LED CONNECTORS

The following figure shows the location of the LED connector on the system board. For
more information, see the following subsections.

Hard Drive LED Connector

The following figure shows the hard disk LED connector on the system board. Table
Appendix A-8 provides the pin assignments.
Figure Appendix A-7 Hard Disk LED Connector
Pin
1
2
3
4
L E D C o n n e c t o r s
Figure Appendix A-6 LED Connectors
1
SPKR RST PWRLED HDLED INFRARED
Table Appendix A-8 Hard Disk LED Pin
Assignments
Signal Name
+5V (white)
HD ACTIVE
Key
+5V
Connector Pin Assignments
4
SLP RP
A-9
