Table of Contents

Advertisement

Quick Links

Download this manual See also: Feature Manual, Programming Manual
Panasonic Telephone Systems
KX-TD1232
www.voicesonic.com
Phone: 877-289-2829
KX-TD816
Digital Super Hybrid System

Programming Guide

Panasonic KX-TD1232, KXTD1232, KX TD1232, TD1232, KX-TD816, KXTD816, KX TD816, TD816
Please read this manual before connecting the Digital Super Hybrid System.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TD1232

Summary of Contents for Panasonic KX-TD1232

  • Page 1: Programming Guide

    Panasonic Telephone Systems KX-TD1232 www.voicesonic.com Phone: 877-289-2829 KX-TD816 Digital Super Hybrid System Programming Guide Panasonic KX-TD1232, KXTD1232, KX TD1232, TD1232, KX-TD816, KXTD816, KX TD816, TD816 Please read this manual before connecting the Digital Super Hybrid System.
  • Page 2 About the other manuals Along with this Programming Guide, the following manuals are available to help you install, know the available features and use the KX-TD816 / KX-TD1232 system: Installation Manual Provides instructions for installing the hardware and optional equipment.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1 General Programming Instructions ..........9 1.1 General Programming Instructions................10 1.2 Using Proprietary Telephones ..................11 1.3 Programming Methods ....................15 1.4 Entering Characters.....................17 1.5 User Programming Mode ....................22 1.6 Programming Example ....................23 2 General Programming ..............27 2.1 Manager Programming ....................28 [000] Date and Time Set.......................28 [001] System Speed Dialing Number Set ................30...
  • Page 4 Table of Contents [122] UCD Overflow......................93 [123] UCD Time Table ......................95 [124] Phantom Extension Number Assignment ..............97 [125] Area Code Assignment ....................99 [126] Caller ID Modification for Local Call ..............101 [127] Caller ID Modification for Long Distance Call............103 [128] PBX Code ........................
  • Page 5 Table of Contents [331] ARS Modify Added Number..................160 [332] Extra Entry Table Selection ..................161 [333] TRS Entry Code Assignment for Extra Table ............162 [334] Emergency Dial Number Set ..................163 [340] TIE Line Routing Table ....................164 [341] TIE Modify Removed / Added Digit................166 2.5 Outside Line Programming ..................168 [400] Outside Line Connection Assignment ..............168 [401] Outside Line Group Assignment ................170...
  • Page 6 Table of Contents [461] PRI Line Coding Assignment .................. 244 [462] PRI Frame Sequence Assignment................245 [463] PRI Timer 1 and Timer 2 Assignment ..............246 [464] PRI Inter Digit Timer 1 Assignment................ 248 [465] PRI Inter Digit Timer 2 Assignment................ 249 [466] PRI Dial Counter for Inter Digit Timer 2 Assignment ..........
  • Page 7 Table of Contents [712] T1 First Dial Timer (DID / TIE)................311 [713] T1 %Break ........................312 [714] T1 Dial Click Tone ....................313 [715] T1 Inter Digit Pause....................314 [716] T1 Flash Detection....................315 [717] T1 Answer Decision Timer..................316 [718] T1 Break Detection....................317 [719] T1 Pulse Type ......................318 [720] T1 TIE Ringing Service....................319 [721] T1 / PRI Reference CO.....................321...
  • Page 8 Table of Contents Programming Guide...

  • Page 9: General Programming Instructions

    General Programming Instructions Section 1 General Programming Instructions Programming Guide...

  • Page 10: General Programming Instructions

    General Programming Instructions 1.1 General Programming Instructions Default Setting This system has a default factory setting. If any of the programming needs to be changed, you will find the necessary information in the Features Guide. This makes the system very simple to install and customize as required by the customer.

  • Page 11: Using Proprietary Telephones

    General Programming Instructions 1.2 Using Proprietary Telephones Soft Buttons and SHIFT Button on the Display DPT Three soft buttons are provided just below the display on the display of Digital Proprietary Telephones (DPT), KX-T7433, KX-T7436, KX-T7230 and KX-T7235. The functions of these soft buttons vary as the programming procedures advance step by step.
  • Page 12 General Programming Instructions Type 5 Press SHIFT to alternate SKP+ SEL NEXT SKP- CLR PREV Soft 1 Soft 2 Soft 3 SHIFT Soft 1 Soft 2 Soft 3 SHIFT You can use either the soft buttons or the overlay buttons. (For overlay buttons, refer to "Using the Overlay"...
  • Page 13 General Programming Instructions Location of Controls with the Overlay The pictures below show the functions of the buttons of the KX-T7433, KX-T7436, KX-T7230 and KX-T7235 while in programming mode. KX-T7431 is the same as KX-T7433 except for the Soft and SHIFT buttons. KX-T7433 KX-T7436 Soft-1...
  • Page 14 General Programming Instructions Viewing the Display The display gives you helpful information, such as what you should do now, what you have done, etc. The KX-T7433, KX-T7436, KX-T7230 and the KX-T7235 utilize two information lines for programming. The upper line is called the Message Line and the lower one is called the Function Line.

  • Page 15: Programming Methods

    General Programming Instructions 1.3 Programming Methods Advancing to the next stage When "SYS-PGM NO? " is displayed, you can select one of the following: • To go to program [000], press the NEXT button. • To go to another program, enter the 3-digit program address. Rotation of jack number Each jack of the Digital Super Hybrid System supports the connection of a digital proprietary telephone and a single line device with different extension numbers (eXtra Device Port: XDP...
  • Page 16 General Programming Instructions Going to another program address After pressing STORE, you can go to another program with either of the following two methods: To go to the next larger program address: Press Soft 1 (SKP+) or VOLUME (DOWN). To go to the next smaller program address: Press SHIFT + Soft 1 (SKP—) or VOLUME (UP).

  • Page 17: Entering Characters

    General Programming Instructions 1.4 Entering Characters Entering Characters You can enter characters to store names or messages in the following programs by using the dialing key pad, buttons or the Jog Dial. [002] System Speed Dialing Name Set [004] Extension Name Set [008] Absent Messages [013] ISDN Extension Name Set [014] VM Name Set...
  • Page 18 General Programming Instructions Combination Table a SHIFT & SHIFT SHIFT SHIFT SHIFT SHIFT Soft + S1 + S2 + S3 Combination SHIFT SHIFT + S1 + S2 Pressing SELECT (Times) Keys & Combination Table b Rotating Jog Dial (Pulses) Keys <...
  • Page 19 General Programming Instructions Please see the following example which shows how to select a desired character. For example, to select the letter "M": Select either of the following three methods: Using the SHIFT and Soft buttons (for KX-T7433 / KX-T7436 / KX-T7230 / KX-T7235 only) * See Combination Table a.
  • Page 20 General Programming Instructions Press SHIFT. Press Soft 3 (i) Enter 5 Press Soft 2 (k) Enter 3 Mik3 Press Soft 2 (e) Mike Using method (2) * See Combination Table a. The display shows: 1. Enter 6. 2. Press SELECT. 3.
  • Page 21 General Programming Instructions The display shows: 2. Rotate Jog Dial one pulse. 3. Enter 4. 4. Rotate Jog Dial six pulse. 5. Enter 5. 6. Rotate Jog Dial four pulses. 7. Enter 3. Mik3 8. Rotate Jog Dial four pulses. Mike The display shows: 1.

  • Page 22: User Programming Mode

    General Programming Instructions 1.5 User Programming Mode User Programming Mode Some programming items are accessible by any display proprietary telephone user in the system. The programming items are listed below: [000] Date and Time Set [001] System Speed Dialing Number Set [002] System Speed Dialing Name Set [003] Extension Number Set [004] Extension Name Set...

  • Page 23: Programming Example

    General Programming Instructions 1.6 Programming Example Programming Example The following programming instructions assume that you have already entered the programming mode and that you will employ method (2) of "Going to another program address" in Section 1.2 Using Proprietary Telephones. Example: Program [001] System Speed Dialing Number Set.
  • Page 24 General Programming Instructions Sample of Description Explanation 6. To program another speed dial (15) Select the best way for you to store another speed number, press NEXT or dial number. Pressing the NEXT / PREV allows PREV, or SELECT and the you to select the next higher / lower speed dial (15) desired speed dial number .
  • Page 25 General Programming Instructions Programming Structure Program Address Programming Group Description [5XX] COS Programming Setting of Class of Service (COS). [6XX] Extension Programming Setting of extension values. [7XX] T1 Programming Setting of T1 Line. [8XX] Resource Programming Assignment of customer-supplied peripherals connected to the system.
  • Page 26 General Programming Instructions Programming Guide...

  • Page 27: General Programming

    General Programming Section 2 General Programming Programming Guide...

  • Page 28: Manager Programming

    General Programming 2.1 Manager Programming [000] Date and Time Set NOTICE It is assumed that you have read Section "General Programming Instructions". Soft button usage is explained in that section, therefore no references will be made to them in the following instructions.
  • Page 29 General Programming Press Keep pressing SELECT until the desired day of the week is displayed. Press STORE. Press NEXT. Display example: 12:00 PM 24 Enter the hour. To change the current entry, press CLEAR and enter the new hour. Press Enter the minute.

  • Page 30: System Speed Dialing Number Set

    General Programming [001] System Speed Dialing Number Set Description Used to program the System Speed Dial numbers. These numbers are available to all extension users. There are 500 numbers available from 000 to 499. Selection • Speed dial number: 000 through 499 •...
  • Page 31 General Programming -To store a pause, press PAUSE. (Refer to Section "Pause Insertion, Automatic" in the Features Guide.) -To store a feature number to convert pulse signals to DTMF (Dual Tone Multi-Frequency) signals, press the and # keys. (Refer to Section "Pulse to Tone Conversion" in the Features Guide.) -To prevent displaying of all or part of the number, press SECRET before and after the secret number, or your entry will not be stored.

  • Page 32: System Speed Dialing Name Set

    General Programming [002] System Speed Dialing Name Set Description Assigns names to the system speed dial numbers assigned in program [001] System Speed Dialing Number Set. KX-T7235, KX-T7431, KX-T7433, and KX-T7436 telephones can show the stored name during System Speed Dialing. Selection •...
  • Page 33 General Programming Features Guide References Special Display Features — Call Directory Programming Guide...

  • Page 34: Extension Number Set

    [003] Extension Number Set Description Assigns an extension number to each extension. Note This programming should be performed before you connect a Panasonic Voice Processing System (VPS) because the VPS can create mailboxes automatically based on your extension plan (extension number set). Selection •...
  • Page 35 9. The and # keys cannot be used. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • An extension number is invalid if the first or second digits do not match with the program "[100] Flexible Numbering, (01) - (16) 1st through 16th hundred extension blocks"...

  • Page 36: Extension Name Set

    To program another jack, press NEXT or PREV, or SELECT and the desired jack number. Repeat steps 4 through 6. Press END. Conditions • There is a maximum of 32 names for KX-TD816, and 128 names for KX-TD1232. Each name has a maximum of 10 characters. Programming Guide...
  • Page 37 General Programming • Program [003] Extension Number Set is used to assign extension numbers. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • For an explanation of jack numbering, see "Rotation of jack number" in section 1.3 Programming Methods.

  • Page 38: Flexible Co Button Assignment

    • Button Code (plus parameter, if required): Button Code Parameter 0 (Single-CO) KX-TD816 - 01 through 08 (Outside line number) KX-TD1232 - 01 through 48 (Outside line number) 1 (DSS) 2 to 4 digits (Extension number) 2 (One-Touch) 16 digits max. (Telephone number)
  • Page 39 General Programming * Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic Voice Processing System (one that supports digital proprietary telephone integration; e.g., KX-TVS100). Default [KX-TD816] All jacks — CO buttons 1 through 8 = Single-CO 01 through 08; Ring tone type 2...
  • Page 40 General Programming • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable. • The number of the CO buttons available depends on the telephone type. (Refer to Buttons on Proprietary Telephones in the Feature Guide.) To program 24 CO buttons, use the...

  • Page 41: Operator / Manager Extension Assignment

    Conditions • Up to two operators and a manager can be programmed. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • The manager cannot be assigned the jack number of the DSS Console Port set in program [007] "DSS Console Port and Paired Telephone Assignment".
  • Page 42 General Programming • If the assigned jack is in eXtra Device Port mode, the proprietary telephone jack is treated as the manager / operator extension. • If there is no operator or manager, press CLEAR in step 3. Features Guide References Manager Extension Operator Programming Guide...

