System Configuration - Dinstar DWG2001 User Manual

DWG Series GSM/CDMA VoIP Gateway User Manual
Index 31: add GSM to GSM route,its mainly used for saving the cost between two carriers
It indecates that calls coming from Port 0 will match the prefix 13[58], "13[58]" include prefix 135
and 138, caller number can't match prefix 135 and 138 will reject by gateway. Meanwhile sending
the calls to Port Group 31<Unicom> if called number match with prefix 133.
4.8 Manipulaton Configuration
Function
It is an optional configuration item, and is used to add IP‐>Tel number change data.
The IP‐>Tel Manipulation defined the rules of add, and deletion of called numbers, which are
referenced by IP‐>Tel routing.
Parameter Description
Parameter
Index
Parameter Description
It uniquely identifies a route. Its value is assigned globally, ranging from 0 to 31.
32
