Installing The Outdoor Unit - Huawei NetCol8000-A Series Quick Manual

Removing Compressor Fasteners
3.3
3.5 Lowering a Fan (Applicable to Downflow Units)
1. Remove the six screws and
then the beam.
4. After the fan rotates to the position
shown in the figure, push the fan
back to the horizontal position.
4

Installing the Outdoor Unit

• Protective cardboard for fins must be removed after installation to protect people from injuries.
• The installation methods of installing NetCol500-A060, NetCol500-A080 and NetCol500-A120
outdoor units are the same. This section describes how to install a NetCol500-A060.
• If the space does not meet the requirements of the recommended layout, you can use any of the
layouts (applicable only to NetCol500-A060) in user manual.
3.4
2. Rotate the fan upward by 30
degrees, and pull the rotating
shaft of the fan to the
outermost side.
5. Secure the beam and tighten
the six screws on the fan
support.
5
Securing to the Floor or Base
3. Slowly rotate the fan by 90
degrees and ensure that the
rotating shaft of the fan is on
the outermost side. Exercise
caution when handling the fan
to avoid body injury.
