Blomberg DW 14110 NBL00 Service Manual

Built - under dishwasher
Hide thumbs Also See for DW 14110 NBL00:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Use and Care Manual, Installation Manual
BUILT - UNDER DISHWASHER
For Models
DW 14110 NBL00
DW 15111 NBL00
DW 14120 NBL00
DW 15121 NBL00
DW 14140 NBL00
DW 15141 NBL00
DW 15110 NBL00
DWT 14210 NBL00
DW 15120 NBL00
DWT 14240 NBL00
DW 15140 NBL00
DWT 14220 NBL00
SERVICE USER MANUAL
DWT 15210 NBL00
DWT 15220 NBL00
DWT 15240 NBL00
DWT 15211 NBL00
DWT 15241 NBL00
DWT 15221 NBL00
BUILT- UNDER DISHWASHER
DWT 14210 NBL00
DWT 14240 NBL00
DWT 14220 NBL00
DWT 14440 ULTRA
DWT 14410 ULTRA
DWT 14420 ULTRA
1
DWT 15210 NBL00
DWT 15220 NBL00
DWT 15240 NBL00
DWT 15211 NBL00
DWT 15241 NBL00
DWT 15221 NBL00
2011

Advertisement

Table of Contents
loading

Related Manuals for Blomberg DW 14110 NBL00

Summary of Contents for Blomberg DW 14110 NBL00

  • Page 1: Cover

    BUILT- UNDER DISHWASHER BUILT - UNDER DISHWASHER SERVICE USER MANUAL For Models DW 14110 NBL00 DW 15111 NBL00 DWT 15210 NBL00 DWT 14210 NBL00 DWT 15210 NBL00 DW 14120 NBL00 DW 15121 NBL00 DWT 15220 NBL00 DWT 14240 NBL00 DWT 15220 NBL00...

  • Page 2: Table Of Contents

    BUILT- UNDER DISHWASHER CONTENTS Page No 1. Cover............................1 2. Contents..........................2 Introduction ..........................5 3.1. Important Safety Instructions ....................5 3.2. Installation ........................... 6 Getting To Know Your Dishwasher ................... 8 4.1. Technical Instructions (Only one model sample) ..............9 Installation Manual ........................
  • Page 3 BUILT- UNDER DISHWASHER 6.1. Proper And Improper Loadıng Of Dıshware ..............37 6.2. What Should Not Be Washed In Your Dishwasher ............38 Operating The Dishwasher ..................... 39 7.1. How To Use Your Dıshwasher: ..................39 7.1.1. Functıon Buttons ......................40 7.2.
  • Page 4 BUILT- UNDER DISHWASHER Assembly And Dısassembly Methods For Key Components ..........81 13.1. Control Panel ......................... 81 13.2. Panel Group ........................81 13.3. Display Group ........................ 82 13.4. On-Off Button Key Holder ....................82 13.5. Overflow Gauge ......................83 13.6. Drain Pump ........................

  • Page 5: Introduction

    BUILT- UNDER DISHWASHER 3. Introduction Please read this user manual and particularly the safety instructions completely and carefully They will save you time and effort and help to ensure optimum dishwasher performance. Be sure to observe all listed warnings and cautions. Look particularly for the icons with exclamation marks inside.

  • Page 6: Installation

    BUILT- UNDER DISHWASHER Under certain conditions hydrogen gas may be produced in a hot water heater system that has not been used for two weeks or more. Hydrogen gas is explosive. If the hot water system has not been used for such period, before using the dishwasher turn on all hot water taps and let the water flow from each for several minutes.
  • Page 7 BUILT- UNDER DISHWASHER Dishwasher must be secured to adjacent cabinetry using the brackets provided. Failure to do this may cause damage to property or bodily injury. The dishwasher installation must be performed in accordance with the installation manual. If you did not receive an installation manual order it by calling 1-800-459-9848 or you may also download it from our web site at www.blombergappliances.com Installation, maintenance and repair should be performed by a qualified installer.

