TDM
Open: IPCP, crc 16, loopback not set
Keepalive set (10 sec)
Scramble disabled
Last input 00:00:04, output 00:00:04, output hang never
Last clearing of "show interface" counters 00:06:07
Input queue: 0/375/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
Output queue: 0/40 (size/max)
5 minute input rate 0 bits/sec, 0 packets/sec
5 minute output rate 0 bits/sec, 0 packets/sec
89 packets input, 4378 bytes
Received 0 broadcasts (0 IP multicasts)
0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
85 packets output, 4040 bytes, 0 underruns
0 output errors, 0 collisions, 1 interface resets
0 unknown protocol drops
0 output buffer failures, 0 output buffers swapped out
0 carrier transitions
Non-inverted data
ASR903-R3# ping 10.10.100.1 re 10
Type escape sequence to abort.
Sending 10, 100-byte ICMP Echos to 10.10.100.1, timeout is 2 seconds:
!!!!!!!!!!
Success rate is 100 percent (10/10), round-trip min/avg/max = 1/1/2 ms

OC-3 SONET POS

ASR903-R1 Configuration
controller SONET 0/5/0
framing sonet
clock source line
!
sts-1 1 - 3 pos
interface POS0/5/0.1
ip address 10.10.100.1 255.255.255.248
encapsulation ppp
ASR903-R3 Configuration
controller SONET 0/5/0
framing sonet
clock source internal
!
OL-30526-01
! create POS interface
! using encapsulation PPP, default is HDLC