  • Page 43: Dss Console Port And Paired Telephone Assignment

    Selection • DSS Console number: KX-TD816 — 1 through 4 KX-TD1232 — 1 through 4 (for Master), 5 through 8 (for Slave) • Jack number for DSS Console: KX-TD816 — 02 through 16 KX-TD1232 — 02 through 32 (for Master), 33 through 64 (for Slave) •...
  • Page 44 General Programming Conditions • The jack number for the Console and that for the paired extension must be entered together. • Multiple DSS Consoles cannot be assigned to the same DSS Console jack. • Multiple DSS Consoles can be paired with the same proprietary telephone jack. •...

  • Page 45: Absent Messages

    General Programming [008] Absent Messages Description Used to program the absent messages. An absent message, if set by the station user, is displayed on the calling extension's telephone to show the reason for the user's absence. Selection • Message number: 1 through 9 •...
  • Page 46 General Programming Conditions • There is a maximum of nine messages. Messages 1 through 6 are programmed at the factory but can be changed. Each message has a maximum of 16 characters. • You can enter a maximum of seven "%" characters per message which can be programmed at each user's extension.

  • Page 47: Quick Dial Number Set

    General Programming [009] Quick Dial Number Set Description Stores up to eight quick dial numbers. Selection • Location number: 1 through 8 • Desired number: 16 digits (max.) Default All location numbers — Not stored Programming Enter 009. Display: 009 QUICK DIAL Press NEXT.

  • Page 48: Isdn Extension Number Set

    Assigns an extension number to each port which is connected to the ISDN unit. Selection • Port number: KX-TD816 — 01 through 04 KX-TD1232 — 01 through 12 • Extension Number: 2 or 3 digits Default All ports — Not stored Programming Enter 012.
  • Page 49 General Programming • Port numbers 01 through 06 are for the Master System, and 07 through 12 are for the Slave, if available. • An extension number is invalid if the first or second digit does not match with the setting in program [100] Flexible Numbering, 1st through 16th hundred extension blocks.

  • Page 50: Isdn Extension Name Set

    Assigns names to the ISDN extension numbers programmed in program [012] ISDN Extension Number Set. Selection • Port number: KX-TD816 — 01 through 04 KX-TD1232 — 01 through 12 • Name: 10 characters (max.) Default All ports — Not stored Programming Enter013.
  • Page 51 General Programming KX-TD816 KX-TD1232 ISDN Port No. TD382 TD384/ TD386 TD382 TD384/ TD386 Master Slave TD284 TD284 Jack 1 Jack 1 Jack 1 Jack 2 Jack 2 Jack 2 Jack 1 Jack 3 Jack 3 Jack 1 Jack 3 Jack 2...

  • Page 52: Vm Name Set

    Description Assigns a name for each voice mail port. Selection • Voice Mail (VM) number: KX-TD816 – 01 through 12 KX-TD1232 – 01 through 24 • Name: 10 characters (max.) Default All Voice Mails — V.Mailxx (xx=01 through 24) Programming Enter 014.

  • Page 53: Disa User Codes

    Assigns the Direct Inward System Access (DISA) User Codes and a Class of Service (COS) to each code. The COS of the code determines the toll restriction level of the DISA caller. This program is available for the KX-TD1232 only. Note Warning for the Direct Inward System Access Users When you enable the Outside –...
  • Page 54 General Programming Press to program COS. Enter a COS number. To change the current entry, enter the new COS number. Press STORE. To program another user code, press NEXT or PREV, or SELECT and the desired DISA user code number. Repeat steps 4 through 8.

  • Page 55: System Programming

    General Programming 2.2 System Programming [100] Flexible Numbering Description Assigns the leading digits of extension numbers and feature numbers for system features. Feature Number List Number Feature Default 1st hundred extension block 2nd hundred extension block 03 - 16 3rd through 16th hundred extension block None Operator call Automatic line access / ARS...
  • Page 56 General Programming Feature Number List Number Feature Default External feature access Station program clear Message waiting Outgoing message Call forwarding / do not disturb Call pickup deny Data line security Call waiting / OHCA / whisper OHCA Executive busy override deny Pickup dialing Absent message Timed reminder...
  • Page 57 General Programming Feature Number List Number Feature Default Other PBX Extension 03 None Other PBX Extension 04 None Other PBX Extension 05 None Other PBX Extension 06 None Other PBX Extension 07 None Other PBX Extension 08 None Other PBX Extension 09 None Other PBX Extension 10 None...
  • Page 58 General Programming Press NEXT. Display: Select NO? Enter a selection number. To enter selection number 01, you can also press NEXT. Display example: 01. 1-EXT BL:1 Enter the feature number. To delete the feature number, press CLEAR. To change the current entry, press CLEAR and enter the new number. Press STORE.
  • Page 59 General Programming Features Guide References Flexible Numbering Programming Guide...

  • Page 60: Day / Night Service Switching Mode

    General Programming [101] Day / Night Service Switching Mode Description This program is used to determine if night mode is set automatically or manually. Selection Manual / Auto (automatic) Default Manual Programming Enter 101. Display: 101 DAY / NT AUTO Press NEXT.

  • Page 61: Day / Night Service Starting Time

    General Programming [102] Day / Night Service Starting Time Description Sets the starting time on a day of the week basis, when automatic day / night switching is programmed in program [101] Day / Night Service Switching Mode. Selection • Day of the week selection number: 1 (Sunday) / 2 (Monday) /3 (Tuesday) / 4 (Wednesday) / 5 (Thursday) / 6 (Friday) / 7 (Saturday) / (every day of the week)
  • Page 62 General Programming To program another day / night mode or day of the week, press NEXT or PREV, or SELECT and the day of the week selection number. Repeat steps 4 through 10. Press END. Conditions • To select the desired day, you may keep pressing NEXT in step 3. To assign every day of the week to one selection, press the key in step 3.

  • Page 63: Automatic Access Outside Line Assignment

    General Programming [103] Automatic Access Outside Line Assignment Description Assigns the sequence in which outside line groups will be accessed when in Automatic Line Access mode. When a user dials the feature number for automatic line access (default=9) or presses the Loop-CO button, an idle line is searched for in the programmed outside line group order.

  • Page 64: Account Codes

    General Programming [105] Account Codes Description Assigns the account codes for Account Code Entry, Verified — All Calls and Verified — Toll Restriction Override modes. If Verified — All Calls is assigned in program [508] Account Code Entry Mode, an account code is required to make an outside call. If Verified — Toll Restriction Override is assigned, an account code is only required for a toll call and overrides toll restriction.
  • Page 65 General Programming Features Guide References Account Code Entry Toll Restriction Override by Account Code Entry Programming Guide...

  • Page 66: Station Hunting Type

    General Programming [106] Station Hunting Type Description Used to enable or disable hunting and set the Station Hunting type for each extension group. There are six Station Hunting types available: Circular, Terminating, Voice Mail (VM), Automated Attendant (AA), Ring Group and Uniform Call Distribution (UCD). If circular hunting is assigned for a group, all of the extensions in the group are searched until an idle one is found.
  • Page 67 • To assign all extension groups to one selection, press the key in step 3. In this case, the display shows the contents programmed for extension group 1. Features Guide References Ring Group Station Hunting Uniform Call Distribution (UCD) Voice Mail Integration Available for the KX-TD1232 only. Programming Guide...

  • Page 68: System Password

    General Programming [107] System Password Description Assigns the password required for entering System Programming mode and for maintenance from a personal computer. Warning The dealer should take care with the system password: Please thoroughly instruct the importance of the password and the dangers involved to the customer.
  • Page 69 General Programming • If less than four digits are entered, they are not stored. • You cannot leave the entry empty. Features Guide References System Programming and Diagnosis with Personal Computer System Programming with Proprietary Telephone Programming Guide...

  • Page 70: Automatic Hold By Co / Dss Button

    General Programming [108] Automatic Hold by CO / DSS Button Description Enables or disables automatically holding an outside call when a DSS (Direct Station Selection) button on the DSS Console or proprietary telephone, or a CO button on a proprietary telephone is pressed.

  • Page 71: Expansion Unit Type

    S6: 6-ISDN lines / PR: 1 PRI line / BD: 4-DID lines / T1: 24-T1 lines / E, E1: 8-Extension lines 1 / E2: 8-Extension lines 2) Default KX-TD816: C;E KX-TD1232: Master and Slave — C;E1;E2 Programming KX-TD816 Enter 109.
  • Page 72 /6-ISDN Line Unit or 4-DID Line Unit can be installed. • There are three expansion areas in each system for the KX-TD1232, areas 1, 2 and 3 from bottom to top. Up to two 8-Station Line Units or Extension Cards with SLT CID and one of 4-CO Line Unit, 2-/4-/6-BRI ISDN Line Unit, PRI ISDN Line Unit, T1 Line Unit or 4-DID Line Unit can be installed.

  • Page 73: Caller Id Code Set

    General Programming [110] Caller ID Code Set Description Sets the identification code of the calling party (Caller ID Code) to utilize a Caller ID Service provided by a specific central office (CO). If an ID Code transmitted from the CO is found in the Caller ID Code Table, the caller's ID Code or name given to the code in program [111] Caller ID Name Set is displayed on the telephone.
  • Page 74 General Programming • Program [406] Caller ID Assignment is used to enable the Caller ID Service on an outside line basis. Features Guide References Caller ID Programming Guide...

  • Page 75: Caller Id Name Set

    General Programming [111] Caller ID Name Set Description With Caller ID Service, the calling party is displayed either by its ID Code or by its name. If the name display is required, use this program to give a name to a caller ID Code stored in program [110] Caller ID Code Set.
  • Page 76 General Programming Features Guide References Caller ID Programming Guide...

  • Page 77: Network Type Assignment

    General Programming [112] Network Type Assignment Description Assigns the type of ISDN network. Selection NI1 (National ISDN1) / ATT Custom Default Programming Enter 112. Display: 112 SWITCH TYPE Press NEXT. Display example: NI1 Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 78: Vm Status Dtmf Set

    General Programming [113] VM Status DTMF Set Description Sets the DTMF (Dual Tone Multi-Frequency) signals transmitted to your Voice Processing System (VPS) to inform the VPS of the VPS ports states quickly: The following signals are sent to the VPS with the assigned DTMF signals: RBT (ringback tone): This signal is sent when calling an extension.
  • Page 79 General Programming Display example: RBT :1 Enter a DTMF signal number. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new number. Press STORE. To program another selection, keep pressing NEXT or PREV until the desired selection is displayed.

  • Page 80: Vm Command Dtmf Set

    General Programming [114] VM Command DTMF Set Description Sets the DTMF (Dual Tone Multi-Frequency) command signals transmitted to your Voice Processing System (VPS). There are four commands available: Leave Message; Get Message; Automated Attendant Service; Voice Mail Service. These commands are used in the following ways: (A) If your VPS is used for Voice Mail (VM) Service (1) Call Forwarding / Intercept Routing to Voice Mail...
  • Page 81 General Programming Programming Enter 114. Display: 114 VM DTMF CMD Press NEXT to program the LV-MSG command. To program another command, keep pressing NEXT until the desired command is displayed. Display example: LV-MSG:H Enter a DTMF signal number. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new number.

  • Page 82: Adjust Time

    General Programming [115] Adjust Time Description Used to adjust the time for checking the normality of system data. Every day at the programmed time, the data adjustment is performed. Selection • Hour: 1 through 12 • Minute: 00 through 59 •...

  • Page 83: Rom Version Display

    Confirms the version of ROM of the system. Display example: P011A30101A Version Date Selection System Number: KX-TD816 — 0 KX-TD1232 —0 (Master) / 1 (Slave) Default Not applicable. Programming Enter 116. Display: 116 ROM VERSION Press NEXT. Display: System NO? Enter the System Number.

  • Page 84: Voice Mail Number Assignment

    Description Assigns the jack number corresponding to the voice mail port for data transmission to the Voice Processing System. The voice mail port is expandable to six ports (12 ports during System Connection for KX-TD1232). Selection KX-TD816 • Jack number: 02 through 16 KX-TD1232 •...
  • Page 85 General Programming KX-TD1232 Enter 117. Display: 117 VMS PORT ASN Press NEXT to program the Master System. Display example: Mast1:# # # Enter a jack number. To delete the current entry, press CLEAR. To change the current entry, press CLEAR and enter the new jack number.

  • Page 86: Voice Mail Extension Number Assignment

    Assigns the extension number for the voice mail number. These numbers can be used the same way extension numbers are used for station access. Selection • Voice mail number (VM): KX-TD816 — 01 through 12 KX-TD1232 — 01 through 24 • Extension Number: 2 to 4 digits Default KX-TD816 —...
  • Page 87 General Programming Conditions • For the KX-TD1232, VM-01 through VM-12 are for the Master system and VM-13 through VM-24 are for the Slave system, if available. • You cannot leave an entry empty. • Double entry and incompatible entry for these numbers are invalid. Valid entry example: 10 and 11, 10 and 110.