  • Page 8: Getting To Know Your Dishwasher

    BUILT- UNDER DISHWASHER 4. Getting To Know Your Dishwasher 2011...

  • Page 9: Technical Instructions (Only One Model Sample)

    4.1. Technical Instructions (Only one model sample) Basic Definitions Brand Blomberg SAP Code 7665389542 Marketing Code DW 14110 NBL00 Manufacturer Productıon Code 94001 EAN Code 8690769665385 Product Button Ctrl - 4 Prg - Without Water Softener - Red Led Type...
  • Page 10 BUILT- UNDER DISHWASHER Packagıng & Dımensıons Height (Cm) 82,0 Height Without Worktop (Cm) 82,0 Width (Cm) 59,8 Depth (Cm) 54,8 Depth, With Door Opened (Cm) 115,0 Height Adjustment (Cm) Dımensıons Packed (Cm) 85,9 X 64,4 X 66,1 (Hxwxd) Dımensıons Packed (İnch) 33 7/8 X 25 3/16 X 26 (Hxwxd) Dımensıons Unpacked (İnch)
  • Page 11 Water Consumption (Liters) 19,80 Energy Consumption (Kwh) 0,74 Program Duration (Min) Insulation Us-L1 Noise Level - Db (A) - Iec 704 Design Panel Blomberg Inlay 1a Panel Color White Inlay Color White Panel Printing Text Knob Color Buttons Color White...
  • Page 12 BUILT- UNDER DISHWASHER Program, Controls Range Ub104 Power On / Off Button Nr Of Programs Programme 1 Quick Wash Programme 2 China Gentle Programme 3 Regular Wash Programme 4 Pots&Pans Buttons Programme Start/Stop Program Control Buttons Screen Key Lock Program Sequence Yes 4 Leds Count Down Half Load...
  • Page 13 BUILT- UNDER DISHWASHER Racks / Baskets Rack Color Albatross, Dark Grey 2 Ral 7037 Rack Type (Lower / Upper) Us2 Type Accessory Color Dark Grey Lower Rack Folding Tines Fixed Lower Basket Folding Tines Fixed Lower Rack Decorative Handle Lower Basket Decorative Handle No Lower Rack Long Tool Basket Lower Basket Long Tool Basket No Lower Rack Bottle Holder...

  • Page 14: Installation Manual

    BUILT- UNDER DISHWASHER 5. Installation Manual Installation Manual For Dishwasher Models 5.1. Important Safety Instructions In addition to these instructions, the dishwasher shall be installed: In accordance with all local codes or, in absence of a local code, In the United States, with the National Electric Code, In Canada, with the Canadian Electric Code C22.1-latest edition/Provincial and Municipal codes and/or local codes Read these installation instructions completely before installing and...

  • Page 15: Inspect The Dishwasher

    How To Contact Us You may either call our Toll Free Number at 1-800-459-9848 or contact us via the web site at www.blombergappliances.com or Contact the Blomberg Distributor for your State or Province as listed on the Distributor Contact List provided.

  • Page 16: Tools Which May Be Needed

    BUILT- UNDER DISHWASHER 5.2. Tools Which May Be Needed 5.3. Materials Which May Be Needed (Additional materials may be required to comply with local codes) 2011...

  • Page 17: Materials Supplied

    BUILT- UNDER DISHWASHER 5.4. Materials Supplied 5.4.1. Parts Supplied Parts for your dishwasher will come in several plastic bags. Check your parts bags shown to make sure you have all the parts as listed to the left. 5.4.2. Manual Bag The dishwasher comes with a manual bag containing: •...

  • Page 18: Dishwasher Specifications

    BUILT- UNDER DISHWASHER 5.5. Dishwasher Specifications 5.6. Technical Features Because we continually strive to improve our products, we may changeour specifications and design without prior notice. This device corresponds to the following directives: UL 749 Household Dishwasher directive. 5.7. Enclosure Preparation For proper dishwasher operation and appearance ensure that the enclosure has the minimum dimensions shown in the figure above.

