Area 02 - bit 7, and bits 12 and 11 are used to select a pulse break ratio and inter-digit pause, if needed. Features Guide References Dial Type Selection General Programming...
Page 144: [40 4]Dtmf Time
Mode Selection can have two settings. This programme sets the duration of the DTMF signals sent to an outside line to DTMF mode. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Time (milliseconds): 80 / 160 Default All outside lines –...
Page 145 2.5 Outside Line Programming Features Guide References Dial Type Selection General Programming...
Page 146: [407-4 08]Dil 1:1 Extension - Day / Night
These programmes specify the extension number for day or night mode. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Extension number: 2 through 4 digits / Disable (no DIL 1:1) Default All outside lines –...
Page 147 2.5 Outside Line Programming • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01. • If an outside line is also programmed for DIL 1:N in programmes [ 603-604]DIL 1:N Extension and Delayed Ringing –...
Page 148: [409-4 10]Intercept Extension - Day / Night
2.5 Outside Line Programming [409-410] I ntercept Extension – Day / Night Description Intercept Routing provides an automatic re-direction of calls which cannot or have not been answered (IRNA: Intercept Routing – No Answer). These programmes set the destination in both day and night modes for each outside line group.
Page 149 2.5 Outside Line Programming Voice Mail extension numbers – [118] Voice Mail Extension Number Set Phantom extension numbers – [130] Phantom Extension Number Set Floating numbers (of External Pagers, DISA messages and extension groups only) – [81 3]Floating Number Assignment PS extension number –...
Page 150: [41 1]Host Pbx Access Codes
2.5 Outside Line Programming [411] H ost PBX Access Codes Description Assigns Host PBX access codes. If the system is installed behind a host PBX, an access code is required to make an outside call. Up to four codes can be stored for an outside line group assigned to the line.
Page 151 2.5 Outside Line Programming • There is a maximum of four access codes per outside line group. Each code has one or two digits, consisting of 0 through 9, and . • If conflicting access codes (such as 8 and 81) are stored for the same outside line group, the 1-digit code (8) only will be in effect.
Page 152: [41 2]Pause Time
2.5 Outside Line Programming [412]Pause Time Description Assigns the length of the pause time. The programmed pause time is automatically inserted after a line access number or a host PBX access code programme d in [411]Host PBX Access Codes or manually inserted if the PAUSE button is pressed by the user. Selection •...
Page 153: Flash Time
2.5 Outside Line Programming [413] Flash Time Description Assigns the length of the flash time. If your system is installed behind a host PBX, External Feature Access (EFA) is necessary to obtain their services. To enable it, select a required hooking signal sending time for the outside line group.
Page 154 2.5 Outside Line Programming • Programme [ 401]Outside Line Group Assignment is used to assign each outside line to an outside line group. Features Guide References External Feature Access Flash General Programming...
Page 155: Disconnect Time
2.5 Outside Line Programming [414] Disconnect Time Description Determines the amount of time between successive accesses to the same outside line. Selection • Outside line group (TRG) number: 1 through 8, ( =all outside line groups) • Time (seconds): 1.5 / 4.0 Default All outside line groups –...
Page 156: Outside Line Name Assignment
Assigns company or customer names to each outside line so that the operator or extension user can view the destination which the caller is trying to reach before answering. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 54, ( =all outside lines) • Name: 10 characters (max.) Default All outside lines –...
Page 157 2.5 Outside Line Programming • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01. Features Guide References Display Message Incoming Outside Call Information Display General Programming...
Page 158: Pay Tone Assignment
An optional Pay Tone Card (KX-TD189) must be installed on the CO Line Card to receive a Pay Tone. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Enable / Disable Default All outside lines –...
Page 159 2.5 Outside Line Programming Features Guide References Incoming Outside Call Information Display Hotel Application General Programming...
Page 160: Line Hunting Sequence
2.5 Outside Line Programming [441] L ine Hunting Sequence Description Assigns the hunting sequence of idle lines, seizing from the smallest to the largest line number or vice versa in an outside line group, on an outside line group basis. Selection •...
Page 161: Cos Programming
2.6 COS Programming 2.6 COS Programming [500-501]Toll Restriction Level – Day / Night Description Each extension must be assigned a Class of Service (COS). These programs set the toll restriction value for each COS in day or night mode. Selection •...
Page 162 2.6 COS Programming Features Guide References Night Service Toll Restriction General Programming...
Page 163: Extension-To-Outside Line Call Duration Limit
2.6 COS Programming [502] Extension-to-Outside Line Call Duration Limit Description This programme allows you to restrict the duration of outside calls on a Class of Service (COS) basis. Selection • COS number: 1 through 8, ( =all COS) • Disable (no limit) / Enable (limit) Default All COS –...
Page 164 2.6 COS Programming Features Guide References Call Forwarding Call Transfer Conference General Programming...
Page 165: Call Transfer To Outside Line
2.6 COS Programming [503] Call Transfer to Outside Line Description This programme determines which Classes of Services (COS) are allowed to perform the Call Transfer to Outside Line function. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS –...
Page 166: Call Forwarding To Outside Line
2.6 COS Programming [504] C all Forwarding to Outside Line Description This programme determines which Classes of Services (COS) are allowed to perform the Call Forwarding to Outside Line function. Selection • COS number: 1 through 8, ( =all COS) •...
Page 167: Executive Busy Override
2.6 COS Programming [505] Executive Busy Override Description Determines which Classes of Services (COS) are allowed to perform Executive Busy Override. Executive Busy Override allows the user to interrupt an established call. Selection • COS number: 1 through 8, ( =all COS) •...
Page 168: Executive Busy Override Deny
2.6 COS Programming [506] E xecutive Busy Override Deny Description This programme is used to determine which Classes of Services (COS) are allowed to den Executive Busy Override. Executive Busy Override Deny allows the user to prevent Executive Busy Override from being executed by another extension user. Selection •...
Page 169: Do Not Disturb Override
2.6 COS Programming [507] Do Not Disturb Override Description This programme determines which Classes of Services (COS) are allowed to perform Do Not Disturb (DND) Override. Selection • COS number: 1 through 8, ( =all COS) • Disable / Enable Default All COS –...
Page 170: Account Code Entry Mode
2.6 COS Programming [508] A ccount Code Entry Mode Description There are three account code modes: Option, Verified-All Calls and Verified-Toll Restriction Override. This programme determines the mode to be used by each Class of Service (COS). Option mode: The user can enter any account code, if needed. Verified –...
Page 171 2.6 COS Programming • Programme [ 105]Account Codes is used to define the Account Codes for the Verified modes. Features Guide References Account Code Entry Toll Restriction General Programming...
Page 172: Off-Hook Call Announcement (Ohca)
2.6 COS Programming [509] O ff-Hook Call Announcement (OHCA) Description This programme determines which Class of Service (COS) are allowed to perform the Off- Hook Call Announcement (OHCA) function. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS –...
Page 173: Extension Programming
(DPT). This programme assigns which jacks are XDP. The SLT and DPT of the programmed jack work as independent extensions. Selection • Jack number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all jacks) • Disable / Enable Default All jacks –...
Page 174 2.7 Extension Programming • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for Jack 01. • Immediately after changing your assignment, the changed setting may not work for a maximum of eight seconds.
Page 175: Class Of Service
Primary and secondary COS numbers can be assigned per extension. Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) ( =all jacks, -1 = first part, -2 = second part) •...
Page 176 2.7 Extension Programming Conditions • There is a maximum of eight Classes of Service. Every extension must be assigned to a Class of Service and is subject to the COS Programming of programmes [5XX] and [991]. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available.
Page 177: Extension Group Assignment
Assigns each extension to an extension group. Extension groups are used for Group Call Pickup, Station Hunting, and Paging – Group. Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) ( =all jacks, -1 = first part, -2 = second part) •...
Page 178 2.7 Extension Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • To assign all jacks to one extension group, press the key in step 3. In this case, the display shows the contents programmed for Jack 01.
