Husqvarna DXR 95 Operator's Manual page 23

Position
1
2
3
4
5
6
7
8
9
Rating plate (DXR 95)
1
2
3
4
5
1. Product type
2. Production year
3. Rated current
4. Short-Circuit Current Rating
5. Manufacturer
6. Hydraulic pressure
7. Product weight with no tools
8. Rated power
9. HID number, refers to the production year
10. Product designation
11. Scannable code
1401 - 005 - 11.01.2024
Function
Movable parts on the product are shown in orange. Not movable parts are shown in gray.
In pattern test. The product part that moves is shown in orange. Movable parts in the
selected operation mode is shown in light blue. Not movable parts are shown in dark blue.
The breaker is in operation.
The custom tool 1, 2 or 3 is in operation.
The concrete crusher is in operation.
The steel shear is in operation. (DXR 145, DXR 275, DXR 305, DXR 315)
The bucket is in operation.
The grapple is in operation.
The drum cutter is in operation.
11
10
Rating plate (DXR 145, DXR 275, DXR
305, DXR 315)
10
HID: XXXXXXXXXXXXXXXXXXXXXXXXX
3~380-420 V, 50 Hz, XX.XA, XX.X kW
3~440-480 V, 60 Hz, XX.XA, XX.X kW
9
HUSQVARNA AB, Huskvarna, SWEDEN
9
8
1. Product type
2. Scannable code
7
3. Product designation
4. Production year
6
5. Product weight with no tools
6. Pressure
7. Rated power
8. Rated current
9. Manufacturer
10. HID number, refers to the production year
The manufacturer's reservation
Husqvarna AB reserves the right to alter specifications
and instructions for the machine without prior
notification. The machine may not be modified without
the manufacturer's written permission. If the machine is
modified after delivery from Husqvarna AB and without
the manufacturer's written permission, it is the owner's
responsibility.
Modification can entail new risks for operators, the
machine and the surroundings. These can include
impaired strength or inadequate protection. It is the
responsibility of the owner to specify which alterations
DXR XXX
DEMOLITION ROBOT
Production Year: XXXX
XXXX kg / XXXX
Max Pressure:
MADE IN SWEDEN
8 7
1
2
3
4
Ibs
5
XXMPa
6
23
