Installing a CSS Module

Unpacking a CSS Module

Installing a Module

Caution
Cisco 11500 Series Content Services Switch Hardware Installation Guide
1-24
To unpack a CSS module:
Verify that the module is the model you ordered by checking the model
1.
number listed on the side of the shipping carton.
Remove the module from the shipping carton, leaving it in its anti-static bag.
2.
Put on the anti-static strap provided with your CSS. For example, wear the
3.
anti-static wrist strap (included in the accessory kit) and stick the copper-tape
end of the strap to an unpainted metal surface on the chassis. Make sure that
the wrist strap makes good contact with your skin.
Remove the module from the anti-static shielding bag and inspect it for
4.
damage.
Always hold the module by the faceplate, being careful not to touch the
components. If the module appears to be damaged, return it to the anti-static
bag, repack it in the shipping carton, and contact your local supplier.
5. To install a module into the CSS chassis, see the
section.
You must power down the CSS before installing or removing a Switch Module in
a CSS 11506.
Chapter 1 Unpacking and Installing the CSS
"Installing a Module"