  • Page 88: Voice Mail Extension Group Assignment

    Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, VM-01 through VM-12 are for the Master system and VM-13 through VM-24 are for the Slave system, if available. • The display shows "VM-XX:#YY-1:EXG Z" in step 3.
  • Page 89 General Programming "-1" of YY-1 means the first part of the jack number in digital line. "YY-2" means the second part of the jack number in digital line. • To assign all voice mail numbers to one selection, press the key in step 3.

  • Page 90: User Password

    General Programming [120] User Password Description Assigns the password required for entering the User Programming mode. In the User Programming Mode, any display digital proprietary telephone user in the system can set the following programs: [000] Date and Time Set [001] System Speed Dialing Number Set [002] System Speed Dialing Name Set [003] Extension Number Set...
  • Page 91 General Programming Features Guide References User Programming (Manager Programming) Programming Guide...

  • Page 92: Walking Cos Password

    General Programming [121] Walking COS Password Description Assigns the password required for Walking COS. Selection Password: 4 through 7 digits Default 1234 Programming Enter 121. Display: 121 COS PASSWORD Press NEXT. Display example: Password:1234 Enter a password. To change the current entry, press CLEAR and enter the new password. Press STORE.

  • Page 93: Ucd Overflow

    General Programming [122] UCD Overflow Description Assigns the destination where the call is transferred to when all extensions in the Uniform Call Distribution (UCD) group are busy. The Time Table number of the overflow extension must also be assigned. Selection •...
  • Page 94 General Programming Features Guide References Uniform Call Distribution (UCD) Programming Guide...

  • Page 95: Ucd Time Table

    Keep pressing SELECT until the desired selection is displayed. Display example: 1:S4 Press Repeat steps 4 and 5. Available for the KX-TD1232 only. Top or second can be selected by program [991] COS Additional Information, COS 3 – Bit 12-15. Programming Guide...
  • Page 96 General Programming Press STORE. Press END. Conditions • "Sx" can be assigned to a space other than the first only when another "Sx" is assigned in the first space. • An assignment after "TR", "RT" or "Blank" is not available. Features Guide References Ring Group Uniform Call Distribution (UCD)

  • Page 97: Phantom Extension Number Assignment

    General Programming [124] Phantom Extension Number Assignment Description Assigns the phantom extension numbers. Each number will be assigned to a flexible CO or DSS (Direct Station Selection) button and used as a Phantom Extension button. Selection • Location number: 001 through 128 •...
  • Page 98 General Programming [003] Extension Number Set, [012] ISDN Extension Number Set, [118] Voice Mail Extension Number Assignment and [813] Floating Number Assignment. Features Guide References Phantom Extension Programming Guide...

  • Page 99: Area Code Assignment

    General Programming [125] Area Code Assignment Description Assigns up to ten area codes which are necessary when using the Caller ID feature. By assigning your area code, the system records the caller's phone number modified by programs [126] Caller ID Modification for Local Call and [127] Caller ID Modification for Long Distance Call.
  • Page 100 General Programming Call Log, Incoming Programming Guide...

  • Page 101: Caller Id Modification For Local Call

    General Programming [126] Caller ID Modification for Local Call Description Assigns removed digits from the received caller's number of a local call, and adds number to make the final number which serves as the Caller ID number. The system records the modified caller's number to the incoming call log list so that the extension user can call back the caller.
  • Page 102 General Programming • There are ten location numbers for modified numbers, which corresponds to those in program [125] Area Code Assignment. Features Guide References Caller ID Call Log, Incoming Programming Guide...

  • Page 103: Caller Id Modification For Long Distance Call

    General Programming [127] Caller ID Modification for Long Distance Call Description Assigns removed digits from the received caller's number of a long distance call, and adds number to make the final number which serves as the Caller ID number. The system records the modified caller's number to the incoming call log list so that the extension user can call back the caller.

  • Page 104: Pbx Code

    General Programming [128] PBX Code Description Assigns the PBX Code as your location number if the "PBX Code method" is employed for Tie Line Network calling. Selection • PBX Code: 1 to 3 digits Default Not Stored Programming Enter 128. Display: 128 PBX CODE Press NEXT.

  • Page 105: Message Waiting Control

    Assigns the data ports which communicate with the message waiting lamp adaptor (KX- TD194). Selection • Unit (TD194) number: KX-TD816 — 1 KX-TD1232 — 1 or 2 (for Master), 4 or 5 (for Slave) • Jack number: KX-TD816 — 02 through 16 KX-TD1232 — 02 through 64 Default All units —...
  • Page 106 • For the KX-TD1232, unit numbers 1 and 2 are for the Master system, and 4 and 5 are for the Slave system. Jack numbers 02 through 32 are for the Master system and 33 through 64 are for the Slave system.

  • Page 107: Message Waiting Lamp Assignment

    General Programming [131] Message Waiting Lamp Assignment Description Assigns the message waiting light pattern. Selection • Message waiting light pattern number: 1 through 12 Default Programming Enter 131. Display: 131 MW LAMP Press NEXT. Display: MW LAMP NO:1 Enter a message waiting light number. Display example: MW LAMP NO:12 Press STORE.
  • Page 108 General Programming • The available message waiting light patterns are as follows. Pattern 01 1.25 s Pattern 02 500 ms Pattern 03 250 ms Pattern 04 250 ms 250 ms Pattern 05 500 ms 500 ms 10±α s Pattern 06 250 ms 20±α...
  • Page 109 General Programming Features Guide References Message Waiting Programming Guide...

  • Page 110: Message Waiting Port Set

    Assigns which single line telephone port is connected to the KX-TD194 port. Selection • Unit (TD194) number: KX-TD816 — 1 KX-TD1232 — 1 or 2 (for Master), 4 or 5 (for Slave) • Message waiting port number: 01 through 16 • Single line telephone jack number: KX-TD816 —...
  • Page 111 • To program another unit, start from step 1. • For the KX-TD1232, the unit numbers 1 and 2 are for the Master system and 4 and 5 are for the Slave system, and jack numbers 01 through 32 are for Master system and 33 through 64 are for Slave system.

  • Page 112: Caller Id Extension Assignment

    Press END. Conditions • For the KX-TD1232, unit numbers 1 and 2 are for the Master system and 3 and 4 are for the Slave system. • The Caller ID information can only be sent to port 1 or 2 on the unit.
  • Page 113 General Programming Call information transferred by the Call Transfer, Screened — to Extension feature cannot be sent. However, when a call is transferred by the Call Transfer, Unscreened feature, the information can be sent to the destination extension. • When several incoming outside calls reach an extension and another extension user picks up one of the calls, Caller ID information can be sent to the extension.

  • Page 114: Hotel Application

    General Programming [134] Hotel Application Description Assigns whether the hotel application is enabled or disabled. Selection ON / OFF Default Programming Enter 134. Display: 134 HOTEL ON / OFF Press NEXT. Display example: HOTEL:OFF Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 115: Did Number Conversion Selection

    General Programming [135] DID Number Conversion Selection Description Selects whether the Direct Inward Dialing (DID) number is allocated as an extension number or is converted using the Transfer Table. Selection • EXT Number / Transfer Table Default Transfer Table Programming Enter 135.

  • Page 116: Did Number Assignment

    General Programming [136] DID Number Assignment Description Assigns the Direct Inward Dialing (DID) number which is converted from the DID subscriber number using the programs [433] DID / TIE Subscriber Number Removed Digit and [434] DID / TIE Added Number. If the converted number matches the number assigned in this program, it reaches the destination assigned in program [137-138] DID Extension ——...
  • Page 117 General Programming • To use this program, "Transfer Table" must be selected beforehand in program [135] DID Number Conversion Selection. Features Guide References Direct Inward Dialing (DID) Programming Guide...

  • Page 118: Did Extension -- Day / Night

    General Programming [137-138] DID Extension —— Day / Night Description Determines the extension which receive a Direct Inward Dialing (DID) call in both the day and night modes. Selection • Location number: 001 through 200 • Extension number: 2 to 4 digits / 0 (operator) Default All locations —...
  • Page 119 General Programming • To use this program, "Transfer Table" must be selected first in program [135] DID Number Conversion Selection, and then the DID number must be assigned in program [136] DID Number Assignment. Features Guide References Direct Inward Dialing (DID) Night Service Programming Guide...

  • Page 120: Did Extension Name Set

    General Programming [139] DID Extension Name Set Description Assigns names to the DID extension assigned in program [136] DID Number Assignment. Selection • Location number: 001 through 200 • Extension number: 10 characters (max.) Default All locations — Not Stored Programming Enter 139.

  • Page 121: Off-Hook Monitor

    General Programming [148] Off-Hook Monitor Description Enables or disables to perform the Off-Hook Monitor. Selection • Enable / Disable Default Enable Programming Enter 148. Display: 148 HOOK MONITOR Press NEXT. Display example: Monitor:Enable Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 122: Lunch Service Starting / Ending Time

    General Programming [150] Lunch Service Starting / Ending Time Description Sets the Lunch starting and ending time for each day of the week. Selection • Day of the week selection number: 1 (Sunday) / 2 (Monday) / 3 (Tuesday) / 4 (Wednesday) / 5 (Thursday) / 6 (Friday) / 7 (Saturday) / (every day of the week) •...
  • Page 123 General Programming Conditions • This programming can only be used if "Auto (automatic)" is selected in program [101] Day / Night Service Switching Mode. • Lunch service ends at the assigned time. For example: If Lunch service is 11:30 AM – 1:00 PM, Day mode starts at 1:01 PM. If Lunch service is 11:30 AM –...

  • Page 124: Break Service Starting / Ending Time

    General Programming [151] Break Service Starting / Ending Time Description Sets the Break starting and ending time for each day of the week. Selection • Day of the week selection number: 1 (Sunday) / 2 (Monday) / 3 (Tuesday) / 4 (Wednesday) / 5 (Thursday) / 6 (Friday) / 7 (Saturday) / (every day of the week) •...
  • Page 125 General Programming Conditions • This feature can only be used if "Auto (automatic)" is selected in program [101] Day / Night Service Switching Mode. • Break service ends at the assigned time. For example: If Break service is 3:00 – 4:00 PM, Day mode starts at 4:01 PM. If Break service is 3:00 –...

  • Page 126: Timer Programming

    General Programming 2.3 Timer Programming [200] Hold Recall Time Description Assigns the length of the hold recall timer. This timer is used to alert an extension that a call has been held for an extended period of time. Selection Time (seconds): 0 through 240 (0=Hold Recall disabled) Default 60 sec Programming...

  • Page 127: Transfer Recall Time

    General Programming [201] Transfer Recall Time Description Sets the number of rings before transfer recall occurs. If a transferred call is not answered after the programmed number of rings, the call returns to the original caller. Selection Number of rings: 0 through 48 (0=Transfer Recall disabled) Default 12 rings Programming...

  • Page 128: Call Forwarding - No Answer Time

    General Programming [202] Call Forwarding — No Answer Time Description Sets the number of rings for Call Forwarding — No Answer feature. If a call is not answered after the programmed number of rings, the call is forwarded to the destination. Selection Number of rings: 1 through 12 Default...

  • Page 129: Intercept Time

    General Programming [203] Intercept Time Description Sets the number of rings for Intercept Routing — No Answer (IRNA) feature. If a call is not answered after the programmed number of rings, the call is redirected to the programmed station. Selection Number of rings: 3 through 48 Default 12 rings...

  • Page 130: Pickup Dial Waiting Time

    General Programming [204] Pickup Dial Waiting Time Description Sets the number of seconds for Pickup Dialing. If the telephone user lifts the handset, the programmed party is called when the time expires. Selection Time (seconds): 1 through 5 Default 1 sec Programming Enter 204.

  • Page 131: Extension-To-Outside Line Call Duration Time

    General Programming [205] Extension-to-Outside Line Call Duration Time Description Sets the maximum time allowed for a conversation with an outside party. If an outside call is originated or answered by a programmed extension user and the timer expires, the call is disconnected.

  • Page 132: Outside-To-Outside Line Call Duration Time

    General Programming [206] Outside-to-Outside Line Call Duration Time Description Sets the maximum time allowed for a conversation between two outside parties. When the timer expires, the Outside-to-Outside Line call is disconnected. Selection Time (minutes): 1 through 64 Default 10 min Programming Enter 206.