  • Page 19: Electrical Preparation

    BUILT- UNDER DISHWASHER 5.7.1. Electrical Preparation To avoid electrical shock and/or a fire hazard, make sure electrical work is properly installed. Only qualified electricians should perform electrical work. Before installation disconnect the power supply to the work area by unplugging the unit, “tripping” the circuit breaker or removing the fuse.

  • Page 20: Preparation For Installing Mounting Brackets

    BUILT- UNDER DISHWASHER 5.8. Preparation For Installing Mounting Brackets Place the two mounting brackets into the top corners of the dishwasher. Bend sides of mounting brackets (A) in order to fix from sides (if necessary). 5.9. Adjusting Height Measure the height of the enclosure. 2011...

  • Page 21: Installing The Foot Supports

    BUILT- UNDER DISHWASHER 5.9.1. Installing The Foot Supports If the height of the enclosure is 337/16” to 341/4” (850mm - 870mm) use short supports as shown in the figure. If the height of the enclosure is above 341/4” (870mm) use long supports as shown in the figure. 2011...

  • Page 22: Installing The Side Trim Strips

    BUILT- UNDER DISHWASHER Adjust the front foot level with the adjusting wrench to balance and raise the dishwasher to the enclosure height. Adjust the rear foot level with a screwdriver to balance and raise the dishwasher to the enclosure height. •...

  • Page 23: Preparing The Water Connection (A)

    BUILT- UNDER DISHWASHER 5.11. Preparing The Water Connection (A) Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder connections must be made before the water line is connected to the dishwasher’s water inlet valve. Water can also be supplied to the dishwasher by using a flexible braided hose line. Check with your plumbing supply sources for the proper hose and 90°...

  • Page 24: Drain Preparation

    BUILT- UNDER DISHWASHER 5.12. Drain Preparation The dishwasher drain hose may be connected to the drain plumbing in one of three ways (Figure A, B, C). • Either one of the above methods must be used or the dishwasher will not operate properly. •...

  • Page 25: Steam Protection Foil

    BUILT- UNDER DISHWASHER 5.13. Steam Protection Foil Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top.

  • Page 26: Placement Of Dishwasher Into The Opening

    BUILT- UNDER DISHWASHER 5.14. Placement Of Dishwasher Into The Opening Make sure all hoses and electrical wire are pulled through the side opening of the cabinet, no hoses are kinked and all slack is taken out as shown in the above figure. 5.15.

  • Page 27: Water Supply Connection

    BUILT- UNDER DISHWASHER 5.15.2. Water Supply Connection Water supply may be connected to the dishwasher in one of two ways: • With metal braided hose. • With copper tubing. 5.15.3. Braided Hose/Copper Tubing After connections are made turn on the water supply to check for leaks. •...

  • Page 28: Fasten Junction Box

    BUILT- UNDER DISHWASHER Install a strain relief (not supplied) into the opening on the kick plate. (Figure A) Pass the electrical supply cable through the strain relief; make sure the strain relief clamps the insulated outer casing of your electrical supply cord and not the wires themselves. Leave 215/16”...

  • Page 29: Readjusting Foot Levels

    BUILT- UNDER DISHWASHER 5.17. Readjusting Foot Levels Now that the dishwasher is in the cabinet you must readjust the feet to bring the dishwasher up to the required height and attach it underneath the countertop. 1. Readjust the front foot levels with adjusting wrench to balance the dishwasher and raise it up under the countertop, make sure the unit is level.

