Foot - Epson L1800 Service Manual

L1800

3.4.11 Foot

1. Remove the Printer Mechanism.
Mechanism (p.61).)
2. Remove the six foot at the backside of the Lower Housing.
Figure 3-105. Removing the Foot
Disassembly And Assembly
(Refer to 3.4.4 Lower Housing / Printer
Foot
Disassembling the Printer Mechanism
3.4.12 Paper EJ Frame Assy
1. Remove the Upper Housing Support Assy. (p.52)
2. Remove the Ink Supply Tube Assy section. (p.102)
3. Remove the Ink Supply Tank Tube Assy section. (p.104)
4. Remove the Left Frame Support Plate.
Unit Step4 (p63), Step5(p63).)
5. Return the rotation position of the Right PG Cam.
6. Remove the four C.B.S. M3 x 6 that secure the Paper EJ Frame Assy.
Tabs
3
2
2) C.B.S. M3x6
(8±1 kgf.cm)
Paper EJ Frame Assy
Figure 3-106. Screws that Secure the Paper EJ Frame Assy
Revision A
(Refer to 3.4.5 Carriage Shaft / Carriage
2) C.B.S. M3x6
(8±1 kgf.cm)
1 4
Tabs
