Digital Copier

Operating Instructions

(For Printer, Document Management System and Class 2 Fax Modem)
DP-2000/2500/3000
Options (Available separately)
DA-AR250/AS200/DS200/DS205/DS210/DS215/ES200/FG230/FG231/FK200/FK210/FS200/MD200
DA-NE200/PC200/PC210/SM08B/SM16B/SM28B/UC200/XN200/XT200; UE-410047/410048/403171
Before operating this equipment, please read
these instructions completely and keep these
operating instructions for future reference.
English

Advertisement

Table of Contents
loading

Related Manuals for Panasonic DP-2000

Summary of Contents for Panasonic DP-2000

  • Page 1: Operating Instructions

    Digital Copier Operating Instructions (For Printer, Document Management System and Class 2 Fax Modem) DP-2000/2500/3000 Options (Available separately) DA-AR250/AS200/DS200/DS205/DS210/DS215/ES200/FG230/FG231/FK200/FK210/FS200/MD200 DA-NE200/PC200/PC210/SM08B/SM16B/SM28B/UC200/XN200/XT200; UE-410047/410048/403171 Before operating this equipment, please read these instructions completely and keep these operating instructions for future reference. English...

  • Page 2: Energy Star

    I Energy Star The DP-2000/2500/3000 copier complies with Tier 2 of the Environmental Protection Agency's Energy Star Program. This voluntary program specifies certain energy consumption and usage standards for copiers. These copiers will automatically “power down” after a specified period of non-use.

  • Page 3: Table Of Contents

    Print Operation ... 74 Printing from Windows Applications ... 74 Printing on Network ... 75 Installing the Panasonic Class 2 Fax Modem ... 78 Installation (Windows 95/98/Me) ... 78 Installation (Windows NT 4.0) ... 84 Installation (Windows 2000) ... 87...
  • Page 4 Journal Folder ... 151 Phone Book Settings Shortcut Activation Folder ... 152 Features ... 153 Activation Procedure ... 154 Main Window (For DP-2000) ... 156 Retrieve/Write ... 157 Open/Save File ... 159 Insert Entry ... 161 Delete Entry ... 162 Starting with: ...

  • Page 5: Precautions

    Precautions For U.S.A. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruc- tion manual, may cause harmful interference to radio communications.

  • Page 6: External View And Control Panel

    External View and Control Panel External View Parallel interface connector • Connect to the PC Power switch • Usually set to ( ) position. Parallel interface cable • (A cable does not come with the unit.) Use a cable of IEEE1284 specifications, with a maximum length of 20 ft (6m).

  • Page 7: Control Panel (For Dp-2500/3000)

    Control Panel (For DP-2500/3000) MULTI-SIZE COPY SORT FEED ADD TONER ON LINE CONTRAST INTERNET PRINTER ON LINE DATA Name ON LINE Switch the printer from off-line status to on-line status. OFF LINE Switch the printer to off-line status. (The printer cannot be set off line when the data LED is blinking.) SECURE PRINT Used to print or delete the security print data.

  • Page 8: Control Panel (For Dp-2000)

    External View and Control Panel Control Panel (For DP-2000) 2SIDED 1SIDED MULTI-SIZE FEED COPY COPIED BLANK MEMORY 2PAGE 2 in 1 COPY FINE Name ON LINE LED DATA LED STOP key SORT COPY STAPLE DP-2000 SHIFT STAMP MEM XMT COPY...
  • Page 9 Digital Copier Printer Section DP-2000/2500/3000...

  • Page 10: Installation And Configuration (Windows 95/98/Me)

    Installation and Configuration (Windows 95/98/Me) Installing the LPR (Line Printer Remote) Monitor Click on the Start button, and click on Run... The Run dialog box appears. Insert CD-ROM containing the LPR folder. In the Open: field, type: D:\English\Lpr\Setup.exe (When drive D is CD-ROM drive.) Click on the button.

  • Page 11: Installing The Printer Driver

    Installation and Configuration (Windows 95/98/Me) Installing the Printer Driver Open the Printers folder. Click the Start key. Place the cursor on Settings and click Printers. Double-click the Add Printer icon. Click the button. Next Select Local printer and click the •...
  • Page 12 Click the button. Have Disk... Specify the drive name and type D:\English\Driver\Win9x. (Where "D" is your CD-ROM drive.) Click the button. Select the device (Panasonic DP-2000, Panasonic DP-2500 or Panasonic DP-3000). Click the button. Next Select LPT1. Click the button.
  • Page 13 Installation and Configuration (Windows 95/98/Me) • Be sure to delete the drivers of earlier versions before updating drivers. NOTE • Restart Windows after updating drivers. In response to Do you want your Windows- based programs to use this printer as the default printer?, select Yes or No.
  • Page 14 Before proceeding, ensure that the Printer is installed, connected to the Network, is turned ON and operating properly. Right-click on the "Panasonic DP-2500" icon in the Printers folder and select Properties from the pop- up menu. The Panasonic DP-2500 Properties dialog box appears.
  • Page 15 Installation and Configuration (Windows 95/98/Me) The Add Port dialog box appears. Click the Other radio button, and select HLPRMON from "Click the type of port you want to add:" and click on the button. The LPR Port Name dialog box appears. Type the IP Address of the DP-2500 and "lp"as the queue name separated by a ":"...

  • Page 16: Configuring The Printer Driver Settings

    • Upon printing, changing properties Paper/Layout, Handling, Quality and Device NOTE • Management tab of the color of property dialog box is not used for the DP-2000/2500 • Sharing Tab in property dialog box is not displayed unless printer sharing has not been Options is allowed by clicking Properties in the print dialog box of an application.

  • Page 17: General Tab

    Installation and Configuration (Windows 95/98/Me) I General Tab Comment Enter comments to the properties, if any. If another user sets up this printer on his or her computer when sharing the printer, the comment specified here will also appear on that computer. However, the comment displayed for an already set-up user will remain unchanged even if the comment is modified later.

  • Page 18: Details Tab

    Installation and Configuration (Windows 95/98/Me) I Details Tab Print to the following port Displays either the port to which the printer is connected or the path to the network printer. To change the printing destination, either select the printing destination port from the list or enter the network path here.
  • Page 19 Installation and Configuration (Windows 95/98/Me) button Spool Settings... Specify the method of sending (spool) documents from the program to the printer. Spool Data Type Select spool data type (EMF format or RAW format). Specifying RAW format results in longer time before placing an application operational after printing on the application.

