Overload protection
When the tool is operated in a manner that causes it to
draw an abnormally high current, the tool automatically
stops without any indication. In this situation, turn the
tool off and stop the application that caused the tool to
become overloaded. Then turn the tool on to restart.
Overheat protection
On
When the tool is overheated, the tool stops automatically,
and the battery indicator blink about 60 seconds. In this situ-
ation, let the tool cool down before turning the tool on again.
Overdischarge protection
When the battery capacity becomes low, the tool stops
automatically. If the product does not operate even
when the switches are operated, remove the batteries
from the tool and charge the batteries.
Switch action
► Fig.6: 1. Stand-by switch 2. Power button 3. Suction
force adjusting knob
To start the cleaner:
1.
Set the stand-by switch to the "I" side. The cleaner
gets into stand-by state.
2.
Press the power button.
To make the cleaner get into stand-by mode, press the
power button again.
To turn off the cleaner, set the stand-by switch to the "O" side.
The suction power can be adjusted according to your work need.
Suction power can be increased by turning the suc-
tion force adjusting knob from the
the
symbol.
NOTICE:
Always set the stand-by switch to the "O"
side when not using the cleaner for long time. The
cleaner consumes power during stand-by state.
Auto-suction stop during wet
suction operation
Only for the cloth filter model
WARNING:
Do not use for a long time while
the float is at work. Using the cleaner with its float at
work for a long time can cause overheat, resulting in
the cleaner deformation.
WARNING:
Do not pick up foam or soapy
liquid. Picking up foam or soapy liquid can cause
foam to come out of air exit before the float works.
Continuing to using in this condition may cause an
electric shock and breakage of the cleaner.
Auto-suction stop works only when using with the float
and float cage.
The cleaner has a float mechanism that prevents water from
immersing into the motor when picking up more than a certain
amount of water. When the tank is full and the cleaner no lon-
ger picks up water, switch off the cleaner and empty the tank.
Locking or unlocking the caster
► Fig.7: 1. Caster 2. Stopper lever 3. FREE position
Locking the caster is convenient when storing the
cleaner, stopping the work on the way and keeping the
cleaner still.
To operate the stopper, move it by hand.
To lock the caster with a stopper, lower the stopper
lever and the caster no longer will rotate. To release the
Blinking
caster from the locked position, raise the stopper lever.
NOTE: When moving the cleaner, make sure that
the caster is unlocked. Moving the cleaner with the
caster in the locked position may cause damage to
the caster.
Carriage handle
When carrying the cleaner, carry it by holding the han-
dle on the head. The handle is retractable at the head
when not in use.
► Fig.8
PARTS DESCRIPTION
Model DVC862L
(Cloth filter (for dry and wet dust) model)
► Fig.9: 1. Tank cover 2. Float 3. Float cage 4. Cloth
Model DVC863L
(Powder filter (for dry dust) model)
► Fig.10: 1. Tank cover 2. Powder filter 3. Damper
symbol to
ASSEMBLY
switched off and the battery cartridge is removed
before carrying out any work on the tool.
assembly or maintenance.
Installing the powder filter and
prefilter (for dry dust)
Optional accessory for cloth filter model
uids or wet dusts when using the powder filter.
Picking up such things may cause the powder filter
breakage.
To use powder filter:
1.
► Fig.11: 1. Float 2. Float cage
2.
mounting position markings.
10 ENGLISH
4. LOCK position
filter 5. Tank
4. Prefilter 5. Tank
CAUTION:
Always be sure that the tool is
CAUTION:
Always wear dust mask during
CAUTION:
Never pick up water or other liq-
Remove the float cage and float by removing the bolts.
Place the prefilter in the tank with aligning the
