Summary of Contents for NETGEAR WGR826V
- Page 1 User’s Manual for Netgear WGR826V Netgear Inc. 4500 Great America Parkway Santa Clara, California 95054 USA. Phone: (408) 907-8000 Fax: (408) 907-8097 Web Site: http://www.netgear.com © NetgearInc. 2004 Page 1 of 36 All Rights Reserved...
- Page 2 Further, Netgear reserves the right to revise this document and to make changes from time to time in its content without being obligated to notify any person of such revisions or changes.
-
Page 3: Table Of Contents
Contents 1 Introduction ..................4 2 Quick Start ..................4 3 Settings and Configuration..............5 3.1 Login......................5 3.2 Basic Settings ....................7 3.2.1 Basic Settings......................7 3.2.2 Logs........................10 3.2.3 Block sites......................12 3.2.4 Rules ........................14 3.2.5 Services ......................... 16 3.2.6 Schedule........................ -
Page 4: Introduction
1 Introduction This User’s Manual describes the configuration of the Netgear WGR826V VoIP TA. 2 Quick Start Basic setting should go through several steps. 1. Log in. 2. Basic Settings 3. Set password. 4. Set LAN IP 5. Set Rules. -
Page 5: Settings And Configuration
3 Settings and Configuration 3.1 Login Run a browser, such as, Inetrnet Explorer, and enter in the router’s administration IP address. For example, “http://192.168.1.1”. Enter the user name and password (By default, user name is set to “root”. No password – leave the filed empty). - Page 6 4) Help windows, which give detailed explanation of the each field in the setting and configuration windows. The WGR826V Settings pages allow you to configure, upgrade and check the status of your NETGEAR Router. Click an item in the leftmost column. The current settings or information for that area appear in the center column.
-
Page 7: Basic Settings
3.2 Basic Settings 3.2.1 Basic Settings Note: If you are setting up the Router for the first time, the default settings may work for you with no changes. Does Your Internet Connection Require A Login? Select this option based on the type of account you have with your ISP. If you need to enter login information every time you connect to the Internet or you have a PPPoE account with your ISP, select Yes. - Page 8 Note: If you have installed PPP software such as WinPoET (from Earthlink) or Enternet (from PacBell), then you have PPPoE. Select Yes. After selecting Yes and configuring your Router, you will not need to run the PPP software on your PC to connect to the Internet. Account Name (also known as Host Name or System Name) For most users, type your account name or user name in this box.
- Page 9 DNS Address The DNS server is used to look up site addresses based on their names. If your ISP gave you one or two DNS addresses, select Use These DNS Servers and type the primary and secondary addresses. Otherwise, select Get Automatically From ISP. Note: If you get 'Address not found' errors when you go to a Web site, it is likely that your DNS servers aren't set up properly.
-
Page 10: Logs
3.2.2 Logs Your router will log security-related events such as denied incoming service requests, hacker probes, and administrator logins, according to your settings on this screen. If you have set up content filtering on the Block Sites page, you can also log when someone on your network tried to access a blocked site. - Page 11 Include in Log Use these checkboxes to determine which events are included in the log. Checking all options will increase the size of the log, so it is good practice to disable any events which are not really required. • Known DoS attacks and Port Scans - If checked, Denial of Service attacks, as well as port scans, will be logged.
-
Page 12: Block Sites
You can specify up to 32 words that, should they appear in the website name (URL) or newsgroup name, will cause the site to be blocked by the router. When users try to access a blocked site, they will get a message: "Blocked by NETGEAR". © NetgearInc. 2004... - Page 13 Note: Keywords are always blocked. To block keywords or Internet domains: 1. Select the Turn keyword blocking on check box. 2. Type a keyword or domain name in the Add Keyword box. 3. Click Add Keyword. The word or domain name appears in the list below. 4.
-
Page 14: Rules
Note: You may select more than one keyword or domain name at a time by pressing the Shift key as you select individual entries. To delete all keywords and domain names: 1. Click Clear List. 2. Click Apply. To allow one computer to have unrestricted access to the Internet: 1. - Page 15 Outbound Services This lists all existing rules for outbound traffic. If you have not defined any rules, only the default rule will be listed. The default rule allows all outgoing traffic. To create a new rule: 1. Click the "Add" button. (It does not matter which radio button is selected) 2.
-
Page 16: Services
Inbound Services This lists all existing rules for inbound traffic. If you have not defined any rules, only the default rule will be listed. The default rule blocks all inbound traffic. To create a new rule: 1. Click the "Add" button. (It does not matter which radio button is selected) 2. - Page 17 The Rules menu contains a list of predefined Services for creating firewall rules. If a service does not appear in the predefined Services list, you can define the service in this menu. The new service will then appear in the Rules menu's Services list. Service Table This table lists all Services you have defined.