  • Page 20: Sharing Tab

    Installation and Configuration (Windows 95/98/Me) I Sharing Tab Not Shared/Shared As Select whether to display or use this printer with other computers. Share Name Specify the name of the shared printer. The displayed name can be used as it is or a new name may be entered.
  • Page 21 Installation and Configuration (Windows 95/98/Me) I Paper/Layout Tab Paper Size Select a document size. Paper Source Specify where the paper you want to use is located in the machine. If you choose Auto Selection, the printer driver will automatically select an appropriate tray according to the Paper Size. Orientation Select the print orientation (Portrait/Landscape).
  • Page 22 Installation and Configuration (Windows 95/98/Me) I Handling Tab Sorter Select whether to Stack or Sort when printing multiple copies. Printing on both sides (Duplex) Select duplex printing for printing on both sides. Note 1) Duplex Printing is allowed only when the Dual-Path Exit Guide Unit, Paper Transport Unit and Automatic Duplex Unit (DA-FK200/FK210/MD200) are mounted.
  • Page 23 Staple Specifying staple printing is allowed if the output bin is set to outer. Note 1) Staple printing is allowed only with Electronic Sorting Board (DA-ES200 : For DP-2000 only) and 1-Bin Finisher (DA-FS200) mounted. Note 2) Select "Sort" in the sort menu.

  • Page 24: Quality Tab

    Installation and Configuration (Windows 95/98/Me) I Quality Tab Halftone Select method of expressing halftone. Select the setting according to the data to be printed and your preference. Normal: Select the halftoning method to be used. Select it according to the details of data and your preference.

  • Page 25: Device Options Tab

    Installation and Configuration (Windows 95/98/Me) I Device Options Tab Secure Print Password Set the password for Secure Print, to enable the feature. Duplex Unit Check this checkbox if the Automatic Duplex Unit (DA-MD200) is installed. Inner Tray Check this checkbox if the Exit Tray (Inner) and the Dual-Path Exit Guide Unit (DA-XN200/FK200) are installed. Specifying inner bins, Inner 1 and Inner 2, is allowed for printing on the printer.

  • Page 26: Setting Print Conditions: Setting On The Device

    Setting Print Conditions: Setting on the Device <For DP-2500/3000> MULTI-SIZE COPY SORT FEED ADD TONER ON LINE CONTRAST INTERNET PRINTER ON LINE DATA <For DP-2000> 2SIDED 1SIDED MULTI-SIZE FEED SORT COPY COPY STAPLE SHIFT COPIED BLANK MEMORY STAMP MEM XMT...

  • Page 27: Installation And Configuration (Windows Nt 4.0)

    Installation and Configuration (Windows NT 4.0) Installing the LPR (Line Printer Remote) Monitor Click on the Start button, point to Settings, and click Control Panel. The Control Panel window appears. Double-click on the Network applet. The Network dialog box appears. Click on the Services tab.
  • Page 28 Installation and Configuration (Windows NT 4.0) Click on the Add... button to display the Select Network Service dialog box, then select Microsoft TCP/IP Printing. Click on the button . Windows NT Setup dialog box appears. Insert the Windows NT 4.0 CD-ROM , and type D:\i386 (where "D:"...

  • Page 29: Installing The Printer Driver

    Installation and Configuration (Windows NT 4.0) Installing the Printer Driver Log in using an account with the authority to change system settings (e.g. Administrator). Open the Printers folder. Click the Start button. Place the cursor on Settings and click Printers. Double-click the Add Printer icon.
  • Page 30 Installation and Configuration (Windows NT 4.0) The Available Ports: list appears. • For local printer, click the and proceed to step 8. • For network printer, click the button. Printer Ports dialog box appears. Select LPR Port and click the button.
  • Page 31 Insert the CD-ROM containing the printer driver. Click the button. Have Disk... Specify drive name and type D:\English\Driver\WinNT4. (Where "D" is your CD-ROM drive.) Click the button. Select the device (Panasonic DP-2000, Panasonic DP-2500 or Panasonic DP-3000). Click the button. Next Next...
  • Page 32 Installation and Configuration (Windows NT 4.0) In response to Do you want your Windows- based programs to use this printer as the default printer?, select Yes or No. Next Click the button. Select Not Shared and click the button. • Select Shared only when installing on a network server.
  • Page 33 Installation and Configuration (Windows NT 4.0) • Be sure to delete the drivers of earlier versions before updating a driver. NOTE Notes: • Restart Windows after updating drivers. The required files are copied. The Printers Icon is now displayed in the Printers folder.

  • Page 34: Configuring The Printer Driver Settings (Administrator)

    Installation and Configuration (Windows NT 4.0) Configuring the Printer Driver Settings (Administrator) To change the printer settings, open the dialog box for the printer properties by the following steps. Log in using an account with the authority to change system settings (e.g. Administrator). Click the Start button, place the cursor on Settings, and then click Printers.
  • Page 35 Installation and Configuration (Windows NT 4.0) I General Tab Comment Enter comments to the properties, if any. If another user sets up this printer on his or her computer when sharing the printer, the comment specified here will also appear on that computer. However, the comment displayed for a user already set-up will remain unchanged even if the comment is modified later.
  • Page 36 Installation and Configuration (Windows NT 4.0) Print Processor... Specify the processor to be used for printing (Print Processor) and the data type (Default Data type). The processor and data type affect the manner in which the printer functions in Windows NT. Normally they do not need to be modified.

  • Page 37: Ports Tab

    Installation and Configuration (Windows NT 4.0) I Ports Tab Print to the following port(s) Displays a list of available ports for printing (Port), their status (Description) and printers that are connected to these ports (Printer). Add Port... Delete Port... Adds/deletes a new port or a new network port. button Configure Port...
  • Page 38 Installation and Configuration (Windows NT 4.0) I Scheduling Tab Available Schedules the printer for operation. Specify operating hours when From-To is selected. Priority Sets printing priority. The slider allows the priority to be adjusted from 1 through 99. Spool print documents... / Print directly to the printer Specify how documents should be sent from the application to the printer.
  • Page 39 Installation and Configuration (Windows NT 4.0) I Sharing Tab Not Shared/Shared Select whether to display or use this printer on or with other computers. Share Name Specify the name of the shared printer. The displayed name can be used as it is or a new name may be entered.

