- Page 1 IR Bullet Camera User Manual UD.6L0201D0089A01...
- Page 2 IR Bullet Camera· User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to Type Model DS-2CC1282P(N)-IT3 Ⅰ DS-2CC12A2P(N)-IT3 DS-2CC1282P(N)-IT5 Ⅱ DS-2CC12A2P(N)-IT5 This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
-
Page 3: Regulatory Information
IR Bullet Camera· User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 IR Bullet Camera· User Manual 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
-
Page 5: Table Of Contents
IR Bullet Camera· User Manual Table of Contents 1 Introduction ................5 1.1 Product Features ............5 1.2 Overview ..............6 2 Installation................8 2.1 Wall Mounting ............8 2.2 Wiring ..............11 Appendix................12 1 Glossary ..............12 2 Troubleshooting............16 3 Technical Maintenances ..........19... -
Page 6: Introduction
IR Bullet Camera· User Manual 1 Introduction 1.1 Product Features This series of camera adopts a new generation sensor with high sensitivity and advanced circuit design technology. It features high resolution, low image distortion and low noise, etc., which makes it suitable for surveillance system and image processing system. -
Page 7: Overview
IR Bullet Camera· User Manual 1.2 Overview Figure 1-1 Overview of Type Ⅰ Bullet Camera Table 1-1 Description Description Description Sun Shield Adjustable Screw Lens Power Cable IR LED Video Cable... - Page 8 IR Bullet Camera· User Manual Figure 1-2 Overview of Type Ⅱ Bullet Camera Table 1-2 Description Description Description Sun Shield Adjustable Screw Lens Power Cable IR LED Video Cable...
-
Page 9: Installation
IR Bullet Camera· User Manual 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during ... - Page 10 IR Bullet Camera· User Manual Push the sun shield to the outermost position and tighten the adjustable screw. Push Figure 2-1 Adjust the Sun Shield 2. Secure the Mount Secure the wall mount to the wall with the screws. Notes: The wall mount you select should be at least 1.5 times longer ...
-
Page 11: Install The Camera
IR Bullet Camera· User Manual Figure 2-2 Secure the Wall Mount 3. Install the Camera Secure the camera to the wall mount with the screws. Figure 2-3 Install the Camera... -
Page 12: Wiring
IR Bullet Camera· User Manual 2.2 Wiring Figure 2-4 The Power Cable and the Video Cable Note: Please make sure that the power adapter is compatible w ith the camera, and the standard power supply is 12V DC. Please refer to the technical specification for more information. -
Page 13: Appendix
IR Bullet Camera· User Manual Appendix 1 Glossary Note: The glossary gives brief explanations to the basic operation principle or the basic function of the camera. However, it doesn’t mean the listed functions are all supported by the camera mentioned in this user manual. Please take the function in the corresponding specification as the standard. -
Page 14: Motion Detection
IR Bullet Camera· User Manual signal remains essentially. When under low illumination, AGC will regulate the gain and amplification of the video signal. S/N ratio: It is the ratio of Signal voltage to noise voltage. The ratio is larger, the effect of noise is less, and the image is clearer. White Balance: White balance can remove the unrealistic color casts. - Page 15 IR Bullet Camera· User Manual This function allows you to block or mask certain area of a scene, thus prevent the personal privacy from recording or live view ing. OSD (On Screen Display): OSD is the texts superimposed on a screen. It can show the menu on the screen.
- Page 16 IR Bullet Camera· User Manual HLC (Highlight Compensation): The HLC is capable of detecting and reversing the bright spots in the picture (such as headlights) to black so as to achieve optimum picture quality. Digital Zoom: Digital zoom helps to crop the entire image, and then digitally enlarge the size of a portion of image that is needed to zoom in on.
-
Page 17: Troubleshooting
IR Bullet Camera· User Manual 2 Troubleshooting Problem 1: Why does the camera restart intermittently? And the problem is much more serious when infrared lights of IR camera are turned on at night. Possible Reasons: The main and common reason is power supply shortage. This problem may happen to the IR camera especially at night, because the infrared lights are turned on at night and increase the power consumption. - Page 18 IR Bullet Camera· User Manual Problem 3: The camera is installed w ith an auto-iris lens. You adjust the focus to get a clear image in the daytime. But the image is defocused at night. Possible Reasons: In the daytime, the illumination is high, so the iris is adjusted to a small size automatically.
- Page 19 IR Bullet Camera· User Manual To Solve the Problem: Check the auto-iris lens connector to ensure good contact. Set the iris driven mode of the camera the same as that of lens. The modes can be VD (video drive) or DD (direct drive). DD mode is commonly used.
-
Page 20: Technical Maintenances
IR Bullet Camera· User Manual 3 Technical Maintenances Lens Maintenance The lens surface is plated an anti-reflection coating. The dust, oil and finger print, etc. w ill cause scratch, mildewed and performance degraded. Please refer to the following method to clean the lens. - Page 21 IR Bullet Camera· User Manual 3. Change the cloth to wipe the bubble until the bubble is clean. Glass Maintenance of IR Camera Steps: 1. Wipe off the dust, water-drop or oil by soft cloth and dry the glass. 2. Use oil free cotton cloth or glass clean paper to wipe the glass from center to outside with alcohol or detergent.
- Page 22 IR Bullet Camera· User Manual...