  • Page 30: Installing The Outer Door

    BUILT- UNDER DISHWASHER Lock the toe kick brackets as shown with the plastic tab in the figure C by pushing the plastic tab on the dishwasher into the teeth of the bracket (C). 3. Now attach the toe kick to the bracket with the two (Ø 3/16” x 1/4”...
  • Page 31 BUILT- UNDER DISHWASHER 2. Remove the plastic mounting brackets from the dishwasher (Figure B). 3. Lay the schematic over the door from the bottom up and mark holes on the wooden door as shown in the drawing (Figure C). 2011...
  • Page 32 BUILT- UNDER DISHWASHER 5. Attach the two mounting brackets to 6. Mount the wooden door onto the dishwasher the wooden door with 4 screws with the plastic mounting brackets which you (Ø 1/8” x 5/8” (Ø 3.5mm x 14mm) have attached (Figure B). (Figure A).
  • Page 33 BUILT- UNDER DISHWASHER 11. Check whether the bottom of the door hits the toe kick of the kitchen cabinet (A). 11.1. If the door hits the toe kick cut the necessary section out of the toe kick (B). 11.2. Apply silicon or sealant to the cut edge of the kitchen cabinet toe kick or paint so it does not absorb moisture.
  • Page 34 BUILT- UNDER DISHWASHER If you have a European kitchen or want to install a wooden toe kick to match your kitchen, please refer to one of the two drawings given below. Follow the same instructions on the brackets as for the removable toe kick. Installation should be done following the steps illustrated in the figures A, B, C, D respectively.

  • Page 35: Installer Checklist

    BUILT- UNDER DISHWASHER 5.20. Installer Checklist Your installer must have completed and checked the following: • The dishwasher is square and level. • The dishwasher is fastened securely to the cabinetry. • The dishwasher door opens and closes freely. The dishwasher door must close without hitting any cabinetry or counter top.

  • Page 36: Loadıng The Dıshwasher

    BUILT- UNDER DISHWASHER 6. Loadıng The Dıshwasher 1. Pull the handle to open the door. If the door is opened during operation, the dishwasher will stop running. Once the door is closed the program will continue. Hot steam can escape! Danger of serious burns or other injury. 2.

  • Page 37: Proper And Improper Loadıng Of Dıshware

    BUILT- UNDER DISHWASHER 6.1. Proper And Improper Loadıng Of Dıshware • Place all large and very dirty items in the lower rack. • Place containers such as cups, glasses pots into dishwasher with opening facing downwards (so that no water can collect). •...

  • Page 38: What Should Not Be Washed In Your Dishwasher

    BUILT- UNDER DISHWASHER 6.2. What Should Not Be Washed In Your Dishwasher • Rust-sensitive steel parts like iron and cast iron that can rust and stain other utensils and damage the interior stainless steel liner of the dishwasher and void the warranty. Do not wash copper, brass, pewter, bronze or tin.

  • Page 39: Operating The Dishwasher

    BUILT- UNDER DISHWASHER 7. Operating The Dishwasher 1. Program lights 6. Start/Pause button 2. Rinse aid level indicator light * 7. Door handle 3. Salt level indicator light * 8. On/Off button 4. Program follow up lights 5. Cycle Select button (* Depending on model) 7.1.

  • Page 40: Functıon Buttons

    BUILT- UNDER DISHWASHER 7.1.1. Functıon Buttons On/Off button. Turn your dishwasher on with the On/Off button. When turning on, the icon on the display module of the last used program will light up. Start/Pause button Use this button to start the selected program; the light on the button lights up. Stop the program with the Start/Pause button if you would like to open the door once the dishwasher’s washing program is running.

  • Page 41: Rinse Aid Level Indicator Light (Depending On Model)

    BUILT- UNDER DISHWASHER 7.2. Rinse aid level indicator light (depending on model) If this indicator light comes on, you have to refill rinse aid. You can also tell whether rinse aid must be refilled by looking at the rinse aid dispenser.
  • Page 42 BUILT- UNDER DISHWASHER If you do not know the hardness of your water supply, use 15 ml / 3 tsp detergent. Increase the amount of detergent if you see white water marks especially surface glassware. Find out the hardness of your water supply by asking your local water department, water softener company, or county extension agent.

