Step 1: Connecting the XL2A Computer and a CD/
DVD Changer/Recorder
If you have purchased a CD/DVD changer, connecting the changer to the
computer is a simple process requiring only a single cable.
Using the supplied i.LINK
®
i.LINK
the node to an i.LINK
Step 2: Connecting your TV
You can receive analog and digital TV signal transmissions using with the
following connections:
HDMI™ Connector
If your TV has a HDMI™ connector, use the supplied HDMI™ cable and
connect one end to your TV and the other end to the HDMI™ connector on
the back panel of the DLS computer.
DVI-D Connector
If your TV has a DVI-D connector, use the supplied HDMI cable and the
HDMI™ to DVI-D adapter. Insert the adapter into the DVI-D TV/monitor. Then
using the supplied HDMI™ cable, connect one end of the cable to the adapter
and the other end to the HDMI™ connector on the back panel of the XL2A
computer.
Component Connectors (Y, Pb, Pr)
If your TV has component connectors, use a component video cable (not
supplied) and connect one end to the corresponding video outputs on your TV
and on the back panel of the XL2A computer. In this type of connection, there
will be separate audio connections.
1.
22
®
connector on the back panel of the XL2A computer, and the end with
®
connector on the back panel of the changer.
i.LINK is a trademark of Sony used only to designate that a product contains an
IEEE1394 connection. The i.LINK connection may vary depending on the soft-
ware applications, operating system and compatible i.LINK devices. All prod-
ucts with an i.LINK connection may not communicate with each other. Please
refer to the documentation that comes with any device having an i.LINK con-
nection for information on compatibility, operating conditions and proper con-
nection. For information on any Sony device having an i.LINK connection,
contact Sony at 1-800-686-7669.
1
cable, connect the end without the node to an
VGX-XL2A Digital Living System