  • Page 40: Security Tab

    Installation and Configuration (Windows NT 4.0) I Security Tab button Permissions Set printer access privileges. button Auditing Displays the persons who used this printer and how they used. button Ownership Set the ownership of the printer. • In order to utilize these features, you need to have selected Audit... from User NOTE Manager's Policies and have enabled File and Object Access in the Audit Policy dialog box.

  • Page 41: Device Settings Tab

    Installation and Configuration (Windows NT 4.0) I Device Settings Tab Halftone Setup button Halftone Setup... Select the halftoning method to be used (halftones specific to the printer). Select it according to the details of data and your preference. • Halftone Pattern Select the pixel size to be used for halftones.
  • Page 42 Installation and Configuration (Windows NT 4.0) • Device Gamma Adjust the gamma of print images (color intensities). • Pixel Diameter Adjust the darkness of the print image. Manipulate the slider to specify the pixel size. You can select between specifying the real size in inches or specifying in percentage relative to the printer resolution. •...

  • Page 43: Configuring The Printer Driver Settings (User)

    Installation and Configuration (Windows NT 4.0) Configuring the Printer Driver Settings (User) To change the printer settings, open the dialog box for the printer properties by the following steps. Select Print in the File menu of the application. Click the Properties...

  • Page 44: Page Setup Tab

    Installation and Configuration (Windows NT 4.0) I Page Setup Tab Paper Size Select the size of the document. Paper Source Specify where the paper you want to use is located in the machine. If you choose Auto Selection, the printer driver will automatically select an appropriate tray according to the Paper Size. Copy Count Specify the number of copies to be printed.

  • Page 45: Advanced Tab

    Installation and Configuration (Windows NT 4.0) I Advanced Tab Paper Size Select the size of the document. Orientation Select the print orientation (Portrait/Landscape). Paper Source Specify where the paper you want to use is located in the machine. If you choose Auto Selection, the printer driver will automatically select an appropriate tray according to the Paper Size.
  • Page 46 Installation and Configuration (Windows NT 4.0) I Advanced Tab Metafile Spooling With Metafile Spooling enabled, the file is spooled in EMF format (metafile compression). With the function disabled, the file is spooled in RAW (non-compression) format. Specifying RAW format results in longer time before placing an application operational after printing on the application.
  • Page 47 Staple Specifying staple printing is allowed if the output bin is set to outer. Note 1) Staple printing is allowed only with Electronic Sorting Board (DA-ES200 : For DP-2000 only) and 1-Bin Finisher (DA-FS200) mounted. Note 2) Paper is stapled at the top left or at the top right. (See table below.)
  • Page 48 Installation and Configuration (Windows NT 4.0) Output Tray Specify the output destination. Note 1) Output Tray selection is allowed only when the Dual-Path Exit Guide Unit, Paper Transport Unit, Exit Tray (Outer) or 1-Bin Finisher (DA-FK200/FK210/XT200/FS200) is installed. Note 2) Post cards cannot be output from the outer tray. Secure Print Select to enable Security Print.

  • Page 49: Setting Print Conditions: Setting On The Device

    Setting Print Conditions: Setting on the Device <For DP-2500/3000> DP-2500 MULTI-SIZE COPY SORT FEED ADD TONER Touch-panel ON LINE CONTRAST INTERNET display PRINTER ON LINE DATA <For DP-2000> 2SIDED 1SIDED MULTI-SIZE FEED SORT COPY COPY STAPLE DP-2000 SHIFT STAMP MEM XMT COPIED BLANK MEMORY COPY...

  • Page 50: Installation And Configuration (Windows 2000)

    System - software using Office 2000. However, the company does not necessarily guarantee normal operation of all applications on Windows 2000. Panasonic has not registered with the Windows 2000 logo. Ignore the warning message about the logo upon installation. Windows 2000 is capable of disallowing installation of drivers without logo registration. If the function has been activated, cancel the function for installation.
  • Page 51 Installation and Configuration (Windows 2000) Select Local printer and click the button. Specify Network Printer for installing a printer on server upon network. Refer to the manual about Windows 2000. Even if the printer is networked, install as Local printer for now. This will be changed in later steps. Click the button.
  • Page 52 Installation and Configuration (Windows 2000) Click the button. Next Enter the IP Address and the Port Name and click button. Next Note: The Port Name is automatically entered by Windows 2000. You may change this as required. Select Custom and click the Settings...
  • Page 53 Installation and Configuration (Windows 2000) Select LPR on Protocol menu. Enter the Queue Name and select LPR Byte Counting Enabled on LPR Settings menu. Click the button. Click the Next button. Click the button. Finish...
  • Page 54 Insert the CD-ROM containing the printer driver. Click the button. Have Disk... Specify the drive name and type D:\English\Driver\WinNT4. (Where "D" is your CD-ROM drive.) Click the button. Select your device (Panasonic DP-2000, Panasonic DP-2500 or Panasonic DP-3000). Click the Next button.
  • Page 55 Installation and Configuration (Windows 2000) Next Click the button. Select Do not share this printer and click the Next button. • Select Share as only when installing onto a network server. Refer to the manual for Windows 2000 for details. Select No and click the Next button.
  • Page 56 Installation and Configuration (Windows 2000) Finish Click the button. Click the button. The required files are copied. The Printers Icon is now displayed in the Printers folder.

  • Page 57: Configuring The Printer Driver Setting On Windows 2000 (Administrator)