  • Page 43: Filling Rinse Aid Dispenser

    BUILT- UNDER DISHWASHER 7.6.1. Filling Rinse Aid Dispenser Keep Your Rinse Aids Out Of The Reach Of Children. Ingestion Or İnhalation Of Rinse Aid May Cause Serious İnjury. Avoid Contact With Skin And Eyes, And Keep Children And İnfirm Persons Away From Rinse Aids.
  • Page 44 BUILT- UNDER DISHWASHER Hardness Table 2011...

  • Page 45: Filling The Dishwasher Salt Dispenser (Dependıng On Model)

    BUILT- UNDER DISHWASHER 7.8. Filling The Dishwasher Salt Dispenser (Dependıng On Model) Never use culinary or table salt. These types of salt do not dissolve in water easily and will damage the function of the softening device. • Only use special dishwasher salt in your machine to soften the water.

  • Page 46: Care And Maıntenance

    BUILT- UNDER DISHWASHER 7.9. Care And Maıntenance Before cleaning or carrying out maintenance, switch off the appliance, disconnect the mains plug and turn off the water tap. Do not repair or replace any part of the dishwasher or attempt any servicing unless specifically recommended by this manual.

  • Page 47: Caring For Your Dishwasher Interior

    BUILT- UNDER DISHWASHER 7.11. Caring For Your Dishwasher Interior Cleaning your dishwasher at regular intervals ensures longer product life and reduces the risk of reccurring problems. Always disconnect the power to machine before cleaning. When cleaning the underside of the main filter, care must be taken on the sharp outer edge to avoid the risk of cut type injuries.

  • Page 48: Cleaning The Spray Arms

    BUILT- UNDER DISHWASHER 7.11.2. Cleaning The Spray Arms Dirt and/or calcium residue may block the nozzles on the spray arms. For this reason, regularly check the spray nozzles. 1. Lower spray arm 2. Upper spray arm 1. Remove the lower rack from the machine. 2.

  • Page 49: Working Principle

    BUILT- UNDER DISHWASHER 8. Working Principle 8.1. Hydraulic System (Water Softener Group) The Standard wash cycle starts with drain cycle (1). Than the water inlet valve (2) is activated by the electronic control board. Intake water quantity is measured via flowmeter (3) Intake water passas through water pocket(4) and the air break(5).
  • Page 50 BUILT- UNDER DISHWASHER 2011...

  • Page 51: Hydraulic System (No Water Softener Group)

    BUILT- UNDER DISHWASHER 8.2. Hydraulic System (No water Softener Group) The Standard wash cycle starts with drain cycle (1). Than the water inlet valve (2) is activated by the electronic control board. Intake water quantity is measured via flowmeter (3) Intake water passas through water pocket(4) and the air break(5), than it is collected in the sump(6).

  • Page 52: Program Flow

    BUILT- UNDER DISHWASHER 8.3. Program Flow In a standard wash cycle there exists 5 steps. Pre wash Main Wash rinse rinse Drying and regeneration step In pre-wash step, soiled dishes get wet and rough dirt particules moved from dish surfaces. In main wash cycle, wash water is heated and detergent is added to clean dishes.

  • Page 53: Component Principle

    BUILT- UNDER DISHWASHER 9. Component Principle 9.1. Heater (Thermostat And Thermic Fuse) It is used for heating the water inside the dishwasher. It consists of a heater which is enclosed by a stainless steel. There is a thermostat and thermic fuse which run in the case of overheating. The heater is driven by 10A/110 V relay.

  • Page 54: Circulation Motor

    BUILT- UNDER DISHWASHER 9.3. Circulation Motor Asynchronous It is the 1 phase-asynchronous motor which is used for circulation of the water inside the dishwasher. The motor is protected by thermic against the problems that may occur due to overheating . Voltage range : 110 –...

  • Page 55: Door Lock Switch

    BUILT- UNDER DISHWASHER 9.5. Door lock switch It consists of a spring-loaded mechanism and a microswitch taking place in this mechanism. The switch, if the door is open, cuts the energy of all the components, without interference from the control board. To detect the fault in the door safety switch, pressing the button shown in the figure whether there is a short-circuit or not between the...

