- Page 1 D20 Touring rack assembly US Manual 1.0...
- Page 2 General information D20 Touring rack assembly US Manual 1.0 Version: 1.0, 09/2016 Copyright © 2016 by d&b audiotechnik Corporation; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.
-
Page 3: Table Of Contents
Contents 1. Z5560 D20 Touring rack assembly US ......4 1.1. Intended use 1.2. Scope of supply 2. Handling, cooling and placement ......5 2.1. Handling 2.2. Cooling and placement 3. ML 1105 Mains power distributor - 20A ....6 3.1. Intended use 3.2. -
Page 4: Intended Use
1. Z5560.US D20 Touring rack assembly US 1.1. Intended use The Z5560.US D20 Touring rack assembly is designed as a closed system rack providing mains power distribution and connector interfaces for 3 x D20 amplifiers. For this purpose, the touring rack is equipped with a mains power distribution device (ML 1105), which also serves as a loudspeaker connector panel. -
Page 5: Handling, Cooling And Placement
3. Push the door to the rear into its park position. 2.2. Cooling and placement When using the d&b Z5560 D20 Touring rack assembly, make sure to provide sufficient space of 0.5 m (1.6 ft) at the front and rear of the touring rack to ensure sufficient cooling airflow. -
Page 6: Ml 1105 Mains Power Distributor - 20A
3. ML 1105 Mains power distributor - 20A ML 1105 Front Panel ML 1105 Rear Panel 3.1. Intended use The ML 1105 Mains power distributor is designed and dimensioned to provide and distribute the mains power supply necessary for the three D20 amplifiers. -
Page 7: Mains Supply
3.2.2. MAINS SUPPLY The ML 1105 Mains power distributor is supplied with a fixed 3-phase 30 A L21-30 mains connector socket. When the rack is connected to the on-site mains power supply, three LED indicators display the presence of the on-site mains supply lines (phase conductor X, Y, Z). -
Page 8: Signal
3.3. Signal 3.3.1. 4 CH. OUTPUTS - NL8 NOTICE! The 4 CH OUTPUTS connectors are only intended as an interface to a rack panel or to loudspeaker multicores such as d&b Z5343.xxx and breakout adapters such as d&b Z5347.xxx and d&b Z4348. xxx. -
Page 9: Z5338 I/O Panel
4. Z5338 I/O Panel 4.1. INPUT The INPUT section represents the input connectors of the first amplifier while the other two amplifiers are linked within the rack. The INPUT section allows both analog and digital audio signals to be fed to the amplifier. - Page 10 CAN-Bus network Represents the CAN input of the first amplifier while the other two amplifiers are linked within the rack. CAN LINK Represents the CAN output of the last amplifier. TERMINATE/ The built-in termination switch allows two LINK settings: 1. LINK: In system racks, at the start of and within a CAN-Bus segment, set the switch to LINK.
-
Page 11: Z5333 Rack Link
5. Z5333 Rack link The rack link cable allows further system racks to be linked together. It is suitable for both analog and digital audio signals as well as for network wiring (Ethernet or CAN-Bus networks). Technical specifications Audio connector ......... 2 x XLR female to 2 x XLR male ................... -
Page 12: Z4010 Ds10 Audio Network Bridge
6. Z4010 DS10 Audio network bridge 6.1. Use with d&b Touring rack I/O panel The DS10 replaces the 1RU drawer of the complete rack assembly. 1. The DS10 is mounted above the I/O panel. If upgrading a complete rack assembly, simply remove the rack drawer. -
Page 13: Declarations
7. Declarations 7.1. Declaration of conformity (ETL symbol) This declaration applies to: D20 RakPak - L21-30/NL8 115v, ML 1105.000 Motion Laboratories part number: 1105-2-K-000-5001 manufactured by Motion Laboratories. ML 1105.001 is ETL listed Conforms to ― UL STD 508A ― UL STD 1640 Certified to ―... - Page 14 www.dbaudio.com...