Page 179: Dil 1:N Extension And Delayed Ringing - Day / Night
These programmes assign the extensions and the notification method for each outside line in both day and night modes. Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) ( =all jacks, -1 = first part, -2 = second part) •...
Page 180 2.7 Extension Programming Press END. Conditions • An extension can be assigned as the destination of as many outside lines as required. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable.
Page 181: Outgoing Permitted Outside Line Assignment - Day / Night
Determines the outside lines which can be accessed by an extension in both day and night modes. The extension users can make outgoing outside calls using the assigned outside lines. Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) ( =all jacks, -1 = first part, -2 = second part) •...
Page 182 2.7 Extension Programming Conditions • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.
Page 183: Doorphone Ringing Assignment - Day / Night
(-1 / -2) ( =all jacks, -1 = first part, -2 = second part) • Doorphone number: KX-TD816 – 1 and 2, two entries (max.) KX-TD1232 – 1 through 4, four entries (max.) Default Jack 01-1– All doorphones; Other jacks – no doorphone (Day / Night) Programming Enter a programme address (607 for day or 608 for night).
Page 184 • Two doorphones can be installed. For the KX-TD1232, doorphones 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available. • You can enter up to two (for KX-TD816) or four (for KX-TD1232) doorphone numbers for each extension.
Page 185: Voice Mail Access Codes
Information, Area 02 - bit 8 is set to "free". Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) (-1 = first part, -2 = second part) • Mailbox number: 16 digits (max.) Default All jacks –...
Page 186 2.7 Extension Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • The system supports a maximum of eight jacks (16 jacks during System Connection for KX-TD1232) for connection to a Voice Processing System as the Voice Mail or Automated Attendant ports.
Page 187: Incoming Call Display
Line Name: The outside line name assigned in the program me [417]Outside Line Name Assignment is displayed. Selection • Jack number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all jacks) • Display Types: Calling / Called / CO Line Nam Default All jacks –...
Page 188 2.7 Extension Programming Features Guide References Display Message Incoming Outside Call Information Display General Programming...
Page 189: Live Call Screening Recording Mode Assignment
Assigns whether to close the mailbox or keep recording the conversation after a call is intercepted. This programme is available when this system is connected to a Panasonic Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP200). Selection •...
Page 190 2.7 Extension Programming • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for jack 01. Features Guide References Voice Mail Integration for Digital Proprietary Telephones General Programming...
Page 191: Resource Programming
2.8 Resource Programming 2.8 Resource Programming [800] SMDR Incoming / Outgoing Call Log Printout Description Used to determine which calls will produce a Station Message Detail Recording (SMDR) printout. Selection • Outgoing calls: All (all calls) / Toll (toll calls only) / Off (no printing) •...
Page 192 2.8 Resource Programming Features Guide References Station Message Detail Recording (SMDR) General Programming...
Page 193: Smdr Format
2.8 Resource Programming [801] SMDR Format Description Used to match the SMDR output to the paper size being used in the printer. Page length determines the number of lines per page. Skip perforation determines the number of lines to be skipped at the end of every page.
Page 194: System Data Printout
2.8 Resource Programming [802] S ystem Data Printou Description Starts or stops printing the system data. All the current system-programmed data is printed out. Selection Start / Stop Default Not applicable. Programming Enter 802. Display: System Data Dump Press NEXT. Display: Print-out:Start Press STORE to start printing.
Page 195: Music Source Use
Press END. Conditions • The music source is a user-supplied item. For KX-TD816, one music source can be installed, for KX-TD1232, two music sources can be installed per system. Music sources 1 and 2 are connected to the Master System, 3 and 4 are to the Slave, if available. Any music source can be used by either system.
Page 196 2.8 Resource Programming Music Source 1 in programme [99 0 ]System Additional Information, Area 06 - Bits 11 and 10. • To disable music, press CLEA in steps 3 and 6. • Programme [ 804]External Pager BGM is used to enable / disable BGM for each external pager.
Page 197: External Pager Bgm
TD816, and two external pagers can be installed for KX-TD1232. • In the case of KX-TD816, please skip steps 6 and 7. • For the KX-TD1232, external pagers 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available.
Page 198 2.8 Resource Programming Features Guide References Background Music (BGM) General Programming...
Page 199: External Pager Confirmation Tone
Press END. Conditions The external pager is a user-supplied item. For KX-TD816, one external pager can be installed, for KX-TD1232, two external pagers can be installed per system. External pagers 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available.
Page 200: Serial Interface (Rs-232C) Parameters
2.8 Resource Programming [806-807] S erial Interface (RS-232C) Parameters Description Assigns the communication parameters for the Serial Interface (RS-232C) for Port 1 (for KX- TD816 and Master System of KX-TD1232) or Port 2 (for Slave System of KX-TD1232). New line code: Select the code for your printer or personal computer.
Page 201 2.8 Resource Programming Display example: Baud Rate:9600 Keep pressing SELECT until the desired selection is displayed. Press STORE. Press NEXT to programme word length. Display example: Word Lengt:8bits Keep pressing SELECT until the desired selection is displayed. Press STORE. Press NEXT to programme parity bit. Display example: Parity:Mark Keep pressing SELEC until the desired selection is displayed.
Page 202: Disa Security Type
2.8 Resource Programming [809] D ISA Security Type Description Assigns the security mode for outside calls attempted by the DISA (Direct Inward System Access) caller. There are two modes: Non Security and Trunk Security (outside line security). Non Security mode allows the caller to access an outside line without dialling a DISA user code.
Page 203: Disa Tone Detection
2.8 Resource Programming [810] DISA Tone Detection Description Enables or disables Tone Detection for outside-to-outside line calls via the Direct Inward System Access (DISA) feature. Enabling tone detection allows the system to detect the end of the call. Selection Enable / Disable Default Enable Programming...
Page 204: Disa / Tie User Codes
2.8 Resource Programming [811] D ISA / TIE User Codes Description Assigns the Direct Inward System Access (DISA) and TIE User Codes and a Class of Service (COS) to each code. The code COS determines the toll restriction level of the DISA and TIE caller.
Page 205 2.8 Resource Programming • Each code should be unique and composed of four through ten numerical digits, 0 through • You cannot leave an entry empty. Features Guide References Direct Inward System Access (DISA) E&M (TIE) Line Service General Programming...
Page 206: Disa Dtmf Repeat
2.8 Resource Programming [812] D ISA DTMF Repeat Description Selects whether the system transmits DTMF (Dual Tone Multi-Frequency) signals directly to the central office (CO) or if the system repeats the DTMF signals to CO in order to adjust gain. This can be done for an outside-to-outside line call via the Direct Inward System Access (DISA) feature during dialling and / or during an established call.
Page 207: Floating Number Assignment
2.8 Resource Programming [813] Floating Number Assignment Description Assigns the floating numbers for External Pagers, DISA (Direct Inward System Access) messages, modem, DTA (Digital Test Access) and extension groups. These numbers can be used in the same way extension numbers are used for station access. Selection •...
Page 208 To avoid making an invalid entry, check the other extension numbers. The default of each extension number is as follows: [003] Extension Number Set KX-TD816 – 101 through 116, 201 through 216 KX-TD1232 – 101 through 164, 201 through 264 [012] ISDN Extension Number Set Not stored.
Page 209: Modem Standard
2.8 Resource Programming [814] Modem Standard Description Assigns the modem standard. There are two standards available – BELL and CCITT Selection BELL / CCITT Default CCITT Programming Enter 814. Display: MODEM Standard Press NEXT. Display example: MODEM:CCITT Keep pressing SELECT until the desired selection is displayed. Press STORE.
Page 210: Smdr Output Mode
2.8 Resource Programming [815] S MDR Output Mode Description Assigns the SMDR Output Mode. There are two standards available – Regular and Charge. Selection Regular / Charge Default Regular Programming Enter 815. Display: SMDR Output Mode Press NEXT. Display example: SMDR:Regular Keep pressing SELECT until the desired selection is displayed.
