Summary of Contents for D-Link DCS-3112

  • Page 2: Table Of Contents

    Audio and Video .................30 Contacting Technical Support ........61 Preset Control ................32 Motion Detection ...............33 Warranty ................62 Time and Date ................34 Registration ..............68 Event Setup ...................35 Application ................36 Add Event ................42 Add Recording ..............43 SD Card ...................45 D-Link DCS-3112 User Manual...
  • Page 3 Section 1 - Product Overview Preface D-Link reserves the right to revise this publication and to make changes in the contents hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description September 6, 2011 DCS-3112 Revision A1 with firmware version V1.00...

  • Page 4: Package Contents

    Section 1 - Product Overview Package Contents DCS-3112 Network Camera Camera Stand CAT5 Ethernet Cable Power Adapter Manual and Wizard on CD-ROM If any of the above items are missing, please contact your reseller. D-Link DCS-3112 User Manual...

  • Page 5: Hardware Overview

    Audio Output for external speakers I/O Connector I/O connectors for external devices Power and network indicator RJ-45 connector for Ethernet which can also be used to power the camera using Ethernet (PoE) Power over Ethernet (PoE) D-Link DCS-3112 User Manual...

  • Page 6: Front

    Section 2 - Hardware Overview Front Lens Connector Connect to a CS mount The IR-Cut Removable sensor judges lighting conditions and switches from color to ICR Sensor infrared accordingly D-Link DCS-3112 User Manual...
  • Page 7 2. DC IRIS: Use an auto iris (DC drive) 3. NTSC: TV output signal selector 4. PAL: TV output signal selector DC-Iris Connector Connector for DC auto iris lens DIP Switch Toggles several different camera options D-Link DCS-3112 User Manual...
  • Page 8 Section 2 - Hardware Overview SD Card Slot Local SD card for storing recorded images and videos D-Link DCS-3112 User Manual...

  • Page 9: Configuration With Wizard

    Configuration with Wizard Insert the DCS-3112 CD into your computer's CD-ROM drive to begin the installation. If the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start automatically, click Start > Run. Type D:\autorun.exe, where D: represents the drive letter of your CD-ROM drive.
  • Page 10 Section 3 - Configuration Click Yes to accept the License Agreement. Then, click Next to continue. To start the installation process, click Next. Note: The installation may take several minutes to finish. D-Link DCS-3112 User Manual...
  • Page 11 Section 3 - Configuration Click Finish to complete the installation. Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE D-Link DCS-3112 User Manual...
  • Page 12 Click the Wizard button to continue. Enter the Admin ID and password. When logging in for the first time, the default Admin ID is admin with the password left blank. Click Next, to proceed to the next page. D-Link DCS-3112 User Manual...
  • Page 13 Select DHCP if your camera obtains an IP address automatically when it boots up. Select static IP if the camera will use the same IP address each time it is started. Click Next, to proceed to the next page. Take a moment to confirm your settings and click Restart. D-Link DCS-3112 User Manual...

  • Page 14: Web-Based Configuration Utility

    Section 3 - Configuration Web-based Configuration Utility This section explains how to configure your new D-Link Network Camera using the Web-based Configuration Utility. Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE Select the camera and click the button labeled "Link"...
  • Page 15 Section 3 - Configuration Enter admin as the default username and leave the password blank. Click OK to continue. Check Always trust content from D-Link and then click Yes to continue. D-Link DCS-3112 User Manual...
  • Page 16 This section shows your camera’s live video. You can select your video profile and view or operate the camera. For additional information about web configuration, please refer to the user manual included on the CD-ROM or the D-Link website. D-Link DCS-3112 User Manual...

  • Page 17: D-Viewcam Setup Wizard

    Section 3 - Configuration D-ViewCam Setup Wizard D-ViewCam software is included for the administrator to manage multiple D-Link IP cameras remotely. You may use the software to configure all the advanced settings for your cameras. D-ViewCam is a comprehensive management tool for IP surveillance.
  • Page 18 Section 3 - Configuration Click Finish to complete the installation. To start D-ViewCam, select Start > All Programs > D-Link D-ViewCam > Main Console. For more detail operation of using D-ViewCam software, please refer to D-ViewCam Manual. D-Link DCS-3112 User Manual...

