DWG Series GSM/CDMA VoIP Gateway User Manual
2.2 Installation procedure
The outlook of DWG2001/DWG2004/DWG2008 looks like a 1U chassis; to install hardware the
cable is needed. After unpacking the equipment, please do follow the procedure as following
steps:
2.2.1 Install SIM card
When installing SIM card, opening blank panel of SIM slot, procedure shows as below:
2.2.2 Antenna installation
Figure 2‐5 shows as below a compelete installation:
Figure 2‐5 Antenna installation
2.2.3 Cable connection of equipment
9