Page 211: Kx-Td197 Baud Rate Set
2.8 Resource Programming [817] KX-TD197 Baud Rate Set Description Assigns the KX-TD197 standard. There are two standards available – BELL and CCITT-V.34. Selection BELL / V.34-9600 / V.34-14400 / V.34-19200 / V. 3 4-28800 / V.34-33600 Default V.34-33600 Programming Enter 817. Display: TD197 Type Press NEXT.
Page 212: Disa Built-In Automated Attendant Number
2.8 Resource Programming [818] D ISA Built-in Automated Attendant Number Description Assigns the DISA (Direct Inward System Access) built-in automated attendant (AA) number. The extension number and the floating number can be assigned as a one digit number and used as a DISA built-in automated attendant number.
Page 213: Optional Programming
2.9 Optional Programming 2.9 Optional Programming [990] System Additional Information Description Allows the following programming items to be changed, if required. Each bit in each Area represents a programming item. Chart for the Areas and Bits Bit Number 16 15 14 13 12 11 10 Display Example Area 01 Area 02 Area 03...
Page 214 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References Sound source during transfer 0 : ringback tone • Call Transfer 1 : Music on Hold • Music on Hold Result of pressing the hookswitch 0 : Consultation Consultation lightly and then placing down the Hold Hold...
Page 215 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References If an outside party is transferred and 0 : initiating Call Transfer unanswered, assigns whether Transfer extension Recall occurs at the transfer initiating 1 : Operator 1 extension or at Operator 1. If the restriction of outside call duration 0 : both calls None...
Page 216 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References An outside line set to pulse or call 0 : 60 Dial Type blocking mode in programme 1 : 67 Selection [402] Dial Mode Selection can have two settings. This assigns the pulse break ratio during dial pulsing.
Page 217 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References 1-16 These bits are provided to assign PAD 0 : 0 dB None Switch Control (volume control of 1 : -3 dB received calls on an outside line). This can be assigned for each outside line.
Page 218 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved In the day mode, selects the destination 0 : DIL 1:N • DDI of incoming DDI numbers or MSN 1 : operator • MSN Ringing numbers when "0" is assigned in Service programmes [151- 152]DDI Ringing Assignment –...
Page 219 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References Sets the time after terminating the 0 : 0 s • DISA OGM. 1 : 5 s • OGM Determines whether the account code is 0 : shown in dots SMDR printed out or not (shown in dots) by the 1 : shown...
Page 220 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References Enables or disables sending outside line 0 : enable E&M (TIE) Line access number "9" to a TIE line. When 1 : disable Service you dial outside line access number "9" and the outside line is busy, the system can automatically send outside line access number "9"...
Page 221 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved Allows to access an outside line has the 0 : enable Outside Line lowest number among idle lines with 1 : disable Access, priority. Automatic Reserved Selects the result when a DISA / DDI / 0 : reorder tone is None MSN / TIE call is invalid.
Page 222 2.9 Optional Programming Explanation Area Description Selection Default Feature Guide References Selects the bearer when using a 0 : 3.1k Audio ISDN proprietary telephone or DECT portable 1 : Speech station. Reserved Reserved Enables or disables the MCID service 0 : enable Malicious Call even after the caller hangs up.
Page 223 2.9 Optional Programming Conditions None Features Guide References None General Programming...
Page 224: Cos Additional Information
2.9 Optional Programming [991] C OS Additional Information Description Sets the number of digits allowed to dial out during an analogue outside call on a Class of Service (COS) basis. If an outside party hangs up and the extension user tries to dial out still on the outside line, the system will disconnect the line at the time the assigned number of digits are dialled.
Page 225 2.9 Optional Programming To change the current entry, press STORE and the new selection. To programme another bit, repeat steps 4 and 5. Press STORE. To programme another COS, press SELECT and the desired COS number. Repeat steps 4 through 8. Press END.
Page 226 2.9 Optional Programming General Programming...
Page 227: Isdn Programming
Section ISDN Programming ISDN Programming...
Page 228: Manager Programming
KX-TD1232 – 01 through 64 • Button Code (plus parameter, if required): Button Code Parameter 0 (Single-CO) KX-TD816: 01 through 08 (Outside line number) KX-TD1232: 01 through 54 (Outside line number) 1 (DSS) 2 through 4 digits (Extension number) 2 (One-Touch Dialling) 16 digits max.
Page 229 * Available when this system is connected to a Voice Processing System which supports digital proprietary telephone integration (e.g. KX-TVP200). Default KX-TD816: All jacks – CO buttons 1 through 8 = Single-CO 01 through 08; Ring tone type 2 Other CO buttons = Not stored KX-TD1232: All jacks –...
Page 230 3.1 Manager Programming Conditions • A centralised telephone is a telephone connected to jack 01 or a jack programmed as a manager extension in programme [006]Ope rator / Manager Extension Assignment. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available.
Page 231: [01 2]Isdn Extension Number Set
Description Assigns an extension number to each port which is connected to the ISDN S0 unit. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Extension Number: 2 or 3 digits Default All ports – Not stored Programming Enter 012.
Page 232 [130] Phantom Extension Number Set Not stored. [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 199, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 199, 291 through 294, 296 through 299 [671] PS Extension Number Set Not stored.
Page 233: [01 3]Isdn Extension Name Set
Assigns names to the ISDN extension numbers programmed in programme [012 ]ISD Extension Number Set. Selection • Port number: KX-TD816 – 01 through 06 KX-TD1232 – 01 through 12 • Name: 10 characters (max.) Default All ports – Not stored Programming Enter 013.
Page 234: Features Guide References
3.1 Manager Programming Features Guide References Integrated Services Digital Network (ISDN) Extension ISDN Programming...
Page 235: [01 4]Budget Management On Isdn Port
[014] Budget Management on ISDN Port Description Assigns the charge limitation of a call on the ISDN extension port basis. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Charge limitation (Charge): 0 through 59999 Default All ports –...
Page 236 3.1 Manager Programming • The displayed currency denomination can be programmed by [121]Assignment of Denomination. Features Guide References Budget Management Charge Fee Reference ISDN Programming...
Page 237: System Programming
3.2 System Programming 3.2 System Programming [100] Flexible Numbering Description Assigns the leading digits of extension numbers and feature numbers for system features. Feature Number List Number Feature Default 1st hundred extension block 2nd hundred extension block 03 - 16 3rd through 16th hundred extension block None Operator call...
Page 238 3.2 System Programming Feature Number List Number Feature Default External feature access Station feature clear Message waiting Outgoing message Call forwarding / Do not disturb Call pickup deny Data line security Call waiting / OHCA / Whisper OHCA Executive busy override deny Pickup dialling Absent message Timed reminder...
Page 239 3.2 System Programming Selection • Selection number: 01 through 89 (See "Feature Number List" for the corresponding features.) • Feature number: 1 or 2 digits (for selection numbers 01 through 16, 68 through 83); 1 through 3 digits (for selection numbers 17 through 67, 84 through 89) Default See "Feature Number List".
Page 240 3.2 System Programming Feature number type Required digits Valid entry Extension blocks / other 1 or 2 digits 0 through 9 PBX extensions TIE line access number 1 through 3 digits 0 through 9 Other feature numbers 1 through 3 digits 0 through 9, , # •...
Page 241 EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) / D (No Use) (Master system only: S3, E1 and E2 for the KX-TD144 or KX-TD146) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
Page 242 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / E&M) unit can be installed.
Page 243: [11 2]Isdn Network Type Assignment
3.2 System Programming [112] ISDN Network Type Assignment Description Assigns the type of ISDN network. Selection ISDN network mode: 000 through 255 Default Mode 8 Programming Enter 112. Display: Network Type Press NEXT. Display example: Mode 8 Enter an ISDN network mode. To change the current entry, press CLEAR and enter the new network mode.
Page 244: [15 0]Ddi Translation Table
3.2 System Programming [150] D DI Translation Table Description Assigns a destination location of incoming Direct Dialling In (DDI) numbers. Incoming DDI numbers are received at extensions assigned to each location number. Selection • Location number: 000 through 399 • DDI number: 16 digits max. Default All locations –...
