D-Link Securicam DCS-3110 Specification Sheet

®

Key Features

+ 1/4" 1.3 Megapixel Progressive Scan
CMOS Sensor
+ 6mm Lens, F1.6
+ 4x Digital Zoom
+ Up to 30 Frames Per Second
+ IR-Cut Removable (ICR) Filter for
Day/Night Use
+ Simultaneous Dual-Stream Support
+ Multicast Streaming
+ Motion Detection Recording with
E-mail Alert
+ Built-in Samba Client
+ Compact Flash Card Slot
+ Built-In Microphone and Speaker Port
for 2-Way Communication
+ Digital I/O Support for Sensors and
Alarms
+ RS-485 for P/T Enclosure Connection
+ Built-in 802.3af PoE
3
D-ViewCam 2.0 FEATURES
+ Manage up to 32 Cameras at once
+ Adjustable Image Size and Quality
+ Custom Recording Schedules
+ Event Notifications
+ Upload a Floor Plan
+ Flip & Mirror Image
DCS-3110 Fixed Network Camera
Day & Night Megapixel Camera with PoE Support
High Resolution Surveillance
The D-Link DCS-3110 Fixed Network Camera is a high
®
performance megapixel camera designed for professional
surveillance and security applications. Equipped with
a 1.3 Megapixel Progressive Scan CMOS sensor and a
6mm Lens, the DCS-3110 allows you to capture a wider
field of view with a resolution of up to 1280 x 1024. The
built-in ICR filter in the DCS-3110 provides automatic
Day/Night functionality, adjusting the image from
color during the day (and in low-light conditions) to
monochrome at night (or in extremely poor lighting
conditions).
With features such as simultaneous MPEG-4/MJPEG
streaming, multicast MPEG-4 streaming, PoE support, a
built-in Compact Flash card slot, and connectivity to a
variety of external devices, the DCS-3110 is an extremely
versatile solution for high quality, high resolution viewing
and reliable recording throughout the day.
Multiple Streaming
The DCS-3110 supports simultaneous streaming of
MPEG-4 and MJPEG video to provide both high quality
and bandwidth efficient compression formats. MJPEG
delivers greater file integrity, making it ideal for detailed
monitoring situations. MPEG-4 has smaller file sizes,
making it more useful for extended recording periods
or for use in low bandwidth networks. Additionally, the
DCS-3110 supports multicast MPEG-4 streaming allowing
users to view content by subscribing to a multicast IP
address on the network.
Flexible Connectivity
The DCS-3110 includes digital input and output ports
(one each) allowing connectivity to external devices
such as IR sensors, switches, and alarm relays. It also
comes with a RS-485 interface, providing connectivity
to an optional Pan/Tilt enclosure, which effectively adds
pan/tilt functionality to the DCS-3110. Additionally, a 12V
interface provides power for an optional LED illuminator.
3GPP Mobile Surveillance
Support for 3GPP Mobile Surveillance
view a live video feed from your compatible Internet-ready
mobile phone with a 3GPP player installed. This extends
your monitoring capability without requiring the use of
a computer, allowing you to check your camera's video
feed while on-the-go.
Additional Features
The DCS-3110 comes with a built-in microphone and
audio ports allowing 2-way audio communication
an external speaker is connected and even includes
an audio switch to ensure privacy when needed. The
DCS-3110 also comes with a built-in Samba client for
NAS so there is no need for a direct connection to a PC or
any other hardware or software to capture and transfer
images. Equipped with 802.3af Power over Ethernet (PoE)
support , the DCS-3110 can receive both power and data
3
over a single Ethernet cable, allowing you to place this
camera in locations without a power outlet
Convenient Management
The included D-Link D-ViewCam™ 2.0 software enables
you to manage up to 32 network cameras, set e-mail
alert notifications, set recording schedules, and trigger
motion detection to record directly to your hard drive.
D-ViewCam 2.0 also allows you to upload a floor plan of
your business and create a realistic layout of where your
cameras are located, further simplifying the management
process.
allows you to
1
when
2