  • Page 133: First Digit Time

    General Programming [207] First Digit Time Description Sets the maximum time allowed between the start of an outside dial tone and the first digit dialed on an outgoing outside call. If an extension user fails to dial any digits during this time, the DTMF (Dual Tone Multi-Frequency) receiver is released.

  • Page 134: Inter Digit Time

    General Programming [208] Inter Digit Time Description Assigns the maximum time allowed between digits on an outgoing toll call. If an extension user fails to dial any digits during this time, the DTMF (Dual Tone Multi-Frequency) receiver is released. This timer applies until the Toll Restriction check is completed. Selection Time (seconds): 5 through 30 Default...

  • Page 135: Dial Start Time

    General Programming [211] Dial Start Time Description Sets the number of milliseconds the system waits before dialing after an outside line is seized. Selection Time (milliseconds): 0 through 40 ( 100 is the actual time) Default 500 msec Programming Enter 211. Display: 211 DIAL START Press NEXT.

  • Page 136: Call Duration Count Start Time

    General Programming [212] Call Duration Count Start Time Description Sets the number of seconds the system waits between the end of dialing and the start of the Station Message Detail Recording (SMDR) timer for outgoing toll calls. When the system has sent out all the digits to the central office and this timer expires, the system starts counting the call.

  • Page 137: Disa Delayed Answer Time

    [213] DISA Delayed Answer Time Description Assigns the number of rings between a call received and the answer by the Direct Inward System Access (DISA) feature. This programming is available for the KX-TD1232 only. Selection Number of rings: 0 through 6 Default...

  • Page 138: Disa Prolong Time

    (except the key). This parameter, the "DISA Prolong Time", sets the duration of these extended periods. This programming is available for the KX-TD1232 only. Selection Time (minutes): 0 through 7 (0=no prolonging)

  • Page 139: Outgoing Message Time

    General Programming [215] Outgoing Message Time Description Sets the maximum allowable recording time for outgoing messages (OGM). This programming is available for the KX-TD1232 only. Selection Time (seconds): 0 / 16 / 32 / 64 (0=no recording) Default 32, 0, 32, 0 (for OGM 1 through 4 from left to right) Programming Enter 215.
  • Page 140 General Programming Features Guide References Direct Inward System Access (DISA) Outgoing Message (OGM) Timed Reminder Uniform Call Distribution (UCD) Programming Guide...

  • Page 141: Message Waiting Ring Interval Time

    General Programming [216] Message Waiting Ring Interval Time Description Sets the Message Waiting ring interval time for a single line telephone. Selection Time (minutes): 0 through 64 Default 0 min (no ring) Programming Enter 216. Display: 216 MW RING TIME Press NEXT.

  • Page 142: Timed Reminder Alarm Ring Time

    General Programming [217] Timed Reminder Alarm Ring Time Description Sets the number of seconds the Timed Reminder alarm rings. Selection Time (seconds): 30 through 240 Default 30 sec Programming Enter 217. Display: 217 TIMED REMIND Press NEXT. Display example: Reminder: 30sec Enter the time.

  • Page 143: Disa Aa Wait Time

    DISA (Direct Inward System Access) built-in auto attendant number if assigned in program [815] DISA Built-in Auto Attendant. This programming is available for the KX-TD1232 only. Selection Time (seconds): 1 through 5...

  • Page 144: Call Park Recall Time

    General Programming [219] Call Park Recall Time Description Sets the number of rings before Call Park Recall occurs. Call Park Recall is used to alert an extension that a call has been parked for an extended period of time. Selection Number of rings: 0 through 48 (0=Call Park Recall disabled) Default 12 rings...

  • Page 145: Tie First / Inter Digit Time

    General Programming [220] TIE First / Inter Digit Time Description Assigns the maximum time allowed between the start of the dial tone and the first digit dialed (First Digit Time), and between digits (Inter Digit Time) on a TIE call. If an extension user fails to dial any digits during this time, the DTMF receiver is released.

  • Page 146: Trs / Ars Programming

    General Programming 2.4 TRS / ARS Programming [300] TRS Override for System Speed Dialing Description Allows you to enable toll restriction override for System Speed Dial Numbers. If this is enabled, all extension users can make System Speed Dialing calls with no restriction. Selection Enable / Disable Default...

  • Page 147: Trs Denied Code Entry For Levels 2 Through 6

    General Programming [301-305] TRS Denied Code Entry for Levels 2 through 6 Description These allow you to specify the numbers which are toll-restricted for each toll restriction level as follows: Program [301]: restricts levels 2 through 6 Program [302]: restricts levels 3 through 6 Program [303]: restricts levels 4 through 6 Program [304]: restricts levels 5 through 6 Program [305]: restricts level 6...
  • Page 148 General Programming Conditions • There is a maximum of 20 toll call numbers which can be restricted for each program. Each number has a maximum of ten digits, consisting of 0 through 9, and . The character " " can be used as a wild card character. •...

  • Page 149: Trs Excepted Code Entry For Levels 2 Through 6

    General Programming [306-310] TRS Excepted Code Entry for Levels 2 through 6 Description These allow you to assign numbers which are exceptions to the toll restriction specified in programs [301] through [305] as follows: Program [306]: applies to level 2 Program [307]: applies to levels 2 through 3 Program [308]: applies to levels 2 through 4 Program [309]: applies to levels 2 through 5...
  • Page 150 General Programming Conditions There is a maximum of five numbers for each program. Each number has a maximum of ten digits, consisting of 0 through 9, and . The character " " can be used as a wild card character. Features Guide References Toll Restriction Programming Guide...

  • Page 151: Special Carrier Access Codes

    General Programming [311] Special Carrier Access Codes Description Assigns special carrier numbers. This allows the system to recognize the user-dialed special carrier number in order to insert the required pause and apply toll restriction. Selection • Location number: 01 through 20 •...

  • Page 152: Ars Mode

    General Programming [312] ARS Mode Description Allows you to turn on or off the Automatic Route Selection (ARS) mode. ARS, if enabled, selects the least expensive route to be used for an outside call. Selection On / Off Default Programming Enter 312.

  • Page 153: Ars Time

    General Programming [313] ARS Time Description Assigns times for the four Automatic Route Selection (ARS) time schedules. It is possible to split a day into four time zones (maximum) so that the least expensive line is selected for that time. According to the service hours and charges offered by your carriers, enter the starting time of each zone.
  • Page 154 General Programming Repeat steps 4 through 8. Press END. Conditions • Enter a starting time for each time schedule. Select "Disable" for idle schedules. • You cannot leave an entry empty. • To assign all days of the week, press the key in step 3.

  • Page 155: Ars Leading Digit Entry For Plans 1 Through 8

    General Programming [314-321] ARS Leading Digit Entry for Plans 1 through 8 Description By entering numbers into each leading digit plan (programs below) you are starting the process to determine which outside line group will be used to route the call. Program [314] [315]...
  • Page 156 General Programming Conditions Each number has a maximum of ten digits, consisting of 0 through 9, and . The character " " can be used as a wild card character (i.e., "do not care" digit). The system scans all the ARS Leading Digit Plans simultaneously from left to right.

  • Page 157: Ars Routing Plans 1 Through 8

    General Programming [322-329] ARS Routing Plans 1 through 8 Description Assigns the outside line group and modification plan to be used for each route plan and time schedule. Program [322] [323] [324] [325] [326] [327] [328] [329] Plan Selection • Time schedule: A / B / C / D •...
  • Page 158 General Programming Press END. Conditions • Up to three outside line groups and modification plans can be assigned for each time schedule. The outside line group number and modification table number must be entered together. The highest priority outside line group number and modification table number is entered first (left to right).

  • Page 159: Ars Modify Removed Digit

    General Programming [330] ARS Modify Removed Digit Description Determines how the dialed number should be modified before transmitting to the central office. You can delete the digits from the beginning of the dialed number. Selection • Modification table number: 1 through 8 •...

  • Page 160: Ars Modify Added Number

    General Programming [331] ARS Modify Added Number Description Determines how the dialed number should be modified before transmitting to the central office. Assigned numbers are added to the beginning of the dialed number. Selection • Modification table number: 1 through 8 •...

  • Page 161: Extra Entry Table Selection

    General Programming [332] Extra Entry Table Selection Description Selects the code table which enables an extra 400 entries within Denied or Except Code Table. Selection • Deny / Except • Level number: 2 through 6 Default Except - 2 Programming Enter 332.

  • Page 162: Trs Entry Code Assignment For Extra Table

    General Programming [333] TRS Entry Code Assignment for Extra Table Description This program allows you to specify the numbers for extra Denied or Excepted Code Table for expansion. Selection • Location number: 001 through 400 • Toll call number: 10 digits (max.) Default All locations —...

  • Page 163: Emergency Dial Number Set

    General Programming [334] Emergency Dial Number Set Description Stores up to ten emergency call numbers. Emergency numbers are not subject to toll restriction, Account Code — Verified mode and Electronic Station Lockout. Selection • Location number: 01 through 10 • Emergency number: 24 digits (max.) Default Location 01 = 911, Other location = Not stored Programming...

  • Page 164: Tie Line Routing Table

    General Programming [340] TIE Line Routing Table Description The TIE line routing table can be programmed. This table is referenced by the system to identify the outside (CO) line route, when an extension user makes a TIE call. A routing pattern appropriate for each call is decided by the first three digits (except the TIE line access code) of the dialed number.
  • Page 165 General Programming Conditions Each TIE line access code has a maximum of three digits, consisting of 0 through 9 and . The character " " can be used as a wild card character. Program [341] TIE Modify Removed / Added Digit is used to modify the TIE line access code.

  • Page 166: Tie Modify Removed / Added Digit

    General Programming [341] TIE Modify Removed / Added Digit Description Assigns the removed and added digits of the TIE call received digits. Digits are removed and added from the beginning of the dialed digits. Selection • Location number: 01 through 32 •...
  • Page 167 General Programming Features Guide References T1 Line TIE Line Service Programming Guide...

  • Page 168: Outside Line Programming

    Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • Outside lines 25 through 48 become available for the T1 line when the KX-TD187 expansion unit is installed in the Master System of the KX-TD1232.
  • Page 169 General Programming Outside lines 25 through 47 become available for the PRI ISDN line when the KX-TD290 expansion unit is installed in the Master System of the KX-TD1232. • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01.

  • Page 170: Outside Line Group Assignment

    CO04 — TRG 4; CO05 — TRG 5; CO06 — TRG 6; CO07 — TRG 7; CO08 — TRG 8 (for KX-TD816) CO08 through CO48 — TRG 8 (for KX-TD1232) Programming Enter 401. Display: 401 CO GROUP 1-8 Press NEXT.
  • Page 171 Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • Outside lines 25 through 48 become available for the T1 line when the KX-TD187 expansion unit is installed in the Master System of the KX-TD1232.

  • Page 172: Dial Mode Selection

    Selection • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 —01 through 24, ( =all outside lines) • DTMF / Pulse / C. Block (call blocking) Default All outside lines — DTMF Programming Enter 402.
  • Page 173 General Programming Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01.

  • Page 174: Pulse Speed Selection

    Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to one selection, press the key in step 3.
  • Page 175 General Programming • Program [990] System Additional Information, Area 02 - Bit 7 and 12, 11 are used to select a pulse break ratio and inter-digit pause, if needed. Features Guide References Dial Type Selection Programming Guide...

  • Page 176: Dtmf Time

    Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to one selection, press the key in step 3.
  • Page 177 General Programming Features Guide References Dial Type Selection Programming Guide...

  • Page 178: Cpc Signal Detection Incoming Set

    Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to one selection, press the key in step 3.
  • Page 179 General Programming • Program [415] CPC Signal Detection Outgoing Set is used to program CPC Signal Detection for outgoing outside calls. Features Guide References Calling Party Control (CPC) Signal Detection Direct Inward System Access (DISA) Programming Guide...

  • Page 180: Caller Id Assignment

    Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to one selection, press the key in step 3.
  • Page 181 General Programming Features Guide References Caller ID Programming Guide...

  • Page 182: Dil 1:1 Extension -- Day / Night

    Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. Outside line numbers in the out-of-service system are unacceptable.
  • Page 183 Jack 2 Jack 4 9, 10 Jack 1 Jack 3 Jack 5 11, 12 Jack 2 Jack 4 Jack 6 Features Guide References Direct In Lines (DIL) Direct Inward System Access (DISA) Night Service Available for the KX-TD1232 only. Programming Guide...