  • Page 19: Live Video

    Recording a Video Clip This control pad can be used to pan, tilt, and zoom Control Pad within the camera's predefined view area, if one has Set a Storage Folder been defined. Listen/Stop Listening Talk/Stop Talking Start/Stop Digital Output D-Link DCS-3112 User Manual...
  • Page 20 (ROI). Stop Stops the camera ePTZ You may select the interface language using this menu. The available options motion are English and Traditional Chinese. Preset Path Starts the camera's motion along the pre- defined path D-Link DCS-3112 User Manual...

  • Page 21: Setup

    Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera and connect the camera to the internet. Click Next to continue. Note: Select DHCP if you are unsure of which settings to choose.
  • Page 22 If you have a Dynamic DNS account and would like the camera to update your IP address automatically, Select Enable DDNS and enter your host information. Click Next to continue. Enter a name for your camera and click Next to continue. D-Link DCS-3112 User Manual...
  • Page 23 If you have selected DHCP, you will see a summary of your settings, including the camera's IP address. Please write down all of this information as you will need it in order to access your camera. Click Apply to save your settings. D-Link DCS-3112 User Manual...

  • Page 24: Motion Detection Setup Wizard

    Please see the Motion Detection section on page 27 for information about how to configure motion detection. Step 2 This step allows you to enable motion detection based on a customized schedule. Specify the day and hours. You may also choose to always record motion. D-Link DCS-3112 User Manual...
  • Page 25 Click Next to continue. Step 4 You have completed the Motion Detection Wizard. Please verify your settings and click Apply to save them. Please wait a few moments while the camera saves your settings and restarts. D-Link DCS-3112 User Manual...

  • Page 26: Network Setup

    Enabling this setting allows your camera to be configured as a UPnP device on your network. Enable UPnP Port Enabling this setting allows the camera to add port forwarding entries into the router automatically on a UPnP capable Forwarding: network. D-Link DCS-3112 User Manual...
  • Page 27 Download Bandwidth: heavily loaded network. Entering a value of '0' indicates that the camera should not monitor bandwidth. Specifying other values will limit the camera's transfer speed to the specified number of Kilobytes per second. D-Link DCS-3112 User Manual...

  • Page 28: Dynamic Dns

    Enter your user name or e-mail used to connect to the DDNS. Password: Enter your password used to connect to the DDNS server. Timeout: Enter DNS Timeout values. Status: Indicates the connection status, which is automatically determined by the system. D-Link DCS-3112 User Manual...

  • Page 29: Image Setup

    This setting controls the amount of coloration, from grayscale to fully saturated. Saturation: Specify a value from 0 to 8 for image edge enhancement. Sharpness: Click this button to reset the image to factory default settings. Reset Default: D-Link DCS-3112 User Manual...

  • Page 30: Audio And Video

    The bps will affect the bit rate of the video recorded by the camera. Higher bit rates result in higher video quality. Select the image quality level for the camera to try to maintain. High quality levels will result in increased bit rates. Fixed quality: D-Link DCS-3112 User Manual...
  • Page 31 This setting controls the amount of gain applied to incoming audio to increase its volume. Audio out off: Ticking this checkbox will mute outgoing audio. Audio out volume level: This setting controls the amount of gain applied to outgoing audio to increase its volume. D-Link DCS-3112 User Manual...

  • Page 32: Preset Control

    A preset sequence is an automated series of camera movements from one preset position to another. A guard tour can be set up to display the video streams from different preset positions in a pre-determined order, and for configurable time periods. D-Link DCS-3112 User Manual...

  • Page 33: Motion Detection

    Right clicking on the camera image brings up the following menu options: Select All: Draws a motion detection area over the entire screen. Clear All: Clears any motion detection areas that have been drawn. Restore: Restores the previously specified motion detection areas. D-Link DCS-3112 User Manual...

