Command Groups

The system commands can be broken down into the functional groups shown below
Command Group
General
System Management
Simple Network
Management Protocol
Authentication
General Security
Measures
Access Control List
Interface
Link Aggregation
Power over Ethernet
Mirror Port
Rate Limiting
Address Table
Spanning Tree
VLANs
Link Layer Discovery
Protocol
Class of Service
Quality of Service

Table 4-4 Command Groups

Description
Basic commands for entering privileged access mode, restarting the
system, or quitting the CLI
Display and setting of system information, basic modes of operation,
maximum frame size, file management, console port and telnet
settings, system logs, SMTP alerts, system clock, switch clustering,
and UPnP
Activates authentication failure traps; configures community access
strings, and trap managers; also configures IP address filtering
Configures user names and passwords, logon access using local or
remote authentication (including AAA), management access through
the web server, Telnet server and Secure Shell; as well as port security,
IEEE 802.1X port access control, and restricted access based on
specified IP addresses
Segregates traffic for clients attached to common data ports; and
prevents unauthorized access by configuring valid static or dynamic
addresses, web authentication, MAC address authentication, and
filtering DHCP requests and replies
Provides filtering for IP frames (based on address, protocol, or TCP/
UDP port number or TCP control code) or non-IP frames (based on
MAC address or Ethernet type)
Configures the connection parameters for all Ethernet ports,
aggregated links, and VLANs
Statically groups multiple ports into a single logical trunk; configures
Link Aggregation Control Protocol for port trunks
Configures power output for connected devices
Mirrors data to another port for analysis without affecting the data
passing through or the performance of the monitored port
Controls the maximum rate for traffic transmitted or received on a port
Configures the address table for filtering specified addresses, displays
current entries, clears the table, or sets the aging time
Configures Spanning Tree settings for the switch
Configures VLAN settings, and defines port membership for VLAN
groups; also enables or configures private VLANs, protocol VLANs,
and voice VLANs
Configures LLDP settings to enable information discovery about
neighbor devices
Sets port priority for untagged frames, selects strict priority or weighted
round robin, relative weight for each priority queue, also sets priority for
TCP/UDP traffic types, and DSCP
Configures Differentiated Services
4
Command Groups
Page
4-10
4-16
4-86
4-100
4-148
4-176
4-188
4-202
4-213
4-219
4-221
4-222
4-226
4-248
4-226
4-286
4-316
4-9
.
