Card Installation and Configuration

Electrostatic Discharge Caution

CAUTION! ESD can damage electronic components when they are improperly handled, and can result in total

or intermittent failures. Always follow ESD-prevention procedures when removing and replacing components.

To prevent ESD damage:

• Use an ESD wrist or ankle strap and ensure that it makes skin contact. Connect the equipment

end of the strap to an unpainted metal surface on the chassis.

• Avoid touching the adapter against your clothing. The wrist strap protects components from

ESD on the body only.

• Handle the adapter by its bracket or edges only. Avoid touching the printed circuit board or

the connectors.

• Put the adapter down only on an antistatic surface such as the bag supplied in your kit.

• If you are returning the adapter to Xilinx Product Support, place it back in its antistatic bag

immediately.

Installing Alveo Data Center Accelerator

Cards in Server Chassis

Because each server or PC vendor's hardware is different, for physical board installation

guidance, see the manufacturer's PCI Express

For programming and start-up details, see Getting Started with Alveo Data Center Accelerator Cards

(UG1301).