    Installation and Configuration (Windows 2000) Configuring the Printer Driver Setting on Windows 2000 (Administrator) To change the printer properties, open the dialog box for the printer properties by the following steps. Log in using an account with the authority to change system settings (e.g. Administrator). Click the Start button, place the cursor on Settings, and then click Printers.
  • Page 58 Installation and Configuration (Windows 2000) General Tab Printer Name Name of the printer specified upon installation is displayed. Location and Comment Enter a comment about the location of the printer installation and information about the printer. If a printer is shared, the location and comment specified in this field appears when another user sets up this printer on his/her computer.
  • Page 59 Installation and Configuration (Windows 2000) I Sharing Tab Not shared/Shared as Specify if this printer is displayed or used on a computer of other users. For sharing a printer, specify the share name of a printer to be shared. A name specified here appears when other users view the printer information on a network button Additional Drivers...
  • Page 60 Installation and Configuration (Windows 2000) I Ports Tab Print to the following port(s) Displays a list of ports that allows printing, their status (description), and printers connected to the ports. Add Port... Add or delete a new local port or a new network port. Configure Port...
  • Page 61 Installation and Configuration (Windows 2000) I Advanced Tab Always available/Available from Specify the operation schedule for a printer. Selecting Available from allows specifying an operation time. Priority Specify the priority in printing. Priority is adjustable from 1 to 99. ORIGINAL of higher priority are printed before those of lower priority.
  • Page 62 Installation and Configuration (Windows 2000) Keep printed documents After printing, documents are kept in the queue. The documents are allowed to be reprinted directly from the queue regardless of the status of an application. Enable advanced printing features Usually enables advanced printing features. Optional features of the printer (page ordering, booklet printing, numbering on sheets) are enabled.
  • Page 63 Installation and Configuration (Windows 2000) I Security Tab Displays a list of users and groups that are assigned access to this printer. A list of standard access permitted/prohibited for each group or user is displayed. Check the checkbox for permitting or prohibiting access.
  • Page 64 Installation and Configuration (Windows 2000) I Device Settings Tab Halftone Setup... Select the method of expressing device halftone (printer-specific halftone). according to printing data and preference. • Halftone Pattern Select the size of pixels to be used for halftone. Selecting larger size pixels results in a rough image, which is suitable for printing of wider area. Enhanced patterns, which allow printing an image of higher resolution using a same number of pixels, may cause random lines or patterns and moire.
  • Page 65 Installation and Configuration (Windows 2000) Duplex Unit Check this checkbox if an optional duplex printing unit (DA-MD200) is installed. Duplex printing function is now enabled. Output Tray If the Exit Tray (Inner) and the Dual-Path Exit Guide Unit (DA-XN200/FK200) are installed, select Inner Tray option.

  • Page 66: Configuring The Printer Driver Settings (User)

    Installation and Configuration (Windows 2000) Configuring the Printer Driver Settings (User) Changes the printer settings. Display the printer settings dialog box by the steps below: Select Print in the File menu of an application. Click the Properties... The dialog box for printer properties appears. Click the top tab of the dialog box and specify the properties.
  • Page 67 Installation and Configuration (Windows 2000) General Tab Select Printer Select a printer for printing. Page Range Select a page range for printing. Number of copies Specify the number of copies. Collate Upon printing two or more copies, pages are output for each copy.
  • Page 68 Installation and Configuration (Windows 2000) Layout Tab Orientation Select portrait (vertical) or landscape (horizontal). Print on Both Sides (Duplex) Specify duplex printing for printing on both sides. Select the binding side (None/Flip on Short Edge/Flip on Long Edge) for duplex printing. Note 1) Duplex Printing on post card is not allowed.
  • Page 69 Installation and Configuration (Windows 2000) Paper/Quality Tab Paper Source Specify an input tray. Selecting Auto Selection allows automatic selection of an input tray according to the paper size. button Advanced... Specify detailed settings. Refer to Advanced (See page 62) for details.
  • Page 70 Installation and Configuration (Windows 2000) I Advanced Paper Size Select a paper size. Resolution Select resolution of the printer (600dpi/300dpi). Scaling Specify a custom zoom when printing a document by zooming in/out at a desired rate. If the zooming rate is specifiable on an application, specify "100%"...
  • Page 71 Staple Specifying staple printing is allowed if the output bin is set to outer. Note 1) Staple printing is allowed only with the Electronic Sorting Board (DA-ES200 : For DP-2000 only) and 1-Bin Finisher (DA-FS200) mounted. Note 2) Paper is stapled at the top left or at the top right. (See table below.)
  • Page 72 Installation and Configuration (Windows 2000) Output Tray Specify the output destination. <Auto Selection, Outer, Inner 1, or Inner 2> Note 1) Output Tray selection is allowed only with the Dual-Path Exit Guide Unit, Paper Transport Unit, Exit Tray (Outer) or 1-Bin Finisher (DA-FK200/FK210/XT200/FS200) is installed. Note 2) Post card cannot be output from the outer tray.

  • Page 73: Setting Print Conditions: Setting On The Device

    Setting Print Conditions: Setting on the Device <For DP-2500/3000> DP-3000 MULTI-SIZE COPY SORT FEED ADD TONER Touch-panel ON LINE CONTRAST INTERNET display PRINTER ON LINE DATA <For DP-2000> 2SIDED 1SIDED MULTI-SIZE FEED SORT COPY COPY STAPLE DP-2000 SHIFT COPIED BLANK MEMORY STAMP MEM XMT COPY...

  • Page 74: Print Operation

    Print Operation Printing from Windows Applications If the printer driver is installed properly and a printer is selected as the default printer in the printer setup, printing can be accomplished from any Windows application with simple operations. To print from most Windows applications, use the Print... command on the File menu. Selecting the Print... command typically displays the following Print dialog box: After selecting the print range to be printed and the number of copies, click on printing.

  • Page 75: Printing On Network

    Printing on Network For sharing a printer by connecting two computers via crossed-cable or using a hub, a connection among computers must be established. Establishing a connection among computers is verified by displaying the connected computers in Network Neighborhood on the desktop. The settings for printer sharing is specified by the following steps: I Printer server (PC connected to a printer) Install the printer driver on a computer to be connected to the main unit.
  • Page 76 Print Operation I Remote (PC that uses other computer's printer) Click Start button, place cursor on Settings and then click Printers. Double-click Add Printer in the printers folder. Add Printer Wizard appears. Click the Next Select Network Printer. Click the Next Specify the other computer's printer by entering the network path.
  • Page 77 Digital Copier Class 2 Fax Modem Section DP-2000/2500/3000...

  • Page 78: Installing The Panasonic Class 2 Fax Modem

    Installing the Panasonic Class 2 Fax Modem Installation (Windows 95/98/Me) The installation is required for transmitting/receiving of Faxes with a PC using general-purpose PC fax function software (recommended: WinFax PRO 10.0). Class 2 Fax Modem Select Settings from the Start menu and open the Control Panel.
  • Page 79 (Windows 98 only) (Windows 98/Me only) Installing the Panasonic Class 2 Fax Modem Next Click the Select No, the device isn't in the list. Click the Next (This screen will only appear if a new device is found.) Select No, I want to select the hardware from a list.
  • Page 80 Installing the Panasonic Class 2 Fax Modem Enter D:\Setup. (Where "D" is your CD-ROM drive.) Click the Next Click the Click the Next Finish Click the Click the button. button. button. button. button and restart the PC. Select Ports (COM&LPT).
  • Page 81 Repeat steps from "1" to "3." Installing the Panasonic Class 2 Fax Modem Select No, the device isn't in the list. Click the (This screen will only appear if a new device is found.) Select No, I want to select the hardware from a list.
  • Page 82 Installing the Panasonic Class 2 Fax Modem Select Don't detect my modem; I will select it from a list. Click the Next button. Click the Have Disk... button. Enter D:\English\Setup. (Where "D" is your CD-ROM drive.) Click the button. Select Panasonic DP-2000, DP-2500 or DP-3000 Class 2 Fax Modem.
  • Page 83 Installing the Panasonic Class 2 Fax Modem Select Panasonic MFP Redirected Com Port (COM3*). * COM number depends on the PC. Click the Next button. Finish Click the button. • Installation of the modem is completed.