  • Page 56: Ntc

    BUILT- UNDER DISHWASHER 9.7. NTC sensor is used to measure temperature in the dishwasher. The resistance value decreases when the temperature rises. NTC temperature - resistance table Temperature (° F) Resistance ( ) Normal Upper Lower 47200 51150 43250 37500 40555 34445 31200...

  • Page 57: Water Inlet Valve

    BUILT- UNDER DISHWASHER 9.9. Water Inlet Valve It is used to take water into the dishwasher. Voltage : 120 60 Hz. Power : 3 VA Resistance : 1,02 Kohm ±%10 In order to control valve, the resistance is measured when the multimeter is in the position as shown in the figure .It is compared with the values above.

  • Page 58: Service Functional Test

    BUILT- UNDER DISHWASHER 10. Service Functional Test Service Functional test is a special sequence of program steps dedicated for service purposes. During the test, some faulty conditions can be detected by the electronics and shown through Program lights (1). To enter the service functional test mode; turn off the On/Off button (1).

  • Page 59: Faulty Condıtıons

    BUILT- UNDER DISHWASHER During the test, if a faulty condition is detected, the indicator on the Start/Pause (6) button blinks and the faulty code is shown on display as given below. In case of multiple errors detected at the same time, all errors will be displayed in order. (*) If the machine has 3 Way valve, then this fault condition can be detected Please refer to the “Faulty Conditions”...

  • Page 60: Heating Fault (3 Program Led)

    BUILT- UNDER DISHWASHER 10.1.3. Heating Fault (3 Program Led) The water temperature in the machine is measured by an NTC (negative temperature coefficient). NTC is simply a resistance value dependent on temperature. At the Heating step, if the temperature rise is less than 1 °C within 3 minutes heating fault occurs. When the fault detected software skips the heating step and continues the program with the next step.

  • Page 61: Trouble Shooting

    BUILT- UNDER DISHWASHER 11. Trouble Shooting 11.1. Machine Is Not Running Machıne Is Not Runnıng Press start/stop button & check whether the drain pump works - Check supply,supplay cord, Drain pump terminal and wiring to works? on/off switch. Start/stop indicator on ? -Check on/off switch.

  • Page 62: No Water Inlet To The Machine

    BUILT- UNDER DISHWASHER 11.2. No Water Inlet To The Machine No Water Inlet To The Machıne -Check the water supply. -Check the water inlet hose (twisted or not ?) -Check the sıeves on the water ınlet valve and the water inlet hose. -Start a program.

  • Page 63: Machine Takes More Water Overflows

    BUILT- UNDER DISHWASHER 11.3. Machine Takes More Water Overflows Machıne Takes More Water, Overflows Check whether elektronic board ıs energized Machine starts filling during drain step water inlet valve energized during drain step ? Check the drain pump works & drains whole water inside.

  • Page 64: Program Is Not Running

    BUILT- UNDER DISHWASHER 11.4. Program Is Not Running Program Is Not Runnıng Check the electronic board is energized Start the functional test program. Program passes to fiil step after 30 -Check the overflow swich. -Check the connections of water inlet valve. -Check the water supply Run the machine till the program blocked.

  • Page 65: Program Is Not Complette

    BUILT- UNDER DISHWASHER 11.5. Program Is Not Complette Program Not Complete/Stops Short, Program Fınıshes Earlıer Machine passes steps as stated in program flow chart -Check elektronics and wirings. Program blocks at filling step. -Check the NTC -Check the wirings -Check the heater and wirings 2011...

  • Page 66: Machine Is Not Draining

    BUILT- UNDER DISHWASHER 11.6. Machine Is Not Draining Machıne Is Not Draınıng Drain pump energızed -Check the elektronics and wirings to drain pump. Drain pump runs -Check the wındıng of the motor. -Check the drain pump blocked or the drain hose blocked. 2011...