Page 245 3.2 System Programming Features Guide References Direct Dialling In (DDI) Integrated Services Digital Network (ISDN) ISDN Programming...
Page 246: [151-1 52]Ddi Ringing Assignment - Day / Night
3.2 System Programming [151-152] D DI Ringing Assignment – Day / Night Description Assigns the destination of each Direct Dialling In (DDI) number in the day and night modes. Selection • Location number: 000 through 399 • Extension number: 2 through 4 digits / 0 (the same as [990] Area 5 – bits 7 and 8 assignments) Default All locations –...
Page 247 3.2 System Programming ISDN extension numbers – [01 2 ]ISDN Extension Number Set Voice Mail extension numbers – [118] Voice Mail Extension Number Set Phantom extension numbers – [130] Phantom Extension Number Set Floating numbers – [8 13]Floating Number Assignment PS extension number –...
Page 248: Isdn Line Programming
COLP (Connected Line Identification Presentation) feature offered by the ISDN network service. Selection • Outside line (CO) number: KX-TD816 – 01 through 08 KX-TD1232 – 01 through 54 • Telephone number: 16 digits (max.) Default All outside lines – Not stored Programming Enter 418.
Page 249 3.3 ISDN Line Programming • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To display parts of the number which have scrolled off the display, press or .
Page 250: [41 9]Isdn Outgoing Clir Service Assignment
If disabled, the subscriber's number of your system is informed to the called party. Selection • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 – 01 through 24, ( =all outside lines) • Enable / Disable Default All outside lines –...
Page 251 3.3 ISDN Line Programming Features Guide References Calling Line Identification Restriction (CLIR) ISDN Programming...
Page 252: [42 1]Isdn Ddi / Msn Removed Digit / Added Number Assignment
Assigns the removed digits and added number to a subscriber's number, and a DDI number sent from the network. Selection • Port number: KX-TD816 – 01 through 04, KX-TD1232 – 01 through 12, ( =all ports) • Removed digits: 0 through 16 (0=no deleting) •...
Page 253 3.3 ISDN Line Programming Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and port numbers 07 through 12 are for the Slave, if available. • Each added number has a maximum of four digits, consisting of 0 through 9. •...
Page 254: [42 4]Isdn Port Type
Press END. Conditions • For the KX-TD816, port numbers 05 and 06 are fixed as "Extension". • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available.
Page 255 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...
Page 256: [42 5]Isdn Layer 1 Active Mode
KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Permanent / Call Default KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent Programming Enter 425. Display: L1 Active Mode Press NEXT.
Page 257 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...
Page 258: [42 6]Isdn Configuration
KX-TD1232 – 01 through 12, ( =all ports) • Point (point to point) / Multipoint (point to multipoint) Default KX-TD816: Ports 05 and 06 – Multipoint; Other ports – Point KX-TD1232: All ports – Point Programming Enter 426. Display: Access Mode Press NEXT.
Page 259 3.3 ISDN Line Programming • After this assignment, you should reset the system to make this assignment is effective. Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...
Page 260: [42 7]Isdn Data Link Mode
KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Permanent / Call Default KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent Programming Enter 427. Display: Data Link Mode Press NEXT.
Page 261 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...
Page 262: [42 8]Isdn Tei Mode
KX-TD1232 – 01 through 12, ( =all ports) • Fix 0 through 63 / Automatic Default KX-TD816: Port 05 and 06 – Automatic; Other ports – Fix 0 KX-TD1232: All ports – Fix 0 Programming Enter 428. Display: TEI Assign Press NEXT.
Page 263 3.3 ISDN Line Programming • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01. • After this assignment, you should reset the system to make this assignment effective. Features Guide References Integrated Services Digital Network (ISDN) ISDN Programming...
Page 264: [42 9]Isdn Extension Multiple Subscriber Number
Selects whether the Multiple Subscriber Number (MSN) is allocated to each terminal equipment (e.g. ISDN telephone) on the ISDN S0 bus or not on an ISDN port basis. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Enable / Disable (no number) Default All ports –...
Page 265 3.3 ISDN Line Programming Features Guide References Multiple Subscriber Numbers (MSN) Ringing Service ISDN Programming...
Page 266: [43 0]Isdn Extension Progress Tone
Description Enables or disables to send the progress tone to ISDN extension on ISDN port basis. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Enable / Disable (no tone) Default All ports –...
Page 267 3.3 ISDN Line Programming Features Guide References Integrated Services Digital Network (ISDN) Extension ISDN Programming...
Page 268: [44 7]Msn Assignment
Description Assigns a maximum of ten Multiple Subscriber Numbers (MSN) on an ISDN port basis. Selection • Port number: KX-TD816 – 01 through 04 KX-TD1232 – 01 through 12 • Location number: 01 through 10 • MSN: 16 digits (max.) Default All ports –...
Page 269 3.3 ISDN Line Programming • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • This programme becomes available when "MSN" is selected in programme [452- 453] I SDN Ring Service Assignment –...
Page 270: [448-4 49]Extension Ringing Assignment - Day / Night For Isdn
Determines which extension receives a call on a MSN basis of the ISDN port in both the day and night modes. Selection • Port number: KX-TD816 – 01 through 04 KX-TD1232 – 01 through 12 • Location number: 01 through 10 • Extension number:...
Page 271 3.3 ISDN Line Programming Conditions • Each extension number can be 2 through 4 digits, consisting of 0 through 9. • When "0" is assigned, the incoming MSN number is sent to the destination assigned in programme [ 990]System Additional Information, Area 05 - bits 7 and 8. •...
Page 272: [45 0]Pri Configuration
3.3 ISDN Line Programming [450] P RI Configuration Description Assigns the number of B channels which are actually used out of the 30 PRI line channels. The CRC4 mode can be also assigned. This programme is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290).
Page 273: [45 1]Pri Reference Co
3.3 ISDN Line Programming [451] PRI Reference CO Description Assigns which outside line number system data each PRI line uses except for the following programmes: • [40 1]Outside Line Group Assignment • [41 7]Outside Line Name Assignment • [41 8]ISDN Line Number Assignment After assigning this programme, the following programme data will become available for PRI outside lines 25 through 54.
Page 274 3.3 ISDN Line Programming Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master system and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to the same selection, press the key in step 3.
Page 275: [452-4 53]Isdn Ring Service Assignment - Day / Night
[452-453] I SDN Ring Service Assignment – Day / Night Description Assigns the ISDN service type for each ISDN port. Selection • Port number: KX-TD816 – 01 through 04, KX-TD1232 – 01 through 12, ( =all ports) • DDI / MSN / Disable Default All ports –...
Page 276 3.3 ISDN Line Programming Multiple Subscriber Numbers (MSN) Ringing Service ISDN Programming...
Page 277: Extension Programming
A primary and a secondary COS numbers can be assiged per port. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • COS number: 1 through 8 Default All ports –...
Page 278 3.4 Extension Programming Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • There is a maximum of eight Classes of Services. Each ISDN extension must be assigned to a Class of Service and is subject to the COS Programming for programmes [5XX] and [991], bit 5.
Page 279 The extension users can make outgoing outside calls using the assigned outside lines. Selection • Port number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • Outside line (CO) number: KX-TD816 – 01 through 08, KX-TD1232 –...
Page 280 3.4 Extension Programming Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01.
Page 281: [61 7]Clip / Colp Number Assignment For Extension
[617] CLIP / COLP Number Assignment for Extension Description Assigns a CLIP/COLP number for each extension. Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2) KX-TD1232 – 01 through 64, (-1 / -2) ( =all jacks, -1 = first part, -2 = second part) •...
Page 282 3.4 Extension Programming Features Guide References Calling Line Identification Presentation (CLIP) Connected Line Identification Presentation (COLP) ISDN Programming...
