Operations - Grizzly PRO QUIET Series Owner's Manual

Breaking in the Pump
1. Turn the switch to the OFF position.
2. Open the drain valve. Turn counterclockwise (loosen).
3. Plug in the air compressor and switch the power switch to the ON position.
4. The compressor will start.
Allow the compressor to run for 15 minutes to break in the internal parts.
After about 15 minutes. If the unit does not operate properly, shut down immediately and
WARNING!
contact product service center (832) 415-6995.
5. After about 15 minutes, turn the power switch to the OFF position.
6. Close the drain valve by turning in clockwise direction.
7. Turn the power switch to the ON position. The compressor will start and fill the tank to the cut-out pressure and stop.
WAR
As compressed air is used, the pressure switch will restart the motor automatically.
NOTE!
During the initial break-in cycle, there will be a slight electrical smell as the motor brushes
NOTE!
seat. This is normal for universal motors and will last for about 5 minutes.
Operating Instructions
Daily Startup
1. Turn the power switch to the OFF position.
2. Close the tank drain valve. Turn in clockwise direction.
3. Plug in the power cord.
4. Turn the power switch to the ON position.
High temperatures are generated by the electrical motor and the pump. To prevent burns or
WARNING!
other injuries, do not touch the compressor while it is running. Allow it to cool before
handling or servicing. Keep children away from the compressor at all times.
