3.4.2 General Specifications

Item
Control Mode
Range
Start control torque
Speed control range
Speed Control Precision
Setting resolution
Keypad setting
Display Function
External signal setting
Frequency Limit Function
Carrier frequency
V/F pattern
Acc/Dec control
Multifunctional analog
output
Multifunctional input
Multifunctional output
Digital Input Signal
Other Function
VAT200 TYPE
V/F or Current Vector Control
0.1~650.0 Hz
150%/1Hz (Current Vector)
1:50 (Current Vector)
±0.5% (Current Vector)
Digital：0.01Hz( Note *1 )；Analog: 0.06Hz/ 60Hz(10bits)
Set directly with▲▼ keys or the VR on the keypad
Four digital LED (or 2×16 LCD) and status indicator; display
frequency/ speed/ line speed/ DC voltage/ Output voltage/ Current/
Rotation direction/ Inverter parameter/ Trouble Log/ Program
Version
External variable resistor/ 0-10V/ 0-20mA/ 10-0V/ 20-0mA
1.
Performs up/down controls, speed control or automatic
2.
procedure control with multifunctional contacts on the
terminal block (TM2)
Respectively setting upper/lower frequency limits and three-
stage prohibited frequencies
2 ~ 16 kHz
18fixable patterns, 1programable curve
Two-stage Acc/Dec time (0.1 – 3,600 seconds) and two-stage S
curves (refer to descriptions on
6 functions (refer to description on
30 functions (refer to
16 functions (refer to
NPN (SINK) / PNP (SOURCE) toggle
Momentary Power Loss Restart, Speed Search, Overload Detection, 8
preset speeds( PLC use 16 preset speeds). Acc/Dec Switch (2
Stages), S Curves, 3-wire Control, PID control, torque boost, Slip
Compensation, Frequency Upper/ Lower Limit, Auto energy saving,
Modbus slave and PC/PDA Link, Auto Restart, Built-in Simple PLC
Function.
3-10
