Grizzly H8155 Replacement Parts

Replacement Parts And Labels

1
2
3
4
5
REF PART # DESCRIPTION
1 PH8155001 WELDERS MASK
2 PH8155002 MASK HANDLE
3 PH8155003 LENSE RETAINING CLIP
4 PH8155004 MASK LENSE
5 PH8155005 UTILITY BRUSH AND SLAG HAMMER
6 PH8155006 CONTROL TIP WRENCH
7 PH8155007 CONTROL TIP
8 PH8155008 WELDING TORCH NOZZLE
9 PH8155009 GAS INLET TUBE
10 PH8155010 HANDLE BRACKET
11 PHTEK11 TAP SCREW #8 X 3/4
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
-16-
9
10
6
7
12
8
11
14
18
16
REF PART # DESCRIPTION
12 PH8155012 HANDLE
13 PH8155013 WIRE FEED ASSEMBLY
14 PH8155014 WIRE SPOOL RETAINING NUT
15 PWN02 WING NUT 1/4-20
16 PH8155016 WELDING TORCH ASSEMBLY
17 PH8155017 WORK CLAMP ASSEMBLY
18 PH8155018 MACHINE ID LABEL
19 PLABEL-14 ELECTRICITY LABEL
20 PH8155020 SHOCK WARNING LABEL
21 PLABEL-12 READ MANUAL 2" X 3 5/16"
13
15
19
20
21
17
H8155 MIG Welder