  • Page 84: Installation (Windows Nt 4.0)

    Installing the Panasonic Class 2 Fax Modem Installation (Windows NT 4.0) Installing the Panasonic Class 2 Fax Modem. The installation is required for transmitting/receiving Faxes with a PC, using general-purpose PC fax function software (recommended: WinFax PRO 10.0). Class 2 Fax Modem Select Settings from the Start menu and open the Control Panel.
  • Page 85 Installing the Panasonic Class 2 Fax Modem Enter D:\English\Setup. (Where "D" is your CD-ROM drive.) Click the Select Panasonic DP-2000, DP-2500 or DP- 3000 Class 2 Fax Modem. Click the Next Select the COM port shown at the bottom of the COM ports list.
  • Page 86 Installing the Panasonic Class 2 Fax Modem Close the Modems Properties screen.

  • Page 87: Installation (Windows 2000)

    Installation (Windows 2000) Installing the Panasonic Class 2 Fax Modem. The installation is required for transmitting/receiving FAX's with a PC, using a general-purpose PC fax function software (recommended: WinFax PRO 10.0). Class 2 Fax Modem Select Settings from the Start menu and open the Control Panel.
  • Page 88 Installing the Panasonic Class 2 Fax Modem Select Add a new device. Click the button. Next Select No, I want to select the hardware from a list. Click the button. Next Select Modems. Click the button. Next...
  • Page 89 Installing the Panasonic Class 2 Fax Modem Select Don't detect my modem; I will select it from a list. Click the Have Disk... Click the Enter D:\English\Setup. (Where "D" is your CD-ROM drive.) Click the Next button. button. button.
  • Page 90 Installing the Panasonic Class 2 Fax Modem Select Panasonic DP-2000, DP-2500 or DP-3000 Class 2 Fax Modem. Click the button. Next Select the COM port shown at the bottom of the COM ports list. Click the button. Next...
  • Page 91 Installing the Panasonic Class 2 Fax Modem If a warning message for logo certification appears, click the button and continue installation. Finish Click the button. • Installation of the modem is completed.
  • Page 92 NOTE...

  • Page 93: Document Management System Section

    Digital Copier Document Management System Section DP-2000/2500/3000...

  • Page 94: Installing The Document Management System

    Installing the Document Management System Insert the provided CD-ROM. Select the language. Next Click the button. Click Install PDMS software. Verify the installation destination and click the Next button.
  • Page 95 Installing the Document Management System Check the model and click the Click the Typical button. Enter the program folder name and click the Next button. The required files are copied. button. Next...
  • Page 96 • By installing this software, the system selects LPT1 as the parallel port to be connected to the device. For connecting the device to a port other than LPT1, change connection ports by selecting [Panasonic], [Panasonic Document Management System], and [Port Selection Utility] from the Start menu.

  • Page 97: Document Manager

    Document Viewer (see page ) in combination, a number of image files can be classified, managed, browsed, and edited. Selecting Panasonic ➝ Panasonic Document Management System ➝ Document Manager in Programs of the Start menu displays the main window of the Document Manager.
  • Page 98 Document Manager Title Bar Displays the title of a screen. Menu Bar Displays the menu of the Document Manager. Tool Bar Displays the tool buttons of the Document Manager. Tool buttons correspond to functions of the menus in the menu bar. Folder Window Displays the folders containing the documents in tree form.

  • Page 99: Basic Operations

    Basic Operations The Document Manager allows editing and managing documents displayed in thumbnail images by dragging and dropping. The function enables various operations as described below: I Selecting documents Clicking thumbnail images in the document window allows selection of documents. cursor on the screen or clicking with the Shift key held down allows selecting two or more documents at one time.
  • Page 100 Document Manager I Copying/Moving Documents Dragging a thumbnail image in document window and dropping it onto a folder in the folder window allows moving the document to the folder. Dragging & dropping with the Ctrl key held down copies a document. Dragging a document and dropping it onto another document in a document folder results in grouping the two documents together.

  • Page 101: Setting Plug-In

    Setting Plug-in I Import document (from scanner) Selecting Acquire Image... in the File menu displays a window for the Document Scanner (See page The operation imports a document read on the scanner into a folder. I Import document (from file) Selecting Open in the File menu displays a dialog box for selecting files.
  • Page 102 Document Manager • OCR software (Application such as e-Typist, etc.) File format Annotation Image type Resolution Correct slant Eliminate noise • PC-FAX software File format Annotation Image type Resolution Correct slant Eliminate noise • E-Mail software (MAPI-compatible mail application such as MS-Outlook, MS-Exchanger, etc.) File format Annotation Image type...

  • Page 103: File Menu

    File Menu I New Folder Create a new folder under a folder that is currently selected. Path of a folder to be created can be specified as required. I Open An image file saved in the computer and can be imported into a folder as a document.
  • Page 104 Document Manager I Rename Change the name of a document. I Properties Display the file properties. I Acquire Image... Using a scanner, etc. selected in Select Source, import a document to a folder that is currently selected. I Select Source Select a TWAIN-compatible device for scanning documents.

  • Page 105: Print Setup

    I Print Print a document selected in the document window. I Print Setup Specify layout and printing size for a document to be printed. Horizontal Position and Vertical Position Adjust the printing position on a sheet. Print Size Select printing in original size or printing in accordance with the sheet size.
  • Page 106 Document Manager I Launch to another application Opens a document selected in the document window with a specified application. Selecting External Application Setup displays a dialog box for adding/changing/deleting the application. Clicking the Add button displays a dialog box to Add External Application.
  • Page 107 I Trash Can Open Trash Can Opens the Trash Can and displays any files. Selecting documents and clicking the Undo documents that have been discarded. Empty Trash Can Deletes the files in the Trash Can. If the documents are emptied from the Trash Can, they are permanently deleted.