  • Page 67: Machine Is Not Circulating

    BUILT- UNDER DISHWASHER 11.7. Machine Is Not Circulating Machıne Is Not Cırculatng Circulation motor is energızed at circulation step -Check the elektronics and wirings to circulation motor. -Check the over flow swıtch and wırıng . -Check the motor windings and the capacitor.

  • Page 68: Machine Does Not Heat

    BUILT- UNDER DISHWASHER 11.8. Machine Does Not Heat Machıne Does Not Heat Heater is energızed at heating step -Check the elektronics and wirings to the heater . -Check the security thermostate and the thermofuse. -Check if the heater resistance 2011...

  • Page 69: Dispenser Cover Does Not Open

    BUILT- UNDER DISHWASHER 11.9. Dispenser Cover Does Not Open Machıne Does Not Heat Heater is energızed at heating step -Check the elektronics and wirings to the heater . -Check the security thermostate and the thermofuse. -Check if the heater resistance 2011...

  • Page 70: Problems Which Are Not Detected During Functional Test

    BUILT- UNDER DISHWASHER 11.10. Problems Which Are Not Detected During Functional Test 2011...
  • Page 71 BUILT- UNDER DISHWASHER 2011...
  • Page 72 BUILT- UNDER DISHWASHER 2011...
  • Page 73 BUILT- UNDER DISHWASHER 2011...
  • Page 74 BUILT- UNDER DISHWASHER 2011...

  • Page 75: Circuit - Whiring - Pcb Diagram

    BUILT- UNDER DISHWASHER 12. Circuit - Whiring - PCB Diagram 2011...
  • Page 76 BUILT- UNDER DISHWASHER 2011...
  • Page 77 BUILT- UNDER DISHWASHER 2011...
  • Page 78 BUILT- UNDER DISHWASHER 2011...
  • Page 79 BUILT- UNDER DISHWASHER 2011...
  • Page 80 BUILT- UNDER DISHWASHER 2011...

  • Page 81: Assembly And Dısassembly Methods For Key Components

    BUILT- UNDER DISHWASHER 13. Assembly And Dısassembly Methods For Key Components 13.1. Control Panel The control panel is detached from the inner metal plate, after unscrewing the 6 screws located on the front side of the inner door, as is seen at the photo. 13.2.

  • Page 82: Display Group

    BUILT- UNDER DISHWASHER Main card holder is dismantled by bending the snap fits located on the panel back structure. The program select, start/stop and the ½ load key caps then easily be dismantled. 13.3. Display Group For the models that have a display, display board holder can be disassembled by releasing the snap fits similiar to the main board holder.

  • Page 83: Overflow Gauge

    BUILT- UNDER DISHWASHER 13.5. Overflow Gauge The mechanism attaching the overflow gauge to the base is pulled to the front direction, by pressing the latches and then is taken out 13.6. Drain Pump The notch is opened and turned in the counter clockwise direction and taken out by rotating it 10- 15˚.

  • Page 84: Heater

    BUILT- UNDER DISHWASHER 13.8. Heater Pipe type heater is used in the machine. It is taken out by unscrewing the two spring clamps. 13.9. Circulation Pump After the clamps and cable connections of the circulation pump are removed, the screws of the motor holding plate connected to the body frame are unscrewed.

  • Page 85: Feedıng Pıpe Of The Upper Spray Arm And Fılter Support

    BUILT- UNDER DISHWASHER 13.10. Feedıng Pıpe Of The Upper Spray Arm And Fılter Support Filter support is freed after the related screw is loosened. After the notch of the feeding pipe of the upper spray arm is released, both of the parts are taken out. After the notch located on the filter support is extended, it is removed from the upper feeding pipe.