  • Page 34: Time And Date

    Enable this feature to obtain time automatically from an Server: NTP server. NTP Server: Network Time Protocol (NTP) synchronizes the DCS-3112 with an Internet time server. Choose the one that is closest to your location. Set the Date and Time This option allows you to set the time and date manually.

  • Page 35: Event Setup

    2. To delete the selected item from the pull-down menu of event, server or media, click Delete. 3. Click on the item name to pop up a window for modifying. Note: You can add up to four events, five servers, and five media fields. D-Link DCS-3112 User Manual...

  • Page 36: Application

    Application In a typical application, when motion is detected, the DCS-3112 Network Camera sends images to a FTP server or via e-mail as notifications. As shown in the illustration below, an event can be triggered by many sources, such as motion detection or external digital input devices. When an event is triggered, a specified action will be performed.
  • Page 37 Application In a typical application, when motion is detected, the DCS-3112 Network Camera sends images to a FTP server or via e-mail as notifications. As shown in the illustration below, an event can be triggered by many sources, such as motion detection or external digital input devices. When an event is triggered, a specified action will be performed.
  • Page 38 Enter the configuration for the target e-mail server account. FTP: Enter the configuration for the target FTP server account. Network Storage: Specify a network storage device. Only one network storage device is supported. SD Card: Use the camera's onboard SD card storage. D-Link DCS-3112 User Manual...
  • Page 39 The maximal file size would be generated. File name prefix: The prefix name will be added on the file name of the video clip. System log: Select this option to save events to the camera system log. D-Link DCS-3112 User Manual...
  • Page 40 Add a date and time suffix to the file name Select this option to add a date and time to the file name suffix. SNAPSHOTS20080104_100341 Date and time suffix File name prefix The format is: YYYYMMDD_HHMMSS D-Link DCS-3112 User Manual...
  • Page 41 8 sec. 9 sec. 10 sec. The moment the trigger is activated. File name prefix Enter the text that will be added at the beginning of the file name. VIDEOS20080104_100341 File name prefix Date and time suffix The format is: YYYYMMDD_HHMMSS D-Link DCS-3112 User Manual...

  • Page 42: Add Event

    Select Always or enter the time interval. Trigger D/O: Select to trigger the digital output for a specific number of seconds when an event occurs. Server: Specify the location where the event information should be saved to. D-Link DCS-3112 User Manual...

  • Page 43: Add Recording

    Size of each file File size for each recording file. You may input the value in the range of 200-5000. for recording: File Name Prefix: The prefix name will be added on the file name of the recording file(s). D-Link DCS-3112 User Manual...
  • Page 44 The password to your account. You may obtain this information from your ISP. HTTP Port: The default value is 80. RTSP port: The port number that you use for RTSP streaming to mobile devices, such as mobile phones or PDAs. The default port number is 554. D-Link DCS-3112 User Manual...

  • Page 45: Sd Card

    If video files are stored on the SD card, click on the video folder and Video: choose the video file you would like to view. Refresh: Reloads the file and folder information from the SD card. D-Link DCS-3112 User Manual...

  • Page 46: Advanced

    "Closed." LED: You may specify whether or not to illuminate the LED on the side of the camera. Video Output: Enable/ disable the BNC terminal TV output signal. D/I and D/O Pin Block D-Link DCS-3112 User Manual...
  • Page 47 The stop bit is used to signal the end of communication for a single packet. The more bits used for stop bits, the greater the lenience in synchronizing the different clocks but the slower the data transmission rate. The stop bit can be set to 1 or 2. The default value is 1. D-Link DCS-3112 User Manual...

  • Page 48: Icr

    Sync With ICR, the power output will be enabled whenever the IR Cut Filter is active. Alternatively, you can select Schedule and manually specify when the power should be enabled. DC Power Output 12V DC, 200mA D-Link DCS-3112 User Manual...

  • Page 49: Https

    Create a certificate request and install. Status: Displays the status of the certificate. Note: The certificate cannot be removed while the HTTPS is still enabled. To remove the certificate you must first uncheck Enable HTTPS secure connection. D-Link DCS-3112 User Manual...