Page 283: [61 8]Clip / Colp Number Assignment For Isdn Extension
[618] CLIP / COLP Number Assignment for ISDN Extension Description Assigns a CLIP/COLP number for each ISDN extension port. Selection • Jack number: KX-TD816 – 01 through 06, KX-TD1232 – 01 through 12, ( =all ports) • CLIP/COLP number: 16 digits (max.) Default All ports –...
Page 284 3.4 Extension Programming Features Guide References Calling Line Identification Presentation (CLIP) Connected Line Identification Presentation (COLP) ISDN Programming...
Page 285: Optional Programming
3.5 Optional Programming 3.5 Optional Programming [990] System Additional Information Description Allows the following programming items to be changed, if required. Each bit in each Area represents a programming item. Chart for the Areas and Bits Bit Number 16 15 14 13 12 11 10 Display Example Area 01 Area 02 Area 03...
Page 286 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References Sound source during transfer 0 : ringback tone • Call Transfer 1 : Music on Hold • Music on Hold Result of pressing the hookswitch 0 : Consultation Consultation lightly and then placing down the Hold Hold...
Page 287 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References If an outside party is transferred and 0 : initiating Call Transfer unanswered, assigns whether Transfer extension Recall occurs at the transfer initiating 1 : Operator 1 extension or at Operator 1. If the restriction of outside call duration 0 : both calls None...
Page 288 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References An outside line set to pulse or call 0 : 60 Dial Type blocking mode in programme 1 : 67 Selection [402] Dial Mode Selection can have two settings. This assigns the pulse break ratio during dial pulsing.
Page 289 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References 1-16 These bits are provided to assign PAD 0 : 0 dB None Switch Control (volume control of 1 : -3 dB received calls on an outside line). This can be assigned for each outside line.
Page 290 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved In the day mode, selects the destination 0 : DIL 1:N • DDI of incoming DDI numbers or MSN 1 : operator • MSN Ringing numbers when "0" is assigned in Service programmes [151- 152]DDI Ringing Assignment –...
Page 291 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References Sets the time after terminating the 0 : 0 s • DISA OGM. 1 : 5 s • OGM Determines whether the account code is 0 : shown in dots SMDR printed out or not (shown in dots) by the 1 : shown...
Page 292 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References Enables or disables sending outside line 0 : enable E&M (TIE) Line access number "9" to a TIE line. When 1 : disable Service you dial outside line access number "9" and the outside line is busy, the system can automatically send outside line access number "9"...
Page 293 3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved Allows to access an outside line has the 0 : enable Outside Line lowest number among idle lines with 1 : disable Access, priority. Automatic Reserved Selects the result when a DISA / DDI / 0 : reorder tone is None MSN / TIE call is invalid.
Page 294: M Programming
3.5 Optional Programming Explanation Area Description Selection Default Feature Guide References Selects the bearer when using a 0 : 3.1k Audio ISDN proprietary telephone or DECT portable 1 : Speech station. Reserved Reserved Enables or disables the MCID service 0 : enable Malicious Call even after the caller hangs up.
Page 295 3.5 Optional Programming Conditions None Features Guide References None ISDN Programming...
Page 296 3.5 Optional Programming ISDN Programming...
Page 297 Section E & M Programming E & M Programming...
Page 298: System Programming
4.1 System Programming 4.1 System Programming [100] F lexible Numbering Description Assigns the leading digits of extension numbers and feature numbers for system features. Feature Number List Number Feature Default 1st hundred extension block 2nd hundred extension block 03 - 16 3rd through 16th hundred extension block None Operator call...
Page 299 4.1 System Programming Feature Number List Number Feature Default External feature access Station feature clear Message waiting Outgoing message Call forwarding / Do not disturb Call pickup deny Data line security Call waiting / OHCA / Whisper OHCA Executive busy override deny Pickup dialling Absent message Timed reminder...
Page 300 4.1 System Programming Selection • Selection number: 01 through 89 (See "Feature Number List" for the corresponding features.) • Feature number: 1 or 2 digits (for selection numbers 01 through 16, 68 through 83); 1 through 3 digits (for selection numbers 17 through 67, 84 through 89) Default See "Feature Number List".
Page 301: [10 0]Flexible Numbering
4.1 System Programming Feature number type Required digits Valid entry Extension blocks / other 1 or 2 digits 0 through 9 PBX extensions TIE line access number 1 through 3 digits 0 through 9 Other feature numbers 1 through 3 digits 0 through 9, , # •...
Page 302 EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) / D (No Use) (Master system only: S3, E1 and E2 for the KX-TD144 or KX-TD146) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
Page 303 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / E&M) unit can be installed.
Page 304: [12 8]Pbx Code
4.1 System Programming [128] P BX Code Description Assigns the PBX Code as your location number if the "PBX Code method" is employed for TIE Line Network calling. Selection PBX Code: 1 through 3 digits Default Not stored Programming Enter 128. Display: PBX Code Press NEXT.
Page 305: [12 9]E&M Signal Assignment
4.1 System Programming [129] E&M Signal Assignment Description Assigns the E&M signal. There are three signals available: Continuous: Continuous E&M (Wink/Immediate) Pulsed Ans: Pulsed E&M with Answer Signal (Wink only) Pulsed No Ans: Pulsed E&M without Answer Signal (Wink only) Selection Continuous / Pulsed Ans / Pulsed No Ans Default...
Page 306: Timer Programming
4.2 Timer Programming 4.2 Timer Programming [220] T IE First / Inter Digit Time Description Assigns the maximum time allowed between the start of the dial tone and the first digit dialled (First Digit Time), and between digits (Inter Digit Time) on an TIE call. If an extension user fails to dial any digits during this time, the DTMF receiver is released.
Page 307: Tie Line Routing Table Programming
4.3 TIE Line Routing Table Programming 4.3 TIE Line Routing Table Programming [340] TIE Line Routing Table Description The TIE line routing table can be programmed. This table is referenced by the system to identify the outside line route, when an extension user makes a TIE call. A routing pattern appropriate for each call is decided by the first three digits (except the TIE line access number) of the dialled number.
Page 308 4.3 TIE Line Routing Table Programming Press END. Conditions • Each TIE line access number has a maximum of three digits, consisting of 0 through 9 and . The character "" can be used as a wild card character. • Programme [ 341]TIE Modify Removed Digit / Added Dial is used to modify the TIE line access number.
Page 309: [34 1]Tie Modify Removed Digit / Added Dial
4.3 TIE Line Routing Table Programming [341] TIE Modify Removed Digit / Added Dial Description Assigns the removed digits and added numbers of a received TIE call. Digits are removed and added from the beginning of the dialled digits. Selection •...
Page 310 4.3 TIE Line Routing Table Programming Features Guide References E&M (TIE) Line Service E & M Programming...
Page 311: Tie Line Programming
4.4 TIE Line Programming 4.4 TIE Line Programming [431] TIE Table Number Assignment Description Assigns a TIE table number to each outside line group. Selection • Outside line group (TRG) number: 1 through 8, ( =all outside line groups) • TIE table number: 1 through 4 Default All outside line groups –...
Page 312 4.4 TIE Line Programming Features Guide References E&M (TIE) Line Service E & M Programming...
Page 313: [43 2]Tie Incoming Assignment
4.4 TIE Line Programming [432] TIE Incoming Assignment Description Assigns the TIE incoming method, immediate or wink, to each TIE table according to your central office service. Immediate: Incoming TIE calls can be received right after the receiving signal arrives. Wink: Incoming TIE calls can be received after the wink signal is transmitted to the central office (after the receiving signal arrives).
Page 314: [43 3]Tie Outgoing Assignment
4.4 TIE Line Programming [433] T IE Outgoing Assignment Description Assings a TIE outgoing method, immediate or wink, to each TIE table according to your central office service. Immediate: Outgoing TIE numbers can be transmitted right after seizing the outside line. Wink: Outgoing TIE numbers can be transmitted after receiving the wink signal from the central office after seizing the outside line.