  • Page 108: Edit Menu

    Document Manager Edit Menu I Undo Undo the last editing operation done. I Cut Delete a selected document from a folder and copy it to the clipboard. I Copy Copy a selected document onto the clipboard. I Paste Paste a document from the clipboard onto a selected folder.

  • Page 109: View Menu

    View Menu I Tool Bar Switch between displaying/hiding the tool bar. I Status Bar Switch between displaying/hiding the status bar. I List Format/Thumbnail Format Switch between list display and thumbnail display in the document window. I Arrange Documents Arrange documents in the document window by specified order.

  • Page 110: Document Menu

    Document Manager Document Menu I Open Open a selected document. Viewer (See page editing. I Duplicate Makes a copy of the selected document in a folder. I Rotate Object Rotate the selected document. 90˚ Clockwise 180˚ 90˚ Counterclockwise I Group Object Makes a group of two or more selected documents.
  • Page 111 I Ungroup Cancel the grouping for grouped documents. dividing all pages into individual documents or releasing only specified documents from a group can be selected. I Enhancement Apply the following correction to a selected document: Correct Skew : Detect any inclination of a document and automatically correct it.

  • Page 112: Document Scanner

    Document Scanner Main Window Upon image scanning, an image is imported directly into a document using a TWAIN-compatible application (image editing software, etc.). Selecting Acquire Image... in the File menu displays a dialog box for the Document Scanner. • The menu for operating the Document Scanner (scanner driver) depends on the NOTE application.
  • Page 113 Preview Window Displays an image after preview-scanning. The scanning area (black frame) is specified on the displayed image. Dragging the mouse in the preview window allows specifying the scanning area (black frame), changing the frame size, and moving the frame. The black-frame area is displayed in values <Output Size>.
  • Page 114 Document Scanner Brightness (valid only when halftone or grayscale is selected) Adjust the brightness for halftone or grayscale documents. Contrast (valid only when halftone or grayscale is selected) Adjust the contrast (difference between dark and light) for halftone or grayscale documents. Invert Scan the image in negative.

  • Page 115: Tool Menu

    Tool Menu I Adjustment - Gamma Curve Display a dialog box for adjusting the gamma (color strength characteristics) of an image. (valid only when halftone or grayscale is selected) Adjust the gamma curve by dragging the slide bar or entering a value. Moving the slide bar in the + direction reduces the difference between the highlight (light portion) and halftone.
  • Page 116 Document Scanner I Adjustment - Highlight and Shadow Displays a dialog box for adjusting the highlight and shadow. (valid only when halftone or grayscale is selected) Adjust the highlight and shadow by dragging the slide bar or entering a value. Enhancing the highlight (bright portion) and the shadow (dark portion) makes clear shades on an image.

  • Page 117: Image Scanning

    Image Scanning Image scanning is performed by the following procedures: Activate TWAIN-compatible application. Select Acquire Image... in the File menu to display Document Scanner. Specify the image type, resolution, and paper size of a document to be scanned. Place a document on the Platen or ADF and click Preview button.
  • Page 118 Document Scanner Apply the following adjustments on the preview image: • Drag the scanning frame (black frame) on the preview window to specify the scanning area. If an area has already been selected, double- clicking with Shift key held down selects the whole image.

  • Page 119: Document Viewer

    Double-clicking on the document (thumbnail) in the Document Manager screen or selecting Open in the Document menu displays the main window of the Document Viewer. • The program is activated also by selecting Panasonic ➝ Panasonic Document NOTE Management System ➝ Document Viewer from Programs of the Start menu.
  • Page 120 Document Viewer Title Bar Displays the title of the screen and the name of the image file being displayed. Menu Bar Displays the menu of the Document Viewer. Tool Bar Displays the tool buttons of the Document Viewer. Tool buttons correspond to functions of the menus in the menu bar.

  • Page 121: Basic Operations

    Basic Operations I Selecting Page Selecting a page by clicking in the page list displays an image of the selected page on the image window. Dragging and dropping a page in the page list can change the order of the pages. I Image Editing The image displayed in the image window is edited with the menu below:...

  • Page 122: Annotation Function

    Document Viewer Annotation Function Document Viewer provides the functions for adding various graphics and text to an image. The graphics and text added to an image are called <Annotation>. The annotation function, unlike usual image editing applications, does not change an image itself but lays graphics and texts onto an image.

  • Page 123: File Menu

    File Menu I Open Opens an image file saved in the computer. Files of the following formats can be opened on the Document Viewer. TIFF : Tagged-Image File Format (TIFF) JPEG : Joint Photographic Experts Group (JPEG) format BMP : Windows standard bitmap format PNG : Portable Network Graphics format DDM : Document Manager file format I Save...
  • Page 124 Document Viewer I Print Prints a document under the editing operation. For a document containing two or more pages, pages from-to can be specified for printing. I Print Setup Specify the layout, printing size, and printing of annotations for a document to be printed. Vertical position and horizontal position Adjust the printing position on a sheet.
  • Page 125 I Launch to another application Opens a document selected in the document window with a specified application. Selecting External Application Setup displays a dialog box for adding/changing/deleting the application. Clicking the Add button displays a dialog box to Add External Application. Name If an external application is specified, the name in this field appears on a link icon.
  • Page 126 Document Viewer I Trash Can Open Trash Can Opens the Trash Can and displays any files. Selecting documents and clicking the documents that has been discarded. Empty Trash Can Deletes the files in the Trash Can. If the documents are emptied from the Trash Can, they are permanently deleted.

  • Page 127: Edit Menu

    Edit Menu I Undo Undo the last editing operation done. I Delete Delete a selected annotation. I Cut Delete a selected annotation from a folder and copy it to the clipboard. I Copy Copy a selected annotation onto the clipboard. I Paste Paste an annotation from the clipboard onto a selected page.

  • Page 128: Page Menu

    Document Viewer Page Menu I Next Page Display the next page. I Previous Display the previous page. I First Display the first page. I Last Display the last page. I Go To Display a specified page. A dialog box for specifying the page is displayed.

