Short instructions for configuring a reversing starter

Parameterization

The basics of parameterization

After the external wiring has been carried out (contactor coils connected,

current measuring module integrated in the main circuit), SIMOCODE pro is

then parameterized.

For this you need to know the following points:

Function blocks are stored internally in the SIMOCODE pro system, e.g. for

control stations, control functions and motor protection.

Function blocks have names.

Function blocks may have set values, e.g. the type of control function and the

set current for overload protection.

Function blocks are equipped with plugs and sockets. These are clearly

To achieve the desired functionality, proceed as follows:

• Connect the function blocks by connecting specific plugs to specific

• If required, set values in the function blocks, e.g. the set current, type of

The inputs of the function blocks in the basic unit are designated as plugs

and labeled accordingly:

The outputs of the function blocks in the basic unit are designated as sockets

and labeled accordingly:

The plugs and sockets of the device inputs and outputs are not connected as

factory defaults. If you press a button now, the contactors will not be

Table 2-2: Schematic of the various SIMOCODE pro function blocks

sockets (i.e "plug the plugs into the sockets")

control function.