Page 315 4.4 TIE Line Programming Features Guide References E&M (TIE) Line Service E & M Programming...
Page 316: Tie Subscriber Number Removed Digit
4.4 TIE Line Programming [434] T IE Subscriber Number Removed Digit Description Assigns the removed digits of a received TIE subscriber number for each TIE table. In this case, digits are removed from the beginning of the received digits. Selection •...
Page 317: Tie Added Number
4.4 TIE Line Programming [435] TIE Added Number Description Assigns the added number to the TIE subscriber number which is determined in programme [43 4]TIE Subscriber Number Removed Digit. This makes the final number which serves as the extension number. Note that digits are inserted at the beginning of the number Selection •...
Page 318: Tie Wink Time Out Assignment
4.4 TIE Line Programming [436] T IE Wink Time Out Assignment Description The TIE outgoing method can be set to the wink mode in programme [ 433]TIE Outgoing Assignment. This programme sets the time the system waits for the confirmation wink signal after an outside line is seized according to your central office service.
Page 319 4.4 TIE Line Programming Features Guide References E&M (TIE) Line Service E & M Programming...
Page 320: Outside-To-Tie Transfer
4.4 TIE Line Programming [437] O utside-to-TIE Transfer Description Enables or disables transferring an incoming outside call to the TIE line on an outside line group basis. This restriction applies to the following: 1) A TIE call using DISA 2) Call Forwarding to a TIE line 3) Call Transfer to a TIE line.
Page 321: Tie-To-Outside Transfer
4.4 TIE Line Programming [438] TIE-to-Outside Transfer Description Enables or disables transferring TIE calls to an outside line on an outside line group basis. This restriction applies to the following: 1) An outside call through another PBX 2) Call Forwarding to an outside line 3) Call Transfer to an outside line.
Page 322: Tie-To-Tie Transfer
4.4 TIE Line Programming [439] T IE-to-TIE Transfer Description Enables or disables transferring TIE calls to a TIE line on an outside line group basis. This restriction applies to the following: 1) A TIE call through another PBX 2) Call Forwarding to a TIE line 3) Call Transfer to a TIE line.
Page 323: Tie Security Type
4.4 TIE Line Programming [440] TIE Security Type Description Assigns the security mode for TIE calls. There are two modes, Non Security and Trunk Security (Outside line security). Non Security mode allows the caller to access an outside line without dialling a TIE user code. Trunk Security mode requires the caller to enter a TIE User Code assigned in programme [811] D ISA / TIE User Codes before making a TIE call.
Page 324: Voice Path Type
Assigns the voice path type on an outside line basis. Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) • 2 wire / 4 wire Default All outside lines –...
Page 325: Voice Level (Transmit)
"4 wire". Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) • -6 db / -3 db / 0 db / +3 db Default All outside lines –...
Page 326: Voice Level (Receive)
"4 wire". Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) • -6 db / -3 db / 0 db / +3 db Default All outside lines –...
Page 327: Tie Receive Dial
DIL 1:1 or DIL 1:N. Selection • Outside line (CO) number: KX-TD816 – 05 through 08, KX-TD1232 – 09 through 12 (Master), 21 through 24 (Slave), ( =all outside lines) •...
Page 328: Resource Programming
4.5 Resource Programming 4.5 Resource Programming [811] D ISA / TIE User Codes Description Assigns the Direct Inward System Access (DISA) and TIE User Codes and a Class of Service (COS) to each code. The code COS determines the toll restriction level of the DISA and TIE caller.
Page 329 4.5 Resource Programming Conditions • This setting is required if Trunk (Outside line) Security mode is selected in programmes [44 0]TIE Security Type and [809 ]DISA Security Type. • Each code should be unique and composed of four through ten numerical digits, 0 through •...
Page 330: Optional Programming
4.6 Optional Programming 4.6 Optional Programming [990] S ystem Additional Information Description Allows the following programming items to be changed, if required. Each bit in each Area represents a programming item. Chart for the Areas and Bits Bit Number 16 15 14 13 12 11 10 Display Example Area 01 Area 02 Area 03...
Page 331 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References Sound source during transfer. 0 : ringback tone • Call Transfer 1 : Music on Hold • Music on Hold Result of pressing the hookswitch 0 : Consultation Consultation lightly and then placing down the Hold Hold...
Page 332 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References If an outside party is transferred and 0 : initiating Call Transfer unanswered, assigns whether Transfer extension Recall occurs at the transfer initiating 1 : Operator 1 extension or at Operator 1. If the restriction of outside call duration 0 : both calls None...
Page 333 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References An outside line set to pulse or call 0 : 60 % Dial Type blocking mode in programme 1 : 67 % Selection [402] D ial Mode Selection can have two settings.
Page 334 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References 1-16 These bits are provided to assign PAD 0 : 0 dB None Switch Control (volume control of 1 : -3 dB received calls on an outside line). This can be assigned for each outside line.
Page 335 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved In the day mode, selects the destination 0 : DIL 1:N • DDI of incoming DDI numbers or MSN 1 : operator • MSN Ringing numbers when "0" is assigned in Service programmes [151-1 52]DDI Ringing Assignment –...
Page 336 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References Sets the time after terminating the 0 : 0 s • DISA OGM. 1 : 5 s • OGM Determines whether the account code is 0 : shown in dots SMDR printed out or not (shown in dots) by the 1 : shown...
Page 337 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References Enables or disables sending outside line 0 : enable E&M (TIE) Line access number "9" to a TIE line. When 1 : disable Service you dial outside line access number "9" and the outside line is busy, the system can automatically send outside line access number "9"...
Page 338 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved Allows to access an outside line has the 0 : enable Outside Line lowest number among idle lines with 1 : disable Access, priority. Automatic Reserved Selects the result when a DISA / DDI / 0 : reorder tone is None MSN / TIE call is invalid.
Page 339 4.6 Optional Programming Explanation Area Description Selection Default Feature Guide References Selects the bearer when using a 0 : 3.1k Audio ISDN proprietary telephone or DECT portable 1 : Speech station. Reserved Reserved Enables or disables the MCID service 0 : enable Malicious Call even after the caller hangs up.
Page 340 4.6 Optional Programming Conditions None Features Guide References None E & M Programming...
Page 341: Dect Programming
Section DECT Programming DECT Programming...
Page 342: Manager Programming
# (Group-CO) 1 through 8 (Outside line group number) * Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic Voice Processing System (one that supports digital proprietary telephone integration; e.g. KX-TVP200). Default All PSs – CO 01 = Loop-CO; CO 02 and CO 03 = Not stored...
Page 343 5.1 Manager Programming Programming Enter 020. Display: PS Flexible Key Press NEXT. Display: PS NO? Enter the PS registration numbe . You can also keep pressing NEXT until the desired PS registration number is displayed. Display: PT-PGM Mode Press the CO button to be changed. The display shows the button pre-assignment.
Page 344: System Programming
5.2 System Programming 5.2 System Programming [100] F lexible Numbering Description Assigns the leading digits of extension numbers and feature numbers for system features. Feature Number List Number Feature Default 1st hundred extension block 2nd hundred extension block 03 - 16 3rd through 16th hundred extension block None Operator call...
Page 345 5.2 System Programming Feature Number List Number Feature Default External feature access Station feature clear Message waiting Outgoing message Call forwarding / Do not disturb Call pickup deny Data line security Call waiting / OHCA / Whisper OHCA Executive busy override deny Pickup dialling Absent message Timed reminder...
Page 346 5.2 System Programming Selection • Selection number: 01 through 89 (See "Feature Number List" for the corresponding features.) • Feature number: 1 or 2 digits (for selection numbers 01 through 16, 68 through 83); 1 through 3 digits (for selection numbers 17 through 67, 84 through 89) Default See "Feature Number List".
Page 347 5.2 System Programming Feature number type Required digits Valid entry Extension blocks / other 1 or 2 digits 0 through 9 PBX extensions TIE line access number 1 through 3 digits 0 through 9 Other feature numbers 1 through 3 digits 0 through 9, , # •...