  • Page 184: Intercept Extension -- Day / Night

    General Programming [409-410] Intercept Extension —— Day / Night Description Intercept Routing provides an automatic re-direction of calls which cannot or have not been answered (IRNA: Intercept Routing — No Answer). These programs set the destination in both day and night modes for each outside line group. Selection •...
  • Page 185 7, 8 Jack 2 Jack 4 Jack 4 Jack 2 Jack 4 9, 10 Jack 1 Jack 3 Jack 5 11, 12 Jack 2 Jack 4 Jack 6 Features Guide References Intercept Routing Available for the KX-TD1232 only. Programming Guide...

  • Page 186: Host Pbx Access Codes

    General Programming [411] Host PBX Access Codes Description Assigns Host PBX or Centrex access codes. If the system is installed behind a host PBX or a Centrex system, an access code is required to make an outside / Centrex call or to access Centrex features.
  • Page 187 General Programming Conditions • This program is only required if a host PBX or Centrex line is connected to the system. Program [401] Outside Line Group Assignment is used to assign the line to an outside line group. • There is a maximum of four access codes per outside line group. Each code has one or two digits, consisting of 0 through 9, and .

  • Page 188: Pause Time

    General Programming [412] Pause Time Description Assigns the length of the pause time. The programmed pause time is automatically inserted after a line access code or a host PBX access code programmed in program [411] Host PBX Access Codes or manually inserted if the PAUSE button is pressed by the user. Selection •...
  • Page 189 General Programming Features Guide References Host PBX Access Pause Insertion, Automatic Programming Guide...

  • Page 190: Flash Time

    General Programming [413] Flash Time Description Assigns the length of the flash time. If your system is installed behind a host PBX or Centrex line, External Feature Access (EFA) is necessary to obtain their services. To enable it, select a required hooking signal sending time for the outside line group.
  • Page 191 General Programming • Program [401] Outside Line Group Assignment is used to assign each outside line to an outside line group. Features Guide References External Feature Access Programming Guide...

  • Page 192: Disconnect Time

    General Programming [414] Disconnect Time Description Determines the amount of time between successive accesses to the same outside line. Selection • Outside line group (TRG) number: 1 through 8, ( =all outside line groups) • Time (seconds): 1.5 / 4.0 Default All outside line groups —...
  • Page 193 General Programming Features Guide References Flash Programming Guide...

  • Page 194: Cpc Signal Detection Outgoing Set

    [405] CPC Signal Detection Incoming Set when the CPC Signal is detected. Selection • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 — 01 through 24, ( =all outside lines) • Enable (detection) / Disable (no detection) Default Disable Programming Enter 415.
  • Page 195 General Programming • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01.

  • Page 196: Reverse Circuit Assignment

    [416] Reverse Circuit Assignment Description Enables or disables Reverse Circuit detection. Selection • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 — 01 through 24, ( =all outside lines) • Regular (no detection) / Reverse (detection) Default Regular Programming Enter 416.

  • Page 197: Outside Line Name Assignment

    To program another outside line, press NEXT or PREV, or SELECT and the desired outside line number. Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. Programming Guide...
  • Page 198 • Outside lines 25 through 48 become available for the T1 line when the KX-TD187 expansion unit is installed in the Master System of the KX-TD1232. Outside lines 25 through 47 become available for the PRI ISDN line when the KX-TD290 expansion unit is installed in the Master System of the KX-TD1232.

  • Page 199: Outside Line Number Assignment For Pri Clip

    • To display parts of the number which have scrolled off the display, press • Outside lines 25 through 47 become available for the PRI ISDN line when the KX-TD290 expansion unit is installed in the Master System of the KX-TD1232. Programming Guide...
  • Page 200 General Programming • Your telephone number will be informed to the called party if the outgoing CLIR feature is disabled for the ISDN line in program [419] ISDN Outgoing CLIR Service Assignment. Features Guide References Calling Line Identification Presentation (CLIP) Calling Line Identification Restriction (CLIR) Display, Call Information Integrated Services Digital Network (ISDN) —...

  • Page 201: Isdn Outgoing Clir Service Assignment

    Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. • To assign all outside lines to the same selection, press the key in step 3.
  • Page 202 General Programming • The outside line number available for the PRI ISDN line is referred to program [721] T1 / PRI Reference CO. Features Guide References Calling Line Identification Restriction (CLIR) Programming Guide...

  • Page 203: Isdn Ring Service Assignment

    To program another outside line, press NEXT or PREV, or SELECT and the desired outside line number. Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, outside lines 01 through 12 are for the Master System and outside lines 13 through 24 are for the Slave, if available. Programming Guide...
  • Page 204 General Programming • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 01. • Lunch / break mode will only work when "Regular" is assigned in this program. •...

  • Page 205: Isdn Port Type

    Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • The ISDN port numbers correspond to the following jack numbers.
  • Page 206 General Programming KX-TD816 KX-TD1232 ISDN Port No. TD382 TD384 / TD386 TD382 TD384 / TD386 Master Slave TD284 TD284 Jack 1 Jack 1 Jack 1 Jack 2 Jack 2 Jack 2 Jack 1 Jack 3 Jack 3 Jack 1 Jack 3...

  • Page 207: Isdn Layer 1 Active Mode

    Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.
  • Page 208 General Programming Features Guide References None Programming Guide...

  • Page 209: Isdn Configuration

    Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.
  • Page 210 General Programming • After this assignment, you should reset the system so that this assignment is activated. Features Guide References None Programming Guide...

  • Page 211: Isdn Data Link Mode

    Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.
  • Page 212 General Programming Features Guide References None Programming Guide...

  • Page 213: Isdn Tei Mode

    Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.
  • Page 214 General Programming • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01. • After this assignment, you should reset the system so that this assignment is activated. Features Guide References None Programming Guide...

  • Page 215: Isdn Extension Multiple Directory Number

    Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.
  • Page 216 General Programming Features Guide References None Programming Guide...

  • Page 217: Isdn Extension Progress Tone

    Press END. Conditions • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.
  • Page 218 General Programming Features Guide References None Programming Guide...

  • Page 219: Did / Tie Format Number Assignment

    General Programming [430] DID / TIE Format Number Assignment Description Assigns a Direct Inward Dialing (DID) and TIE format number to each outside line group. Selection • Outside line group (TRG) number: 1 through 8, ( =all outside line groups) •...

  • Page 220: Did / Tie Incoming Assignment

    General Programming [431] DID / TIE Incoming Assignment Description Assigns a DID / TIE incoming method, immediate or wink, to each DID / TIE format according to your central office service. Immediate: Incoming DID and TIE calls can be received right after the receiving signal arrives.
  • Page 221 General Programming Features Guide References Direct Inward Dialing (DID) T1 Line Programming Guide...

  • Page 222: Did / Tie Outgoing Assignment

    General Programming [432] DID / TIE Outgoing Assignment Description Assigns a DID and TIE outgoing method, immediate or wink, to each DID / TIE format according to your central office service. Immediate: Outgoing DID and TIE numbers can be transmitted right after seizing the outside line.
  • Page 223 General Programming Features Guide References Direct Inward Dialing (DID) T1 Line Programming Guide...

  • Page 224: Did / Tie Subscriber Number Removed Digit

    General Programming [433] DID / TIE Subscriber Number Removed Digit Description Assigns the removed digits of received a DID and TIE subscriber number for each DID / TIE format. In this case, digits are removed from the beginning of the received digits. Selection •...
  • Page 225 General Programming TIE Line Service Programming Guide...

  • Page 226: Did / Tie Added Number

    General Programming [434] DID / TIE Added Number Description Assigns the added number to the DID and TIE subscriber number which is determined in program [433] DID / TIE Subscriber Number Removed Digit. This makes the final number which serves as the extension number. Note that digits are inserted at the beginning of the number.
  • Page 227 General Programming T1 Line TIE Line Service Programming Guide...

  • Page 228: Did / Tie Wink Time Out Assignment

    General Programming [435] DID / TIE Wink Time Out Assignment Description The DID / TIE outgoing method can be set to the wink mode in program [432] DID / TIE Outgoing Assignment. This program sets the time the system waits for the confirmation wink signal after an outside line is seized according to your central office service.
  • Page 229 General Programming Features Guide References Direct Inward Dialing (DID) T1 Line TIE Line Service Programming Guide...

  • Page 230: Co-To-Tie Transfer

    General Programming [436] CO-to-TIE Transfer Description Enables or disables transferring an incoming outside call to the TIE line on an Outside (CO) line group basis. This restriction applies to the following: 1) Call Forwarding to a TIE line 2) Call Transfer to a TIE line. Selection •...

  • Page 231: Tie-To-Co Transfer

    General Programming [437] TIE-to-CO Transfer Description Enables or disables transferring TIE calls to an outside line on an outside line group basis. This restriction applies to the following: 1) An outside call through another PBX 2) Call Forwarding to an outside line 3) Call Transfer to an outside line. Selection •...

  • Page 232: Tie-To-Tie Transfer

    General Programming [438] TIE-to-TIE Transfer Description Enables or disables transferring TIE calls to a TIE line on an outside line group basis. This restriction applies to the following: 1) A TIE call through another PBX 2) Call Forwarding to a TIE line 3) Call Transfer to a TIE line. Selection •...

  • Page 233: Tie Security Type

    General Programming [439] TIE Security Type Description Assigns the security mode for TIE calls. There are two modes, Non Security and Trunk Security (Outside line security). Non Security mode allows the caller to access an outside line without dialing a TIE user code. Trunk Security mode requires the caller to enter a TIE User Code assigned in program [017] DISA User Codes before making a TIE call.

  • Page 234: Line Hunting Sequence

    General Programming [440] Line Hunting Sequence Description Assigns the hunting sequence of idle lines, seizing from the smallest to the largest line number or vice versa in an outside line group, on an outside line group basis. Selection • Outside line group (TRG) number: ( =all outside line groups) 1 through 8, •...

  • Page 235: Spid Assignment

    Assigns a maximum of eight Service Profile Identifiers (SPID) on an ISDN port basis. Selection • Port number: KX-TD816 — 01 through 04 KX-TD1232 — 01 through 12 • Location number: 1 through 8 • SPID: 20 digits (max.) Default All ports —...
  • Page 236 General Programming • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.

  • Page 237: Dn Assignment

    Assigns a maximum of eight Directory Numbers (DN) on an ISDN port basis. Selection • Port number: KX-TD816 — 01 through 04 KX-TD1232 — 01 through 12 • Location number: 1 through 8 • DN: 20 digits (max.) Default All ports — All locations — Not stored Programming Enter 454.
  • Page 238 General Programming • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.

  • Page 239: Extension Ringing Assignment -- Day / Night For Isdn

    Selection • Port number: KX-TD816 — 01 through 04 KX-TD1232 — 01 through 12 • Location number: 1 through 8 • Extension number: 2 to 4 digits / 0 (operator) / Disable Default All ports — All locations — Disable — Day / Night Programming Enter a program address (455 for day or 456 for night).
  • Page 240 General Programming • For the KX-TD1232, port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.

  • Page 241: Dil 1:1 - Lunch / Break Group

    Description Assigns a lunch / break group to each DIL1:1 destination. Selection • Outside (CO) line number: KX-TD816 — 01 through 08 KX-TD1232 — 01 through 24 • Group number: 1 through 8 Default All outside lines — Blank Programming For Lunch Enter 457.
  • Page 242 General Programming Display: CO Line NO? Enter an outside line number. To enter outside line number 01, you can also press NEXT. Display example: CO01: Enter a group number. To change the current entry, press CLEAR and the new number. Display example: CO01:1 Press STORE.

  • Page 243: Pri Connection Assignment

    [460] PRI Connection Assignment Description Assigns the number of B channels which are actually used out of the 23 PRI line channels. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290). Selection •...

  • Page 244: Pri Line Coding Assignment

    General Programming [461] PRI Line Coding Assignment Description Sets a line coding for the PRI ISDN line. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290). Selection • B8ZS / AMI Default...

  • Page 245: Pri Frame Sequence Assignment

    [462] PRI Frame Sequence Assignment Description Sets a frame format for the PRI ISDN line. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290). Selection • ESF (Extend Multiframe) / F4 (4-Frame Multiframe) / F12 (12-Frame Multiframe) /...

  • Page 246: Pri Timer 1 And Timer 2 Assignment

    If "Not Effective" is selected, the counter and timers are not used. In this case, the timer assigned in program [208] Inter Digit Time is used. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290).
  • Page 247 General Programming Conditions • To assign all outside lines to one selection, press the key in step 3. In this case, the display shows the contents programmed for outside line 25. Features Guide References Integrated Services Digital Network (ISDN) — Primary Rate Interface (PRI) Programming Guide...

  • Page 248: Pri Inter Digit Timer 1 Assignment

    Description Assigns inter-digit timeout for Timer 1. For details, please see "Description" of [463] PRI Timer 1 and Timer 2 Assignment. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290). Selection Time (seconds): 1 through 30...

