Table 4-24 Punch Block 1 (System Alarm) Pinouts - Motorola iDEN Site Controller System Manual

Chapter 4 Installation
Intercabling Connections

Table 4-24 Punch block 1 (system alarm) pinouts

Alarm
code EAS/EAS2 function
210 reserved for system use
219 Site entry
220 Site high ambient temperature
221 Site low ambient temperature
223 Site AC surge protector
224 reserved for system use
241 RFC #4 circuit breaker
242 AC power failure
243 LO DC voltage
244 HI DC voltage
245 Breaker alarm failure
246 Minor rectifier module failure
4-52
Punch block 2
signal pairs (left side)
(NOTE)
28
3
Gen 3 Site Controller System Manual
Punch block 1
signal pairs (right side)
23
48
7
32
8
33
9
34
11
36
22
47
21
46
12
37
13
38
14
39
15
40
16
41
68P80801E30-A 5/1/2002
