Hose Reel Mounting Kit

Workman

Model No. 07027

This product contains a chemical or chemicals known to the State of California to

Safety

Safety and Instructional Decals

Safety decals and instructions are easily visible to the operator and are located near any area of potential

danger. Replace any decal that is damaged or lost.

1. Attention—read the Operator's Manual; do not carry more

than 45 kg (100 lb).

1. Warning—do not carry any passengers.

8111 Lyndale Avenue South

Bloomington, MN 55420

GTX Series Utility Vehicle

Proposition 65 Warning

cause cancer, birth defects, or reproductive harm.

133-7202

133-4641

WARNING

CALIFORNIA

Form No. 3406-359 Rev A

Installation Instructions

Original Instructions (EN)

Printed in the USA

Page 1 Form No. 3406-359 Rev A Hose Reel Mounting Kit Workman ® GTX Series Utility Vehicle Model No. 07027 Installation Instructions WARNING CALIFORNIA Proposition 65 Warning This product contains a chemical or chemicals known to the State of California to cause cancer, birth defects, or reproductive harm.
Page 2 The hose-reel mount is designed to fit aftermarket hose reels with mounting patterns of either 40 x 23 cm (15-3/4 x 9 inches) or 39 x 25 cm (15-7/16 x 10 inches). Toro recommends the following aftermarket hose reels: •...
Page 3 Installing the Hose-Reel Mount Parts needed for this procedure: Hose-reel mount Tube mount Hex-head screw (1/2 x 2-1/4 inches) Figure 2 Locknut (1/2 inch) 1. Tube mount 3. ‘T’ handle Clevis pin (1/2 x 2 inches) 2. Front hitch attachment 4.
Page 4 4. Insert the tube mount into the front hitch attachment and secure it with the clevis pin (1/2 x 2 inches) and hairpin cotter (Figure 5. Tighten the ‘T’ handle on the front hitch attachment (Figure Installing the Hose-Reel Mount to the Rear of the Machine 1.