  • Page 249: Pri Inter Digit Timer 2 Assignment

    Description Assigns inter-digit timeout for Timer 2. For details, please see "Description" of [463] PRI Timer 1 and Timer 2 Assignment. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290). Selection Time (seconds): 1 through 30...

  • Page 250: Pri Dial Counter For Inter Digit Timer 2 Assignment

    Assigns counter value of dialed digits. Before this value, Timer 1 is used. After this value, Timer 2 is used. For details, please see "Description" of [463] PRI Timer 1 and Timer 2 Assignment. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290). Selection...

  • Page 251: Dil 1:1 Extension -- Lunch / Break

    458] DIL 1:1 — Lunch / Break Group. Selection • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 — 01 through 24, ( =all outside lines) • Extension number: 2 through 4 digits / Disable (no DIL 1:1) Default All outside lines —...
  • Page 252 General Programming • You set the extension numbers in program [003] Extension Number Set, voice mail extension numbers in program [118] Voice Mail Extension Number Assignment, phantom extension numbers in program [124] Phantom Extension Number Assignment or floating numbers, DISA (Direct Inward System Access) and extension group in program [813] Floating Number Assignment.

  • Page 253: Cos Programming

    General Programming 2.6 COS Programming [500-501] Toll Restriction Level —— Day / Night Description Each extension must be assigned a Class of Service (COS). These programs set the toll restriction value for each COS in day or night mode. Selection •...
  • Page 254 General Programming Features Guide References Night Service Toll Restriction Programming Guide...

  • Page 255: Extension-To-Outside Line Call Duration Limit

    General Programming [502] Extension-to-Outside Line Call Duration Limit Description This program allows you to restrict the duration of outside calls on a Class of Service (COS) basis. Selection • COS number: ( =all COS) 1 through 8, • Disable (no limit) / Enable (limit) Default All COS —...
  • Page 256 General Programming • Program [990] System Additional Information, Area 02 - Bit 2 is used to program Limited Call Duration to be done for outgoing calls only. Features Guide References Call Forwarding — to Outside Line Call Transfer, Screened — to Outside Line Conference, Unattended Limited Call Duration Programming Guide...

  • Page 257: Call Transfer To Outside Line

    General Programming [503] Call Transfer to Outside Line Description This program determines which Classes of Services (COS) are allowed to perform the Call Transfer to Outside Line function. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS —...

  • Page 258: Call Forwarding To Outside Line

    General Programming [504] Call Forwarding to Outside Line Description This program determines which Classes of Services (COS) are allowed to perform the Call Forwarding to Outside Line function. Selection • COS number: 1 through 8, ( =all COS) • Disable / Enable Default All COS —...

  • Page 259: Executive Busy Override

    General Programming [505] Executive Busy Override Description Determines which Classes of Services (COS) are allowed to perform Executive Busy Override — Extension / Outside Line. Executive Busy Override allows the user to interrupt an established call. Selection • COS number: 1 through 8, ( =all COS) •...

  • Page 260: Executive Busy Override Deny

    General Programming [506] Executive Busy Override Deny Description This program is used to determine which Classes of Services (COS) are allowed to deny Executive Busy Override. Executive Busy Override Deny allows the user to prevent Executive Busy Override — Extension / Outside Line from being executed by another extension user. Selection •...

  • Page 261: Do Not Disturb Override

    General Programming [507] Do Not Disturb Override Description This program determines which Classes of Services (COS) are allowed to perform Do Not Disturb (DND) Override. Selection • COS number: 1 through 8, ( =all COS) • Disable / Enable Default All COS —...

  • Page 262: Account Code Entry Mode

    General Programming [508] Account Code Entry Mode Description There are three account code modes: Option, Verified-All Calls and Verified-Toll Restriction Override. This program determines the mode to be used by each Class of Service (COS). Option mode: The user can enter any account code, if needed. Verified —...
  • Page 263 General Programming • Program [105] Account Codes is used to define the Account Codes for the Verified modes. • Program [601] Class of Service is used to assign a Class of Service to each extension. Features Guide References Account Code Entry Toll Restriction Override by Account Code Entry Programming Guide...

  • Page 264: Off-Hook Call Announcement (Ohca)

    General Programming [509] Off-Hook Call Announcement (OHCA) Description Enables or disables to perform the Off-Hook Call Announcement (OHCA) on a Class of Service (COS) basis. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS —...

  • Page 265: Night Service Access

    General Programming [510] Night Service Access Description Enables or disables switching the Day / Night service on a Class of Service (COS) basis. Selection • COS number: 1 through 8, ( =all COS) • Enable / Disable Default All COS — Disable Programming Enter 510.

  • Page 266: Pits Programming Level

    General Programming [511] PITS Programming Level Description Regulates station programming, depending on the COS. This programming has two levels as follows. Level 1: enables all station programming. Level 2: disables CO button programming in station programming. Selection • COS number: 1 through 8, ( =all COS) •...
  • Page 267 General Programming Features Guide References None Programming Guide...

  • Page 268: Extension Programming

    • The eXtra Device Port feature must be assigned "Disable" for Direct Station Selection (DSS) Console ports. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available.
  • Page 269 General Programming • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for Jack 01. • Immediately after changing your assignment, the changed setting may not work for a maximum of eight seconds.

  • Page 270: Class Of Service

    Selection • Jack number: KX-TD816 — 01 through 16, (-1 / -2), KX-TD1232 — 01 through 64, (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) • COS number: 1 through 8 Default All jacks-1/2 —...
  • Page 271 General Programming • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.

  • Page 272: Extension Group Assignment

    • There is a maximum of eight extension groups. Each extension can only belong to one group. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available.
  • Page 273 General Programming • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • To assign all jacks to one extension group, press the key in step 3. In this case, the display shows the contents programmed for Jack 01. Features Guide References Call Pickup, Group Extension Group...

  • Page 274: Dil 1:N Extension And Delayed Ringing -- Day / Night

    Selection • Jack number: KX-TD816 — 01 through 16, (-1 / -2), KX-TD1232 — 01 through 64, (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 —...
  • Page 275 • An extension can be assigned as the destination of as many outside lines as required. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable.

  • Page 276: Outgoing Permitted Outside Line Assignment -- Day / Night

    Selection • Jack number: KX-TD816 — 01 through 16, (-1 / -2), KX-TD1232 — 01 through 64, (-1 / -2), ( =all jacks, -1 = first part, -2 = second part) • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 —...
  • Page 277 General Programming Conditions • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.

  • Page 278: Doorphone Ringing Assignment -- Day / Night

    To program another jack, press NEXT or PREV, or SELECT and the desired jack number. Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Programming Guide...
  • Page 279 5, 6 5, 6, 7, 8 5, 6 5, 6, 7, 8 Opener number • You can enter up to four (for KX-TD816) or eight (for KX-TD1232) doorphone numbers for each extension. Features Guide References Door Opener Doorphone Call Night Service...

  • Page 280: Voice Mail Access Codes

    Repeat steps 4 through 6. Press END. Conditions • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Jack numbers in the out-of-service system are unacceptable.
  • Page 281 • Each mailbox number has a maximum of 16 digits, consisting of 0 through 9, , # and PAUSE. • To display parts of the mailbox number which have scrolled off the display, press Features Guide References Voice Mail Integration Available for the KX-TD1232 only. Programming Guide...

  • Page 282: Live Call Screening Recording Mode Assignment

    Press END. Conditions • In case of the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods.
  • Page 283 General Programming • To assign all jacks to one selection, press the key in step 3. In this case, the display shows the contents programmed for jack 01. Features Guide References Live Call Screening (LCS) Voice Mail Integration for Digital Proprietary Telephones Programming Guide...

  • Page 284: Isdn Class Of Service

    Selection • Port number: KX-TD816 — 01 through 04, ( =all ports) KX-TD1232 — 01 through 12, ( =all ports) • COS number: 1 through 8 Default All ports — COS 1 Programming Enter 613.
  • Page 285 General Programming • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for Port 01. Features Guide References Class of Service (COS) Programming Guide...

  • Page 286: Outgoing Permitted Outside Line Assignment -- Day / Night For Isdn

    Selection • Port number: KX-TD816 — 01 through 06, ( =all ports) KX-TD1232 — 01 through 12, ( =all ports) • Outside line (CO) number: KX-TD816 — 01 through 08, KX-TD1232 — 01 through 24, ( =all outside lines) •...
  • Page 287 General Programming Conditions • Port numbers 01 through 06 are for the Master System and 07 through 12 are for the Slave, if available. • Refer to program [423] for the list of the ISDN port numbers and their corresponding jack numbers.

  • Page 288: Extension

    Sets a Call Forwarding – No Answer Time for each extension. Selection • Jack number: KX-TD816 — 01 through 16 (-1 / -2), KX-TD1232 — 01 through 64 (-1 / -2), (-1 = first part, -2 = second part, =all jacks) • Number of rings: 0 through 12 Default All jacks —...

  • Page 289: Lunch / Break Group Assignment

    General Programming [620] Lunch / Break Group Assignment Description Assigns extensions for a lunch / break group. A lunch / break group can be assigned to up to 8 extensions (PT / SLT). Selection • Group number: 1 through 8 •...
  • Page 290 General Programming Features Guide References Lunch / Break Service Night Service Programming Guide...

  • Page 291: Cordless Pits Extension Port

    Only Ring-calling can be used. Paging: using the paging features. Selection • Jack number: KX-TD816 — 01 through 16, KX-TD1232 — 01 through 64, ( =all jacks) • Yes (prevent) / No (allow) Default All jacks – all outside lines – No Programming Enter a 621.
  • Page 292 General Programming Conditions • If "Yes" is selected for a jack for wired PITS, the speakerphone functions written in the description do not work. Connect a cordless PITS if "Yes" is selected. Features Guide References None Programming Guide...

  • Page 293: Extension Clip Number Assignment

    Conditions • Each number has a maximum of 16 digits, consisting of 0 through 9. • For the KX-TD1232, jack numbers 01 through 32 are for the Master System and 33 through 64 are for the Slave, if available. Programming Guide...
  • Page 294 General Programming • To display parts of the number which have scrolled off the display • For an explanation of jack numbering, see "Rotation of jack number" in Section 1.3 Programming Methods. • To assign all jacks to one extension group, press the key in step 3.

  • Page 295: Isdn Extension Clip Number Assignment

    Assigns the identification number of the calling party to each ISDN extension in order to utilize the Calling Line Identification Presentation (CLIP) feature provided by the ISDN line service. This program is only available for the KX-TD1232 with the Primary Rate Interface ISDN Expansion Unit (KX-TD290).
  • Page 296 General Programming • To assign all ports to one selection, press the key in step 3. In this case, the display shows the contents programmed for port 07. Features Guide References Integrated Services Digital Network (ISDN) — Primary Rate Interface (PRI) Programming Guide...

  • Page 297: T1 Programming

    2.8 T1 Programming [700] T1 Channel Assignment Description Assigns a channel type to each T1 channel. This program is available for the KX-TD1232 only. Selection • T1 channel number: 01 through 24, ( =All T1 channels) • Channel type: LCOT / GCOT / DID / TIE / OPX / Disable Default All T1 channels —...

  • Page 298: T1 Dial Mode

    General Programming [701] T1 Dial Mode Description Assigns a signal type to each T1 channel. This program is available for the KX-TD1232 only. Selection • T1 channel number: 01 through 24, ( =All T1 channels) • Signal type: Pulse-10 / Pulse-20 / DTMF-80 / DTMF-160 Default All T1 channels —...

  • Page 299: T1 Cot Cpc (In)

    General Programming [702] T1 COT CPC (IN) Description Sets a CPC signal detection time to each T1 channel, assigned COT, on receiving a call. This program is available for the KX-TD1232 only. Selection • T1 channel number: ( =All T1 channels) 01 through 24, •...

  • Page 300: T1 Did Cpc (In)

    General Programming [703] T1 DID CPC (IN) Description Sets a CPC signal detection time to each T1 channel, assigned DID, on receiving a call. This program is available for the KX-TD1232 only. Selection • T1 channel number: ( =All T1 channels) 01 through 24, •...

  • Page 301: T1 Cot Cpc (Out)

    General Programming [704] T1 COT CPC (OUT) Description Sets a CPC signal detection time to each T1 channel, assigned COT, on making a call. This program is available for the KX-TD1232 only. Selection • T1 channel number: ( =All T1 channels) 01 through 24, •...