  • Page 50: Access List

    Section 3 - Configuration Access List Here you can set access permissions for users to view your DCS-3112. Allow list: The list of IP addresses that have the access right to the camera. Start IP address: The starting IP Address of the devices (such as a computer) that have permission to access the video of the camera.

  • Page 51: Maintenance

    Enable OSD: Select this option to enable the On-Screen Display feature for your camera. Label: Enter a label for the camera. Show Time: Select this option to enable the time-stamp display on the video screen. D-Link DCS-3112 User Manual...

  • Page 52: Backup And Restore

    Load Configuration. Restore to Factory Default: You may reset your camera and restore the factory settings by clicking Restore Factory Defaults. Reboot Device: This will restart your camera. D-Link DCS-3112 User Manual...

  • Page 53: Firmware Upgrade

    Section 3 - Configuration Firmware Upgrade The camera's current firmware version will be displayed on this screen. You may visit the D-Link Support Website to check for the latest available firmware version. To upgrade the firmware on your DCS-3112, please download and save the latest firmware version from the D-Link Support Page to your local hard drive.

  • Page 54: Status

    Section 3 - Configuration Status Device Info This page displays detailed information about your device and network connection. D-Link DCS-3112 User Manual...

  • Page 55: Logs

    Section 3 - Configuration Logs This page displays the log information of your camera. You may download the information by clicking Download. You may also click Clear to delete the saved log information. D-Link DCS-3112 User Manual...

  • Page 56: Help

    Section 3 - Configuration Help This page provides helpful information regarding camera operation. D-Link DCS-3112 User Manual...

  • Page 57: Di/Do Schematics

    Section 3 - Configuration DI/DO Schematics DI/DO D-Link DCS-3112 User Manual...
  • Page 58 Connect to an alarm or buzzer. Refer to page 57. Connect to the RS-485 interface for controlling auxiliary equipment 485+/485- such as an external camera enclosure to perform PAN and TILT movement. Refer to page 57 for more information. D-Link DCS-3112 User Manual...

  • Page 59: Technical Specifications

    ƒ Audio input / output ƒ RS-485 ƒ Video output IPv4, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP/HTTPS, Network Network Protocols Samba Client, PPPoE, UPnP Port Forwarding, RTP/RTSP/RTCP, IP filtering, 3GPP, IGMP, ONVIF compliant ƒ...
  • Page 60 0 to 40 ˚C (32 to 104 ˚F) Temperature Storage -20 to 70 °C (-4 to 158 °F) Temperature Humidity 20% to 80% non-condensing Weight 560 g DCS-3112 Certifications CE (Class A), LVD, FCC (Class A), ICES-003, C-Tick Dimensions 180.4 135.9 139.4 D-Link DCS-3112 User Manual...

  • Page 61: Contacting Technical Support

    • Hardware Revision (located on the label on the bottom of the Network Camera (e.g. rev A1)) • Serial Number (s/n number located on the label on the bottom of the Network Camera). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.

  • Page 62: Warranty

    Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement hardware need not be new or have an identical make, model or part. D-Link may, at its option, replace the defective Hardware or any part thereof with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.
  • Page 63 D-Link further warrants that, during the Software Warranty Period, the magnetic media on which D-Link delivers the Software will be free of physical defects. The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to replace the non-conforming Software (or defective media) with software that substantially conforms to D-Link’s...
  • Page 64 • USA residents send to 17595 Mt. Herrmann, Fountain Valley, CA 92708. D-Link will not be held responsible for any packages that are lost in transit to D-Link. The repaired or replaced packages will be shipped to the customer via UPS Ground or any common carrier selected by D-Link.
  • Page 65 While necessary maintenance or repairs on your Product can be performed by any company, we recommend that you use only an Authorized D-Link Service Office. Improper or incorrectly performed maintenance or repair voids this Limited Warranty.
  • Page 66 No part of this publication or documentation accompanying this product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States Copyright Act of 1976 and any amendments thereto.
  • Page 67 The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. For detailed warranty information applicable to products purchased outside the United States, please contact the corresponding local D-Link office.

  • Page 68: Registration

    Appendix E - Registration Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.0 September 6, 2011 D-Link DCS-3112 User Manual...
