PVT SYSTEM

TROUBLESHOOTING

TROUBLESHOOTING
SITUATION PROBABLE CAUSE
Worn or broken drive clutch spring.
Engine RPM
Drive clutch shift weight too heavy.
below specified
operating range,
Driven clutch spring worn out or broken.
although engine
is properly tuned.
Worn driven clutch sliders
Drive clutch binding.
Erratic engine
operating RPM
Belt worn unevenly - thin / burnt spots.
during
acceleration or
load variations.
Driven clutch malfunction.
Sheave face grooved.
Incorrect drive clutch spring (too high of
rate).
Drive clutch shift weights incorrect for
application (too light).
Engine RPM
Drive clutch binding.
above specified
operating range.
Driven clutch binding.
Converter sheaves greasy; belt slipping.
Drive belt worn too narrow.
Harsh drive clutch
engagement.
Wrong drive clutch spring installed
Drive belt turns
Wrong belt for application.
over
Abuse (continued throttle application when
vehicle is stationary, excess load)
Belt burnt, thin
Dragging brake
spots
Slow, easy clutch engagement
5.18
REMEDY
Replace with recommended spring.
Install correct shift weight kit to match engine
application.
Replace spring; refer to proper installation
location.
Disassemble driven clutch; inspect sliders for
wear.
Disassemble drive clutch; inspect shift weights
for wear and free operation.
Clean and polish stationary shaft hub;
reassemble clutch without spring to determine
problem area.
Replace belt.
Replace sliders.
Inspect helix.
Inspect movable sheave for excessive bushing
clearance.
Replace the clutch.
Install correct recommended spring.
Install correct recommended shift weights.
Disassemble and clean clutch, inspecting shift
weights and rollers. Reassemble without the
spring and move sheaves through entire range
to further determine probable cause.
Disassemble, clean, and inspect driven clutch,
noting worn sheave bushing and helix/roller
wear
Clean sheaves with denatured alcohol or brake
cleaner, install new belt.
Replace belt.
Replace spring with correct one
Replace with correct belt.
Caution operator to operate machine within
guidelines.
Inspect brake system.
Fast, effective use of throttle for efficient
engagement.