  • Page 302: T1 Did Cpc (Out)

    General Programming [705] T1 DID CPC (OUT) Description Sets a CPC signal detection time to each T1 channel, assigned DID, on making a call. This program is available for the KX-TD1232 only. Selection • T1 channel number: ( =All T1 channels) 01 through 24, •...
  • Page 303 General Programming T1 Line Programming Guide...

  • Page 304: T1 Did Receive Digits

    General Programming [706] T1 DID Receive Digits Description Sets a maximum number of the received dial digits for each T1 channel assigned DID. This program is available for the KX-TD1232 only. Selection • T1 channel number: ( =All T1 channels) 01 through 24, •...
  • Page 305 General Programming Features Guide References Direct Inward Dialing (DID) T1 Line Programming Guide...

  • Page 306: T1 Clock Mode

    General Programming [707] T1 Clock Mode Description Assigns a clock mode for the T1 line. This program is available for the KX-TD1232 only. Selection • Internal / External Default External Programming Enter 707. Display: 707 CLOCK MODE Press NEXT. Display: External Keep pressing SELECT until the desired selection is displayed.

  • Page 307: T1 Line Coding

    General Programming [708] T1 Line Coding Description Sets a line coding for the T1 line. This program is available for the KX-TD1232 only. Selection • B8ZS / AMI Default B8ZS Programming Enter 708. Display: 708 LINE CODING Press NEXT. Display: B8ZS Keep pressing SELECT until the desired selection is displayed.

  • Page 308: T1 Frame Sequence

    General Programming [709] T1 Frame Sequence Description Sets a frame format for the T1 line. This program is available for the KX-TD1232 only. Selection • ESF / D4 Default Programming Enter 709. Display: 709 FRAME SEQ Press NEXT. Display: ESF Keep pressing SELECT until the desired selection is displayed.

  • Page 309: T1 Frame Option

    Assigns an ESF frame option for the T1 line. This is only available when the ESF is selected on the frame sequence. This program is available for the KX-TD1232 only. Selection • C=A, D=B / C=0, D=0 / C=1, D=0 / C=0, D=1 / C=1, D=1...

  • Page 310: T1 First Dial Timer (Co)

    [711] T1 First Dial Timer (CO) Description Sets a timer to prevent a first dial being sent too early on the T1 channels assigned COT. This program is available for the KX-TD1232 only. Selection • Time: 01 – 16 ( 0.5 seconds is the actual time)

  • Page 311: T1 First Dial Timer (Did / Tie)

    Description Sets a timer to prevent the first dial being sent too early on the T1 channels assigned DID and TIE. This program is available for the KX-TD1232 only. Selection • Time: 001 – 255 ( 32 milliseconds is the actual time)

  • Page 312: T1 %Break

    General Programming [713] T1 %Break Description Sets a "%Break" for the T1 line assigned Pulse. This program is available for the KX-TD1232 only. Selection • 60% / 67% Default Programming Enter 713. Display: 713 T1 %BREAK Press NEXT. Display: T1 %Break:60% Keep pressing SELECT until the desired selection is displayed.

  • Page 313: T1 Dial Click Tone

    General Programming [714] T1 Dial Click Tone Description Sets to send a dial click tone of the T1 line. This program is available for the KX-TD1232 only. Selection • Yes (to send) / No (not to send) Default Programming Enter 714.

  • Page 314: T1 Inter Digit Pause

    General Programming [715] T1 Inter Digit Pause Description Sets a time of the inter digit pause for the T1 line. This program is available for the KX-TD1232 only. Selection • 630 msec / 830 msec / 1030 msec Default 830 msec Programming Enter 715.

  • Page 315: T1 Flash Detection

    General Programming [716] T1 Flash Detection Description Sets a flash detection time for the T1 line. This program is available for the KX-TD1232 only. Selection • Disable / 208-1016 msec / 80-1016 msec / 208-1544 msec / 80-1544 msec Default...

  • Page 316: T1 Answer Decision Timer

    General Programming [717] T1 Answer Decision Timer Description Sets an answering detection time for the T1 line. This program is available for the KX-TD1232 only. Selection • Time: 001 through 255 ( 32 milliseconds is the actual time) Default Programming Enter 717.

  • Page 317: T1 Break Detection

    General Programming [718] T1 Break Detection Description Sets a break detection time for the T1 extension. This program is available for the KX-TD1232 only. Selection • Time: 16 – 96 ms / 16 – 136 ms Default 16 – 96 ms Programming Enter 718.

  • Page 318: T1 Pulse Type

    General Programming [719] T1 Pulse Type Description Sets a dialing pulse type for the T1 line. This program is available for the KX-TD1232 only. Selection • TYPE-A / TYPE-B / TYPE-C Default TYPE-A Programming Enter 719. Display: 719 PULSE TYPE Press NEXT.

  • Page 319: T1 Tie Ringing Service

    Sets a type to receive a call in the T1 channels assigned TIE/DID. If "DIL" is selected, DIL 1:1 or DIL 1:N will perform. This program is available for the KX-TD1232 only. Selection • Outside (CO) line number: 25 through 48, ( = all outside lines from 25 to 48) •...
  • Page 320 General Programming TIE Line Service Programming Guide...

  • Page 321: T1 / Pri Reference Co

    Description Assigns a reference outside (CO) line number when T1 channel or PRI ISDN channel is used as an outside line. This program is available for the KX-TD1232 only. Selection • Outside (CO) line number: ( = all outside lines from 25 to 48)
  • Page 322 • Outside lines 25 through 48 become available for the T1 line when the KX-TD187 expansion unit is installed in the Master System of the KX-TD1232. Outside lines 25 through 47 become available for the PRI ISDN line when the KX-TD290 expansion unit is installed in the Master System of the KX-TD1232.

  • Page 323: T1 Answer Wait Timer

    Description Assigns an automatic disconnect timer to stop making a call on TIE / DID line, if the called party does not answer. This program is available for the KX-TD1232 only. Selection • Outside (CO) line number: ( = all outside lines from 25 to 48) 25 through 48, •...
  • Page 324 General Programming T1 Line TIE Line Service Programming Guide...

  • Page 325: T1 Sending Tie Caller Id

    Description Sends a caller ID on the DTMF (Dual Tone Multi-Frequency) signaling on the T1 channels assigned TIE. This program is available for the KX-TD1232 only. Selection • Outside (CO) line number: ( = all outside lines from 25 to 48) 25 through 48, •...
  • Page 326 General Programming TIE Line Service Programming Guide...

  • Page 327: T1 Extension Number

    General Programming [725] T1 Extension Number Description Assigns an extension number of the T1 channels set OPX. This program is available for the KX-TD1232 only. Selection • Port number: 01 through 24, • Extension number: 2 or 4 digits Default All ports —...

  • Page 328: T1 Extension Name

    [726] T1 Extension Name Description Assigns names to the extension numbers of T1 channel set OPX, programmed in [725] T1 Extension Number. This program is available for the KX-TD1232 only. Selection • Port number: ( = all ports) 01 through 24, •...
  • Page 329 General Programming Features Guide References Display, Call Information Intercom Calling T1 Line Programming Guide...

  • Page 330: T1 Extension Cos Number

    General Programming [727] T1 Extension COS Number Description Assigns a "Class of Service (COS)" to each extension of T1 channels. This program is available for the KX-TD1232 only. Selection • Port number: ( = all ports) 01 through 24, • COS number:...
  • Page 331 General Programming T1 Line Programming Guide...

  • Page 332: T1 Extension Outgoing Permitted Outside Line Assignment - Day

    Determines the outside lines which can be accessed by an extension on the T1 line in day mode. The extension user on the T1 line can make outgoing outside line calls using the assigned outside lines. This program is available for the KX-TD1232 only. Selection • Port number:...
  • Page 333 General Programming Conditions None Features Guide References Outside Line Connection Assignment — Outgoing Night Service T1 Line Programming Guide...

  • Page 334: T1 Extension Outgoing Permitted Outside Line Assignment - Night

    Determines the outside lines which can be accessed by an extension on the T1 line in night mode. The extension user on the T1 line can make outgoing outside line calls using the assigned outside lines. This program is available for the KX-TD1232 only. Selection • Port number:...
  • Page 335 General Programming Conditions None Features Guide References Night Service T1 Line Programming Guide...

  • Page 336: T1 Extension Voice Mail Access Codes

    Description Assigns a mailbox number for each extension on the T1 line, "[990] System Additional Information, Area 02 - Bit 8" is set to free. This program is available for the KX-TD1232 only. Selection • Port number: 01 through 24 •...
  • Page 337 General Programming • To display parts of the mailbox number which have scrolled off the display, press Features Guide References T1 Line Voice Mail Integration Programming Guide...

  • Page 338: Resource Programming

    General Programming 2.9 Resource Programming [800] SMDR Incoming / Outgoing Call Log Printout Description Used to determine which calls will produce a Station Message Detail Recording (SMDR) printout. Selection • Outgoing calls: All (all calls) / Toll (toll calls only) / Off (no printing) •...
  • Page 339 General Programming Features Guide References Station Message Detail Recording (SMDR) Programming Guide...

  • Page 340: Smdr Format

    General Programming [801] SMDR Format Description Used to match the SMDR output to the paper size being used in the printer. Page length determines the number of lines per page. Skip perforation determines the number of lines to be skipped at the end of every page. Selection •...

  • Page 341: System Data Printout

    General Programming [802] System Data Printout Description Starts or stops printing the system data. All or a specific range of the current system- programmed data is printed out. The ranges are as follows: Manager: Manager Programming [000] through [017] System: System Programming [100] through [151] Timers: Timer Programming [200] through [220]...
  • Page 342 General Programming Press STORE to start printing. Printing starts. To stop printing, press SELECT and go to step 4. When printing is completed, the display shows: Display: Print-Out:Finish Press STORE. Display: Print-Out:Stop Press END. Conditions • It is necessary to connect a printer to the Serial Interface (RS-232C) port provided on the system.

  • Page 343: Music Source Use

    • The music source is a user-supplied item. For KX-TD816, one music source can be installed, for KX-TD1232, two music sources can be installed per system. Music sources 1 and 2 are connected to the Master System, 3 and 4 are to the Slave, if available. Any music source can be used by either system.
  • Page 344 General Programming Features Guide References Background Music (BGM) Background Music (BGM) — External Music on Hold Programming Guide...

  • Page 345: External Pager Bgm

    TD816, and two external pagers can be installed for KX-TD1232. • In the case of KX-TD816, please skip steps 6 and 7. • For the KX-TD1232, external pagers 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available.
  • Page 346 General Programming Features Guide References Background Music (BGM) — External Programming Guide...

  • Page 347: External Pager Confirmation Tone

    The external pager is a user-supplied item. For KX-TD816, one external pager can be installed, for KX-TD1232, two external pagers can be installed per system. External pagers 1 and 2 are installed in the Master System, 3 and 4 in the Slave, if available.

  • Page 348: Serial Interface (Rs-232C) Parameters

    [806-807] Serial Interface (RS-232C) Parameters Description Assigns the communication parameters for the Serial Interface (RS-232C) interface for Port 1 (for KX-TD816 and Master System of KX-TD1232) or Port 2 (for Slave System of KX- TD1232). New line code: Select the code for your printer or personal computer. If your printer or personal computer automatically feeds lines with a carriage return, select "CR".
  • Page 349 General Programming Press NEXT to program baud rate. Display example: Baud Rate:9600 Keep pressing SELECT until the desired selection is displayed. Press STORE. Press NEXT to program word length. Display example: Word Lengt:8bits Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 350: Disa Security Type

    All Security mode requires the caller to enter a DISA user code before making both an outside call and an intercom call. This program is available for the KX-TD1232 only. Selection Non (non security) / Trunk (trunk security) / All (all security)

  • Page 351: Disa Tone Detection

    Enables or disables Tone Detection for outside-to-outside line calls via the Direct Inward System Access (DISA) feature. Enabling tone detection allows the system to detect the end of the call. This program is available for the KX-TD1232 only. Selection Enable / Disable...

  • Page 352: Disa Dtmf Repeat

    This can be done for an outside-to-outside line call via the Direct Inward System Access (DISA) feature during dialing and / or during an established call. This program is available for the KX-TD1232 only. Selection • Dial (during dialing) / Call (during an established call) •...

  • Page 353: Floating Number Assignment

    Selection • Floating station: KX-TD816 — Pager1 / E-Group 1 through 8 / MODEM KX-TD1232 — Pager1 through 4 / DISA1 / DISA2 / MODEM / E-Group 1 through 8 • Floating number: 2 to 4 digits Default KX-TD816 —...
  • Page 354 [003] Extension Number Set KX-TD816 — 101 through 116, 201 through 216 KX-TD1232 — 101 through 164, 201 through 264 [012] ISDN Extension Number Set Not assigned. [118] VM Extension Number Assignment KX-TD816 —...