  • Page 86: Flow-Meter

    BUILT- UNDER DISHWASHER 13.13. Flow-Meter The electronic counter on the flowmeter located at the left lower corner of the regeneration container, is taken out as demonstrated in the photo and detached from the socket. 13.14. Hinge Plates 3 screws on the both sides are loosened. 2 screws on the both sides of the connection sheet of the hinge arm are unscrewed and the plates are removed.

  • Page 87: Draın Hose, Water Inlet Valve, And Clıp Box

    BUILT- UNDER DISHWASHER 13.16. Draın Hose, Water Inlet Valve, And Clıp Box To render services to these components, the operators should work on the backside of the machine. The concrete sheet should be removed. The hose holder is taken out by turning as it is seen in the picture 30 cm The drain hose holder is made up two symmetric parts, which fit together by the help of the snaps, and should be located approximately 30 cm from the hose end.

  • Page 88: Bottom Layout

    BUILT- UNDER DISHWASHER For dismantling the interference filter and the main power cable first of all dismantle the sockets. Unscrew the screw mounted on the main power cable holder and release the cable. Then unscrew the two screws, assembling the interference filter and the concrete sheet. Push the filter as it is seen in the picture in order to release it.
  • Page 89 BUILT- UNDER DISHWASHER Drain pump gasket and drain pump gasket holder assembled to the sump drain hose outlet. This side of This side of gasket and gasket and gasket holder gasket holder should be should be located located as inside the shown on the sump.

  • Page 90: Explode View

    BUILT- UNDER DISHWASHER 14. Explode View 14.1. Main Body 2011...

  • Page 91: Inner Tub

    BUILT- UNDER DISHWASHER 14.2. Inner Tub 2011...

  • Page 92: Door Group

    BUILT- UNDER DISHWASHER 14.3. Door group. 2011...

  • Page 93: Panel Group

    BUILT- UNDER DISHWASHER 14.4. Panel Group 2011...
  • Page 94 BUILT- UNDER DISHWASHER 15. Part list Common reference numbers list for all UB1 models is shown below. REF. DESCRIPTION REF. DESCRIPTION Foot Group-Adjustable 5052 Card Holder-Back Foot Group-Adjustable-Rıght-Back 5710 Water Inlet Valve Foot Group-Adjustable-Left-Front 5711 Screw Rear Feet Adjustable Left Back 5830 Counter Group Rear Adjustable Foot Connectıon Part 6161 Rınse Aıd Glass...
  • Page 95 BUILT- UNDER DISHWASHER REF. DESCRIPTION REF. DESCRIPTION 2609 Raıl Wheel Group 7835 Hose Between Counter And Regeneratıon U. 2610 Raıl 7844 Hose 2611 Raıl Cap 7910 Sump Gasket 2612 Raıl Cap 8318 Hose Clamp (Ø 16.4) 2613 Raıl Wheel Screw 8319 Hose Clamp 2615 Raıl Wheel Holder 8357 Hose Clamp.(Ø...
  • Page 96 BUILT- UNDER DISHWASHER REF. DESCRIPTION Kıck Plate Kıck Plate Sheet Sıde Supportıng Part Sıde Supportıng Part Door Lock Cotton Fleece 2413 Upper Basket Wheel Group 2415 Upper Basket Mechanısm Maın Frame 2416 Upper Basket Mechanısm-Left 2417 Upper Basket Mechanısm-Rıght 2423 Plate Holder-Left 2424 Plate Holder-Rıght 2425 Lower Basket Foldıng Part 2426 Lower Basket Foldıng Part...
  • Page 97 BUILT- UNDER DISHWASHER REF. DESCRIPTION Kıck Plate Kıck Plate Sheet Sıde Supportıng Part Sıde Supportıng Part Door Lock Cotton Fleece 2413 Upper Basket Wheel Group 2415 Upper Basket Mechanısm Maın Frame 2416 Upper Basket Mechanısm-Left 2417 Upper Basket Mechanısm-Rıght 2423 Plate Holder-Left 2424 Plate Holder-Rıght 2425 Lower Basket Foldıng Part 2426 Lower Basket Foldıng Part...