Page 348 EXT1) / E2 (8 EXT2) / A1 (16 SLT1) / A2 (16 SLT2) / D (No Use) (Master system only: S3, E1 and E2 for the KX-TD144 or KX-TD146) Default KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 Programming KX-TD816 Enter 109.
Page 349 – A, A1, A2 (16-SLT lines): KX-TD174 • There are two expansion areas in the KX-TD816, areas 1 and 2 from bottom to top. One extension line unit and one outside line (CO / ISDN S0 / E&M) unit can be installed.
Page 350: Extension Programming
Selection (With a display PT) • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • PS extension number: 2 through 4 digits (With a PS) • DECT system number: 1 through 4 •...
Page 351 5.3 Extension Programming • (If disabled) Display: Rejected The Cell Station (CS) may not be connected or not working. After connecting the CS or resetting the PBX, wait for at least one minute and try again from the beginning. (With a PS) Slide the Power switch ON.
Page 352 5.3 Extension Programming Press the Auto/OK button. Display example: (if disabled): UNLOCKED (if enabled): ENTER PASSWORD If you select "ENABLE" in step 16, enter a System Lock password. Display: ENTER PASSWORD =**** Press the Auto/OK button. Display: REENTER PASSWORD Enter the System Lock password again. Display: REENTER PASSWORD =****...
Page 353 [130] Phantom Extension Number Set Not stored. [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 199, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 199, 291 through 294, 296 through 299 Features Guide References...
Page 354: Ps Termination
5.3 Extension Programming [651] P S Termination Description Deletes a stored PS so that it cannot be used in the system. Selection • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 Default Not applicable Programming Enter 651.
Page 355 5.3 Extension Programming You can also keep pressing NEXT until the desired PS registration number is displayed. Display example: PS01:EXT 281 Press STORE. Display: Rejected (The PS is not registered correctly.) The display will show the next example below in a few seconds. Display example: Delete? Go to Step 7 when not deleting.
Page 356: Ps Extension Name Set
Assigns names to the PS extension numbers programmed in progr amme [671]PS Extension Number Set. Selection • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • Name: 10 characters (max.) Default All PSs – Not stored Programming Enter 653.
Page 357: Sxdp Assignment
Disables or enables the Super EXtra Device Port (SXDP) feature for wired extensions. Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2), KX-TD1232 – 01 through 64 (-1 / -2), (-1= first part, -2= second part, =all jacks) •...
Page 358: Ps Budget Management
[655] P S Budget Management Description Assigns the charge limitation for a call on a PS basis. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • Charge limitation: 0 through 59999 Default All PSs –...
Page 359 5.3 Extension Programming Features Guide References Budget Management Charge Fee Reference DECT Programming...
Page 360: Ps Charge Verification Assignment
Assigns the PS which is allowed to refer or clear the charge information on the extension, outside line, account code, and total. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • Enable / Disable Default All PSs –...
Page 361: Ps Class Of Service
PS. Primary and secondary COS numbers can be assigned for each PS. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • COS number: 1 through 8 Default All PSs –...
Page 362 5.3 Extension Programming • To assign all PSs to one COS, press the key in step 3. In this case, the display shows the contents programmed for the PS which has the lowest PS registration number. Features Guide References Class of Service (COS) DECT Programming...
Page 363: Ps Extension Group Assignment
Assigns each PS to an extension group. Extension groups are used for Group Call Pickup. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • Extension group number: 1 through 8 Default All PSs –...
Page 364 5.3 Extension Programming Extension Group DECT Programming...
Page 365: Ps Dil 1:N Extension - Day / Night
PSs. This programme assigns the PSs for each outside line in both the day and night modes. Selection • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • Outside line number: KX-TD816 – 01 through 08, KX-TD1232 –...
Page 366 5.3 Extension Programming Conditions • To assign all outside lines to "Disable", press the key in step 4. In this case, the display shows the contents programmed for outside line 01. • When you change the PS registration number by pressing NEXT or PREV, the outside line number will not changed.
Page 367: Ps Outgoing Permitted Outside Line Assignment - Day / Night
Determines which outside lines can be accessed by a PS in both the day and night modes. PS users can make outgoing outside calls using the assigned outside lines. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • Outside line number: KX-TD816 –...
Page 368 5.3 Extension Programming Conditions • To assign all PSs or all outside lines to one selection, press the key in step 3 or 4. In this case, the display shows the contents programmed for outside line 01 or the PS 01. •...
Page 369: Ps Doorphone Ringing Assignment - Day / Night
Conditions • For the KX-TD1232, doorphone 1, 2 are installed in the Master System and 3, 4 in the Slave, if available. • You can enter two (KX-TD816) or up to four (KX-TD1232) doorphone numbers for each extension. DECT Programming...
Page 370 5.3 Extension Programming Features Guide References Door Opener Doorphone Call Night Service DECT Programming...
Page 371: Ps Voice Mail Access Codes
Assigns a mailbox number for each PS only if programme [990] System Additional Information, Area 02 - bit 8 , is set to "free". Selection • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • Mailbox number: 16 digits (max.) Default All PSs –...
Page 372 5.3 Extension Programming • To display parts of the mailbox number which have scrolled off the display, press or Features Guide References Voice Mail Integration for Inband DECT Programming...
Page 373: Ps Extension Number Set
[671] PS Extension Number Set Description Assigns an extension number to each PS. Selection • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • PS extension number: 2 through 4 digits Default All PSs – Not stored Programming Enter 671.
Page 374 Not stored. [813] Floating Number Assignment KX-TD816 – 191 through 194, 196, 198, 199, 291 through 294, 298, 299 KX-TD1232 – 191 through 194, 196 through 199, 291 through 294, 296 through 299 • Programme [ 653]PS Extension Name Set is used to name the PSs.
Page 375: Ps Password Set
Assigns a registration password, which is used for registration (programme [650]PS Registration), to each PS. Selection • PS registration number: KX-TD816 – 01 through 16 KX-TD1232 – 01 through 64 • PS password: 4 digits Default All PSs – 1234 Programming Enter 672.
Page 376: Clip / Colp Number Assignment For Ps
Description Assigns a CLIP / COLP number to each Portable Station. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • CLIP / COLP number: 16 digits (max.) Default All PSs –...
Page 377 5.3 Extension Programming Connected Line Identification Presentation (COLP) DECT Programming...
Page 378: Ps Incoming Call Display
Line Name: The outside line name assigned in the [417] programme is displayed. Selection • PS registration number: KX-TD816 – 01 through 16, KX-TD1232 – 01 through 64, ( =all PS registration numbers) • Display Types: Calling / Called / Line Name Default All PSs –...
Page 379 5.3 Extension Programming Features Guide References Display Message Incoming Outside Call Information Display DECT Programming...
Page 380: Cell Station Number Assignment For Master Cs
Selection • Cell Station number: KX-TD816 – RIF1 / RIF2 / RIF3 / RIF4 / RIF5 / RIF6 KX-TD1232 – E1-RIF1 / E1-RIF2 / E1-RIF3 / E1-RIF4 / E1-RIF5 / E1-RIF6 / E2-RIF1 / E2-RIF2 / E2-RIF3 / E2-RIF4 / E2-RIF5 / E2-RIF6...
Page 381: Ps Radio System Id Reference
5.3 Extension Programming [681] PS Radio System ID Reference Description Shows a radio system ID which is required for each PS to recognise its registered PBX. Selection None Default Not stored Programming Enter 681. Display: Radio Sys-ID SET Press NEXT. Before a Radio System ID is assigned;...
Page 382: Radio Information Data Clear
5.3 Extension Programming [682] R adio Information Data Clear Description Clears the assigned radio information data. Selection None Default Not applicable Programming Enter 682. Display: Radio DATA Clear Press NEXT. Display example: Clear OK? Press STORE. Press END. Conditions • The data, regarding following system programmings, is cleared; [65 0]PS Registration [67 2]PS Password Set Features Guide References...