  • Page 355: Modem Standard

    General Programming [814] Modem Standard Description Assigns the modem standard. There are two standards available — BELL and CCITT. Selection BELL / CCITT Default BELL Programming Enter 814. Display: 814 MODEM TYPE Press NEXT. Display example: MODEM:BELL Keep pressing SELECT until the desired selection is displayed. Press STORE.

  • Page 356: Disa Built-In Auto Attendant

    General Programming [815] DISA Built-in Auto Attendant Description Assigns the DISA (Direct Inward System Access) built-in auto attendant number. The extension number and the floating number can be assigned as a one digit number and used as a DISA built-in auto attendant number. Selection •...

  • Page 357: Kx-Td197 / Kx-Td198 Baud Rate Set

    BELL / V.34-9600 / V.34-14400 / V.34-19200 / V.34-28800 / V.34-33600 Default V.34-33600 Programming Enter 817. Display: 817 TD197 TYPE (for KX-TD1232) 817 TD198 TYPE (for KX-TD816) Press NEXT. Display example: Mast.:V.34-33600 Keep pressing SELECT until the desired selection is displayed.

  • Page 358: Doorphone Tone Frequency Selection

    Selection • Doorphone number: KX-TD816 — 1 through 4, ( = all doorphones) KX-TD1232 — 1 through 8, ( = all doorphones) • Type1 / Type2 / Type3 / Type4 / Type5 / Type6 / Type7 / Type8 Default All doorphones — Type2 Programming Enter 818.

  • Page 359: Doorphone Ringing Time

    Description Selects the doorphone ringing time. Selection • Doorphone number: KX-TD816 — 1 through 4, ( = all doorphones) KX-TD1232 — 1 through 8, ( = all doorphones) • 15sec / 30sec (seconds) Default All doorphones — 30sec Programming Enter 820.

  • Page 360: Optional Programming

    General Programming 2.10 Optional Programming [990] System Additional Information Description Allows the following programming items to be changed, if required. Each bit in each Area represents a programming item. Chart for the Areas and Bits Bit Number 16 15 14 13 12 11 10 Display Example Area 01 Area 02 Area 03...
  • Page 361 General Programming Explanation Area Description Selection Default References Sound source during transfer. 0 : ringback tone • CALL 1 : Music on Hold TRANSFER FEATURES • Music on Hold Result of pressing the hookswitch 0 : Consultation Consultation lightly and then replacing the handset Hold Hold (during a CO line call (single line...
  • Page 362 General Programming Explanation Area Description Selection Default References If an outside party is transferred and 0 : initiating Call Transfer, unanswered, assigns whether Transfer extension Unscreened - to Recall occurs at the originating transfer 1 : Operator 1 Extension extension or at the Operator 1. If Limited CAll Duration is enabled in 0 : both calls Limited Call...
  • Page 363 General Programming Explanation Area Description Selection Default References An outside line set to pulse or call 0 : 60 % Dial Type blocking mode in program [402] Dial 1 : 67 % Selection Mode Selection can have two settings. This assigns the pulse break ratio during dial pulsing.
  • Page 364 KX-TD816, and outside line numbers [1] through [24] correspond to outside line numbers [1] through [24] correspond to outside lines 1 through 24 for KX-TD1232. Prevents or allows a call originated by 0 : prevent Voice Mail an Automated Attendant (AA) port of...
  • Page 365 General Programming Explanation Area Description Selection Default References Enables or disables the automatic time 0 : enable Caller ID adjustment by Caller ID information 1 : disable once a day by the first call received after 3:00AM. An outside-to-outside DISA call can be 0 : 10 times Direct Inward prolonged many times.
  • Page 366 General Programming Explanation Area Description Selection Default References Unused Enables or disables dial tone 2 when an 0 : disable None extension sets programmable extension 1 : enable features such as Call Waiting. Determines the result when pressing the 0 : Terminate Flash FLASH or FLASH / RCL button during 1 : Flash...
  • Page 367 General Programming Explanation Area Description Selection Default References Determines whether the account code is 0: not printed out Account Code printed out or not (shown in dot) in the 1: printed out Entry SMDR. 3, 2 Reserved Enables or disables sending outside 0 : enable (CO) line access code "9"...
  • Page 368 General Programming Explanation Area Description Selection Default References Enables or disables the DTMF signal to 0 : enable Direct Inward the ISDN line. 1 : disable System Access (DISA) Unused Enables or disables the hooking signal 0 : disable None when the reverse signal does not return.
  • Page 369 General Programming Explanation Area Description Selection Default References Sends a dial tone to another system 0 : send TIE Line Service when a channel assigned on TIE is 1 : not send captured. Unused Sends a dial tone to extensions when a 0 : send TIE Line Service TIE line access code is dialed.
  • Page 370 General Programming Explanation Area Description Selection Default References Sends a dial tone to the extension when 0 : send T1 Line a CO button or the line access 1 : not send (Automatic or Outside Line Group) code is pressed. This programming allows each outside line group (TRG) to work as follows.
  • Page 371 General Programming Display example: 0010100011111001 Keep pressing to move the cursor to the desired bit. Enter your selection. To change the current entry, press STORE and the new selection. To program another bit, repeat steps 4 and 5. Press STORE. To program another area, press SELECT and the desired area code.

  • Page 372: Cos Additional Information

    General Programming [991] COS Additional Information Description Adds the following programming items on a Class of Service (COS) basis, if required. Bits 1-8: COS Additional Information Bits 9-16: System Additional Information COS 1-8 There are 8 bits available in Bit 1-8 as follows: Bit Number 16 15 14 13 12 11 10 1 1 1 1 0 0 0 0...
  • Page 373 General Programming System Additional Information 2 COS 3-6 There are 8 bits available in System Additional Information Area as follows: Bit Number 16 15 14 13 12 11 10 1 1 1 1 1 1 1 1 Display Example ↓ (COS Additional Information) Explanation for COS 3 Features Guide...
  • Page 374 General Programming Explanation for COS 3 Features Guide Description Selection Default References Determines where "RT" of the 0 : second • Ring Group sequence returns in the UCD (Ring 1 : top • Uniform Call Group) Time Table 4. Distribution (UCD) Unused Explanation for COS 4...
  • Page 375 General Programming Explanation for COS 5 Features Guide Description Selection Default References Determines the destination when an 0 : Wait Voice Mail incoming call arrives at Voice Mail, 1 : IRNA Integration if all VM ports are busy. destination Wait: The call waits until a VM port becomes free.
  • Page 376 General Programming Explanation for COS 6 Features Guide Description Selection Default References Unused Selection • COS number: 1 through 8, ( =all COS) • Selection : See "Selection" shown in the lists. Default See "Default" shown in the lists. Programming Enter 991.

  • Page 377: Default Values

    Default Values Section 3 Default Values Programming Guide...
  • Page 378 [003] Extension Number Set KX-TD816 Jack 01-1 through 16-1 = 101 through 116; Jack 01-2 through 16-2 = 201 through 216 KX-TD1232 Jack 01-1 through 64-1 = 101 through 164; Jack 01-2 through 64-2 = 201 through 264 [004] Extension Name Set All jacks —...
  • Page 379 [108] Automatic Hold by CO / DSS Button DSS button — Enable, CO button — Disable [109] Expansion Unit Type KX-TD816: C;E KX-TD1232: Master and Slave — C;E1;E2 [110] Caller ID Code Set All locations — Not stored [111] Caller ID Name Set All locations —...
  • Page 380 KX-TD816 — Assignment VM-01=165, VM-02=166, VM-03=167, VM- 04=168, VM-05=169, VM-06=170, VM-07=177, VM-08=178, VM-09=181, VM-10=182, VM- 11=183, VM-12=184 KX-TD1232 — VM-01=165, VM-02=166, VM-03=167, VM- 04=168, VM-05=169, VM-06=170, VM-07=177, VM-08=178, VM-09=181, VM-10=182, VM- 11=183, VM-12=184, VM-13=171, VM-14=172, VM-15=173, VM-16=174, VM-17=175, VM- 18=176, VM-19=179, VM-20=180, VM-21=185,...
  • Page 381 Default Values Program Default [136] DID Number Assignment All locations — Not Stored [137-138] DID Extension —— Day / Night All locations — Not Stored [139] DID Extension Name Set All locations — Not Stored [148] Off-Hook Monitor Enable [150] Lunch Service Starting / Ending Time Every day of the week –...
  • Page 382 Default Values Program Default [219] Call Park Recall Time 12 rings [220] TIE First / Inter Digit Time 5 sec [300] TRS Override for System Speed Dialing Disable [301-305] TRS Denied Code Entry for Levels 2 All locations — Not stored through 6 [306-310] TRS Excepted Code Entry for Levels All locations —...
  • Page 383 CO05 — TRG 5; CO06 — TRG 6; CO07 — TRG 7; CO08 — TRG 8 (for KX-TD816) CO08 through CO48 — TRG 8 (for KX-TD1232) [402] Dial Mode Selection All outside lines — DTMF [403] Pulse Speed Selection All outside lines — 10 pps [404] DTMF Time All outside lines —...
  • Page 384 Default Values Program Default [424] ISDN Layer 1 Active Mode All ports — Permanent [425] ISDN Configuration All ports — Multipoint [426] ISDN Data Link Mode All ports — Permanent [427] ISDN TEI Mode All ports — Automatic [428] ISDN Extension Multiple Directory All ports —...
  • Page 385 Default Values Program Default [462] PRI Frame Sequence Assignment [463] PRI Timer 1 and Timer 2 Assignment All outside lines — Effective [464] PRI Inter Digit Timer 1 Assignment 5sec [465] PRI Inter Digit Timer 2 Assignment 3sec [466] PRI Dial Counter for Inter Digit Timer 2 7digit Assignment [467-468] DIL 1:1 Extension ——...
  • Page 386 Default Values Program Default [605-606] Outgoing Permitted Outside Line All jacks-1/2 — all outside lines — Enable —— Day Assignment —— Day / Night / Night [607-608] Doorphone Ringing Assignment — Jack 01-1— All doorphones; Other jacks — no — Day / Night doorphone ——...
  • Page 387 Default Values Program Default [710] T1 Frame Option C=A, D=B [711] T1 First Dial Timer (CO) [712] T1 First Dial Timer (DID / TIE) [713] T1 %Break [714] T1 Dial Click Tone [715] T1 Inter Digit Pause 830 msec [716] T1 Flash Detection Disable [717] T1 Answer Decision Timer [718] T1 Break Detection...
  • Page 388 Pager 1=196; E-Group 1=191; E-Group 2=192; E- Group 3=193; E-Group 4=194; E-Group 5=291; E- Group 6=292; E-Group 7=293; E-Group 8=294; MODEM=299 KX-TD1232 — Pager 1=196; Pager 2=197; Pager 3=296; Pager 4=297; DISA 1=198; DISA 2=298; MODEM=299; E-Group 1=191; E-Group 2=192; E-Group 3=193; E- Group 4=194;...

  • Page 389: Index

    Index Section 4 Index...
  • Page 390 Index DID Number Conversion Selection DIL 1:1 Extension —— Day / Night Absent Messages DIL 1:1 Extension —— Lunch / Break Account Code Entry Mode DIL 1:1 — Lunch / Break Group Account Codes DIL 1:N Extension and Delayed Ringing —— Day Adjust Time / Night Area Code Assignment...
  • Page 391 Index Host PBX Access Codes Outside Line Name Assignment Hotel Application Outside Line Number Assignment for PRI CLIP Outside-to-Outside Line Call Duration Time Inter Digit Time Intercept Extension —— Day / Night Intercept Time Pause Time ISDN Class of Service PBX Code ISDN Configuration Phantom Extension Number Assignment...
  • Page 392 Index T1 DID CPC (OUT) T1 DID Receive Digits T1 Extension COS Number T1 Extension Name T1 Extension Number T1 Extension Outgoing Permitted Outside Line As- signment – Day T1 Extension Outgoing Permitted Outside Line As- signment – Night T1 Extension Voice Mail Access Codes T1 First Dial Timer (CO) T1 First Dial Timer (DID / TIE) T1 Flash Detection...
  • Page 393 Index...
  • Page 394 Index...
  • Page 395 Index...
  • Page 396 See More Panasonic Manuals www.voicesonic.com Phone: 877-289-2829 Copyright: This manual is copyrighted by Kyushu Matsushita Electric Co., Ltd. (KME). Under the applicable copyright laws, this manual may not be reproduced in any form, in whole or part, without the prior written consent of KME and its licensee.
