Cisco Catalyst 6000 Installation Note page 9

Figure 1
Figure 2
Step 2 Hold the SIMM by the edges and gently lift and remove it, placing it on an antistatic mat or foam.
Step 3 Remove the securing screws and cap nut (see
78-10605-03
Flash SIMM Location on the MSFC
Mounting holes
Removing the Flash SIMM
Catalyst 6000 Family Multilayer Switch Feature Card 2 Installation Note
Removing the MSFC from the Supervisor Engine 1A
Flash SIMM
holder
DRAM DIMM
Figure 3).
9
