Introduction
The T10501 Wood lathe Center Kit provides a
variety of centers for the specific weight, size, and
wood type of the workpiece to be turned.
This 9-piece kit is designed for a lathe with a 1"
x 8 TPI (RH) spindle and a tailstock that accepts
mT#1 or mT#2 tooling.
The included mounting adapter accepts the six
accompanying ⁄ ", 1", and 1
5
8
and multi-spur drive centers. The mT#1 and mT#2
live centers offer rigidity while providing ample
tool clearance. Two wrenches are provided for
tightening and loosening the mounting adapter
and drive centers to the spindle.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ " diameter four-spur
1
2
COPYRIGHT © JulY, 2013 BY GRIZZlY INDuSTRIAl, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
#Dm15800 PRINTED IN CHINA
MODEL T10501
WOOD LATHE CENTER KIT
INSTRUCTIONS
Inventory
(see Figure
Description
A. live Center mT#2 ....................................... 1
B. live Center mT#1 ....................................... 1
C. Spur-Drive Center
D. Spur-Drive Center 1" .................................. 1
E. Spur-Drive Center 1
F.
multi-Spur Drive Center
G. multi-Spur Drive Center 1" .......................... 1
H. multi-Spur Drive Center 1
I.
Wrenches ................................................... 2
J. mounting Adapter 1" x 8 TPI ...................... 1
A
B
F
J
I
Figure 1. T10501 inventory.
Assembly
This 9-piece center kit is designed for quick and
easy installation.
Select the spur-drive center according to work-
piece size, wood type, and moisture content. Spur
drive centers are best for soft or wet wood, while
shorter toothed multi-spur drive centers are ideal
for dry or hardwood.
1
)
⁄ " ................................. 1
5
8
⁄ " ............................... 1
1
2
⁄ " ........................ 1
5
8
⁄ " ...................... 1
1
2
D
C
E
G
H
Qty