  • Page 129: Annotation Menu

    Annotation Menu I Display Annotation Switch between displaying and hiding the annotation. I Header Creates a header annotation. Selecting header annotation displays a header-specifying frame. If an annotation such as graphics and texts are created within the displayed frame, the frame is managed as a header. I Footer Creates a footer annotation.
  • Page 130 Document Viewer I Text Creates a text annotation. annotation menu (or tool button), and drag the mouse in the image window to specify the display position. A dialog box for text setup will appear. Enter the text to display, and then specify text color and font.
  • Page 131 I Rectangle Creates a rectangle annotation. Select rectangle annotation in the annotation menu (or tool button), and drag the mouse in the image window to draw a rectangle. I Ellipse Creates an ellipse annotation. Select the ellipse annotation in the annotation menu (or tool button), and drag the mouse in the image window to draw an ellipse.
  • Page 132 Document Viewer I White Block Creates a white rectangle (solidly white-painted rectangle) annotation. Select the white annotation in the annotation menu (or tool button), and drag the mouse in the image window to draw a white rectangle. I Black Block Creates a black rectangle (solidly black-painted rectangle) annotation.
  • Page 133 I Marker Creates a marker annotation. Select the marker annotation in the annotation menu (or tool button), and drag the mouse in the image window to draw a marker. I Label Creates a label annotation. Select the label annotation in the annotation menu (or tool button), and drag the mouse in the image window to draw label displays Text Format Setup dialog box.
  • Page 134 Document Viewer I Stamp Creates a stamp annotation. pastes another image file like a stamp. Select the stamp annotation in the annotation menu (or tool button), and drag the mouse in the image window to specify the area, displaying the stamp dialog box. Selecting the stamp allows drawing a stamp image.

  • Page 135: Page Number

    I Page Number Creates a page number annotation. Select the page number annotation in the annotation menu (or tool button), and drag the mouse in the image window to specify the area, displaying the text the settings dialog box. Specify format, color, and font of the page number to be displayed.

  • Page 136: Image Menu

    Document Viewer Image Menu I Correct Skew Detects the Skew of a document and automatically corrects it. The dialog box of Correct Skew is displayed. Adjust the Skew to be corrected by the slide bar. If Preview has been checked, the adjustment result is displayed on the image window.
  • Page 137 I Brightness/Contrast Adjust the brightness and contrast of an image. (Valid only for grayscale or RGB color image) The dialog box of Brightness/Contrast is displayed. Adjust the brightness and contrast by sliding the bar. If Preview has been checked, the adjustment result is displayed on the image window.

  • Page 138: Rgb Color

    Document Viewer I Monochrome Converts the selected page into a monochrome image. The dialog box of Threshold Sizes is displayed. Adjust the B/W Threshold by sliding the bar. If Preview has been checked, the adjustment result is displayed on the image window. I Grayscale Converts the selected page into a grayscale image.

  • Page 139: View Menu

    View Menu Grayscale Indication Selects grayscale display when displaying a monochrome image on the image window in reduced size. Picture Quality Precedence Switch the setting if making the image quality a higher priority than the displaying speed. Tool Bar Switch between displaying/hiding the tool bar. Status Bar Switch between displaying/hiding the status bar.

  • Page 140: Status Monitor

    Yellow Gray NOTE • Installing the Panasonic Document Management System adds the status monitor to • Connecting the device to a network server disables the status monitor. Device is operational under standby, printing, copying status. Device inspection is required under initialization, running out of staples, open cover, paper jam, etc.

  • Page 141: Task Bar Menu

    Status Monitor Task Bar Menu Right-clicking on the status monitor in the System Tray displays the dropdown menu as shown below: About Displays the version information about the status monitor. Open Status Monitor Displays details about the current status of the device. Pop up when error occurs If the menu is selected, a checkmark appears or a pop-up error dialog box appears upon occurrence of an error.

  • Page 142: Display Status Details

    Status Monitor Display Status Details Right-clicking the status monitor icon in the Task Bar and selecting Open Status Monitor in the dropdown menu displays a dialog box for the status monitor. I Status Tab Model Displays the name and number of a connected device. Device Status Displays the current status of the device.

  • Page 143: Configuration Tab

    Status Monitor I Configuration Tab Model Displays the name and number of a connected device. Configuration Display a list with the current device configuration (optional devices, etc.). Status Displays the communication status between the status monitor and the device.

  • Page 144: Paper Tab

    Status Monitor I Paper Tab The tab displays the type, size, and if there is any paper loaded in the paper tray. A comment by the user can be entered freely in the <Paper Type> field. • Changing the types of loaded paper does not change the comment in <Paper Type> NOTE unless it is rewritten by a user.

  • Page 145: Configuration Editor

    This utility allows you to edit the machine configuration through the Parallel Port connected between the PC and the device. Startup Windows, and select Panasonic ➝ Panasonic Document Management System ➝ MFP Utilities ➝ Configuration Editor from the Programs in the Start menu to display the configuration editor dialog box.
  • Page 146 Configuration Editor Retrieve button Retrieve the current settings of the selected folder from the device. Write button Write's the settings in the folder to the device. button Open File Opens the settings in the folder from a file. Save File button Saves the settings in the folder to a file.

  • Page 147: User Parameters Folder

    Configuration Editor User Parameters Folder Specify the originating party name and telephone number, etc. to be registered on the device for fax communications.

  • Page 148: Fax Parameters Folder

    Configuration Editor Fax Parameters Folder Display or change the Fax Parameter Settings.

  • Page 149: Copier Settings Folder

    Configuration Editor Copier Settings Folder Display or change the Copier Settings.

  • Page 150: General Functions Folder

    Configuration Editor General Functions Folder Display or change the General Functions.

  • Page 151: Journal Folder

    Configuration Editor Journal Folder Display the Fax communication journal.

  • Page 152: Phone Book Settings Shortcut Activation Folder

    Configuration Editor Phone Book Settings Shortcut Activation Folder When the Phonebook Folder is selected the Phone Book Editor utility will be started.

  • Page 153: Phone Book Editor

    Phone Book Editor Features This function allows registering, deleting, and modifying fax phone numbers in the main unit from a connected PC. Registering, deleting, modifying fax numbers can be operated on the control panel of the machine. Features provided by the Phone Book Editor function are as follows: Retrieve/Write Retrieve fax numbers in main unit to the PC, or send fax numbers from the PC to the main unit.

  • Page 154: Activation Procedure

    Take the following steps to activate the phonebook editor software. Click Start at the bottom left of the PC screen. Start Select Programs. Select Panasonic. Select Panasonic Document Management System. Select MFP Utilities. Select Phone Book Editor. Phone Book Editor splash screen appears and...
  • Page 155 Main Window (For DP-2500/3000) The screen shown below appears on the PC: Indication Station Name Key Name Telephone No. About Retrieve Write Open File Save File Insert Entry Delete Entry Help Exit Description Station name (Up to 15 characters) (Up to 200 stations) Key name (Up to 10 characters) Telephone number (Up to 36 digits) Version information of software...

