- Page 1 Z5600.552 Manual 1.2 en...
- Page 2 General information Z5600.552 Manual Version: 1.2 en, 06/2022, D2760.US .01 Copyright © 2022 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
- Page 3 9. Unplug the rack assembly during lightning storms or when – Do not operate the rack assembly while it is wet or standing unused for long periods of time. in liquid. d&b Z5600.552 Manual 1.2 en...
-
Page 4: Table Of Contents
DN1 Ethernet switch............13 5.1 Overview.................. 13 5.2 Mains connection..............13 5.3 Front panel................13 5.3.1 ETH 9 - ETH 11..............13 5.3.2 Mode selection..............14 5.3.3 LED indicators................ 14 5.4 Rear panel................15 Rack wiring diagrams............. 16 d&b Z5600.552 Manual 1.2 en... -
Page 5: D40 Touring Rack Assembly 10 Ru - Nema
D40 Touring rack assembly 10 RU - NEMA 1.1 Intended use The Z5600.552 D40 Touring rack assembly NEMA is designed as a closed system rack providing mains power distribution and connector interfaces for 3 x D40 amplifiers. For this purpose, the touring rack is equipped with a mains power distribution device (Z5605.001), which also serves as a loudspeaker connector... - Page 6 Dimensions and weight Height x width x depth 710 x 600 x 715 mm 28 x 23.6 x 28.2" Total weight ( 1x DN1 included) 110 kg / 242 lb d&b Z5600.552 Manual 1.2 en...
-
Page 7: Handling, Cooling And Placement
Make sure both the front and rear doors are opened and pushed into their park positions to provide sufficient cooling. When using the d&b Z5600.552 Touring rack assembly, make sure to provide sufficient space of 0.5 m (1.6 ft) at the front and rear of the touring rack to ensure adequate cooling airflow. -
Page 8: Z5605.001 Mains Power Distributor And Ls Panel - Nema
The Z5605.001 Mains power distributor is supplied with a NEMA 30 A 3ØY 120/208 VAC male connector socket that accepts max. a corresponding NEMA female connector. Required mains supply network configuration 30 A 3ØY 120/208 VAC 50-60 Hz, B or C-Frame type. max. d&b Z5600.552 Manual 1.2 en... -
Page 9: Amp 1 / Amp 2 / Amp 3 Mains Supply
One of these sockets is used to apply mains supply for the DN1 device. The remaining sockets are intended for the connection of low current devices such as notebooks or additional Ethernet switches. The sockets are equipped with dedicated circuit-breakers (20 A / B-Frame type). d&b Z5600.552 Manual 1.2 en... -
Page 10: Amplifier Mains Outputs
1+/— = Channel A pos. / neg. 2+/— = Channel B pos. / neg. 3+/— = Channel C pos. / neg. 4+/— = Channel D pos. / neg. Please refer to the corresponding channel assignment label above each connector as shown in the graphic opposite. d&b Z5600.552 Manual 1.2 en... -
Page 11: Output
12 CH OUTPUT AMP 1/2/3 LKA25 Amplifier LKA25 Amplifier LKA25 Amplifier AMP 1 AMP 2 AMP 3 1– 1– 1– 2– 2– 2– 3– 3– 3– 4– 4– 4– d&b Z5600.552 Manual 1.2 en... -
Page 12: Z5604 I/O Panel
DN1 when linking entire rack assemblies, as shown in the graphic opposite. It is recommended to link a maximum of up to 6 rack assemblies in this way. I/O panel, rack link example: 2ch Analog audio and Ethernet/OCA d&b Z5600.552 Manual 1.2 en... -
Page 13: Dn1 Ethernet Switch
ArraySight sender unit, which is integrated in the flying frame for vertical aiming of the entire array. maximum total of 25 W. If the maximum power is exceeded, PoE supply will be shut off. d&b Z5600.552 Manual 1.2 en... -
Page 14: Mode Selection
Alle remote settings are set to default. 5.3.3 LED indicators All device states and operating modes are indicated by dedicated multi-colored LEDs. Note: In case of an device error, connect the device to R1 via OCA to obtain further information. d&b Z5600.552 Manual 1.2 en... -
Page 15: Rear Panel
No active connection No AVB network No PoE enabled information device connected LED flashing Traffic PoE Error 5.4 Rear panel ETH 1 - ETH 8 The DN1 device provides a RJ45 8-port panel at the rear of the device. d&b Z5600.552 Manual 1.2 en... -
Page 16: Rack Wiring Diagrams
Rack wiring diagrams Mains power connection and internal mains supply distribution d&b Z5600.552 Manual 1.2 en... - Page 17 Internal 4 CHANNEL OUTPUT wiring d&b Z5600.552 Manual 1.2 en...
- Page 18 Internal analog audio INPUT and LINK wiring d&b Z5600.552 Manual 1.2 en...
- Page 19 Internal digital audio INPUT and LINK wiring d&b Z5600.552 Manual 1.2 en...
- Page 20 Internal Ethernet network wiring d&b Z5600.552 Manual 1.2 en...
- Page 22 www.dbaudio.com...
