Configure a RAID Array
Certain VAIO
RAID 0, RAID 1, RAID 5, or RAID 10. The number of pre installed SATA disk
drives vary depending on the RAID level purchased. See your computer's
specification sheet for details about your specific hardware configuration.
Note: When installing additional disk drives, make sure that you use identical
S-ATA drives, when possible. If you install drives that vary in size, storage
capacity will be limited to the size of the smallest drive.
Before You Begin
To configure your RAID array, perform the following steps
1 Back up your computer's data to external media. Creating, altering, or
configuring for RAID deletes all data from the targeted hard disk drives.
2 Create the VAIO
your data files after you configure the RAID volumes to perform a hard disk
recovery.
For additional information about creating recovery discs, see the VAIO
Recovery Guide located in VAIO
To access the online documentation
1 Using the wireless keyboard, click
All Programs
2 From the VAIO
then select the desired document from the list.
Install Additional Hard Disc Drives
If you purchased a RAID Ready computer, you may be required to install
additional hard disks to configure the RAID array to the desired level. In
addition to the procedure here, you can locate additional procedures for
installing hard disks in the section titled "About Hard Disk Drive Installation" of
the VAIO
To install additional hard disk drives
1 Place all S-ATA disk drives into the drive holder inside the computer's chassis.
2 Connect one end of the S-ATA data cable(s) to the S-ATA connection, starting
with Port-0 on the motherboard. Connect the data cables of any additional
disks to Ports 1 and 2.
146
®
computers can be ordered for purchase already configured for
®
Recovery Discs media. The discs are required to recover
®
> VAIO Support
®
Support Central page, select
®
Computer User's Guide.
®
Support Central.
Start in the Windows
Central.
®
VAIO
VGX-XL2A Digital Living System
®
®
taskbar, then click
Documentation, and