Page 383: Optional Programming
5.4 Optional Programming 5.4 Optional Programming [990] System Additional Information Description Allows the following programming items to be changed, if required. Each bit in each Area represents a programming item. Chart for the Areas and Bits Bit Number 16 15 14 13 12 11 10 Display Example Area 01 Area 02 Area 03...
Page 384 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References Sound source during transfer 0 : ringback tone • Call Transfer 1 : Music on Hold • Music on Hold Result of pressing the hookswitch 0 : Consultation Consultation lightly and then placing down the Hold Hold...
Page 385 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References If an outside party is transferred and 0 : initiating Call Transfer unanswered, assigns whether Transfer extension Recall occurs at the transfer initiating 1 : Operator 1 extension or at Operator 1. If the restriction of outside call duration 0 : both calls None...
Page 386 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References An outside line set to pulse or call 0 : 60 Dial Type blocking mode in programme 1 : 67 Selection [402] Dial Mode Selection can have two settings. This assigns the pulse break ratio during dial pulsing.
Page 387 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References 1-16 These bits are provided to assign PAD 0 : 0 dB None Switch Control (volume control of 1 : -3 dB received calls on an outside line). This can be assigned for each outside line.
Page 388 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved In the day mode, selects the destination 0 : DIL 1:N • DDI of incoming DDI numbers or MSN 1 : operator • MSN Ringing numbers when "0" is assigned in Service programmes [151- 152]DDI Ringing Assignment –...
Page 389 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References Sets the time after terminating the 0 : 0 s • DISA OGM. 1 : 5 s • OGM Determines whether the account code is 0 : shown in dots SMDR printed out or not (shown in dots) by the 1 : shown...
Page 390 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References Enables or disables sending outside line 0 : enable E&M (TIE) Line access number "9" to a TIE line. When 1 : disable Service you dial outside line access number "9" and the outside line is busy, the system can automatically send outside line access number "9"...
Page 391 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References Reserved Allows to access an outside line has the 0 : enable Outside Line lowest number among idle lines with 1 : disable Access, priority. Automatic Reserved Selects the result when a DISA / DDI / 0 : reorder tone is None MSN / TIE call is invalid.
Page 392 5.4 Optional Programming Explanation Area Description Selection Default Feature Guide References Selects the bearer when using a 0 : 3.1k Audio ISDN proprietary telephone or DECT portable 1 : Speech station. Reserved Reserved Enables or disables the MCID service 0 : enable Malicious Call even after the caller hangs up.
Page 393 5.4 Optional Programming Conditions None Features Guide References None DECT Programming...
Page 394 5.4 Optional Programming DECT Programming...
Page 395: Default Values
Section Default Values Default Values...
Page 396 All speed dial numbers – Not stored [002] System Speed Dialling Name Set All speed dial numbers – Not stored [003] Extension Number Set KX-TD816: Jack 01-1 through 16-1 = 101 through 116; Jack 01-2 through 16-2 = 201 through 216 KX-TD1232: Jack 01-1 through 64-1 = 101 through 164;...
Page 397 1234 [108] One-Touch Transfer by DSS Button Enable [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 [113] VM Status DTMF Set RBT – 1; BT – 2; ROT – 3; DND – 4; Answer – 5;...
Page 398 Programme Default [119] Voice Mail Extension Group Assignment All voice mail numbers – EXG 1 [120] Charge Display Selection in Meter [121] Assignment of Denomination Not stored [122] Charge Verification Assignment All jacks – Enable [123] Charge Verification ID Code Set 1234 [124] Hotel Application Disable...
Page 399 Programme Default [209] Automatic Redial Repeat Times 10 times [210] Automatic Redial Interval Time 60 s [211] Dial Start Time 500 ms [212] Call Duration Count Start Time [213] DISA Delayed Answer Time 1 ring [214] DISA Prolong Time 3 min [215] Outgoing Message Tim 32, 0, 32, 0 (for OGM 1 through 4 from left to right) [216] Message Waiting Ring Interval Time...
Page 400 CO04 – TRG 4; CO05 – TRG 5; CO06 – TRG 6; CO07 – TRG 7; CO08 – TRG 8 (for KX-TD816) CO08 through CO54 – TRG 8 (for KX-TD1232) [402] Dial Mode Selection All outside lines – Pulse [403] Pulse Speed Selection All outside lines –...
Page 401 Programme Default [507] Do Not Disturb Override All COS – Disable [508] Account Code Entry Mode All COS – Option [509] Off-Hook Call Announcement (OHCA) All COS – Enable [600] EXtra Device Port All jacks – Disable [601] Class of Service All jacks-1/2 –...
Page 402 Bits 4, 3, 2 and 1: All COS – 0000 / Bit 5: All COS – 1 3 ISDN Programming Programme Default [005] Flexible CO Button Assignment KX-TD816: All jacks – CO buttons 1 through 8 = Single-CO 01 through 08; Ring tone type 2 Other CO buttons = Not stored KX-TD1232: All jacks –...
Page 403 [424] ISDN Port Type All ports – CO [425] ISDN Layer 1 Active Mode KX-TD816: Port 05 and 06 – Call; Other ports – Permanent KX-TD1232: All ports – Permanent [426] ISDN Configuration KX-TD816: Ports 05 and 06 – Multipoint; Other ports –...
Page 404 4 E & M Programming Programme Default [100] Flexible Numbering See "Feature Number List". [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 [128] PBX Code Not stored [129] E&M Signal Assignment Continuous [220] TIE First / Inter Digit Time...
Page 405 All PSs – CO 01 = Loop-CO; CO 02 and CO 03 = Not stored [100] Flexible Numbering See "Feature Number List". [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave – C;E1;E2 [650] PS Registration All PSs – Not stored [651] PS Termination...
Page 406 Programme Default [655] PS Budget Management All PSs – 0 [656] PS Charge Verification Assignment All PSs – Enable [657] PS Class of Service All PSs – Primary, Secondary – COS 1, COS 1 [658] PS Extension Group Assignment All PSs – Extension group 1 [659-660] P S DIL 1:N Extension –...
Page 407 Default Values...
Page 408: Index
Index Section 7 Index...
Page 409 Index Cell Station Number Assignment for Master CS AA (Automated Attendant) Characters Charge Display Selection AA hunting Charge limitation AA Service Charge Margin Rate Absent Messages Charge Verification Assignment Account button Charge Verification ID Code Set Account code Circular hunting Account Code Entry Class of Service (COS) Account Code Entry Mode...
Page 410 Index Direct Dialling In (DDI) External Pager Confirmation Tone EXtra Device Port (XDP) Direct In Lines (DIL) Direct Inward System Access (DISA) Feature numbers DISA (Direct Inward System Access) First Digit Time Flash DISA AA Wait Time FLASH button DISA Built-in Automated Attendant Flash Time DISA Built-in Automated Attendant Number Flexible CO Button Assignment...
Page 411 Index ISDN Port Type ISDN Ring Service Assignment – Day / Night NEXT button Night button ISDN Service button Night Service ISDN TEI Mode Off-Hook Call Announcement (OHCA) Jack number Off-Hook Monitor Jog Dial OGM (Outgoing Message) OHCA (Off-Hook Call Announcement) KX-TD144 One-Touch Dialling button KX-TD146...
Page 412 Index PS Class of Service Station Hunting PS Doorphone Ringing Assignment – Day / Station Hunting Type Night Station Message Detail Recording (SMDR) PS Extension Group Assignment PS Extension Name Set Station Speed Dialling PS Extension Number Set STORE button PS Flexible CO Button Assignment Super EXtra Device Port (SXDP) PS Incoming Call Display...
Page 413 Index Unit location Unit Type User Password User Programming Verified – All Calls mode Verified – Toll Restriction Override mode VM Command DTMF Set VM hunting VM Service VM Status DTMF Set Voice Level (Receive) Voice Level (Transmit) Voice Mail (VM) Service Voice Mail Access Codes Voice Mail Extension Voice Mail Extension Group...
