2.2

Control Panel Board Installation (Step 2)

1. Place the mounting clips on the enclosure
standoffs.
2. Place the top edge of the control panel board
between the enclosure retaining slots, and then
set the control panel board on the mounting
clips.
3. Secure the control panel board to the mounting
clips using the supplied screws.
