- Page 1 Drain Cleaner Manual K-1500A/B & K-1500SP Drain Cleaning Machines • Français – 15 • Castellano – pág. 33 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 2: Table Of Contents
Work Area Safety ................................2 Electrical Safety................................2 Personal Safety ................................3 Power Tool Use and Care ............................3 Service ..................................3 Specific Safety Information Drain Cleaner Safety ..............................4 RIDGID ® Contact Information............................4 Description, Specifications and Standard Equipment Description ..................................5 Specifications ................................5 Standard Equipment..............................5 Machine Inspection ...............................6 Machine Set-Up................................6... -
Page 3: Recording Form For Machine Serial Number
Drain Cleaner K-1500A/B & K-1500SP Drain Cleaning Machines WARNING! Read this Operator’s Manual carefully before using this tool. Failure to understand and follow the contents of Drain Cleaning Machine this manual may result in Record Serial Number below and retain product serial number which is located on nameplate. electrical shock, fire and/or serious personal injury. -
Page 4: Safety Symbols
The operator’s manual con- tains important information on the safe and proper operation of the equipment. This symbol means always wear RIDGID drain cleaning mitts while operating drain cleaner. This symbol means always wear safety glasses with... -
Page 5: Personal Safety
K-1500A/B, & K-1500SP Drain Cleaning Machines • Disconnect the plug from the power source and/or (GFCI) protected supply. Use of a GFCI reduces the the battery pack from the power tool before making risk of electric shock. any adjustments, changing accessories, or storing power tools. -
Page 6: Drain Cleaner Safety
K-1500A/B, & K-1500SP Drain Cleaning Machines Drain Cleaner Safety the drain inlet or properly support exposed cable when the distance exceeds 2' (0.6 m). Greater dis- • Before using the tool, test the ground fault circuit in- tances can cause control problems leading to twisting, terrupter (GFCI) provided with the power supply kinking or breaking of the cable. -
Page 7: Description, Specifications And Standard Equipment Description
(GFCI) is built into the line cord. A toggle or rotary switch pro- FrameAssembly. vides FORWARD/OFF/REVERSE control of the motor. See the RIDGID Catalog for machine model options and Machines are designed to use sectional-type cable that accessories. Every machine model includes as standard has a quick coupling system for disconnecting tools. -
Page 8: Machine Inspection
• Flammable liquids, vapors or dust that may ignite. 2. Position the Drain Cleaning Machine within 2' of Figure 2 – K-1500B and K-1500SP Drain Cleaning sewer inlet. Greater distance can result in cable twist- Machines ing or kinking. -
Page 9: Operating Instructions
K-1500A/B, & K-1500SP Drain Cleaning Machines To Couple Cable To Uncouple Cable and Tools and Tools Snap Together Insert Pin Slide Apart Figure 5 – Coupling and Uncoupling Tools NOTE! Proper Tool Selection A good rule of thumb is to use a tool at least 1" smaller than the line to be cleaned. - Page 10 K-1500A/B, & K-1500SP Drain Cleaning Machines against dirt and other foreign objects. Wear rubber 3. Pull enough extra cable through machine to form al- soled, non-slip shoes. most a half circle between machine and line opening. Be very careful when cleaning drains where clean- 4.
-
Page 11: Special Procedures
K-1500A/B, & K-1500SP Drain Cleaning Machines • Secure the cable by looping it in the line (Figure 7). Special Procedures This procedure is especially useful when cleaning Reverse Operation a line with a steep grade. Running machine in reverse will cause premature failure of cable. -
Page 12: Storing And Transporting Cable
A-369X " Replacement Jawset Figure 11 – Storing Cables On “A” Frame Models Accessories Only the following RIDGID products have WARNING been designed to function with the Sectional Drain Clean - ing Machines. Other accessories suitable for use with other tools may become hazardous when used on the ma- chines. -
Page 13: Maintenance Instructions
12). 63180 T-46 Flue Brush, 5 " 63185 T-47 Flue Brush, 6" NOTE! See RIDGID Catalog for complete list of tools and accessories. Figure 12 – Replacing Clutch Jaws 278-104-421.10_REV. A GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 14: Removing Clutch End Play
The “Maintenance Instructions” will take care of most of the service needs of this machine. Any problems not ad- Figure 14 – Removing Clutch End Play dressed by this section should only be handled by an authorized RIDGID service technician. GlobalTestSupply 278-104-421.10_REV. A www. -
Page 15: Wiring Diagrams
WARNING K-1500A/B, & K-1500SP Drain Cleaning Machines Tool should be taken to a RIDGID Independent Auth - orized Service Center or returned to the factory. All repairs made by Ridge Tool service facilities are warranted against defects in material and workmanship. - Page 16 K-1500A/B, & K-1500SP Drain Cleaning Machines K-1500SP Wiring Diagram 120V/60 Hz Switch Ground Screw in Switchbox Green L2 White Green L1 Black Black Service Cord Line cord Modification: White Cut off existing terminals Strip Wire Ends .25 in. K-1500SP Wiring Diagram 220-240V/50 Hz Switch NOTE: Switch modified using...