  • Page 156: Main Window (For Dp-2000)

    Phone Book Editor Main Window (For DP-2000) The screen shown below appears on the PC: Indication Abbr. Dialing No. Tab One-Touch Tab About Abbr. Dialing No. Telephone No. Station Name Retrieve Write Open File Save File Insert Entry Delete Entry...

  • Page 157: Retrieve/Write

    Retrieve/Write This function retrieves the fax numbers in the connected device by PC and writes fax numbers from the PC to main unit. Phone Book Editor Click Retrieve. Retrieve Click the button. A list of fax numbers in the machine is displayed. Modify and add destination names and dial numbers on this screen.
  • Page 158 Phone Book Editor Click Write after the editing is completed. Write Click the button. The phonebook information is written to the connected device.

  • Page 159: Open/Save File

    Open/Save File This function opens the phonebook file in the PC, edits the file and then saves the file in the PC again. Phone Book Editor Click Open File Open File Click the button. The File Open dialog box appears Select a file from the list (e.g.
  • Page 160 Phone Book Editor Click Save File after the editing is completed. Save File Click the button. The phonebook information is saved in the PC. For Save File: Select an existing file from the list or enter a new file name. Click the Save button.

  • Page 161: Insert Entry

    Insert Entry This function adds or deletes lines in the list when editing the phonebook. The steps for inserting lines is as follows: Phone Book Editor Example: Insert a line between the 2nd and 3rd lines. Click the portion indicated as Click Insert Entry.

  • Page 162: Delete Entry

    Phone Book Editor Delete Entry The steps for deleting lines is as follows: Example: Delete the 3rd line. Click the portion indicated as Click Delete Entry. The screen shown on the left appears. Click The line is deleted as shown on the left.

  • Page 163: Troubleshooting Troubleshooting

    Troubleshooting Starting with: If the printing operation fails, check the following points first: • Connection cables are properly connected. • Length of connection cables is not longer than 20 ft. (6 m). • Power of devices is turned on. • Paper is loaded on the device properly. •...

  • Page 164: Document Is Not Printed Correctly

    The specified paper has not been loaded on the device. Specify the settings again or load the appropriate paper. The document margin is not sufficient. On the DP-2000/2500/3000, a margin of approx. 5 mm or more is required at the sheet edge.

  • Page 165: Error Messages Displayed On The Computer

    Error messages displayed on the computer Problem Error in writing to LPT1. Unable to write to the Specified device. Error in writing to LPT1. Printer timeout error occurred. Printing is disabled due to an error in the current printer settings. Action Verify that the device is connected to the computer correctly.

  • Page 166: Adding Paper( )

    Troubleshooting Adding Paper( ) I 550-sheet paper drawer/tray • Do not use paper with folds or wrinkles. NOTE Refer to page 44 for details on changing the paper size for the paper tray. • Unused paper should always be placed into a bag and the opening should be sealed for storage.

  • Page 167: Replacing The Toner Cartridge And Waste Toner Bottle( )

    Replacing the Toner Cartridge and Waste Toner Bottle( • For optimum copy quality use the recommended Panasonic toner. Store toner in a cool NOTE dark place. Do not unseal toner before use. Use it as fast as possible after unsealing.
  • Page 168 Troubleshooting • Do not reuse the toner from the waste toner bottle. NOTE Shake the new toner cartridge well. Install the new toner cartridge into the copier, and pull out the protective seal. Note: Pull on the seal slowly and straight out. Install a new waste toner bottle.

  • Page 169: Removing A Misfeed Paper

    Removing a Misfeed Paper I Paper Misfeed Indicators and Locations When paper misfeed occurs, the misfeed indicator and the misfeed location(s) will be displayed on the touch panel display. MULTI-SIZE COPY SORT FEED ADD TONER ON LINE CONTRAST INTERNET PRINTER ON LINE DATA Paper Misfeed Locations...
  • Page 170 Troubleshooting • Make sure that the misfeed indicator goes off after removing all misfed paper. NOTE I Finisher • Make sure that the misfeed indicator goes off after removing all misfed paper. Pull out the finisher. Lift up the lever and clear the paper jam.

  • Page 171: Removing A Paper Misfeed

    Removing a Paper Misfeed • Make sure that the misfeed indicator goes off after removing all misfed paper. NOTE Troubleshooting I Paper Transport Area • Make sure that the misfeed indicator goes off after removing all misfed paper. Push the latch to open the cover.
  • Page 172 Troubleshooting • Make sure that the misfeed indicator goes off after removing all misfed paper. NOTE Paper Entry area • Make sure that the misfeed indicator goes off after removing all misfed paper. Open the right cover. Remove misfed paper. Open the heat roller cover.

  • Page 173: Automatic Duplex Unit

    • Make sure that the misfeed indicator goes off after removing all misfed paper. NOTE Troubleshooting Automatic Duplex Unit (ADU) Open the paper feed guide. Remove misfed paper. Close the right cover.

  • Page 174: System Console

    Troubleshooting • Make sure that the misfeed indicator goes off after removing all misfed paper. NOTE I System Console • Make sure that the misfeed indicator goes off after removing all misfed paper. Pull out the paper tray. Remove misfed paper. Return the paper tray to the original position.
  • Page 175 • Push the tab on the center of the ADF cover to close it. NOTE • Make sure that the misfeed indicator goes off after removing all misfed paper. Troubleshooting I ADF/i-ADF • Make sure that the misfeed indicator goes off after removing all misfed paper.
  • Page 176 Troubleshooting Make sure that the misfeed indicator goes off after removing all misfed paper. NOTE Lift up the ADF tray top cover. Remove misfed paper. Close the ADF tray top cover. <i-ADF> Lift up the ADF tray top cover. Open the entry cover. Remove misfed paper.

  • Page 177: Appendix

    Appendix Printing/Scanning Area 0.1/2.5 0.1/2.5 0.1/2.5 0.1/2.5 Bottom (Unit: inches/mm)

  • Page 178: Parallel Interface Connector

    Appendix Parallel Interface Connector The printer has a parallel interface for connecting to PC. Shape of Connector Signal lines and pin arrangement Signal name /STB DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 /ACK BUSY SELECT /AUTOFD* Not used *Signal used for bidirectional communication Signal functions Signal name /STB...
  • Page 179 NOTE...
