Remove vEdge 5000 Router Components

Table 90:
Item
Chassis board sensor0
Chassis board sensor1
CPU junction
temperature
Checking Alarms and Notifications
To view the current chassis environment condition , enter the show hardware environment command at
the system prompt. The system displays the power supply status, temperature sensor readings, fan speed, and
related alarm status if any exists.
To view the severity of active alarms, enter the show hardware alarms command at the system prompt. The
system displays the alarm severity and a brief description of the cause of each active alarm.
To view temperature thresholds at which green, yellow, and red alarms are generated, enter the show hardware
temperature-thresholds command at the system prompt. The system displays the alarm temperature threshold
information for a mother board in the router and for the router's CPU.
To view all other events on a Viptela device, enter the show notification stream command. The system
displays notifications about events that have occurred on the Viptela device.
LEDs and LCD Panel
The chassis LED located on the front panel of the vEdge 5000 router indicates the status of the router. See
Front Panel Components for details of the LEDs and the status they indicate.
The LCD panel also displays information about the status and health of the router.
Additional Information
show hardware alarms show hardware environment show notification stream show hardware
temperature-thresholds Front Panel Components Check Alarms and Events
Remove vEdge 5000 Router Components
The vEdge 5000 router is a stiff sheet-metal structure that houses the hardware components. The
field-replaceable units (FRUs) in the vEdge routers are:
• Power supply
• Fan tray
• Pluggable Interface Modules (PIM)
• SFP and SFP+ transceiver
Hardware Installation Guide for vEdge Routers
244
Yellow Alarm (degrees Red Alarm (degrees
C) C)
Normal Bad Fan
50 45
50 45
85 80
vEdge 5000 Router
Normal Bad Fan
70 65
70 65
95 90
