Specifications

Digital I/O
Resistors
Voltage
Prototyping Area
Traces
Physical
CE Compliance
When connected to other test objects, this product may cause radio interference.
Caution
In a residential environment, the user may be required to take adequate measures to reduce
the radio interference.
© National Instruments Corporation
DIO channels.......................................... 16, differential
Control I/O channels .............................. 6, differential
Number................................................... 44
Maximum voltage .................................. 5 V
Dimensions............................................. 4 cm × 9 cm
Solder pads ............................................. 154, unconnected
Type ....................................................... Matched length to 100 mils
AC impedance........................................ 100 Ω differential
Dimensions............................................. 17.55 cm × 2.07 cm × 20.32 cm
I/O connectors ........................................ One 73-pin DDC connector,
Refer to the regulatory statement for this product for additional
compliance information. To obtain this information for this product,
visit
ni.com/certification
and click the appropriate link in the Certification column.
(1.57 in. × 3.54 in.)
(6.91 in. × 0.816 in. × 8 in.)
44 SMA connectors
, search by model number or product line,
15 NI SMA-2164 User Guide