-
Page 18: Schedule
Service Definition This section displays data for the current Service, and allows you to enter data to create a new rule. Name Enter a suitable name for this Service. Type Select the correct type for this Service. Start Port Enter the beginning of the required port range here, and the end of the range in the "Finish Port" field. -
Page 19: Time Of Day
Days Select the required days • Every Day - all days will automatically be selected • Sunday, Monday .. If "Every Day" is NOT selected, you can choose the required days individually. Time of day This determines when the schedule is applied, for each day selected above. Enter the desired Start and Finish times. -
Page 20: E-Mail
Timezone The Router will determine the current time and date by contacting a Network Time (NTP) Server on the Internet. In order to display your local time, you must select your Time Zone from the list. If your region uses Daylight Savings Time, you must manually check Adjust for Daylight Savings Time at the beginning of the adjustment period, and uncheck it at the end of the Daylight Savings period. - Page 21 • A known hacker attack is directed at your IP address • A computer on the Internet scans your IP address for open ports • Someone on your LAN (Local Area Network) tries to visit a blocked site. If you'd like to have alerts and logs sent to you by e-mail, fill out the settings on this form. You can always check the logs manually by viewing the Logs page.
-
Page 22: Router Status
Send E-Mail alerts immediately If you want E-mail alerts sent immediately whenever a security incident occurs, select the appropriate checkboxes. If you ONLY want alerts sent, select None for the log schedule below. Click Apply to have your changes take effect. 3.2.8 Router Status You can use the Router Status page to check the current settings and statistics for your Router. - Page 23 • IP Address - LAN IP address of the Router. • DHCP - indicates if the WGR826V is acting as a DHCP Server for devices on your LAN. • IP Subnet Mask - subnet mask associated with the LAN IP address.
- Page 24 • Region - the location (country). • Channel - the current channel in use. • Wireless AP - indicates if the Access Point feature of the WGR826V is enabled or not. If not enabled, the Wireless LED on the front panel will be off.
-
Page 25: Attached Devices
3.2.9 Attached Devices This page shows the IP Address, Device Name and MAC (Media Access Control) Address for each computer attached to the Router. You cannot change any of the values on this page. To update this page and to show the current attached devices, click on the Refresh button. -
Page 26: Diagnostics
3.2.11 Diagnostics You can use this page to perform various diagnostics. For normal operation, these are not required. Ping or Trace an IP address Ping Use this to send a "ping" packet request to the specified IP address. This is often used to test a connection. - Page 27 Perform a DNS Lookup A DNS (Domain Name Server) converts the Internet name (e.g. www.netgear.com) to an IP address. If you need the IP address of a Web, FTP, Mail or other Server on the Internet, you can do a DNS lookup to fing the IP address.
-
Page 28: Router Upgrade & Provisioning
You install new versions of the Router's software using the Firmware Upgrade page. Go to the NETGEAR Web site to get new versions of the Router software. After downloading the file, you'll need to unzip (or unstuff) it before upgrading the Router. - Page 29 Router. If you are unable to successfully upgrade using this method, refer to the Reference Manual on the WGR826V Resource CD for other ways to upgrade the Router. Provisioning of TA: TA contacts a provisioning server for dynamic configuration of VoIP parameters. Configuration, image upgrade, interface address change notifications are carried over automatically by TA.
- Page 30 Connect a serial cable to console port of TA ( baud rate 115200). Press "return" key on the keyboard. You should get linux bash prompt (#) Enter cli from the bash prompt. You will get WGR826V's CLI prompt. #cli **************************************************************...
- Page 31 For VoIP trace, enable trace for the VoIP module using the following command : iGateway:/>traceenable VOIP iGateway:/>tracestart iGateway:/>traceset all Dump of Config File You can see the dump of Config File received from SASVP. From bash prompt, #cat /igateway/prvdump XML Message Logs You can see the XML message exchanges between TA and SASVP.
-
Page 32: Lan Ip Setup
The URL to communicate to SASVP can be set by browsing to TA and clinking on "Router upgrade and Provisiong" link. You should see four sections in the page. In "Automatic Provisioning" , you can modify the URL for SASVP server . This URL is used to communicate with SASVP server. "Upload SASVP CA Certificate "... - Page 33 LAN TCP/IP Setup These are advanced settings that you may configure if you are a network administrator and your network contains multiple Routers. If you make any changes to these settings you will need to restart your computer(s) for the settings to take effect. •...
-
Page 34: Use Router As Dhcp Server
Routers on your network must use multicasting. Use Router As DHCP Server The WGR826V Router is set up by default as a DHCP (Dynamic Host Configuration Protocol) Server, which provides the TCP/IP configuration for the all the computers that are connected to the Router. -
Page 35: Static Route
1. Select the radio button next to the reserved address you want to edit. 2. Click the Edit button. 3. Edit the IP Address, MAC Address or Device Name. 4. Click the Accept button when finished. To Delete A Reserved IP Address: 1. - Page 36 To set up a static route: 1. Click the Add button. 2. Type a route name for this static route in the Route Name box under the table. (This is for identification purpose only.) 3. Select Active to make this route effective. 4.
